SUPV1 SIRIUS Plug and Play Vehicle Kit For use with most newer SIRIUS Plug and Play Radios with the FM Extender Cable Installation Guide Congratulations on the Purchase of your new SUPV1 SIRIUS Universal Plug and Play Vehicle Kit Your new SUPV1 SIRIUS Universal Plug and Play Vehicle Kit lets you enjoy SIRIUS ® Satellite Radio’s digital entertainment in any vehicle. Use this manual as a guide for the installation. The SUPV1 SIRIUS Universal Plug and Play Vehicle Kit will work with the Sportster™ 4 and most new SIRIUS plug and play satellite radios. See your Plug and Play user manual for specific product compatibility. For the latest information about this and other SIRIUS products and accessories, visit http://www.sirius.com. [ Table of Contents ]  Table of Contents TablE oF ConTEnTS 3 WaRnIng and SaFETy InFoRMaTIon 4 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 CoPyRIghTS & TRadEMaRKS 6 PaCKagE ConTEnTS 7 ConTRolS 9 InSTallaTIon 10 Installing the Vehicle Dock . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Installing the Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Connecting the Cigarette Lighter Adapter . . . . . . . . . . . . . . . . . . . . . 19 Docking the SIRIUS Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Maximizing Audio Quality From Your SIRIUS Radio . . . . . . . . . . . . . . . . . . 21 Subscribing to the SIRIUS Service . . . . . . . . . . . . . . . . . . . . . . . . 36 TRoUblEShooTIng 37 oPTIonal aCCESSoRIES 38 WaRRanTy 39 SPECIFICaTIonS 40 SIRIUS Id 41 [ Warning and Safety Information ]  Warning and Safety Information Safety Precautions Be sure to observe the following warnings. Failure to follow these safety instructions and warnings may result in a serious accident and/or personal injury. Installation must be performed according to this installation guide. SIRIUS is not respon- sible for issues arising from installations not performed according to the procedures in this guide. Do not operate the SIRIUS radio in a way that might divert your attention from driving safely. As a driver, you alone are responsible for safely operating your vehicle in accor- dance with traffic safety laws at all times. Do not install the unit where it may obstruct your view through the windshield, or of your vehicle’s indicator displays. Before attaching the suction cup mount to your windshield, you should check your state and local laws for regulations regarding mounting this device on your windshield. Do not install the unit where it may hinder the function of safety devices such as an airbag. Doing so may prevent the airbag from functioning properly in the event of an accident. To avoid short circuits, do not open the unit, and never put or leave any metallic objects (coins, tools, etc.) inside the vehicle dock. If the unit emits smoke or unusual odors, turn the power off immediately, and disconnect the unit from any power source. Do not drop the unit or subject it to strong shocks. The installation and use suggestions contained in this manual are subject to any restric- tions or limitations that may be imposed by applicable law. The purchaser should check applicable law for any restrictions or limitations before installing and/or operating this unit. • • • • • • • • • [ Warning and Safety Information ]  Do not install the FM Extender Cable where it will hinder or block your view. In some states it may be illegal to mount it on the windshield of your vehicle. Check applicable law for any restrictions or limitations before installing the extender cable on your windshield. Do not install the FM Extender Cable where it may hinder the function of safety devices such as an airbag. Doing so may prevent the airbag from functioning properly in the event of an accident. Warnings notice To drivers In California and Minnesota State law prohibits drivers in California and Minnesota from using suction mounts on their windshields while operating motor vehicles. Other dashboard or friction mounting options should be used. SIRIUS does not take any responsibility for any fines, penalties, or damages that may be incurred as a result of disregarding this notice. (See California Vehicle Code Sec- tion 26708(a); Minnesota Statutes 2005, Section 169.71) operating Temperature The SIRIUS Cigarette Lighter Adapter is designed to operate between -20° to +85° C (-4° to +185° F). Avoid leaving it in a vehicle or elsewhere where the temperature may fall outside this range. Cleaning and Maintenance If the vehicle dock becomes dirty, turn the power off and wipe it clean with a soft cloth. Do not use hard cloths, strong cleaning fluids, paint thinner, alcohol, or other volatile solvents to clean. These may cause damage to the unit. Cigarette lighter adapter The SUPV1 cannot be powered directly from a vehicle’s 12 VDC power system. It must be powered using the included Cigarette Lighter Adapter only. Connecting the SUPV1 directly to the vehicle’s 12 VDC power system may result in damage to the vehicle dock or SIRIUS radio, or both. • • [ Copyrights & Trademarks ]  Copyrights & Trademarks © 2006 SIRIUS Satellite Radio Inc. All Rights Reserved. ® “SIRIUS”, the SIRIUS dog logo, channel names and logos are trademarks of Sirius Satellite Radio Inc. All Rights Reserved. ™ “Sportster” is a trademark of Sirius Satellite Radio Inc. Hardware, subscription, and activation fee required. For full Terms & Conditions, visit http://sirius.com. Prices and programming are subject to change. Not available in HI and AK. Equipment and subscription sold separately. Installation required with some equipment. [ Package Contents ]  Package Contents The following items are included with your purchase of the SUPV1 SIRIUS Universal Plug and Play Vehicle Kit. Unpack the kit carefully and make sure that everything shown is present. If anything is missing or damaged, or if the kit fai…
