P3HSP5Digital Satellite Radio

Ki Ryung Electronics Co., Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Sep 10, 2007
Application Purpose: Original Equipment
Date of Application: Sep 10, 2007
Equipment Note: Digital Satellite Radio
Frequency Range: 88.10000000 - 107.90000000
Company: Ki Ryung Electronics Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Sportster 5Sportster 5 Satellite Radio User GuideUser Guide Congratulations on the Purchase of your new SIRIUS Sportster SP5 Plug-n-Play Radio Your new SIRIUS Sportster™ SP5 Plug-n-Play Radio lets you enjoy SIRIUS ® Satellite Radio’s digital entertainment anywhere you’ve installed the SUPH1 SIRIUS Universal Plug and Play Home Kit, SUPV1 SIRIUS Universal Plug and Play Vehicle Kit, or the SUBX1 SIRIUS Plug and Play Universal Boombox (each sold separately). Use this manual to familiarize yourself with all of SIRIUS Sportster’s features and capabilities. For the latest information about this and other SIRIUS Sportster products and accessories, visit http://www.sirius.com. [ Table of Contents ] 4 Table of Contents TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 WARNING AND SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . 6 FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Canadian Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 COPYRIGHTS & TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . 10 PACKAGE CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Installing the Vehicle Dock . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Installing the Magnetic Antenna . . . . . . . . . . . . . . . . . . . . . . . . . 21 Connecting the Cigarette Lighter Adapter . . . . . . . . . . . . . . . . . . . . . 34 Docking the SIRIUS Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Connecting Your SIRIUS Radio to Your Vehicle’s Audio System . . . . . . . . . . . . 35 Direct Wired Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Direct FM Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Cassette Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Wireless Connection Using the FM Extender Antenna . . . . . . . . . . . . . . . 39 Subscribing to the SIRIUS Service . . . . . . . . . . . . . . . . . . . . . . . . 49 CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 SIRIUS Sportster SP5 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . 50 Remote Control Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Vehicle Dock Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . 54 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Display Screen Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Navigating Menus and Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Display (D ISP) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Search Modes (Category, Channel, Artist, Song Title) . . . . . . . . . . . . . . . . 58 [ Table of Contents ] 5 Direct Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Channel Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Jump Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Memory (MEMO) and Song Seek (S-Seek) Functions . . . . . . . . . . . . . . . . . 64 Instant Replay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 FM Transmitter Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 MENU OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 Sirius ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 FM Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 Jump Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80 S-Seek Alert Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 Audio Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 Channel Preview Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 Factory Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 Parental Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87 Sports Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89 NASCAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89 NFL, NBA, NHL, College Football, College Basketball . . . . . . . . . . . . . . . 91 Time-Based Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93 Program Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 Auto Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 OPTIONAL ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . 97 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 SIRIUS ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101 [ Warning and Safety Information ] 6 Warning and Safety Information FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, includ…

Text truncated - open the document above for the full version.

Cover Letter(s)

#505 SK Apt. Factory, 223-28 Sangdaewon1-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do 462-705 Korea [TEL]031-746-8500 [FAX]031-746-8700 전사-002 (Rev. 2) www.onetech.co.k r Date : 2007. 07. 27 Ref. No : To : Application Examiner / Reviewing Engineer FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 CC : Subject : Request for confidentiality per Section 0.459 of FCC Rules Applicant: KI RYUNG ELECTRONICS CO., LTD. FCC ID: P3HSP5 To whom it may concern, Request is hereby submitted, on behalf of my client, KI RYUNG ELECTRONICS CO., LTD., to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Schematics Block Diagram Operational Description Rationale for request for confidentiality: KI RYUNG ELECTRONICS CO., LTD. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. If you have questions or need further information, please contact the undersigned. Sincerely, Y.K. Kwon / Chief Engineer Onetech Corp. Email: [email protected] #505 SK Apt. Factory, 223-28 Sangdaewon1-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do 462-705 Korea [TEL]031-746-8500 [FAX]031-746-8700 전사-002 (Rev. 2) www.onetech.co.k r From : Michael Jang /Manager Marketing Division ONETECH Corp.

Cover Letter(s)

#505 SK Apt. Factory, 223-28 Sangdaewon1-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do 462-705 Korea [TEL]+82-31-746-8500 [FAX]+82-31-746-8700 전사-002(Rev 2) www.onetech.co.kr FCC Laboratory July 27, 2007 7435 Oakland Mills Road Columbia, MD 21046 Attention: Application Examiner / Reviewing Engineer Subject: Confirmation Letter for FM Transmitter Applicant: Ki Ryung Electronics Co., Ltd., FCC ID: P3HSP5 To whom it may concern, We, Onetech Corp., would like to answer following questions for requesting by the TCB, Compliance Certification Services Inc on behalf of our customer, Ki Ryung Electronics Co., Ltd. 1. How does this device operate? Î It shall be operated in home or car. 2. Provide information on the device and its antenna Î It is a digital satellite radio that has a function for transmitting of FM broadcasting frequency range. The external FM antenna which shall be supplied by the responsible party shall be used according to user’s guide. 3. How is it installed? Î When installing the vehicle dock in your vehicle, choose a location in your vehicle where it will not block your vision, interfere with the vehicle control, or obstruct the air bag. This device is suction cup mounted or vent mounted. 4. What test procedure was used? Î ANSI C 63.4: 2003 5. If tested in a car, how was it configured/tested? Î It was tested in a car. In site testing was performed for three vehicles based on the following vehicle sizes; small, medium and large. 6. Was the tuning range properly verified? Î Yes, the low channel is 88.1MHz, and the highest channel is 107.9MHz. Please refer to the statement and test data on page 29 and page 30 of the test report. 7. Was the bandwidth properly tested with maximum audio input? Î The EUT does not have an audio input port, so the EUT transmitted signal that was generated by satellite signal generator with maximum audio level. If you have questions or need further information, please contact the undersigned. Sincerely, Y.K. Kwon / Director Onetech Corp.

External Photos

FCC ID. : P3HSP5 Report No. : E077R-061 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-ri, Chowol-eup, Gwangju-si, Gyeonggi-do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : P3HSP5 Report No. : E077R-061 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-ri, Chowol-eup, Gwangju-si, Gyeonggi-do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : P3HSP5 Report No. : E077R-061 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-ri, Chowol-eup, Gwangju-si, Gyeonggi-do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : P3HSP5 Report No. : E077R-061 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-ri, Chowol-eup, Gwangju-si, Gyeonggi-do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904) FCC ID. : P3HSP5 Report No. : E077R-061 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.0) HEAD OFFICE : #505 SK APT. Factory 223-28, Sangdaewon 1 dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, 462-705, Korea (TEL: +82-31-746-8500, FAX: +82-31-746-8700) EMC Testing Dept : 307-51 Daessangryung-ri, Chowol-eup, Gwangju-si, Gyeonggi-do, 464-860, Korea. (TEL: +82-31-765-8289, FAX: +82-31-766-2904)

ID Label/Location Info

Test Report

IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 1 of 16 Verification of Compliance CFR 47 Part 15 Subpart C Test Report File No. : 07-IST-0291 Date of Issue : July 20, 2007 Model(s) : SP5 ■ Basic □ Alternate Kind of Product : Digital Satellite Radio Applicant : KIRYUNG ELECTRONICS Co., Ltd. Address : 219-6,Gasan-Dong, Kumchun-Ku,Seoul,153-023, Korea Guro Dan Ji P.O. Box 37 Manufacturer : KIRYUNG ELECTRONICS Co., Ltd. Address : 219-6,Gasan-Dong, Kumchun-Ku,Seoul,153-023, Korea Guro Dan Ji P.O. Box 37 Test Result ■ Positive □ Negative Reviewed By Approved By Comment(s) -Investigations requested : Measurement to the relevant clauses of FCC rules and regulations Part 15 Subpart C Section 15.239 - intentional Radiators. -The test report with appendix consists of 16 pages. -The test result only responds to the tested sample. -It is not allowed to copy this report even partly without the allowance of IST EMC Laboratory. -This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 2003. S.J.Cho / EMC Group Manager B.S.Kim / Chief IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 2 of 16 TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Environmental conditions, Power supply system used, Product information 3 Descriptions of test 4 Radiated Emission Equipment Under Test 5 Summary 6 ■ Test Conditions and Data – Emissions Test Conditions / Data and Plots ◆ Radiated Emissions 88.1 MHz - 107.9 MHz Applicable Test Conditions / Data and Plots 7-10 Appendix A. The Photos of Test Setup 11-16 Note: IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 3 of 16 INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. 400-19, Singal-dong, Giheung-gu, Yongin-si, Genggi-do, 446-599, Korea TEL : +82 31 326 6700 FAX : +82 31 326 6797 ENVIRONMENTAL CONDITIONS Temperature 22.5 °C Humidity 68 % Atmospheric pressure 1010 mbar POWER SUPPLY SYSTEM USED Power supply system Input : DC 12V, (Car Battery) Output : DC 5.2V (Refer to the product information) PRODUCT INFORMATION Satellite Frequencies 2322.293/2330.207 MHz Terrestrial Frequencies 2326.250 MHz Power Requirements 5.2Volts,Negative Ground,DC Dimension-W x H x D 114.2(W) x 62.5(H) x 16.9(D) mm Operating Temperature -20 ~ 85°C Tx Frequency Range 88.1 MHz ~107.9 MHz (range into 200 KHz Step) - EMC suppression device is not used during the test . - Please refer to user’s manual. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 4 of 16 DESCRIPTION OF TEST Radiated Emissions: The measurement was performed over the frequency range of 30 MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurement was made with the detector set for "quasi-peak" within a bandwidth of 120 KHz. - Procedure of Test Preliminary measurements were made at 3 meter using bi-log antennas, and spectrum analyzer to determine the frequency producing the max. Emission in anechoic chamber. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turn-table azimuth and height with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30 MHz to 1000 MHz using bi-log antenna. Above 1 GHz, linearly polarized double ridge horn antennas were used. Final measurements were made at open site with 3-meters test distance using bi-log antenna or horn antenna. The OATS have been verified in regular for its normalized site attenuation. The test equipment was placed on a wooden table. Sufficient time for the EUT, peripheral equipment, and test equipment was allowed in order for them to warm up to their normal operating condition. Each frequency found during pre-scan measurements was re-examined by manual. The detector function was set to CISPR quasi-peak mode and the bandwidth of the receiver was set to 120 kHz or 1MHz depending on the frequency of type of signal. The EUT, peripheral equipment and interconnecting cables were re-configured to the set-up producing the max. Emission for the frequency and were placed on top of a 0.8-meter high nonmetallic 1 x 1.5 meter table. The EUT, peripheral equipment, and interconnecting cables were re-arranged and manipulated to maximize each emission. The turntable containing the system was rotated; the antenna height was varied 1 to 4 meters and stopped at the azimuth or height producing the maximum emission. Each emission was maximized by: varying the mode of operation to the EUT and/or peripheral equipment and changing the polarity of the antenna, whichever determined the worst-case emission. 3m Control Room Receiver Control Room Receive r EUT 3m IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 5 of 16 Equipment Under Test Operation – mode of the E.U.T. : The equipment under test was operated during the measurement under following conditions : Standby Mode Operational Condition : Transmit RF signal Test set-up Note : IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 6 of 16 SUMMARY Emissions ■ Radiated Emission The requirements are ● MET ○ Not MET Minimum limit margin 7.49 dB at 97.9 MHz Maximum limit exceeding Remarks : Limits are kept with more 3dB margin. - Large Vehicle test Date Begin of testing : July. 17, 2007 End of testing : July. 18, 2007 Prepared By Note : - ■ means the test is applicable, - □ is not applicable. S.C.JANG / EMC Project Manager IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 07-IST-0291 7 of 16 TEST CONDITIONS AND DATA Radiated Emission [Applicable] ◆ Test Equipment Used Name Type Manufacturer Calibration Date Serial Number ESCS 30 Test Receiver Rohde & Schwarz Aug. 17, 2006 100171 VULB 9160 Antenna Schwarzbeck Aug. 14, 2006 3047 ◆ Test Accessories Used Type Manufacturer Aneroid Barometer Sato Hygrometer Sato ◆ Test …

Text truncated - open the document above for the full version.

Test Setup Photos
