P25HEMC4556B2103RVideo Game System Base Unit

ENGLISH LYNX ™ WIRELESS CONTROLLER XBOX ™ Thank you for purchasing the Mad Catz Lynx Wireless controller for use with the Xbox video game system. The Lynx puts you in control of your game system with all the comfort of a remote controller combined with the reliability of cutting-edge wireless technology. With its "unblockable" RF signal transceivers, the Lynx lets you comfortably play from up to 40’ from your Xbox while maintaining complete control over your gaming experience. This user guide will help you understand how to use your Lynx and get the most from the features it has to offer. The Lynx is one of the most durable and reliable accessories you can buy. Be sure to visit www.madcatz.com to register your product and check out our full line of other quality video game accessories. TABLE OF CONTENTS LAYOUT 2 POWER SAVE MODE 3 MULTIPLE CONTROLLERS 3 CAUTIONS 3 TROUBLESHOOTING 4 WARRANTY 5 TECHNICAL SUPPORT 5 LAYOUT Base Unit: Used to transmit and receive data from the controller to the game console. Houses two memory card expansion slots. Directional Pad: The D-pad controls the direction in which the character moves. Analog Sticks: The two analog sticks each control two axes (X-and Y-axis). Certain software titles will allow you to modify the way that the analog sticks are used and react in the games. Triggers Buttons (L and R): These are action buttons and their specific functions depend on the software being used. Action Buttons ( A, B, X, Y, Black, White ) : These buttons are used to perform various actions, depending on the software. For more details, see the software instruction manual. Start Button: This button is generally used to make selections in the menus and for pausing the game. For more details, see the software instruction manual. Back Button: This button is used to navigate backwards in the game menus. For more details, see the software instruction manual. Channel Selector: This is used for selecting a unique channel for each player's Lynx and Base Unit Motor Control Selector: This is used to choose whether the motors are "0" (off), "1" (low intensity), or "2" (high intensity). 12 BASE UNIT CONTROLLER MEMORY CARD SLOTS MOTOR CONTROL SELECTOR CHANNEL SELECTOR ANALOG STICK ANALOG STICK BACK START WHITE BLACK ACTION BUTTONS DIRECTIONAL PA D POWER SAVE MODE The Lynx controller has an automatic “Sleep” mode -- when the controller is not in use for more than three minutes, the controller will partially turn itself off in order to conserve batteries. To wake the controller from sleep mode, press D-Pad, analog sticks, BACK button or START button of the controller. When storing the controller for extended periods of time, or while traveling with the controller, remove the batteries to conserve battery life. MULTIPLE CONTROLLERS If you want to use two or more Lynx controllers at the same time (as in multi- player games), simply plug the controllers into the game system as you normally would and begin play. Confirm that each Lynx controller has a unique player number (1,2,3 or 4) and that it matches the player number selected on the Base Unit. When you play in the multi-player mode: 1. Insert the game disk and turn on your console. 2. Insert the Base Unit for the first controller into the Player-1 Controller port on the game console. 3. Confirm the link between first Base Unit and first Lynx by using the controller to see if it works in the game or game menu. 4. Insert the Base Unit for the second Lynx into the Player-2 Controller port on the game console. 5. Confirm the link between second Base Unit and second Lynx controller by using the controller to see if it works in the game or game menu. 6. IMPORTANT – Confirm that each Lynx controller has a unique player number (channel 1,2,3 or 4) and that it matches the player number selected on the Base Unit. CAUTIONS - IMPORTANT! Before using this product read all accompanying information and your game system’s instruction manual for safety, health and other information - To prevent fire or shock hazard, do not expose this unit to rain or moisture. Do not use within 30’ of any water such as swimming pools, bathtubs, or sinks. - To avoid electrical shock, do not disassemble. Refer servicing to qualified personnel only. ENGLISH ENGLISH - This unit should be operated only from the power source indicated on the unit. If you are not sure of the type of electrical power supplied to your home, contact your local power company. - Never push objects of any kind, other than authorized items, into the product as they may touch dangerous voltage points or short out parts that could result in fire or electrical shock. - Stop using this unit immediately if you begin to feel tired or if you experience discomfort or pain in your hands and/or arms while operating the unit. If the condition persists, consult a doctor. - Do not attempt to operate the unit in any way except with your hands. Do not bring the unit in contact with your head, face, or near the bones of any other part of your body - The vibration function of this unit can aggravate injuries. Switch off or do not use the vibration function of the unit if you have any ailment of the bones or joints of your hands or arms. - Avoid prolonged use of this unit. Take breaks every 30 minutes. - Use this unit only as intended. - Do not dispose of batteries in fire. Refer to local country, state and city guidelines for appropriate methods of battery disposal. - Do not put batteries into unit backwards. - Misuse of batteries within this unit may cause batteries to leak and/or explode and lead to personal injury. - This product contains small parts that may cause choking if swallowed. Not intended for children under 3 years of age. TROUBLESHOOTING Problem: The Lynx controller does not respond. Solution: Make sure the batteries are fully charged and have not run out. Solution: Confirm that each Lynx controller has a unique player number (channel 1,2,3 or 4) and that it matches the player number selected on…

Text truncated - open the document above for the full version.

F C C CONFIDENTIALITY Date: 05/23/03 To: FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Non disclosure for FCC ID: P25HEMC4556B2103C and P25HEMC4556B2103R. To Whom It May Concern: Pursuant to 47 CFR Section 0.459, Mad Catz, Inc. hereby requests non disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID #’s P25-HEMC4556B2103C and P25-HEMC4556B2103R. a. Schematic Diagrams b. Operational Description c. Block Diagram Above materials contain trade secrets, proprietary and technical information which would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. ( Mad Catz, Inc.) understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Sincerely yours, Doug Shepherd, Engineering Specialist, Mad Catz, Inc.

Response to TCB Findings 1. The AC line conducted emissions is applicable to the host unit required by 15.207(c) while the transmitter is operating. Please supply test data Supplied. Please see “Conducted Emissions Test Data” document. 2. Host unit AC input voltage should be varied from 85% to 115% and radiated field strength of the fundamental emission should be checked as required by 15.31(e). Supplied. Please see “Conducted Emissions Test Data” document.

Mad Catz Interactive, Inc. 2.4 GHz wireless controller for X-Box Video Game System 2408.448 – 2476.032MHz Digital Radio FCC ID#: P25HEMC4556B2103R Photo One – External Mad Catz Lynx Wireless Base Unit Base Unit connects to the X-Box Video Game System Mad Catz Interactive, Inc. 2.4 GHz wireless controller for X-Box Video Game System 2408.448 – 2476.032MHz Digital Radio FCC ID#: P25HEMC4556B2103R Photo Two – External Mad Catz Lynx Wireless Base Unit Front View of Base Unit which connects to the X-Box Video Game System Mad Catz Interactive, Inc. 2.4 GHz wireless controller for X-Box Video Game System 2408.448 – 2476.032MHz Digital Radio FCC ID#: P25HEMC4556B2103R Photo Three – External Mad Catz Lynx Wireless Base Unit Bottom View of Base Unit which connects to the X-Box Video Game System Mad Catz Interactive, Inc. 2.4 GHz wireless controller for X-Box Video Game System 2408.448 – 2476.032MHz Digital Radio FCC ID#: P25HEMC4556B2103R Photo Four – External Mad Catz Lynx Wireless Base Unit Close-Up of Ink Printed FCC ID Number. Note: This photo shows the location and print style for the 900MHz version of the base unit. The 2.4GHz version of the unit utilizes the same form factor with the FCC ID Number painted on in the same location. Please refer to the schematic drawing of this filing for the proper FCC ID Number and the paint characteristics.

L O W B A T T 1 2 3 4 C H A N N E L LOW M O T O R C O N T R O L Frequency: 2.4 GHz This Device Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: P25HEMC4556B2103R IC ID: 4633AHEMC4556B2103R The shape and design of this product is a tradedress Mad Catz Inc. 2003 www.Madcatz.com Item # 4556 Wireless Controller For XboxTM Made in China Frequency: 2.4 GHz This Device Complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. USE MOTOR CONTROL UNDER BATTERY DOOR TO INCREASE BATTERY LIFE WARNING: Remove Batteries During Travel or Storage FCCID: P25HEMC4556B2103C: IC:4633AHEMC4556B2103C Pantone Silver 877U Pantone Red 032C

L.S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, WI 53012 262-375-4400 Fax: 262-375-4248 COMPLIANCE TESTING OF: Lynx™ Wireless-Controller Base Unit PREPARED FOR: Mad Catz, Incorporated 7480 Mission Valley Road Suite 101 San Diego, CA 92108-4406 TEST REPORT NUMBER: 303325-BT TEST DATE(S): May through July 2003 All results of this report relate only to the items that were tested. This report is not to be reproduced, except in full, without written approval of L. S. Compliance, Inc. L.S. Compliance, Inc. Page 2 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz Table of Contents Section Description Page Index 2 1 L. S. Compliance in Review 3 2 A2LA Certificate of Accreditation 4 3 A2LA Scope of Accreditation 5 4 Validation Letter-U.S. Competent Body for EMC Directive 89/336/EEC 6 5 Signature Page 7 6 Product and General Information 8 7 Product Description 8 8 Test Requirements 9 9 Declaration of Conformity 9 10 Introduction 10 11 Purpose 10 12 Radiated Emissions Test 11-18 13 Conducted Emissions Test, (AC Line) 19 14 Conducted Emissions Test, power output 20-22 15 Conducted Emissions Test, spurious emissions 23-26 16 Conducted Emissions Test, occupied bandwidth 27-28 17 Conducted Emissions Test, spectral density 29-30 Appendix A Test Equipment List 31 L.S. Compliance, Inc. Page 3 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz 1. L. S. Compliance In Review L. S. Compliance, Inc. is located in Cedarburg, Wisconsin – United States. We may be contacted by: Mail: L. S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, Wisconsin 53012 Phone: 262-375-4400 Fax: 262-375-4248 E-mail: [email protected] As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025 : 2003 with Electrical (EMC) Scope of Accreditation A2LA Certificate Number: 1255.01 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Conformity Assessment Body operating under the U. S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union EMC Directive 89/336/EEC, Article 10.2. Date of Validation: January 16, 2001 Federal Communications Commission (FCC) – USA Listing of 3 Meter Semi-Anechoic Chamber based on 47CFR 2.948 FCC Registration Number: 90756 Listing of 3 and 10 meter OATS based on 47CFR 2.948 FCC Registration Number: 90757 Industry Canada On-file, 3 Meter Semi-Anechoic Chamber based on 47CFR 2.948 File Number: IC 3088 On-file 3 and 10 Meter OATS based on RSS-210 File Number: IC 3088-A L.S. Compliance, Inc. Page 4 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz 2. A2LA Certificate of Accreditation L.S. Compliance, Inc. Page 5 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz 3. A2LA Scope of Accreditation L.S. Compliance, Inc. Page 6 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz 4. Validation Letter – U.S. Competent Body for EMC Directive 89/336/EEC L.S. Compliance, Inc. Page 7 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz 5. Signature Page Prepared By: July 21, 2003 Teresa A. White, Document Coordinator Date Tested By: July 21, 2003 Thomas T. Smith, EMC Engineer Date Tested By: July 21, 2003 Abtin Spantman, EMC Engineer Date Tested By: signed by Mark Wolski July 21, 2003 Mark Wolski, RF Engineer Date Approved By: July 21, 2003 Kenneth L. Boston, EMC Lab Manager Date PE #31926 Licensed Professional Engineer Registered in the State of Wisconsin, United States L.S. Compliance, Inc. Page 8 of 31 Test Report Number: 303325-BT Prepared For: Mad Catz 6. Product and General Information Manufacturer: Mad Catz, Incorporated Model No.: Base Unit Serial No.: Engineering Unit Description: 2.4 GHz Wireless Controller for the X-Box video game system. 7. Product Description The Mad Catz Lynx™ wireless controller is used with the X-box video game system to provide the user with the comfort of a remote controller with out the hindrance of cables and wires. There are two components to the Lynx™ wireless system: a “Game Controller”, and a “Base Unit”. The Mad Catz Lynx™ system replaces the normally wired connection between the Handset game controller and the X-box. One of twelve possible channels is used in the 2.4 GHz ISM band, depending on the setting of the ‘player number’ switch and if any of the other channels are already occupied. The system supports up to four players and each player will use one of three possible channels: Player Number Channel Number Frequency (MHz) 1 2408.448 1 5 2433.024 9 2457.600 2 2414.592 2 6 2439.168 10 2463.744 3 2420.736 3 7 2445.312 11 2469.888 4 2426.880 4 8 2451.456 12 2476.032 The Handset contains a Controller board and an RF Transceiver board. The Handset Controller board consists of the various game control devices such as switches and joy-sticks, which are multiplexed into the microprocessor, which in turn controls the RF transceiver. The Base unit contains the same RF transceiver board, and a separate controller board with a microprocessor that controls the RF communications, and a microprocessor that interfaces with the game box. A packetized protocol is used in bi-directional communications with the Base. To maximize battery life, the Handset microprocessor places itself and the RF transceiver board in a sleep mode immediately after a transaction is finished. The microprocessor’s onboard sleep timer is used to wake the microprocessor up approximately 9 ms later. At this time data, is gathered from the game control devices, and the RF transceiver board is awakened to perform its internal self-alignment process. The data is then packetized in a proprietary format and sent (using a simple FSK protocol) to the Base unit. The Base unit receives the packet, decodes it to ensure the packet is valid, and returns a shorter Acknowledge message to the Handset. The entire transaction takes less than 500 microseconds. L.S. Compliance, Inc. Page 9 of 3…

Text truncated - open the document above for the full version.

Conducted Emission Setup Overview Photo of setup during Conducted Emission testing, showing the X-Box and the Base Unit, along with the Game Controller for normal duplex operation. The AC mains supply was varied ±15% of nominal, and no change in performance or anomalies were observed. The data presented below is from measurements at mid channel. -15% VNom +15% 102VAC 120VAC 138VAC Channel 6 89.9dBUV/m 89.6dBμV/m 89.8dBμV/m No spurious Anomalies were observed . Additional Equipment Used: Asset # Manufacturer Model # Serial # Description Date EE960054 HP 971A JP40011152 Multimeter (to verify settings) 07-24-03 EE960070 Cal. Instruments 1251RP N/A Power Supply (AC) 10-02-02 CC000219C HP 6201B 1145A04094 Variable Power Supply (DC) N/A Conducted RF measurements at AC mains (X-Box). The units were placed in “normal operation” mode, and the emissions were investigated on low, mid, and high channels, and found to be similar. Data and signature scans presented here are from the mid band – Channel 6, and are typical of all channels investigated. Signature Scan of Conducted Emissions Base Unit, Normal, Channel 1, Line 1 15.107 FCC Limit (dBμV) Margin (dB) Frequency (MHz) Q-Peak (dBμV) Average (dBμV) Q-Peak Average Q-Peak Average 0.18 MHz 45.1 18.0 64.5 54.5 19.4 36.5 0.6 MHz 24.9 24.0 56 46 31.1 22.0 1.40 MHz 26.2 25.0 56 46 29.8 21.0 4.0 MHz 31.2 29.9 56 46 24.8 16.1 24.5 MHz 29.8 28.8 60 50 30.2 21.2 Signature Scan of Conducted Emissions Base Unit, Normal, Channel 1, Line 2 Investigated Channel 1 and Channel 12 – Symetric Performance, only Screen Captures on Channel 1, Full Duplex Communication 15.107 FCC Limit (dBμV) Margin (dB) Frequency (MHz) Q-Peak (dBμV) Average (dBμV) Q-Peak Average Q-Peak Average 0.16 47.3 19.3 65.5 55.5 18.2 36.2 4.0 30.9 29.5 56 46 25.1 25.5 6.1 25.5 21.9 60 50 34.5 28.1 24.6 29.5 28.5 60 50 30.5 21.5

Mad Catz Base Set Up Photos Setup for the Radiated Emissions Test for the Base Unit Top-view of the EUT Front view of the EUT View of Test Setup During the Conducted RF measurements, RF Transceiver Board
