P25GOMC8846C0107CPS3 Wireless Controller

Mad Catz, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: May 31, 2007
Application Purpose: Original Equipment
Date of Application: May 22, 2007
Equipment Note: PS3 Wireless Controller
Frequency Range: 2402.00000000 - 2481.00000000
Company: Mad Catz, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Page 22 MadCatz, Inc. PS3 Wireless ControllerFCC ID:P25GOMC8846C0107C This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

External Photos

!! Page 7 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Photographs Figure 1 General Appearance Figure 2 General Appearance !! Page 8 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 3 General Appearance Figure 4 General Appearance Label Location !! Page 9 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 5 General Appearance Figure 6 Main Board, Component Side

ID Label/Location Info

Page 4 MadCatz, Inc. PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C Label Drawing Please refer Exhibit 2 Figure 4 for Label Placement Location !! Page 8 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 3 General Appearance Figure 4 General Appearance Label Location

Internal Photos

!! Page 9 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 5 General Appearance Figure 6 Main Board, Component Side !! Page : ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 7 Main Board, Component Side Figure 8 Main Board, Component Side !! Page 21 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 9 Main Board, Component Side !!!!!!!! Figure 10 Main Board, Component Side !!!!!!!! ! !! Page 22 ! MadCatz, Inc. ! PS3 Wireless ControllerIC ID: 4633A-GOC0107C FCC ID:P25GOMC8846C0107C ! Figure 11 Main Board, Component Side !!!!!!!! ! Figure 12 Main Board, Component Side

RF Exposure Info

RF Exposure Statement 1. Standard Applicable According to 1.1307 (b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a portable device. 2. Measurement Result: This is a portable device and the max peak output power is -10.31 dBm (.00009 W). Lower than the low threshold 60/f GHz = (24.19 mW), d<2.5 cm general population category. The SAR/MPE measurement is not necessary.

Test Report

FCC ID:P25GOMC8846C0107C Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 APPLICATION FOR CERTIFICATION On Behalf of MadCatz, Inc. PS3 Wireless Controller Model Number: MOV8846C Prepared for : MadCatz, Inc. 7480 Mission Valley Road, Suite 101, San Diego, California, 92108 Prepared By : Audix Technology (Shenzhen) Co., Ltd. No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, China Tel: (0755) 26639496 Report Number ACS-F07178 Date of Test Mar.09~May.31, 2007 Date of Report May. 31, 2007 FCC ID:P25GOMC8846C0107C Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 TABLE OF CONTENTS Description Page Test Report Declaration 1. SUMMARY OF STANDARDS AND RESULTS ........................................................................4 1.1. Description of Standards and Results .................................................................................................... 4 2. GENERAL INFORMATION .................................................................................................... 2-1 2.1. Description of Device (EUT) .............................................................................................................2-1 2.2. Tested Supporting System Details......................................................................................................2-1 2.3. Test Facility ........................................................................................................................................2-2 2.4. Measurement Uncertainty...................................................................................................................2-2 3. POWER LINE CONDUCTED EMISSION TEST.................................................................. 3-1 4. RADIATED EMISSION TEST ................................................................................................. 4-1 4.1. Test Equipment...................................................................................................................................4-1 4.2. Block Diagram of Test Setup .............................................................................................................4-1 4.3. Radiated Emission Limit Standard: FCC 15.249 ...............................................................................4-2 4.4. EUT Configuration on Test ................................................................................................................4-2 4.5. Operating Condition of EUT ..............................................................................................................4-3 4.6. Test Procedure ....................................................................................................................................4-3 4.7. Radiated Emission Test Results .........................................................................................................4-3 5. BAND EDGES MEASUREMENT.......................................................................................... 5-23 5.1. Test Equipment.................................................................................................................................5-23 5.2. Block Diagram of Test Setup ...........................................................................................................5-23 5.3. Test Standard ....................................................................................................................................5-23 5.4. Band Edges Limit .............................................................................................................................5-23 5.5. Test Procedure ..................................................................................................................................5-23 6. DEVIATION TO TEST SPECIFICATIONS ........................................................................ 6-28 7. PHOTOGRAPH ......................................................................................................................... 7-1 7.1. Photos of Radiated Emission Test (In Anechoic Chamber) ...............................................................7-1 FCC ID:P25GOMC8846C0107C Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 TEST REPORT DECLARATION Applicant MadCatz, Inc. EUT Description PS3 Wireless Controller (A) MODEL NO. : MOV8846C (B) SERIAL NO. : N/A (C) POWER SUPPLY : DC 3V Test Procedure Used: FCC Rules and Regulations Part 15 Subpart C 2006 The device described above is tested by Audix Technology (Shenzhen) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C limits for radiated and conducted emissions. The test results are contained in this test report and Audix Technology (Shenzhen) Co., Ltd. is assumed full responsibility for the accuracy and completeness of tests. Also, this report shows that EUT is technically compliant with FCC requirements. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shenzhen) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Mar.09~May.31, 2007 Prepared by : Annie Wu / Assistant Reviewer : Iceman Hu / Senior Engineer Approved & Authorized Signer : Ken Lu / Deputy Manager Name of the Representative of the Responsible Party : Signature : FCC ID:P25GOMC8846C0107C Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 1. SUMMARY OF STANDARDS AND RESULTS 1.1. Description of Standards and Results The EUT have been tested according to the applicable standards as referenced below. EMISSION Description of Test Item Standard Limits Results Power Line Conducted Emission Test FCC Part 15: 2006 ANSI C63.4-2003 Class C Limit N/A Radiated Emission Test FCC Part 15: 2006 ANSI C63.4-2003 Class C Limit PASS Band…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID:P25GOMC8846C0107C Page 12-1 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 12. PHOTOGRAPH 12.1.Photos of Radiated Emission Test 30-1000MHz FCC ID:P25GOMC8846C0107C Page 12-2 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 FCC ID:P25GOMC8846C0107C Page 12-3 Audix Technology (Shenzhen) Co., Ltd. Report No. ACS-F07178 Above 1000MHz
