Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: P4GTVEE26A Project No. : 1206C140A Equipment : Wireless Speaker System Model : Tvee®26A Applicant : Boston Acoustics INC. Address : 7 Constitution Way, Woburn, Massachusetts 01801, USA According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. No.3, Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Ant. Brand name Model Name Antenna TypeConnector Gain (dBi) 1 N/A N/A PCB AntennaN/A 3.3 TEST RESULTS EUT： Wireless Speaker System Model Name ： Tvee®26A Temperature： 25 °C Relative Humidity： 58 % Pressure： 1009 hPa Test Voltage ： AC 120V/60Hz Test Mode ： CH01/ CH10 /CH18 -5Mbps Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result 3.3 2.1380 1.73 1.4894 0.000634 1 Complies 3.3 2.1380 1.00 1.2589 0.000536 1 Complies 3.3 2.1380 0.29 1.0691 0.000455 1 Complies

Neutron Engineering Inc. Report No.: NEI-FICP-1-1206C140A Page 1 of 68 FCC/IC Radio Test Report FCC ID: P4GTVEE26A IC: 10104A-TVEE26A This report concerns (check one) : Original Grant Class II Change Issued Date : Jul. 12, 2012 Project No. : 1206C140A Equipment : Wireless Speaker System Model Name : Tvee®26A Applicant : Boston Acoustics, INC. Address : 7 Constitution Way, Woburn, Massachusetts 01801, USA Manufacturer : Boston Acoustics, INC. Address : 7 Constitution Way, Woburn, Massachusetts 01801, USA Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Jun. 19, 2012 Date of Test: Jun. 19, 2012 ~ Jul. 11, 2012 Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) Neutron Engineering Inc. No.3,Jinshagang 1st Road, ShiXia, Dalang Town, Dong Guan, China. TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. Report No.: NEI-FICP-1-1206C140A Page 2 of 68 Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of CHINA, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FICP-1-1206C140A Page 3 of 68 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 CONDUCTED EMISSION MEASUREMENT 14 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST AND SETTING 14 4.1.3 TEST PROCEDURE 15 4.1.4 DEVIATION FROM TEST STANDARD 15 4.1.5 TEST SETUP 15 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 18 4.2.1 RADIATED EMISSION LIMITS 18 4.2.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 19 4.2.3 TEST PROCEDURE 20 4.2.4 DEVIATION FROM TEST STANDARD 20 4.2.5 TEST SETUP 21 4.2.6 EUT OPERATING CONDITIONS 22 4.2.7 TEST RESULTS (BETWEEN30 – 1000 MHZ) 23 4.2.8 TEST RESULTS (ABOVE 1000 MHZ) 27 5 . NUMBER OF HOPPING CHANNEL 45 5.1 APPLIED PROCEDURES / LIMIT 45 5.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 45 5.1.2 TEST PROCEDURE 45 5.1.3 DEVIATION FROM STANDARD 45 5.1.4 TEST SETUP 45 5.1.5 EUT OPERATION CONDITIONS 45 5.1.6 TEST RESULTS 46 6 . AVERAGE TIME OF OCCUPANCY 47 Neutron Engineering Inc. Report No.: NEI-FICP-1-1206C140A Page 4 of 68 Table of Contents Page 6.1 APPLIED PROCEDURES / LIMIT 47 6.1.1 MEASUREMENT INSTRUMENTS LIST 47 6.1.2 TEST PROCEDURE 47 6.1.3 DEVIATION FROM STANDARD 47 6.1.4 TEST SETUP 48 6.1.5 EUT OPERATION CONDITIONS 48 6.1.6 TEST RESULTS 49 7 . HOPPING CHANNEL SEPARATION MEASUREMENT 51 7.1 APPLIED PROCEDURES / LIMIT 51 7.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 51 7.1.2 TEST PROCEDURE 51 7.1.3 DEVIATION FROM STANDARD 51 7.1.4 TEST SETUP 51 7.1.5 EUT OPERATION CONDITIONS 51 7.1.6 TEST RESULTS 52 8 . BANDWIDTH TEST 54 8.1 APPLIED PROCEDURES / LIMIT 54 8.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 54 8.1.2 TEST PROCEDURE 54 8.1.3 DEVIATION FROM STANDARD 54 8.1.4 TEST SETUP 54 8.1.5 EUT OPERATION CONDITIONS 54 8.1.6 TEST RESULTS 55 9 . PEAK OUTPUT POWER TEST 57 9.1 APPLIED PROCEDURES / LIMIT 57 9.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 57 9.1.2 TEST PROCEDURE 57 9.1.3 DEVIATION FROM STANDARD 57 9.1.4 TEST SETUP 57 9.1.5 EUT OPERATION CONDITIONS 57 9.1.6 TEST RESULTS 58 10 . ANTENNA CONDUCTED SPURIOUS EMISSION 58 10.1 APPLIED PROCEDURES / LIMIT 58 10.1.1 MEASUREMENT INSTRUMENTS LIST AND SETTING 58 10.1.2 TEST PROCEDURE 58 10.1.3 DEVIATION FROM STANDARD 58 10.1.4 TEST SETUP 58 10.1.5 EUT OPERATION CONDITIONS 58 10.1.6 TEST RESULTS 58 Neutron Engineering Inc. Report No.: NEI-FICP-1-1206C140A Page 5 of 68 Table of Contents Page 11 . EUT TEST PHOTO 58 Neutron Engineering Inc. Report No.: NEI-FICP-1-1206C140A Page 6 of 68 1. CERTIFICATION Equipment : Wireless Speaker System Brand Name : Boston® Model Name : Tvee®26A Applicant : Boston Acoustics, INC. Factory : Premium Loudspeakers (Huizhou) Co., Ltd Address : Tymphany Industrial Area, Xin Lian Village, Xin Xu Tow, Hui Yang District, Hui Zhou City, Guang Dong Province, P.R.C China Date of Test : Jun. 19, 2012 ~ Jul. 11, 2012 Test Item : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.247) / ANSI C63.4 : 2003 / ANSI C63.10:2009 / FCC Public Notice DA 00-705, March 30, 2000. Canada RSS-210:2010 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configura…
