User's Guide Wireless Optical Mouse Introduction Congratulations on your purchase of the most innovative mini wireless mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, the mouse can track reliably even on tricky polished or wood-grain surfaces. It offers even more advance that will make you more productive and more comfortable. A. Hardware Installation 2. Connect the receiver a. Turn on your PC. b. Connect the receiver to USB port on PC. PC USB port The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any button of the mouse" is compulsory to wake it up. Power on/off: There is a Power on/off switch designed to save the battery power while non-usage of a longer period. User can push DPI button to change the resolution. The LED on wheel bar will be flashed when dpi has been sucessfully switched. 1. Insert the battery a. Remove the battery compartment cover on the top case of the mouse. b. Fit in the battery according to the diagram indicated in the battery cabinet. c. Close the battery compartment cover properly. d. Make sure the Power on/off swich on the bottom of the mouse is ON. e. The Low Power LED on the wheel bar will be on for 6 seconds if the mouse power is on. 3. Communication : The mouse & the receiver A. Auto-link mode 1. Make sure the Power On-Off Switch on the bottom of the mouse is ON. 2. Operate the mouse, and cursor's movement is mapping mouse movement. Now the mouse and the receiver is auto-linked successfully. Wheel button ID reset button Mouse 2.4GHz (distance 6~8m), 16 Channels/2 16 ID Using state-of-art technology. High tracking speed and sensitivity. Nano receiver. Longer battery life. Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch. Ergonomic design. 800/1600 dpi switchable button. Rubber side grips. 2*AA Alkaline batteries included. Power on/off switch Features Battery cover Receiver Internet Forward & Backward button Receiver Dpi button + - A wrong battery placement may cause batteries overheat. Battery compartment cover 2 * AA batteries Pull out the receiver Low power indicator ◎ Battery use reminders 1. Remove worn-out batteries from equipment immediately and dispose of promptly. 2. Keep all battery (used or new) out of the reach of children. 3. To have the battery with a regular check and replace a new battery if not used for a long time. 4. Never dispose of battery in fire, as it could explode. 5. Do not use the wrong type of battery (e.g. Ni MH, NiCd, and etc) in the mouse. FCC statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example-use only shielded interface cables when connecting to computer or peripheral devices). FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits sent forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. and (2) This device must accept any interference received, including interference that may cause undesired operation. ◎ Troubleshooting a. Make sure you have connected the receiver correctly to the computer's USB port. b. For the best performance, we suggest you to locate the receiver with a distance from other electrical devices, such as the computer, the computer monitor or external storage drives. c. Make sure you have set the communication between the receiver and the mouse. Refer to the Communication:The mouse and the receiver. d. If you find the communication channel does not connect well. You can use the software connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able to get the software from the included diskette of the package or download from your local brand vendor's website. e. Make sure that you are not working the mouse on glossy or reflective surfaces. This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end its life separately from your household waste. There are sparate collection system for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product. Press ID reset button Execute ID connection software 1 23 ID links OK! 4. Replace a new battery Please replace a new battery and follow the previous instructions. (2, 3) The red LED on the scroll wheel is the low battery power indicator. It indicates that battery inside the mouse is needed to be replaced. Note While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source out and transfer to another free c…
