P5A-CL0004Wireless Mouse

1. Insert the batteries a. Take out the receiver on the bottom case first, press the battery cover release button on the bottom of the mouse which is under the receiver. b. Remove the battery compartment cover on the top case of the mouse. c. Fit in the batteries accordingly to the diagram indicated in the battery cabinet. d. Close the battery compartments cover properly. e. Make sure the Power on-off swich on the bottom of the mouse is ON. f. The Low Power LED in the wheel bar will blink 3 seconds if the mouse power is on. Wheel button Dpi button Battery cover ID reset button LED indicator Receiver Mouse Receiver Introduction Congratulations on your purchase of the most innovative wireless mini mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, the mouse can track reliably even on tricky polished or wood-grain surfaces. It of fers even more advance that will make you more productive and more comfortable. A. Hardware Installation 2.4GHz (distance 6~8m), 16 Channels/4096 ID Using state-of-art laser technology. High tracking speed and sensitivity. 4-way scrolling. Storable mini receiver One year battery life. (*Optional for specific laser long-life models) Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch Data report rate : 125 Report/Sec. 800/1600 dpi switchable button. 2*AA Alkaline batteries included. Power on/off switch This product complies with IEC 60825-1, Class I laser product. Your product complies with FCC and CE rules. Safety Notice Please DO NOT direct the laser beam at anyone's eyes. Features + - A wrong battery placement may cause batteries overheat. Battery compartment cover 2 * AA batteries Battery cover release button Low power Led/ Power on indicator/ Dpi switching indicator 2. Connect the receiver a. Turn on your PC. b. Connect the receiver to USB port on PC PC USB port The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any button of the mouse" is compulsory to wake it up. Power on/off: There is a Power on/off switch designed to save the batteries power while non-usage of a longer period. Users can push DPI button to change the resolution. The low power LED will be flashed when dpi has been successfully swithced. 12 Press ID reset button Execute ID connection software Led indicator blinks faster 1 23 4 ID links OK! 4. Replace the new batteries Please replace a pair of new batteries and follow the previous instructions. (2, 3) The red LED on the scroll wheel is the low batteries power indicator. It indicates that batteries inside the mouse are needed to be replaced. Note While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source out and transfer to another free channel. During the transferring, the cursor movement may have a second delay. Note Trouble Shooting a. Make sure you have connected the receiver correctly to the computer's USB port. b. For the best performance, we suggest you to locate the receiver with a distance from other electrical devices, such as the computer, the computer monitor or external storage drives. c. Make sure you have set the communication between the receiver and the mouse. Refer to the Communication :The mouse and the receiver d. If you find the communication channel does not connect well. You can use the software connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able to get the software from the included diskette of the package or download from your local brand vendor's website. e. Some system devices might conflict with the mouse. Confirm the IRQ/address settings of these devices for conflicts, and change the settings as required. f. Make sure that you are not working the mouse on glossy or reflective surfaces. g. Try unplugging then reconnecting the receiver cable to your computer. Battery use reminders 1. Remove worn-out batteries from equipment immediately and dispose of promptly. 2. Keep all batteries (used or new) out of the reach of children. 3. To have the batteries with a regular check and replace new batteries if not used for a long time. 4. Never dispose of batteries in fire, as they could explode. 5. Always replace all the batteries at the same time. Mixing old and new batteries or mining types (such as alkaline with zinc carbon) will reduce overall performance and could cause leakage or rupture. 6. Do not mix different types of batteries (e.g. Ni MH, NiCd, alkaline, and etc) in the mouse. 7. Remove batteries from the electrical device if the device is not going to be used for a long time. 8. If the performance of the batteries decreases substantially, it is time to replace the batteries. 5. Operation 4-Way Scrolling: a. Vertical Scrolling Roll wheel up to scroll up; roll wheel down to scroll down. b. Horizontal Scrolling Hold the wheel to left to scroll left; hold the wheel to right to scroll right. Release wheel to stop scrolling function. B. Driver Installation The mouse features plug & play. It is not necessary to install the driver to operate the mouse. The driver is an optional item included. However if the model purchased is with 4-Way Scrolling function, you may require the mouse software driver to make the 4-Way scrolling function effective. 1. Un-install or removing the current mouse driver Before installing the driver of the mouse, we suggest that you check if any other mouse driver installed in your system. If yes, in order not to make conflict, please un-install or remove that driver before installing the mouse. 2. Install the mouse 4-Way Scrolling driver a.Select setup.exe to install the driver from the CD. b.or you can download the 4-Way Scrolling driver from vendor's website. 3. Communication : The mouse & the receiver The 2.4Ghz RF mouse features a dual-way transmission technology which enables the mouse and the receiver auto-communication. A. Auto-link mode 1. Make sure the Power On-Off Switch on t…

Text truncated - open the document above for the full version.

Project No.: 0707C046 Page 2 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 2 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 3 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 3 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 4 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 4 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 5 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 5 of 6 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 6 of 6 Neutron Engineering Inc. 0707C046

L180 Laser Wireless Mouse Laser FCC ID:P5A-CL0004 FCC ID:P5A-CL0004

Project No.: 0707C046 Page 2 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 2 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 3 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 3 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 4 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 4 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 5 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 5 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 6 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 6 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 7 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 7 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 8 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 8 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 9 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 9 of 10 Neutron Engineering Inc. 0707C046 0707C046 Project No.: 0707C046 Page 10 of 10 Neutron Engineering Inc. 0707C046

Report No.: NEI-FCCP-1-0707C046 Page 2 of 41 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-1-0707C046 Page 3 of 41 Neutron Engineering Inc. Table of Contents Page 1 . CERTIFICATION 4 2 . SUMMARY OF TEST RESULTS 5 2.1 TEST FACILITY 6 2.2 MEASUREMENT UNCERTAINTY 6 3 . GENERAL INFORMATION 7 3.1 GENERAL DESCRIPTION OF EUT 7 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 MEASUREMENT INSTRUMENTS LIST 12 4.1.3 TEST PROCEDURE 13 4.1.4 DEVIATION FROM TEST STANDARD 13 4.1.5 TEST SETUP 13 4.1.6 EUT OPERATING CONDITIONS 14 4.1.7 TEST RESULTS 15 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 MEASUREMENT INSTRUMENTS LIST 18 4.2.3 TEST PROCEDURE 18 4.2.4 DEVIATION FROM TEST STANDARD 18 4.2.5 TEST SETUP 19 4.2.6 EUT OPERATING CONDITIONS 19 4.2.7 TEST RESULTS (Between 30 – 1000 MHz) 20 4.2.8 TEST RESULTS (Above 1000 MHz) 22 4.2.9 TEST RESULTS (2400 – 2483.5 MHz) 34 4.2.10 TEST RESULTS (Restricted Bands Requirements) 35 5 . EUT TEST PHOTO 40 Report No.: NEI-FCCP-1-0707C046 Page 4 of 41 Neutron Engineering Inc. 1. CERTIFICATION Equipment : Wireless Mouse Trade Name : ARESON M o d e l N o . : L180 Applicant : ARESON Technology Corp. Data of Test : Jul. 09, 2007 ~ Jul .13, 2007 Te s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.249) / RSS-210: 2004/ ANCI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-0707C046) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and CNLA according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: NEI-FCCP-1-0707C046 Page 5 of 41 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Radiated Spurious Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Report No.: NEI-FCCP-1-0707C046 Page 6 of 41 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report is C01/OS02 at the location of No.132-1, Lane 329, Sec. 2, Palain Road, Shijr City, Taipei, Taiwan. Neutron's test firm number is 95335 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE C01 ANSI150 KHz ~ 30MHz 1.94 B. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE OS-01 ANSI30MHz ~ 200MHz V 3.82 30MHz ~ 200MHz H 3.60 200MHz ~ 1,000MHz V 3.86 200MHz ~ 1,000MHz H 3.94 OS-02 ANSI30MHz ~ 200MHz V 2.48 30MHz ~ 200MHz H 2.16 200MHz ~ 1,000MHz V 2.50 200MHz ~ 1,000MHz H 2.66 Report No.: NEI-FCCP-1-0707C046 Page 7 of 41 Neutron Engineering Inc. 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Mouse Trade Name ARESON Model No. L180 OEM Brand/Model No. N/A Model Difference N/A Product Description The EUT is a Wireless Mouse. Product Type Low Power Communication Device Operation Frequency: 2402~2479 MHz Modulation Type: FSK Number Of Channel 16 CH Antenna Designation: Integra Antenna Gain(Peak) -4.03 dBi Output Power: 83.39 dBuv/m (AV Max.) Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Power Source Battery supplied supplied(Mouse)/ PC System (Dongle) Power Rating DC 3V(MOUSE)/DC 3.3V(Dongle) Connecting I/O Port(s) Please refer to the User's Manual Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. Report No.: NEI-FCCP-1-0707C046 Page 8 of 41 Neutron Engineering Inc. 2. Freqeuncy Band Channel No. Frequency 1 2402 MHz 2 2405 MHz 3 2408 MHz 4 2411 MHz 5 2425 MHz 6 2433 MHz 7 2435 MHz 8 2439 MH…
