P5A-CL0007Wireless Mouse

User's Guide Mini Wireless Laser Mouse L-180 FCC statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example-use only shielded interface cables when connecting to computer or peripheral devices). FCC Radiation Exposure Statement . Channel The Wireless Channel sets the radio frequency used for communication. Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channel are available. If using multiple Access Points, it is better if adjacent Access Points use different Channels to reduce interference. In "infrastructure" mode, Wireless Stations normally scan all Channels, looking for an Access point. If more than one Access Point can be used, the one with the strongest signal is used. (This can only happen within an ESS.) IF using "Ad-hoc" mode (no Access Point), all Wireless stations should be set to use the same 5 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. and (2) This device must accept any interference received, including interference that may cause undesired operation. 1. Insert the batteries a. Take out the receiver on the bottom case first, press the battery cover release button on the bottom of the mouse which is under the receiver. b. Remove the battery compartment cover on the top case of the mouse. c. Fit in the batteries accordingly to the diagram indicated in the battery cabinet. d. Close the battery compartments cover properly. e. Make sure the Power on-off swich on the bottom of the mouse is ON. f. The Low Power LED in the wheel bar will blink 3 seconds if the mouse power is on. Wheel button Dpi button Battery cover ID reset button LED indicator Receiver Mouse Receiver Introduction Congratulations on your purchase of the most innovative wireless mini mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, the mouse can track reliably even on tricky polished or wood-grain surfaces. It offers even more advance that will make you more productive and more comfortable. A. Hardware Installation 2.4GHz (distance 6~8m), 16 Channels/4096 ID Using state-of-art laser technology. High tracking speed and sensitivity. 4-way scrolling. Storable mini receiver One year battery life. (*Optional for specific laser long-life models) Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch Data report rate : 125 Report/Sec. 800/1600 dpi switchable button. 2*AA Alkaline batteries included. Power on/off switch This product complies with IEC 60825-1, Class I laser product. Your product complies with FCC and CE rules. Safety Notice Please DO NOT direct the laser beam at anyone's eyes. Features + - A wrong battery placement may cause batteries overheat. Battery compartment cover 2 * AA batteries Battery cover release button Low power Led/ Power on indicator/ Dpi switching indicator 2. Connect the receiver a. Turn on your PC. b. Connect the receiver to USB port on PC PC USB port The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any button of the mouse" is compulsory to wake it up. Power on/off: There is a Power on/off switch designed to save the batteries power while non-usage of a longer period. Users can push DPI button to change the resolution. The low power LED will be flashed when dpi has been successfully swithced. 12 Press ID reset button Execute ID connection software Led indicator blinks faster 1 23 4 ID links OK! 4. Replace the new batteries Please replace a pair of new batteries and follow the previous instructions. (2, 3) The red LED on the scroll wheel is the low batteries power indicator. It indicates that batteries inside the mouse are needed to be replaced. Note While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source out and transfer to another free channel. During the transferring, the cursor movement may have a second delay. Note Trouble Shooting a. Make sure you have connected the receiver correctly to the computer's USB port. b. For the best performance, we suggest you to locate the receiver with a distance from other electrical devices, such as the computer, the computer monitor or external storage drives. c. Make sure you have set the communication between the receiver and the mouse. Refer to the Communication :The mouse and the receiver d. If you find the communication channel does not connect well. You can use the software connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able to get the software from the included diskette of the package or download from your local brand vendor's website. e. Some system devices might …

Text truncated - open the document above for the full version.

Project No.: 0802C019 Page 2 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 3 of 14 Neutron Engineering Inc. 0802C019 0802C0191 Project No.: 0802C019 Page 11 of 14 Neutron Engineering Inc. 0802C019 0802C019 121 Project No.: 0802C019 Page 12 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 2 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 3 of 14 Neutron Engineering Inc. 0802C019 0802C0191 Project No.: 0802C019 Page 11 of 14 Neutron Engineering Inc. 0802C019 0802C019 121 Project No.: 0802C019 Page 12 of 14 Neutron Engineering Inc. 0802C019 0802C019

L180 L180-Laser Wireless Mouse L180-Laser FCC ID:P5A-CL0007 Rating:3V 100mA

Project No.: 0802C019 Page 4 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 5 of 14 Neutron Engineering Inc. 0802C019 0802C019 21 Project No.: 0802C019 Page 6 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 7 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 8 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 9 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 10 of 14 Neutron Engineering Inc. 0802C019 121 Project No.: 0802C019 Page 13 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 14 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 4 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 5 of 14 Neutron Engineering Inc. 0802C019 0802C019 21 Project No.: 0802C019 Page 6 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 7 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 8 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 9 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 13 of 14 Neutron Engineering Inc. 0802C019 0802C019 Project No.: 0802C019 Page 14 of 14 Neutron Engineering Inc. 0802C019 0802C019

Report No.: NEI-FCCP-1-0802C019 Page 2 of 47 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutronshall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-1-0802C019 Page 3 of 47 Neutron Engineering Inc. Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 12 4 . EMC EMISSION TEST 13 4.1 CONDUCTED EMISSION MEASUREMENT 13 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 4.1.2 MEASUREMENT INSTRUMENTS LIST 13 4.1.3 TEST PROCEDURE 14 4.1.4 DEVIATION FROM TEST STANDARD 14 4.1.5 TEST SETUP 14 4.1.6 EUT OPERATING CONDITIONS 15 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 MEASUREMENT INSTRUMENTS LIST 18 4.2.3 TEST PROCEDURE 19 4.2.4 DEVIATION FROM TEST STANDARD 19 4.2.5 TEST SETUP 20 4.2.6 EUT OPERATING CONDITIONS 20 4.2.7 TEST RESULTS (BETWEEN 30 – 1000 MHz) 21 4.2.8 TEST RESULTS (ABOVE 1000 MHz) 23 4.2.9 TEST RESULTS (2400 – 2483.5 MHz) 35 4.2.10 TEST RESULTS (Restricted Bands Requirements) 36 5 . BANDWIDTH TEST 40 5.1 MEASUREMENT INSTRUMENTS LIST 40 5.2 TEST PROCEDURE 40 5.3 DEVIATION FROM STANDARD 40 5.4 TEST SETUP 40 5.5 EUT OPERATION CONDITIONS 40 5.6 TEST RESULTS 41 Report No.: NEI-FCCP-1-0802C019 Page 4 of 47 Neutron Engineering Inc. Table of Contents Page 6 . ANTENNA CONDUCTED SPURIOUS EMISSION 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 MEASUREMENT INSTRUMENTS LIST 43 6.1.2 TEST PROCEDURE 43 6.1.3 DEVIATION FROM STANDARD 43 6.1.4 TEST SETUP 43 6.1.5 EUT OPERATION CONDITIONS 44 6.1.6 TEST RESULTS 45 7 . EUT TEST PHOTO 47 Radiated Measurement Photos 47 Report No.: NEI-FCCP-1-0802C019 Page 5 of 47 Neutron Engineering Inc. 1. CERTIFICATION Equipment : Wireless Mouse Trade Name : N/A Model Name. : L180 A p p l i c a n t : Areson Technology Corporation Date of Test : Feb. 19, 2008 ~ Feb. 26, 2008 T e s t I t e m : ENGINEERING SAMPLE Standards : FCC Part15, Subpart C(15.249)/ ANCI C63.4 : 2003 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-0802C019) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). Test result included in this report is only for the Mouse part of the product. Report No.: NEI-FCCP-1-0802C019 Page 6 of 47 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.249) Standard Section Test Item Judgment Remark 15.207 Conducted Emission - N/A 15.249 Radiated Spurious Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Report No.: NEI-FCCP-1-0802C019 Page 7 of 47 Neutron Engineering Inc. 2.1 TEST FACILITY The test facilities used to collect the test data in this report is C01/OS02 at the location of No.132-1, Lane 329, Sec. 2, Palain Road, Shijr City, Taipei, Taiwan. Neutron's test firm number is 95335 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE C01 ANSI150 KHz ~ 30MHz 1.94 B. Radiated Measurement : Test Site Method Measurement Frequency Range Ant. H / V U，(dB) NOTE OS-01 ANSI30MHz ~ 200MHz V 3.82 30MHz ~ 200MHz H 3.60 200MHz ~ 1,000MHz V 3.86 200MHz ~ 1,000MHz H 3.94 OS-02 ANSI30MHz ~ 200MHz V 2.48 30MHz ~ 200MHz H 2.16 200MHz ~ 1,000MHz V 2.50 200MHz ~ 1,000MHz H 2.66 Report No.: NEI-FCCP-1-0802C019 Page 8 of 47 Neutron Engineering Inc. 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Mouse Trade Name N/A Model Name. L180 OEM Brand/Model Name N/A Model Difference N/A Product Description The EUT is a Wireless Mouse. Product Type Low Power Communication Device Operation Frequency: 2402~2479 MHz Modulation Type: GFSK Number Of Channel 16CH Antenna Designation: Printed antenna Antenna Gain(Peak) 6.61 dBi (Mouse) Output Power: 91.19 dBuV/m (AV Max.) Based on the application, features, or specification exhibited in User's Manual, the EUT…

Text truncated - open the document above for the full version.

Report No.: NEI-FCCP-1-0802C019 Page 47 of 47 Neutron Engineering Inc. 7. EUT TEST PHOTO Radiated Measurement Photos TX Mode Report No.: NEI-FCCP-1-0802C019 Page 47 of 47 Neutron Engineering Inc. 7. EUT TEST PHOTO Radiated Measurement Photos TX Mode
