P5A-CA0001WIRELESS PRESENTER

User's Guide 2.4GHz Wireless Multimedia Presenter Remote Trackball Wireless Presenter Laser Pointer Multimedia Controller 4-in-1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Caution : To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. INTRODUCTION Thank you for the purchase of the most innovative 2.4GHz multimedia presenter. Consolidating 2.4GHz wireless, trackball, and presenter technology. 4-in-1 design: a wireless remote media controller, a wireless trackball in the air, a laser pointer, and a remote presenter while users have presentation toward audience. 16 channels with 4096 ID. No interference! Wide range and long transmission distance of Max. 10M. Remote trackball for cursor control. Timer setting for presentation duration Timer alarm by vibration for presentation time control Page up / down between presentation slides. Laser pointer Presentation buttons: Slide forward / back, Black screen, Esc. Multi-media button controls: Play / Pause, Previous /Next track, Volume control Power on / off switch for save the battery. Plug and Play. No need to install driver. Storable wireless receiver. Smart-Link channel ID. Please DO NOT direct the laser beam at anyone's eyes. Trackball Right button Time table Left button Presenter This product complies with IEC 60825-1, Class I laser product. Your product complies with FCC and CE rules. Safety Notice Features Laser pointer Black screen Next Previous Stop Esc Volume up Volume down Page down Play/Pause Page up Timer adjustment button Timer setting button Power On/Off switch ID reset button 12 Receiver ID reset button 1. Insert the batteries A. Open the battery cover on the back of the presenter B. Fit in the batteries according to the diagram indicated in the battery compartment. C. Close the battery cover. 2. Connect the presenter and the receiver A. Pull the receiver from the bottom of presenter. B. Plug receiver into the USB port of your PC 3. Establish communication between the presenter and the receiver Remote trackball : The trackball can be used as a pointing device to move the cursor Right / Left button: Using left and right buttons as a mouse's right and left buttons. Timer setting for presenter: This is to allow you to set the presentation duration from 10 minutes, 20 minutes, up to 60 minutes. You can adjust it according to your demand. Once the time is set, the presenter will alarm you by vibration 5 minutes before ending of your presentation, and alarm again while ending. Re-set timer: Re-press Timer Setting button again to re-set An incorrect battery placement may cause batteries over heat. + - 2 AAA batteries PC USB port Battery compartment Battery cover Press ID reset buttonRed Led indicator blinks slowly Press ID reset buttonRed Led indicator blinks faster 1 2345 ID links OK! 34 4. Operation A. Auto-link mode: The presenter has auto-link function itself. B. Manual mode: 1. Press the ID reset button on the front of the receiver(step 1), and make sure the red LED will blink slowly.(step 2) 2. Press the ID reset button in the right side of the presenter .(step 3) 3. The Receiver's red LED indicator will blink at a faster rate until an identical ID is set up.(step 4) 4. The ID indicator of the receiver will blink any time when the presenter is working. ESC : Press ESC to escape from the slides of Power Point Black Screen : Press the Black Screen button, the screen will be black during the presentation. Press any key to return. Page up / down : Press Page Up / Down button to return or go to the next slide of Power Point. Laser pointer : Use laser pointer to point what a user wants to point at the monitor. Play / Pause : Play the music or pause the music in Volume Up / Down : Press Volume Up / Down button to turn up or down the music volume Track Last / Next : Press the buttons to go to the last track or forward. Stop : Stop the music. Please DO NOT direct the laser beam at anyone's eye. 5. Power On / Off There is a power on / off switch on the right side of the presenter to save the battery power. It is for saving battery life while the user doesn't need to use it in a period of time. Trouble Shooting a. Make sure you have connec…

Text truncated - open the document above for the full version.

Power supply Battery AAA*2 (3V) Regulator (3V) U4 Timer Control IC (BJ8F153) U2 Time Indication LED D1~D6 Vibrational Motor EEPROM 93CC46 U2’ RF IC Crystal nRF24L01 & Oscillator U3 16MHz Y2 VDD MCU Oscillator CR81P200 & 4MHz U1 Y1 M O S I MOSI MISO RFCLK M I S O R F C L K R F | C E R F | C S I R Q I/O Antenna P01 Block Diagram ID SW PDF created with pdfFactory trial version www.pdffactory.com MCU CY7C63803 U1 PC USB Port RF IC crystal nRF24L01 & oscillator 16MHz U2 Y1 Antenna I/O C18 Block Diagram ID SW PDF created with pdfFactory trial version www.pdffactory.com

EUT - Front View EUT - Back View

FCC ID Label Sample for Model: RF presenter FCC ID: P5A-CA0001 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID Label This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. Proposed Label Location on EUT EUT Bottom View/proposed FCC Mark Location FCC ID: P5A-CA0001

PCB1 - Front View PCB1 - Back View PCB2 - Front View PCB2 - Back View

P01 circuit description 1. Working frequencies is basing on 2.4GHz , it have 16 channels which can switched by ID SW. The 16 frequencies is changed under below arrange when you press the ID button, 2402MHz, 2432MHz, 2462mHz, 2405MHz, 2435MHz, 2465MHz, 2408MHz, 2439MHz, 2468MHz, 2411MHz, 2447MHz, 2471MHz, 2425MHz, 2476MHz, 2450MHz, 2479MHz. 2. The power supply is used 2* AAA alkaline cell ,and the DC-DC regulator U4 steady the voltage at 3V . Power switch ‘PWS’ can cut off or turn on the power supply. 3. Buttons managed by the U1(MCU) ‘s I/O matrix gives the signal to the MCU when you pressed . Then the MCU encode the signal and send the data to 2.4G RF transceiver U3. Move the trackball will do the same process. 4. U3 modulate the data signal and transmitted it by antenna. PDF created with pdfFactory trial version www.pdffactory.com

55 44 33 22 11 D D C C B B A A POWER PSW NEAR TO U5 RFCLKMOSIIRQMISORF-CERF-CS B00 B01 B02 B03 SCAN0SCAN1SCAN2 IR-C XBXAYAYB <Doc> V-A Area 2.4G NODIC B 1 1 Thursday, August 03, 2006 TitleSize Document Number Rev Date: Sheet of VDD E2_CSEFCLKMOSI PC_GND MISO VDD_B VDD_B VDD V3.0 V3.0 VDD_B V3.0 R4 22K C7 102P L2 22uH~200uH BLANK R11 22K5% RB R6 330R C620P IR2 R7 330R TA R8 330R C50.1u XA R5470K R3 330R Y216M UP C141.5P C220p IR1 D3 L36.8nH LB D8 1N5817 R15 330R Q1 3904 C2 47u~100u R1339K D6 YA D2 V+ R1447K Q1 3904 YB R6 1M C820P C50.1u R1039K C152.2nF C40.1u R21 330R XB C1 47u~100u >>| NODIC-24L01 U4 12345 6 7 8 9 10 1112131415 16 17 18 19 20 CECSCLKMOSIMISO IRQ VDD VSS XC2 XC1 VDD-PA ANT1ANT2 VSS VDD IREF VSS VDD DVDD VSS R4 330R D5 |<< R1 330R TC >| U3 93C46 78 1234 56 NC VCC CSSKD1DO GND NC R239K 3V Y1 4MHz R2330R C6 103P EM78153 U1 921456 10 14131211738 P50P67P66VDDP65P64P63 P62 P61P60 VSS P53P52P51 V- C30.1u C111.5P L2 3.3nH R5 330R L1 22uH~200uH C40.1u D1 PAUSE DONW U5 AP16CMP57AD 123456789 1011121314 1516171819202122232425262728 RTCCVDDSETVSSIR-CSCAN0SCAN1SCAN2BATE2-CSNCMOSIMISOIRQ RFCLK RFCSRFCE Y2Y1 X2X1 B00B01B02B03 OSC2OSC1 RESET U1 3.0V 1 2 3 GND OUT IN D2 L43.9nH C1 20p TS C12333P ID R3 22K C164.7P D4 R12 39K

FCC TEST REPORT Page 1 of 24 FCC ID : P5A-CA0001 Applicant : Areson Technology Corporation 12F, No.111-6, Hsing-De Rd. SanChung, Taipei Hsien, Taiwan Equipment Under Test (EUT) : Product description : Wireless presenter Model No. : RF presenter Standards : FCC 15 Paragraph 15.249 Date of Test : October 16, 2006 Test Engineer : Tiger Su Reviewed By : PERPARED BY: Waltek Services (Shenzhen) Co., Ltd. 8C,West Tower, Aidi Building, No.5003 Binhe Rd, Futian District, Shenzhen518045, Guangdong, China. Tel: 86-755-83551033 Fax: 86-755-83552400 Areson Technology Corporation FCC ID: P5A-CA0001 2 Contents Page 1 COVER PAGE..........................................................................................................................................................1 2 CONTENTS.......................................................................................................................................................2 3 TEST SUMMARY.............................................................................................................................................4 4 GENERAL INFORMATION...........................................................................................................................5 4.1 CLIENT INFORMATION..........................................................................................................................................5 4.2 GENERAL DESCRIPTION OF E.U.T. .......................................................................................................................5 4.3 DETAILS OF E.U.T................................................................................................................................................5 4.4 DESCRIPTION OF SUPPORT UNITS.........................................................................................................................5 4.5 STANDARDS APPLICABLE FOR TESTING...............................................................................................................5 4.6 TEST FACILITY.....................................................................................................................................................6 4.7 TEST LOCATION...................................................................................................................................................6 5 EQUIPMENT USED DURING TEST.............................................................................................................7 6 CONDUCTED EMISSION TEST...................................................................................................................8 6.1 TEST EQUIPMENT.................................................................................................................................................8 6.2 TEST PROCEDURE.................................................................................................................................................8 6.3 CONDUCTED TEST SETUP.....................................................................................................................................9 6.4 EUT OPERATING CONDITION...............................................................................................................................9 6.5 CONDUCTED EMISSION LIMITS...........................................................................................................................10 6.6 CONDUCTED EMISSION TEST RESULT................................................................................................................10 7 RADIATION EMISSION TEST....................................................................................................................11 7.1 TEST EQUIPMENT...............................................................................................................................................11 7.2 MEASUREMENT UNCERTAINTY..........................................................................................................................11 7.3 TEST PROCEDURE...............................................................................................................................................11 7.4 RADIATED TEST SETUP......................................................................................................................................12 7.5 SPECTRUM ANALYZER SETUP............................................................................................................................12 7.6 CORRECTED AMPLITUDE & MARGIN CALCULATION.........................................................................................13 7.7 SUMMARY OF TEST RESULTS.............................................................................................................................13 7.8 EUT OPERATING CONDITION.............................................................................................................................14 7.9 RADIATED EMISSIONS LIMIT..............................................................................................................................14 7.10 RADIATED EMISSIONS TEST RESULT..................................................................................................................15 8 BAND EDGE...................................................................................................................................................17 8.1 TEST EQUIPMENT...............................................................................................................................................17 8.2 TEST PROCEDURE...............................................................................................................................................17 8.3 EUT OPERATION................................................................................................................................................17 8.4 BAND EDGE................................................…

Text truncated - open the document above for the full version.

Radiation Emission Test View For 30MHz-1000MHz Radiation Emission Test View For 1GHz-25GHz
