P5A-CB0014Optical Wireless Mouse

Wireless O PTICAL M OUSE User's Guide Receiver Wheel button Power on/off switch Battery cover Dpi button Mouse 2.4GHz (distance 6~8m), 32 Channels/2 24 ID Using state-of-art technology. High tracking speed and sensitivity. Nano receiver. Longer battery life. Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch. 800/1600 dpi switchable button. Super Slim design. 2*AAA Alkaline batteries included. Features ID reset button Internet Forward & Backward button Pull out the receiver A wrong battery placement may cause batteries overheat. + - Battery compartment cover 2 * AAA batteries Introduction Congratulations on your purchase of the most innovative mini wireless mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, the mouse can track reliably even on tricky polished or wood-grain surfaces. It offers even more advance that will make you more productive and more comfortable. A. Hardware Installation 2. Connect the receiver a. Turn on your PC. b. Connect the receivere to USB port on PC. PC USB port The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any button of the mouse" is compulsory to wake it up. Power on/off: There is a Power on/off switch designed to save the batteries power while non-usage of a longer period. User can push DPI button to change the resolution. The LED on wheel bar will be flashed when dpi has been successfully switched. 1. Insert the batteries a. Remove the battery compartment cover on the bottom case of the mouse. b. Fit in the batteries accordingly to the diagram indicated in the battery cabinet. c. Close the battery compartment cover properly. d. Make sure the Power on-off switch on the bottom of the mouse is ON. e. The Low Power LED on the wheel bar will be on for 6 seconds if the mouse power is on. 3. Communication : The mouse & the receiver The 2.4Ghz RF mouse features a dual-way transmission technology which enables the mouse and the receiver auto-communication. A. Auto-link mode 1. Make sure the Power On-Off Switch on the bottom of the mouse is ON. 2. Operate the mouse, and cursor's movement is mapping mouse movement. Now the mouse and the receiver is auto-linked successfully. If you find the commuication channel does not connect well, you can unplug the receiver, re-plug it back into the USB port on PC, and then within 15 seconds press the ID reset button on the back of mouse. Now the mouse and the receiver is linked uccessfully. y. 5. Always replace all the batteries at the same time. Mixing old and new batteries or mining types (such as alkaline with zinc carbon) will reduce overall performance and could cause leakage or rupture. 6. Do not mix different types of batteries (e.g. Ni MH, NiCd, alkaline, and etc) in the mouse. 7. Remove batteries from the electrical device if the device is not going to be used for a long time. 8. If the performance of the batteries decreases substantially, it is time to replace the batteries. ◎ Trouble Shooting a. Make sure you have connected the receiver correctly to the computer's USB port. b. For the best performance, we suggest you to locate the receiver with a distance from other electrical devices, such as the computer, the computer monitor or external storage drives. c. Make sure you have set the communication between the receiver and the mouse. Refer to the Communication: The mouse and the receiver d. If you find the communication channel does not connect well. You can use the software connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able to get the software from the included diskette of the package or download from your local brand vendor's website. 4. Replace the new batteries Please replace a pair of new batteries and follow the previous instructions. (2, 3) The red LED on the scroll wheel is the low batteries power indicator. It indicates that batteries inside the mouse are needed to be replaced. Note While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source out and transfer to another free channel. During the transferring, the cursor movement may have a second delay. Note B. Manual mode FCC statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example-use only shielded interface cables when connecting to computer or peripheral devices). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. and (2) This device must accept any interference received, including interference that may cause undesired operation. This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end its life separately from your household waste. There are sparate…

Text truncated - open the document above for the full version.

Report No.: C121010Z05-RP1 Page 1/3 Report No.: C121010Z05-RP1 Page 2/3 . Report No.: C121010Z05-RP1 Page 3/3 .

Label Location

Rating:3V==100mA FCC ID:P5A-CB0014 Wireless Optical Mouse Made in China ARESON 

Report No.: C121010Z05-RP1 Page 1/5 Report No.: C121010Z05-RP1 Page 2/5 . Report No.: C121010Z05-RP1 Page 3/5 . Report No.: C121010Z05-RP1 Page 4/5 . Report No.: C121010Z05-RP1 Page 5/5 .

Report No: C121010Z05-RP1 FCC ID: P5A-CB0014 Page 1/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C for Optical Wireless Mouse Model: B002MR Brand: Areson Test Report Number: C121010Z05-RP1 Issued for Areson Technology Corporation 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: October 15, 2012 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No: C121010Z05-RP1 FCC ID: P5A-CB0014 Page 2/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 C121010Z05-RP1 Initial Issue ALL Nancy Fu Report No: C121010Z05-RP1 FCC ID: P5A-CB0014 Page 3/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ...........................................................................................4 2 EUT DESCRIPTION.................................................................................................5 3 TEST METHODOLOGY...........................................................................................6 3.1. DESCRIPTION OF TEST MODES.......................................................................................6 4 TEST METHODOLOGY...........................................................................................7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................7 5 INSTRUMENT CALIBRATION ................................................................................8 6 SETUP OF EQUIPMENT UNDER TEST .................................................................8 6.1. DESCRIPTION OF SUPPORT UNITS .................................................................................8 6.2. CONFIGURATION OF SYSTEM UNDER TEST..................................................................8 7 FACILITIES AND ACCREDITATIONS ....................................................................9 7.1. FACILITIES ..........................................................................................................................9 7.2. ACCREDITATIONS ..............................................................................................................9 7.3. MEASUREMENT UNCERTAINTY .......................................................................................9 8 FCC PART 15.249 REQUIREMENTS ...................................................................10 8.1. BAND EDGES MEASUREMENT .......................................................................................10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT ...........................................16 8.3. SPURIOUS EMISSIONS MEASUREMENT .......................................................................19 Report No: C121010Z05-RP1 FCC ID: P5A-CB0014 Page 4/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product Optical Wireless Mouse Model B002MR Brand Areson Tested October 10~15, 2012 Applicant Areson Technology Corporation 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY Manufacturer Dong Guan Hong Sheng Electronic Corp. (China) No.28, Sha-wu S. Ave., Sha-Wu, Tang-Xia, Dong-Guan, Guang-Dong, China 523725 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Ruby Zhang Supervisor of Report Dept. Compliance Certification Service Inc. Report No: C121010Z05-RP1 FCC ID: P5A-CB0014 Page 5/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product Optical Wireless Mouse Model Number B002MR Trade Name Areson Model Discrepancy N/A Identify Number C121010Z05-RP1 Power Supply DC3V supplied by the battery Frequency Range 2408-2474 MHz Transmit Power Peak: 84.10dBuV/m (Max.) Average: 80.33dBuV/m (Max.) Modulation Technique FHSS(FSK) Number of Channels 34 Channels Antenna Specification PCB Antenna with 0dBi gain(MAX) Temperature Range -5°C ~ +45°C Note: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: P5A-CB0014 filing to comply with Section 15.207, 15.209 and 15.249 of the FCC Part 15, Subpart C Rules. Report No: C121010Z05-RP1 FCC ID: P5A-…
