P5A-CB0016Mini Wireless Optical Mouse

User's Guide Mini Wireless Optical Mouse PC USB port Pull out the receiver Battery compartment cover 2 * AAA batteries Wheel button ID reset button Power on/off switch Battery cover Receiver Low power indicator Receiver Mouse Introduction Congratulations on your purchase of the most innovative wireless mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, the mouse can track reliably even on tricky polished or wood-grain surfaces. It offers even more advance that will make you more productive and more comfortable. A. Hardware Installation 2.4GHz (distance 6~8m), 34 Channels/2 16 ID Using state-of-art technology. High tracking speed and sensitivity. Nano receiver. Longer battery life. Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch. Ergonomic design. 800 dpi resolution. 2*AAA Alkaline batteries included. Features A wrong battery placement may cause batteries overheat. 2. Connect the receiver a. Turn on your PC. b. Connect the receivere to USB port on PC. The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any button of the mouse" is compulsory to wake it up. Power on/off: There is a Power on/off switch designed to save the batteries power while non-usage of a longer period. User can push DPI button to change the resolution. The LED on top case will be flashed when dpi has been sucessfully swithced. 1. Insert the batteries a. Remove the battery compartment cover on the bottom case of the mouse. b. Fit in the batteries accordingly to the diagram indicated in the battery cabinet. c. Close the battery compartment cover properly. d. Make sure the Power on-off swich on the bottom of the mouse is ON. e. The Low Power LED on the top case will blink 3 seconds if the mouse power is on. 3. Communication : The mouse & the receiver The 2.4Ghz RF mouse features a dual-way transmission technology which enables the mouse and the receiver auto-communication. A. Auto-link mode 1. Make sure the Power On-Off Switch on the bottom of the mouse is ON. 2. Operate the mouse, and cursor's movement is mapping mouse movement. Now the mouse and the receiver is auto-linked successfully. Press ID reset button Execute ID connection software 1 23 ID links OK! 4. Replace the new batteries Please replace a pair of new batteries and follow the previous instructions. (2, 3) The red LED on the scroll wheel is the low batteries power indicator. It indicates that batteries inside the mouse are needed to be replaced. Note While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source out and transfer to another free channel. During the transferring, the cursor movement may have a second delay. Note ◎ Trouble Shooting a. Make sure you have connected the receiver correctly to the computer's USB port. b. For the best performance, we suggest you to locate the receiver with a distance from other electrical devices, such as the computer, the computer monitor or external storage drives. c. Make sure you have set the communication between the receiver and the mouse. Refer to the Communication :The mouse and the receiver d. If you find the communication channel does not connect well. You can use the software connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able to get the software from the included diskette of the package or download from your local brand vendor's website. e. Some system devices might conflict with the mouse. Confirm the IRQ/address settings of these devices for conflicts, and change the settings as required. f. Make sure that you are not working the mouse on glossy or reflective surfaces. ◎ Battery use reminders 1. Remove worn-out batteries from equipment immediately and dispose of promptly. 2. Keep all batteries (used or new) out of the reach of children. 3. To have the batteries with a regular check and replace new batteries if not used for a long time. 4. Never dispose of batteries in fire, as they could explode. 5. Always replace all the batteries at the same time. Mixing old and new batteries or mining types (such as alkaline with zinc carbon) will reduce overall performance and could cause leakage or rupture. 6. Do not mix different types of batteries (e.g. Ni MH, NiCd, alkaline, and etc) in the mouse. 7. Remove batteries from the electrical device if the device is not going to be used for a long time. 8. If the performance of the batteries decreases substantially, it is time to replace the batteries. B. Manual mode If you find the communication channel does not connect well, you can use the software connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able to download the software from your local brand vendor's website. FCC statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this …

Text truncated - open the document above for the full version.

Areson Technology Corporation 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY TAIPEI COUNTY 241 Ta i w a n FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Areson Technology Corporation Addresss 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY City TAIPEI COUNTY 241 Country Ta i w a n request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: P5A - CB0016 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) TAIPEI COUNTY 241 Ta i w a n 2012-12-14 Boda Zheng Manager

Areson Technology Corporation 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY TAIPEI COUNTY 241 Ta i w a n FCC Authorization Letter Number: CF304 Version: V01 Date: 01-02-2010 We, (the approval holder) Company name Areson Technology Corporation Addresss 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY City TAIPEI COUNTY 241 Country Ta i w a n declare that the following representative (agent): Name (person) Ruby Zhang Company name Compliance Certification Services Inc. Address No.10-1 Mingkeda Logistics park, No.18 Huanguan South Road. Guan Lan Town, Baoan District, Shenzhen, China City Shenzhen, Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Mini Wireless Optical Mouse Type or Model(s) B316 3D5DB, B316 3D3B Tradename or Brand(s) Areson We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) TAIPEI COUNTY 241 Ta i w a n 2012-12-14 Boda Zheng Manager

Report No.: C121203Z02-RP1 Page 1/4 Report No.: C121203Z02-RP1 Page 2/4 Report No.: C121203Z02-RP1 Page 3/4 Report No.: C121203Z02-RP1 Page 4/4

Report No.: C121203Z02-RP1 Page 1/4 Report No.: C121203Z02-RP1 Page 2/4 Report No.: C121203Z02-RP1 Page 3/4 Report No.: C121203Z02-RP1 Page 4/4

S/N:00000001 Mini Wireless Optical Mouse Made in China FCC ID P5A-CB0016

Report No.: C121010Z05-RP1 Page 1/6 Report No.: C121010Z05-RP1 Page 2/6 Report No.: C121010Z05-RP1 Page 3/6 Report No.: C121010Z05-RP1 Page 4/6 Report No.: C121010Z05-RP1 Page 5/6 Report No.: C121010Z05-RP1 Page 6/6

Report No: C121203Z02-RP1 FCC ID: P5A-CB0016 Page 1/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C for Mini Wireless Optical Mouse Model: B316 3D5B/B316 3D3B Brand: Areson Test Report Number: C121203Z02-RP1 Issued for Areson Technology Corporation 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: December 10, 2012 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No: C121203Z02-RP1 FCC ID: P5A-CB0016 Page 2/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 C121203Z02-RP1 Initial Issue ALL Sunny Wang Report No: C121203Z02-RP1 FCC ID: P5A-CB0016 Page 3/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ...........................................................................................4 2 EUT DESCRIPTION.................................................................................................5 3 TEST METHODOLOGY...........................................................................................6 3.1. DESCRIPTION OF TEST MODES.......................................................................................6 4 TEST METHODOLOGY...........................................................................................7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS............................................7 5 INSTRUMENT CALIBRATION ................................................................................8 6 SETUP OF EQUIPMENT UNDER TEST .................................................................8 6.1. DESCRIPTION OF SUPPORT UNITS .................................................................................8 6.2. CONFIGURATION OF SYSTEM UNDER TEST..................................................................8 7 FACILITIES AND ACCREDITATIONS ....................................................................9 7.1. FACILITIES ..........................................................................................................................9 7.2. ACCREDITATIONS ..............................................................................................................9 7.3. MEASUREMENT UNCERTAINTY .......................................................................................9 8 FCC PART 15.249 REQUIREMENTS ...................................................................10 8.1. BAND EDGES MEASUREMENT .......................................................................................10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT ...........................................12 8.3. SPURIOUS EMISSIONS MEASUREMENT .......................................................................19 Report No: C121203Z02-RP1 FCC ID: P5A-CB0016 Page 4/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product Mini Wireless Optical Mouse Model B316 3D5B/B316 3D3B Brand Areson Tested December 3~10, 2012 Applicant Areson Technology Corporation 11F.,NO.646, SEC.5,CHONGSIN RD., SANCHONG CITY Manufacturer Dong Guan Hong Sheng Electronic Corp. (China) No.28, Sha-wu S. Ave., Sha-Wu, Tang-Xia, Dong-Guan, Guang-Dong, China 523725 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Ruby Zhang Supervisor of Report Dept. Compliance Certification Service Inc. Report No: C121203Z02-RP1 FCC ID: P5A-CB0016 Page 5/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product Mini Wireless Optical Mouse Model Number B316 3D5B/B316 3D3B Trade Name Areson Model Discrepancy The difference only on the left no side keys for the model B316 3D3B; and the black colour for the model B3163D3B, the blue colour for the model B316 3D5B. Identify Number C121203Z02-RP1 Power Supply DC3V supplied by the battery Frequency Range 2408-2474 MHz Transmit Power Peak: 85.04dBuV/m (Max.) Average: 81.80dBuV/m (Max.) Modulation Technique FHSS(FSK) Number of Channels 34 Channels Antenna Specification PCB Antenna with 0dBi gain(MAX) Temperature Range -5°C ~ +45°C Note: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufa…

Text truncated - open the document above for the full version.

Report No.: C121203Z02-RP1 FCC ID: P5A-CB0014 Page 1/1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST Below 1GHz Above 1GHz
