Laser Multi-touch Mouse User's Guide Right button Left button Middle button Mode button ID reset button Mouse Introduction Congratulations on your purchase of the most innovative mini wireless mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, the mouse can track reliably even on tricky polished or wood-grain surfaces. It offers even more advance that will make you more productive and more comfortable. A. Hardware Installation 2.4GHz (distance 6~8m), 67 Channels/ 2 24 ID Multi Touch Function Using state-of-art technology. High tracking speed and sensitivity. Nano receiver. 4-way scrolling. Longer battery life. Auto-Link, Plug and Play! No need to set the channel ID. Power on/off switch. 800/1600 dpi switchable button. 2*AAA Alkaline batteries included. Power on/off switch This product complies with IEC 60825-1, Class I laser product. The product complies with FCC and CE rules. Safety Notice Please DO NOT direct the laser beam at anyone's eyes. Features + - A wrong battery placement may cause batteries overheat. Battery compartment cover 2 * AAA batteries Battery cover 2. Connect the receiver a. Turn on your PC. b. Connect the receivere to USB port on PC. PC USB port The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any button of the mouse" is compulsory to wake it up. Power on/off: There is a Power on/off switch designed to save the batteries power while non-usage of a longer period. User can push DPI button to change the resolution. The Low Power LED will be flashed when dpi has been successfully switched. Receiver 1. Insert the batteries a. Remove the battery compartment cover from the bottom case of the mouse. b. Fit in the batteries accordingly to the diagram indicated in the battery cabinet. c. Close the battery compartment cover properly. d. Make sure the Power on-off switch on the bottom of the mouse is ON. e. The Low Power LED will be on for 6 seconds if the mouse power is on. Pull out the receiver Receiver Dpi button Low power indicator / dpi switch display Touch area Scroll up & downTilt left & right Scroll up & down 4. Replace the new batteries Please replace a pair of new batteries and follow the previous instructions. (2, 3) The red LED is the low batteries power indicator. It indicates that batteries inside the mouse are needed to be replaced. Note Press ID reset button 123 ID links OK! 5. Multi Touch Function a. Mode Switch : If encountering any interference while the mouse is working, the mouse and the receiver will automatically seek and transfer to another free channel. During the transfer, you may experience a brief delay in the cursor movement. Note 3. Communication : The mouse & the receiver The 2.4Ghz RF mouse features a dual-way transmission technology which enables the mouse and the receiver auto-communication. A. Auto-link mode 1. Make sure the Power On-Off Switch on the bottom of the mouse is ON. 2. Operate the mouse, and cursor's movement is mapping mouse movement. Now the mouse and the receiver is auto-linked successfully. B. Manual mode • If the communication channel does not connect well, take the receiver out of the USB port and plug it in again. • Then press the ID reset button at the bottom of the mouse to confirm ID links (see illustration below). Mode switch button Mode light indicator Mode 1 > LED off Mode 2 > Red light on Mode 3 > Green light on b. Touch Function: Mode 1 ( LED OFF ) /////////////////////////////////////////////////////// Tilt left & rightPage up & downForward & backward Mode 2 ( Red LED ON for 6 sec ) /////////////////////////////////////////// Tilt left & right function will be active after driver installation. To function the 4-way scrolling in some applications in Window VISTA such as Word, Excel, PowerPoint and etc., the driver should be installed. Note Tilt left & right function will be active after driver installation. Speedy scrolling : moving finger fast on the touch area for continuously scrolling up / down / left / right. To stop scrolling, just tip the touch area. Normal scrolling : moving finger slowly for scrolling. To function the 4-way scrolling in some applications in Window VISTA such as Word, Excel, PowerPoint and etc., the driver should be installed. Note PC USB port Rotate left & rightZoom in & Zoom out Mode 3 ( Green LED ON for 6 sec ) //////////////////////////////////////// To zoom in and out on IE, Excel, Word, website To rotate photos under Windows Picture Viewer in clockwise / anti-clockwise Note B. Driver Installation The mouse features plug & play. It is not necessary to install the driver to operate the mouse. The driver is an optional item included. However if the model purchased is with 4-Way Scrolling function, you may require the mouse software driver to make the 4-Way scrolling function effective. 1. Un-install or removing the current mouse driver Before installing the driver of the mouse, we suggest that you check if any other mouse driver installed in your system. If yes, in order not to make conflict, please un-install or remove that driver before installing the mouse. 2. Install the mouse 4-Way Scrolling driver a.Select setup.exe to install the driver from the CD. b.or you can download the 4-Way Scrolling driver from vendor's website. ◎ Battery use reminders 1. Remove worn-out batteries from equipment immediately and dispose of promptly. 2. Keep all batteries (used or new) out of the reach of children. 3. To have the batteries with a regular check and replace new batteries if not used for a long time. 4. Never dispose of batteries in fire, as they could explode. 5. Always replace all the batteries at the same time. Mixing old and new batteries or mining types (such as alkaline with zinc carbon) will reduce overall performance and could cause leakage or rupture. 6. Do not mix different types of batteries (e.g. Ni MH, NiCd, alkaline, and etc) in the mouse. 7. Remove batteries from the electrical devi…
