P4M-ACT2334G Vehicle Tracker with Hotspot

4G Vehicle Tracker with Hotspot user Manual (ACT233L) All Rights Reserved. 1/13 4G Vehicle Tracker with Hotspot Users Manual APRIL, 2013 ACT233L, V1.0 AnyDATA AnyTime AnyPlace Any Wireless Data Solutions™ 4G Vehicle Tracker with Hotspot user Manual (ACT233L) All Rights Reserved. 2/13 AnyDATA ACT233L Copyright © 2009 AnyDATA Corp. All Rights Reserved. Any part of this document may not be distributed, communicated, reproduced or transmitted in any form or by any means, electronic or mechanical or otherwise, for any purpose, without the permission of AnyDATA Corp. This document can be subjected to revision without further notice. Contact Address Headquarter AnyData Corporation 5 Oldfield, Irvine, CA 92618, http://www.anydata.net e-mail: [email protected] Rep:1-949-833-0011 Fax: 1-949-833-0022 AnyData(China) 489 Song Tao Road, Sector B, 1st Fl. Pudong ZhanJiang Hi- Tech Park, Shanghai, 201203, P.R.China http://www.anydata.net.cn e-mail: [email protected] Rep:+86-21-5080-4828 Fax:+86-21-5080-3828 AnyData.Net Inc.(Korea) DaeGo Bldg, 8th., 1591-10 Kwanyang-dong, Dongan_gu, Anyang City, Kyunggi-do Korea. http://www.anydata.co.kr e-mail: [email protected] Rep:+82-31-380-7100 Fax:+82-31-476-6021 4G Vehicle Tracker with Hotspot user Manual (ACT233L) All Rights Reserved. 3/13 Contents Contents 3 Figures 3 Tables 4 1 Introduction 5 1.1 Purpose ......................................................................................................................... 5 1.2 Technical Detail ...................................................................................................... 5 1.3 Revision History ...................................................................................................... 5 2 Physical Contents 6 3 Description: 4G Vehicle Tracker with Hotspot 7 3.1 The Latest Vehicle Tracker in GPS Technology ............................................ 7 3.2 Alerts & Messages .................................................................................................... 7 3.3 Tracking Reports ...................................................................................................... 7 3.4 Vehicle Door Lock/Unlock with remote control ............................................ 7 3.5 Vehicle Door Look/Unlock with remote control from cloud server ...... 8 3.6 Vehicle Door Lock/Unlock with remote control through Bluetooth ...... 9 4 handing the 4G Vehicle Tracker with Hotspot 10 4.1 Set-up ......................................................................................................................... 10 4.2 Power supply from vehicle (typical 13.5V) ................................................ 10 5 Powering On/Off the 4G Vehicle Tracker with Hotspot 11 5.1 Powering On/OFF ...................................................................................................... 11 6 4G Vehicle Tracker with Hotspot Specifications 12 6.1 Form Factor .............................................................................................................. 12 6.2 Hardware Specifications ..................................................................................... 12 6.3 Software Specifications ..................................................................................... 12 6.4 External INTERFACE ................................................................................................ 13 6.5 Environmental .......................................................................................................... 13 7 Limitations of Liability 13 Figures Figure 2.1: Package Contents ............................................................................................... 6 Figure 3.1: External Interface .......................................................................................... 8 Figure 4.1: Installation of ACT233L in vehicle ....................................................... 10 4G Vehicle Tracker with Hotspot user Manual (ACT233L) All Rights Reserved. 4/13 Tables Table 1.1: Revision History .............................................................................................. 5 RF Exposure Warning: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact during normal operation is minimized. In order to avoid the possibility of exceeding the FCC radio frequency exposure limit, human proximity to the antenna should not be less than 20 cm. Information to user (FCC Part 15.21): Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. Information to user (Industry Canada license-exempt RSS standards) This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. 4G Vehicle Tracker with Hotspot user Manual (ACT233L) All Rights Reserved. 5/13 1 INTRODUCTION 1.1 PURPOSE This manual discusses the purpose and usage of the 4G Vehicle Tracker with Hotspot(ACT233L). 1.2 TECHNICAL DETAIL Please refer to Operation Description.pdf for a more detailed description of the ACT233L. 1.3 REVISION HISTORY The revision history for this manual is shown in Table 1.1. Table 1.1: Revision History Version Date Description V 1.0 APR 2013 Initial Release – ACT233L 4G Vehicle Tracker with Hotspot user Manual (AC…

Text truncated - open the document above for the full version.

FCC Authorization 20/05/2013 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Subject: Agent Authorization Request regarding application for certification of FCC ID: P4M- ACT233 Dear Jackson Caressa, We, AnyDATA , 5 Oldfield, Irvine, CA 92618 , hereby authorize Ferdinand Custodio of TUV SUD America located at 10040 Mesa Rim Road San Diego, CA 92121, 858-678-1444 , to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on Nov 20 th 2013. Sincerely, Company Officer: Jerry Ryoo / Director Telephone Number: 949-900-6040 (ext:260) Email: [email protected]

FCC Confidentiality Request 20/05/2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: P4M-ACT233 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, AnyDATA hereby requests permanent confidential treatment of information accompanying this application as outlined below:  Schematics  Bill of Materials/Parts List  Block Diagrams  Tune up procedure  Operation Description AnyDATA also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days  Users Manual  Internal Photos  External Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Jerry Ryoo Telephone Number: 949-900-6040 (ext:260) Email: [email protected]

BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD FCC ID: P4M-ACT233 Attestation for FCC Part 15B Declaration of Conformity Please be notified that we, the undersigned, AnyDATA Corp. declares that the product, which bears the above FCC ID is compliant with the FCC Part 15B requirements for DoC. The DoC procedure shall be carried out prior to marketing the device in the US. Sincerely, Company Officer: Jerry Ryoo / Director Telephone Number: 949-900-6040 (ext:260) Email: [email protected]

FCC ID P4M-ACT233 IC: 4594B-ACT233

ANYDATA CORPORATION PROPRIETARY & CONFIDENTIAL FCC Device Label 1 1. Model Name : ACT233L 2. FCC ID : P4M-ACT233 3. S/N: Date Code(YYYYMMDD) + S/N number(7digits) - Font Size : Arial 5.5 4. S/N bar code : 7digits Serial Number only - Bar code : 128B - Height : 2mm 5. IMEI : 15 digits - Font : Arial 5.5 6. IMEI bar code : 15 digits - Bar code : 128B - Height : 2mm 7. Registration Key : Hex 8digits (Upper case) - Font : Arial 5.5 - 8digit should be Hexadecimal with hyphen on the center S/N Bar Code (S/N Only) IMEI Bar Code (15 digits) S/N : YYYYMMDD1234567 IMEI : 123456789012345 Registration Key : AB12-C34D Label Location

Internal Photographs FCC ID P4M-ACT233 IC: 4594B-ACT233

Report No. SC1304495G May 2013 America Report On Maximum Permissible Exposure Evaluation for AnyDATA ACT233L 4G Vehicle Tracker with Hotspot OET Bulletin 65 Edition 97-01 including Supplement C Report No. SC1304495G Page 2 of 18 REPORT ON TEST REPORT NUMBER PREPARED FOR Maximum Permissible Exposure Evaluation for AnyDATA 4G Vehicle Tracker with Hotspot SC1304495G AnyDATA 5 Oldfield Irvine, CA 92618 CONTACT PERSON Kevin Kim Principal Engineer (949) 900-6040 x306 [email protected] PREPARED BY Ferdinand S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED May 22, 2013 Report No. SC1304495G Page 3 of 18 Revision History SC1304495G AnyDATA ACT233L ACT233L 4G Vehicle Tracker with Hotspot DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 05/22/13 Initial Release Ferdinand Custodio Report No. SC1304495G Page 4 of 18 CONTENTS Section Page No 1 REPORT SUMMARY ............................................................................................................................... 5 1.1 Introduction ................................................................................................................................................ 6 1.2 Brief Summary Of Results ........................................................................................................................... 7 1.3 Product Information ................................................................................................................................... 8 1.4 Requirements From The Standard ............................................................................................................ 10 2 TEST DETAILS ...................................................................................................................................... 12 2.1 MPE Calculations For Individual Transmitter ............................................................................................ 13 2.2 Worst Case Co-Located Exposure Conditions ........................................................................................... 16 3 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................................... 17 3.1 Accreditation, Disclaimers and Copyright ................................................................................................. 18 Report No. SC1304495G Page 5 of 18 SECTION 1 REPORT SUMMARY Maximum Permissible Exposure Evaluation for AnyDATA 4G Vehicle Tracker with Hotspot Report No. SC1304495G Page 6 of 18 1.1 INTRODUCTION The information contained in this report is intended to show compliance of AnyDATA 4G Vehicle Tracker with Hotspot to the requirements of OET Bulletin 65 Edition 97-01 including Supplement C. Objective To perform verification to determine the Equipment Under Test's (EUT’s) compliance with FCC §1.1307 Subpart I. Manufacturer AnyDATA Model Name ACT233L Model Number(s) ACT233L FCC ID Number P4M-ACT233 IC Number 4594B-ACT233 Test Specification/Issue/Date OET Bulletin 65 Edition 97-01 including Supplement C (June 2001) Name of Engineer(s) Ferdinand S. Custodio Related Document(s)  Report No: SC1304495A AnyDATA ACT233L FCC IC Part 15.247 RSS210 WLAN BT LE Test Report  Report No: SC1304495B AnyDATA ACT233L FCC Part 15.247 RSS210 BT FHSS Test Report  Report No: SC1304495C AnyDATA ACT233L FCC Part 15.231 RSS210 Test Report  Report No: SC1304495D AnyDATA ACT233L FCC IC Part 27 Test Report  Report No: SC1304495E AnyDATA ACT233L FCC IC Part 22 and 24 Test Report  447498 3 D01 General RF Exposure Guidance v05 (Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies). Page 7 of 18 1.2 BRIEF SUMMARY OF RESULTS A brief summary of verification carried out in accordance with OET Bulletin 65 Edition 97-01 including Supplement C is shown below. Transmitter Description of Evaluation Evaluation Type Result FCC Part 15.247 (WLAN) Individual MPE evaluation MPE calculated Compliant FCC Part 15.247 (BT) Individual MPE evaluation MPE calculated Compliant FCC Part 15.231 Individual MPE evaluation MPE calculated Compliant FCC Part 22 and 24 (CDMA) Individual MPE evaluation MPE calculated Compliant FCC Part 27 (LTE) Individual MPE evaluation MPE calculated Compliant All transmitters (co-located) Sum of the MPE ratios Calculated Compliant Page 8 of 18 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 1.3 PRODUCT INFORMATION 1.3.1 EUT General Description The Equipment Under Test (EUT) was an AnyDATA ACT233L 4G Vehicle Tracker with Hotspot as shown in the photograph below. The EUT connects to a vehicle’s OBD2 port; it enables remote functions and vehicle tracking through a Smartphone app. Page 9 of 18 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 1.3.2 EUT General Description EUT Description ACT233L 4G Vehicle Tracker with Hotspot Model Number(s) ACT233L Rated Voltage 13.5 VDC Nominal voltage. Capability 800/1900 CDMA2000 1xRTT and 1xEV-DO Release 0 Revision A, Band 4 and 13 LTE, 802.11 b/g/n WLAN, BT and Part 15.231 Transmitter 1.3.3 Antenna Details  Main Antenna (Tx/Rx for LTE B13/4 and CDMA BC0/1) Integral custom PIFA type  Diversity Antenna (Rx for LTE B13/4 and CDMA BC0/1) Integral custom ILA type  BT/WIFI Antenna (Tx/Rx for BT/WIFI) Integral custom ILA type  RF Transmitter Antenna (Tx for Transmitter) Integral Chip antenna Mode Part 15.231 Transmitter Frequency (MHz) 300 319 434 Antenna Gain (dBi) -6 -6 -8 Mode LTE B13 Frequency (MHz) 782 Antenna Gain (dBi) -6 Mode LTE B4 Frequency (MHz) 1710 1732 1755 Antenna Gain (dBi) -5 -4 -3.5 Mode CDMA BC0 Frequency (MHz) 824 836 849 Antenna Gain (dBi) -4 -4 -4 Mode CDMA BC1 Frequency (MHz) 1850 1880 1910 Antenna Gain (dBi) -3.5 -5 -4.5 Mode WiFi/BT Frequency (MHz) 2400 2440 2480 Antenna Gain (dBi) -6 -5.5 -6.5 Page 10 of 18 TÜV SÜD AMERICA INC 10040 Mesa Rim…

Text truncated - open the document above for the full version.

Report No. SC1304495E May 2013 America Report On Application for Grant of Equipment Authorization of the AnyDATA ACT233L 4G Vehicle Tracker with Hotspot FCC CFR 47 Part 2, Part 22 and 24 IC RSS-Gen and RSS-132 and RSS-133 FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495E Page 2 of 69 REPORT ON TEST REPORT NUMBER PREPARED FOR Radio Testing of the AnyDATA 4G Vehicle Tracker with Hotspot SC1304495E AnyDATA 5 Oldfield Irvine, CA 92618 CONTACT PERSON Kevin Kim Principal Engineer (949) 900-6040 X306 [email protected] PREPARED BY Ferdinand S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED May 20, 2012 FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495E Page 3 of 69 Revision History SC1304495E AnyDATA ACT233L 4G Vehicle Tracker with Hotspot DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 05/20/13 Initial Release Ferdinand Custodio FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495E Page 4 of 69 CONTENTS Section Page No 1 REPORT SUMMARY ............................................................................................................................... 5 1.1 Introduction ................................................................................................................................................ 6 1.2 Brief Summary Of Results ........................................................................................................................... 7 1.3 Product Information ................................................................................................................................... 8 1.4 EUT Test Configuration ............................................................................................................................. 10 1.5 Deviations From The Standard ................................................................................................................. 12 1.6 Modification Record ................................................................................................................................. 12 1.7 Test Methodology ..................................................................................................................................... 12 1.8 Test Facility ............................................................................................................................................... 12 1.9 Sample Calculations .................................................................................................................................. 13 2 TEST DETAILS ...................................................................................................................................... 14 2.1 Transmitter Conducted Output Power ..................................................................................................... 15 2.2 Effective Radiated Power .......................................................................................................................... 17 2.3 Equivalent Isotropic Radiated Power ........................................................................................................ 19 2.4 Occupied Bandwidth ................................................................................................................................. 21 2.5 Peak-Average Ratio ................................................................................................................................... 29 2.6 Band Edge/Conducted Spurious Emissions ............................................................................................... 33 2.7 Field Strength Of Spurious Radiation ........................................................................................................ 44 2.8 Frequency Stability ................................................................................................................................... 51 2.9 Receiver Spurious Emissions ..................................................................................................................... 55 2.10 Power Line Conducted Emissions ............................................................................................................. 58 3 TEST EQUIPMENT USED ...................................................................................................................... 59 3.1 Test Equipment Used ................................................................................................................................ 60 3.2 Measurement Uncertainty ....................................................................................................................... 61 4 DIAGRAM OF TEST SETUP ................................................................................................................... 62 4.1 Test Setup Diagram ................................................................................................................................... 63 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................................... 68 5.1 Accreditation, Disclaimers and Copyright ................................................................................................. 69 FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495E Page 5 of 69 SECTION 1 REPORT SUMMARY Radio Testing of the AnyDATA 4G Vehicle Tracker with Hotspot FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495E Page 6 of 69 1.1 INTRODUCTION The information contained in this report is intended to show verification of the AnyDATA 4G Vehicle Tracker with Hotspot to the requirements of the following:  FCC CFR 47 Part 2, Part 22 and 24  IC RSS-Gen and RSS-132 and RSS-133. Objective To perform Radio Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer AnyDATA Model Number(s) ACT233L FCC ID Number P4M-…

Text truncated - open the document above for the full version.

Report No. SC1304495D May 2013 America Report On Application for Grant of Equipment Authorization of the AnyDATA ACT233L 4G Vehicle Tracker with Hotspot FCC CFR 47 Part 2 and 27 IC RSS-Gen and RSS-139 Issue 2 February 2009 FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495D Page 2 of 92 REPORT ON TEST REPORT NUMBER PREPARED FOR Radio Testing of the AnyDATA 4G Vehicle Tracker with Hotspot SC1304495D AnyDATA 5 Oldfield Irvine, CA 92618 CONTACT PERSON Kevin Kim Principal Engineer (949) 900-6040 X306 [email protected] PREPARED BY Ferdinand S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED May 17, 2013 FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495D Page 3 of 92 Revision History SC1304495D AnyDATA ACT233L 4G Vehicle Tracker with Hotspot DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 05/17/13 Initial Release Ferdinand Custodio FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495D Page 4 of 92 CONTENTS Section Page No 1 REPORT SUMMARY ............................................................................................................................... 5 1.1 Introduction ................................................................................................................................................ 6 1.2 Brief Summary Of Results ........................................................................................................................... 7 1.3 Product Information ................................................................................................................................... 8 1.4 EUT Test Configuration ............................................................................................................................. 11 1.5 Deviations From The Standard ................................................................................................................. 13 1.6 Modification Record ................................................................................................................................. 13 1.7 Test Methodology ..................................................................................................................................... 13 1.8 Test Facility ............................................................................................................................................... 13 1.9 Sample Calculations .................................................................................................................................. 14 2 TEST DETAILS ...................................................................................................................................... 15 2.1 Transmitter Conducted Power Measurements ........................................................................................ 16 2.2 Equivalent Isotropic Radiated Power ........................................................................................................ 21 2.3 Effective Radiated Power Output Data ..................................................................................................... 26 2.4 Occupied Bandwidth ................................................................................................................................. 28 2.5 Peak-Average Power Ratio........................................................................................................................ 38 2.6 Band Edge ................................................................................................................................................. 46 2.7 Conducted Spurious Emissions ................................................................................................................. 56 2.8 Field Strength Of Spurious Radiation ........................................................................................................ 68 2.9 Frequency Stability ................................................................................................................................... 76 2.10 Receiver Spurious Emissions ..................................................................................................................... 78 2.11 Power Line Conducted Emissions ............................................................................................................. 81 3 TEST EQUIPMENT USED ...................................................................................................................... 82 3.1 Test Equipment Used ................................................................................................................................ 83 3.2 Measurement Uncertainty ....................................................................................................................... 84 4 DIAGRAM OF TEST SETUP ................................................................................................................... 85 4.1 Test Setup Diagram ................................................................................................................................... 86 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................................... 91 5.1 Accreditation, Disclaimers and Copyright ................................................................................................. 92 FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495D Page 5 of 92 SECTION 1 REPORT SUMMARY Radio Testing of the AnyDATA 4G Vehicle Tracker with Hotspot FCC ID P4M-ACT233 IC: 4594B-ACT233 Report No. SC1304495D Page 6 of 92 1.1 INTRODUCTION The information contained in this report is intended to show verification of the AnyDATA ACT233L 4G Vehicle Tracker with Hotspot to the requirements of the following:  FCC CFR 47 Part 2 and 27  IC RSS-Gen and RSS-139 Issue 2 February 2009. Objective To perform Radio Testing to determine the Equipment U…

Text truncated - open the document above for the full version.

FCC ID P4M-ACT233 IC: 4594B-ACT233 Conducted Port Test Setup (Unlicensed) Conducted Port Test Setup (Licensed) Radiated Emissions Test Setup Radiated Emissions Test Setup (Licensed) Radiated Emissions Test Setup (Unlicensed)
