P45TD2020D24GRToy RC Side Drifter Monster Truck

FUJIAN TEAMDA PHOTOELECTRICITY CO., LTD

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: May 27, 2020
Application Purpose: Original Equipment
Date of Application: May 27, 2020
Equipment Note: Toy RC Side Drifter Monster Truck
Frequency Range: 2405.00000000 - 2450.00000000
Company: FUJIAN TEAMDA PHOTOELECTRICITY CO., LTD
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

REMOTE CONTROL SIDE DRIFTING TRUCK 6+ Printed in China LED Status Light Diagonal Forward-Left On/O Demo Mode Dance Demo Spin Left/Spin RightForward/Reverse Diagonal Forward-Right Roll LeftRoll Right Diagonal Reverse-Left Diagonal Reverse-Right Note: After the remote control turns on, the indicator light is always on. After connecting the signal of the remote control vehicle, the indicator light will turn on by pressing any button on the remote control. If you turn on the remote control and the indicator light is on, the indicator goes out after a long time without matching the remote, but the remote control is still in operation and needs to be turned o. 1x Side Drifting Truck Direction360 Degree Rotation 1x Remote REMOTE OVERVIEW DIRECTIONS WARNING: CHOKING HAZARD - Small parts. Not for children under 3 years. Battery CoverO/On Battery Cover The car requires 4 “AA” 1.5V batteries (not included). The remote requires 2 “AAA” 1.5V batteries (not included). • For indoor use only. Avoid water when operating. • Do not use people or animals as obstacles. • Never operate your vehicle on the street or highway. • Do not run car into furniture objects or hard surfaces as this will cause damage to both the objects and car. • Keep fingers, hair and loose clothing away from the tires, gears and motor while car is switched to “ON”. • Do not expose to extreme temperatures or moisture • Do not leave car or transmitter near sources of heat or under direct sunlight for long periods of time. • Adult supervision is recommended when operating car. • Thoroughly inspect products before every use. If the product appears worn, frayed/splintered, cracked, or broken in any manner, discontinue use and discard immediately. • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries. • Alkaline batteries are recommended. Use only the specified voltage. • Insert batteries using the correct polarity. Always use, replace, and recharge (if applicable) batteries under adult supervision. • Do not charge with non-rechargeable batteries. • Do not short-circuit the battery supply terminals. • Do not dispose of batteries in fire, batteries may explode or leak. • Remove batteries before storing. • Recycle or dispose of batteries according to federal, state, and local laws. • Keep these instructions for future reference. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1)This device may not cause harmful interference, and 2)This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. © 2020 MerchSource, LLC. Irvine, CA 92618. All rights reserved. KEEP THIS INSTRUCTION MANUAL AS IT CONTAINS IMPORTANT INFORMATION FOR FUTURE REFERENCE

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD 2020.5.27 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD ____ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: P45TD2020D24GR Product Description: Toy RC Side Drifter Monster Truck Model:TD2020D,1012179,1012283 Sincerely, Client’s signature Client’s name: Kelvin Ou Title : Senior Manager Contact information / address : Triangulation Point Shengqiao Town, Zhaoan,County,Zhangzhou City,Fujian Province P.R.China

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 6.0 FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD 2020.5.27 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: P45TD2020D24GR Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name: Kelvin Ou Title : Senior Manager Contact information / address : Triangulation Point Shengqiao Town, Zhaoan,County,Zhangzhou City,Fujian Province P.R.China

Cover Letter(s)

FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD Declaration of Identical Product Hereby, Name of manufacturer: FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD Address: Triangulation Point Shengqiao Town, Zhaoan,County,Zhangzhou City,Fujian Province P.R.China City: Zhangzhou Country: China declares that: Product description: Toy RC Side Drifter Monster Truck Type designation(s): 1012179,1012283 Trademark: SHARPER IMAGE Family name is technically identical to: Product description: Toy RC Side Drifter Monster Truck Type designation: TD2020D Trademark: SHARPER IMAGE Certificate number (if applicable) They are identical with the test modelTD2020D except the color of the appearance, trade name and model name for trading purpose. Date: 2020.5.27 City: Zhangzhou Name: Kelvin Ou Signature

External Photos

ID Label/Location Info

Label and Location

Internal Photos

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 6 Report Version 1 Reference No.: 200304N047-2 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 6 Report Version 1 Reference No.: 200304N047-2 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 6 Report Version 1 Reference No.: 200304N047-2 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 6 Report Version 1 Reference No.: 200304N047-2 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 6 Report Version 1 Reference No.: 200304N047-2 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 6 of 6 Report Version 1 Reference No.: 200304N047-2 Wire ANT

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 27 Report Version 1 Test Report No.: RF200304N047- 2 TEST REPORT Applicant: FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD Address: Triangulation Point, Shengqiao Town, Zhaoan County,Zhangzhou City, Fujian Province P.R .China Manufacturer or Supplier FUJIAN TEAMDA PHOTOELECTRICITY CO.,LTD Address Triangulation Point, Shengqiao Town, Zhaoan County,Zhangzhou City, Fujian Province P.R .China Product: Toy RC Side Drifter Monster Truck Brand Name: SHARPER IMAGE Model: TD2020D Additional Model & Model Difference 1012179,1012283 Date of tests: Mar. 05 to Apr. 30, 2020 the tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C, Section 15.249 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Evans He Project Engineer / EMC Department Approved by David Huang Supervisor / EMC Department Date: May 09, 2020 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942, Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 27 Report Version 1 Test Report No.: RF200304N047- 2 TABLE OF CONTENTS RELEASE CONTROL RECORD ........................................................................................................3 1 SUMMARY OF TEST RESULTS ................................................................................................4 2 MEASUREMENT UNCERTAINTY ..............................................................................................4 3 GENERAL INFORMATION.........................................................................................................5 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................5 3.2 DESCRIPTION OF TEST MODES ..............................................................................................6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ..............................................................7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................7 4. TEST TYPES AND RESULTS ....................................................................................................8 4.1 RADIATED EMISSION MEASUREMENT ...................................................................................8 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT .....................................................8 4.1.2 TEST INSTRUMENTS ...................................................................................................9 4.1.3 TEST PROCEDURES .................................................................................................. 10 4.1.4 DEVIATION FROM TEST STANDARD ......................................................................... 10 4.1.5 TEST SETUP ............................................................................................................... 11 4.1.6 EUT OPERATING CONDITIONS ................................................................................. 12 4.1.7 TEST RESULTS ........................................................................................................... 13 4.2 20DB BANDWIDTH MEASUREMENT ...................................................................................... 22 4.2.1 LIMITS OF 20dB BANDWIDTH MEASUREMENT ............................................................ 22 4.2.2 TEST INSTRUMENTS ..................................................................................................... 22 4.2.3 TEST PROCEDURE ........................................................................................................ 23 4.2.4 DEVIATION FROM TEST STANDARD ............................................................................. 23 4.2.5 TEST SETUP ................................................................................................................... 23 4.2.6 EUT OPERATING CONDITIONS ..................................................................................... 23 4.2.7 TEST RESULTS .............................................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos
