P5J-FYMASMBD-01PCS portable transeiver

T-Mobile Device Owner’s Manual Release 1.0 February 12, 2002 Copyright© Danger, Inc. 2000-2002 All rights reserved. Confidential material of Danger, Inc., 124 University Avenue, Palo Alto, CA 94301 May not be duplicated or copied without the prior written consent of Danger, Inc. FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Contents February 12, 2002T-Mobile Device Owner’s Manual3 T-Mobile Device Owner’s Manual Contents FCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1.StartHere......................................................................... 9 Thank You for Purchasing a T-Mobile Device! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Your T-Mobile Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Powering Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Using the Wrist Strap to Carry Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 T-Mobile Device User Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Using the Holster to Protect Your Device Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Use Your Device Safely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 2.DeviceBasics .................................................................... 13 Parts of Your T-Mobile Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Device Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Control Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Headset/Camera Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Charging Outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 USB Mini-B Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Typing Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 3.AboutYourSmartCard ............................................................ 22 What Is a Smart Card? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Exactly What Information Is on My Device SIM? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Can I Remove My SIM? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 How Do I Handle My SIM? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 What Happens If I Lose My SIM? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 What Happens If I Put A Different SIM in My Device? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 4.SettingYourPreferences........................................................... 24 Application-Wide Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Application-Specific Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Controls Pane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 AutoText . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Date & Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Jump Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Keyboard & Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Quiet Mode and Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Sleep Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Contents February 12, 2002T-Mobile Device Owner’s Manual4 5.TheJumpScreen ................................................................. 34 How to Open the Jump Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 The T-Mobile Device Applications Preview Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 How to Select a T-Mobile Device Application . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

T-Mobile Device Reference Guide Release 1.0 May 9, 2002 Copyright© Danger, Inc. All rights reserved. 27-0002-09 Contents Welcome 4 I. Device Controls 6 Opening and Closing the Display 6 Control Buttons 7 II. Registration 8 III. Device Basics 12 Battery Charger 12 USB Cable 13 Title Bar 13 Device Settings 15 Customization 18 The Jump Screen 19 Menus 20 IV. The Desktop Web Interface 21 V. Using the Applications 23 Make a Phone Call 23 Answer a Phone Call 24 Add a Number to Your Speed Dial List 24 Change Your Phone Ringtone 25 Check Your Voice Mail 25 Import Contacts from Your SIM Card 26 2 Contents Send a Phone Message 26 Browse the Web 27 Bookmark a Web Site 27 Signing on to the AOL ® Instant Messenger™ Service 28 ® Instant Messenger™ Service 28 ® Send an Instant Message 28 Send an Email 29 Fetch Email from External Accounts 30 Fetch Email Using Your Device’s Web Browser 32 Send a Photo 32 Add a Contact to the Address Book 33 Import Address Book Contacts 34 Add an Event to Calendar 35 Create a Note 35 Add a To Do 36 Insert the Camera Accessory into Your Device 36 Take a Photo 37 Play Games 37 VI. Keyboard Shortcuts 37 VII. The Online Owner’s Manual 38 VIII.Troubleshooting 39 IX. Customer Care 44 X. Notices 45 Contents 3 Welcome! Thank you for buying a T-Mobile device. It will change the way you communicate, get organized, and stay connected. Your T-Mobile device connects seamlessly to wireless networks, which gives you the ability to browse the Internet, exchange instant messages, and send and receive email with image attachments. Other features include a full-featured phone, personal information management (PIM) applications, access to a personal Web portal, entertainment applications, and a camera accessory. Read detailed instructions on using the applications in the online T-Mobile Device Owner’s Manual at www.t-mobile.com.T-Mobile Device Owner’s Manual at www.t-mobile.com.T-Mobile Device Owner’s Manual 4 Welcome! Here’s what you’ll find in the box: T-Mobile device SIM card Battery charger Hands-free headset USB cable (Mini-B type) Wrist strap Carrying case Start Here card Reference Guide T-Mobile Welcome Guide If any of these items are missing, please contact T-Mobile Customer Care at 1 (800) 937-8997. Now, let’s get started! Welcome! 5 Warning Device Controls Opening and Closing the Display Normal operating position of the device is horizontal, with the wheel on the right side. To open the display, press your left thumb on the lower-left corner of the display and gently push in a clockwise direction. The display will spring smoothly into position: BACK To close the display, reverse the motion to pivot the display counter-clockwise and snap it into the closed position. Do not open or close the display in the wrong direction or you will risk damaging your device. Stop if you feel any resistance; the display should spring smoothly into position. 6 Device Controls I. Control Buttons MENU JUMP POWER DIRECTIONAL PAD WHEEL BACK MENU button Pressing opens a menu of actions you can take on the current screen. If you press the MENU button and no menu appears, this means there are no menu items available for the current screen. JUMP button Pressing takes you back to the Jump screen, your starting point for launching all the device applications. POWER Press the power button to turn the device on and off. DIRECTIONAL PAD (D-Pad) Press to scroll or move within text fields. The D-Pad “rocks” into eight different directions or positions. WHEEL Use the wheel to highlight then select buttons or links. Rotating the wheel toward you advances the current selection through the “selectable” elements on a screen and scrolls you down a Web page. Pressing the wheel selects the highlighted item or opens a pop-up menu. BACK button Pressing once takes you back to the screen you were previously viewing; pressing twice takes you back two screens, etc. In a dialog box, press to save your changes and dismiss the dialog box. If a menu is open, press to close it. Device Controls 7 Registration Before you can start using your device, you must complete the registration steps, as explained in step 3 on your Start Here card. This section of the Reference Guide takes you through the registration process in more detail. Note that these instructions are for new users (not returning users). Returning users are asked to sign in using their existing username and password. 1 Wait for account activation. Before you can use your account, T-Mobile must activate your account. This can take up to 48 hours, but usually takes only 1-3 hours. You’ll know your device has been activated when the Welcome screen appears on your device display: Press the wheel to select the New User button and advance to the next screen. For subsequent screens, you’ll press the Next button to advance. 2 Type your first and last names. Use the keyboard to type your First name, then rotate the wheel to highlight the Last name field. Type your last name, then scroll to highlight the Next button, then press the wheel to advance to the next screen. 8 Registration II. 3 Select a username. The username you select will be the first part of your email address (for example, [email protected]). Before your select a username, read the following guidelines: n Usernames must start with an alphabetic character (A-Z), but can include numbers and underscores ( _ ), but no other punctuation. n Usernames must be at least 2 but no more than 32 characters in length. n Usernames are not case-sensitive. Once you decide on a username, type it on the screen: 4 Select a password. Select a password that follows the rules below: n Passwords must contain at least six characters, can include both letters and numbers but no spaces. n Passwords are case-sensitive. For example, if you set your password to be “Hard2Guess”, then you will not be authenticated if you sign in by typing “hard2guess”. After you type your password, type it again to confirm. Registration 9 5 Select a “secret questi…

Text truncated - open the document above for the full version.


     "!$#%&')(
 *+-,./+0+' %' 120+3"4!$5 *6#7". ! 8
9
: 1 5%<; + ,=/99.  5%<; ://, ># + ,=/99.  ># ://, ?46@ (
1):9'A B C 'D9
38 , EF.AC '( %99 G 8 .).F9 !F G .12):0:)9A ; ' ,,.A *H4I'F
+ 1 :D "
 J$'F+(1  K.0. D
,

16 April 2002 Telecommunication Certification Body Radio Frequency Investigation Ltd. Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ England Subject: Request for Certification Approval Deferral FCC ID: P5J- FYMASMBD-01 I wo uld like to request that the approval of our FCC grant for the applicatio n with FCC ID P5J-FYMASMBD-01 be deferred until 30 June 2002. Yours sincerely, Markus Wallgren Sr. Director, Hardware Development Danger, Inc. 124 University Ave. Palo Alto, CA 94301

8 July 2002 Telecommunication Certification Body Radio Frequency Investigation Ltd. Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ England Subject: Certification Application FCC ID: P5J- FYMASMBD-01 It is requested that the following information is to be held co nfidential on behalf of Danger, Inc. FCC Rules Part 0.459 refers. Exhibit 810 circuit diagram pages, 1 bill of material file, 14 board layout pages Schematics, consisting of circuit diagram, bill of materials, and board layout: These are considered to be trade secrets of Danger, Inc. Danger, Inc. has invested considerable time and money in the development of these schematics. It is important that any competitor not receive unfair advantage in the market place by getting access to these documents. Exhibit 4Four pages Tune-up procedure. Yo urs si ncer ely , Markus Wallgren Sr. Director, Hardware Development Danger, Inc. 124 University Ave. Palo Alto, CA 94301

8 July 2002 Telecommunication Certification Body Radio Frequency Investigation Ltd. Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ England Subject: Certification Application FCC ID: P5J- FYMASMBD-01 It is requested that the following information is to be held co nfidential on behalf of Danger, Inc. FCC Rules Part 0.459 refers. Exhibit 810 circuit diagram pages, 1 bill of material file, 14 board layout pages Schematics, consisting of circuit diagram, bill of materials, and board layout: These are considered to be trade secrets of Danger, Inc. Danger, Inc. has invested considerable time and money in the development of these schematics. It is important that any competitor not receive unfair advantage in the market place by getting access to these documents. Exhibit 4Four pages Tune-up procedure. Yo urs si ncer ely , Markus Wallgren Sr. Director, Hardware Development Danger, Inc. 124 University Ave. Palo Alto, CA 94301

Danger Hiptop Operational Description 7 February 2002 The Danger Hiptop is a PDA-like device which comprises • a GSM-1900 cell phone • web browser based on GPRS (class 8, class B) • e-mail application • instant messenger application • SMS application • various personal information management (PIM) tools It has a built-in, non-removable lithium ion battery. The nominal voltage is 4.2V, and the battery supplies 1350mA. Hardware accessories include • battery charger • camera • hands-free kit • USB cable The Hiptop is initially configured in a powered-down shipping mode. In this mode, the battery charger must be connected in order to power up the device. Once the device begins booting, the battery charger can be removed. The run time depends heavily on the usage mode of the Hiptop. In the worst case, in which the Hiptop is in a call at full transmit power (30dBm), a run time of at least three hours can be expected. Note that the Hiptop will not run properly if the battery is fully discharged, even if the battery charger is connected. In order to be used, the Hiptop needs a SIM. This is inserted in the left side of the unit. The gray plastic piece which covers the slot needs to be removed, which exposes the SIM slot. If a SIM is inserted while the Hiptop is on, the unit should be rebooted. The unit can be rebooted by pressing and holding the “@”, “1”, and “0” keys. They should be depressed in that order, in rapid succession. It may take some practice to get this right! The unit can also be rebooted by inserting an object such as a straightened-out paper clip into the small hole labeled “RESET”. This hole is above the keyboard, and accessible only if the display is held in a 45-degree position. In order to place a call, the “Telephone” application should be selected in the main menu (the so- called “Chooser”). A telephone number can be entered using the keyboard, and the number can be dialed either by pressing the scroll wheel on the right, or the “enter” key. The call can be terminated by highlighting the “End call” button with the scroll wheel and then pressing the scroll wheel or the “enter” key. The unit will sleep after being idle for a certain number of minutes. In order to get the unit out of this mode, the display can be turned 180 degrees, or any key on the keyboard can be pressed. The unit can be put in the powered-down shipping mode by pressing and holding the “SYM” key on the left side of the keyboard for four seconds, and then releasing it.

MEANS FOR DETERMINING AND STABILIZING FREQUENCY, SUPPRESSION OF SPURIOUS RADIATION, LIMITING MODULATION, AND LIMITING POWER As required by § 2.1033(c)(10), this exhibit details the methods employed to determine and stabilize frequency, suppress spurious radiation and to limit both modulation and power Means for Determining and Stabilizing Frequency No absolute frequency stability requirements are levied against broadband PCS equipment operating under the authority of Part 24, Subpart J. However, per § 24.235, the frequency stability of the equipment shall be sufficient to ensure that the fundamental emission stays within the authorized frequency block. Specifically, this is accomplished as follows: The transmit RF carrier of the Core Engine is generated by a voltage controlled oscillator (VCO) which is phase locked to a 13 MHz master reference source. This 13 MHz source is synchronized to the GSM network and, within the Core Engine, is controlled by an 11 bit DAC to keep the carrier to within ±0.1 ppm of the network reference. Measurements of the stability of the fundamental emission of the Core Engine over variations in temperature and input voltage are presented in the test report. As a GSM-compliant terminal, the stability of the Core Engine carrier is to be within ±0.1 ppm (±200 Hz in 2000 MHz) of the nominal value, in accordance with GSM performance requirements (see J-STD- 007, Personal Communications Services, Air Interface Specification; Volume 1, Radio Path Physical Layer, Section 7.4.1). Means for Suppression of Spurious Radiation Suppression of spurious and harmonic radiation in the Core Engine is ensured through good engineering practices and proper transmitter design, lay-out, and construction. 1. Transmitter Architecture and Design Frequency plan of the transmitter— local oscillator frequencies were selected to minimize spurious products. Use of an upconversion loop architecture to minimize spurious and noise power level in the PCS1900 receive band (1930-1990 MHz). Lowpass filtering within and prior to the T/R switch to further reduce harmonics. 2. Physical Realization of the Core Engine Fully shielded GSM radio module construction with filtering on all signal (data, control, clock) and power supply leads. Localized shielding over the GSM radio and digital/baseband sections. Careful component placement and layout, multi-layer circuit board construction, microstrip signal routing, and construction techniques to eliminate cavity moding and resonances. Means for Limiting Modulation Per GSM specifications, the modulation scheme implemented by the Core Engine is Gaussian MSK (GMSK), with a bandwidth- time product of BT = 0.3. Modulation rate is 1625/6 kbps, or approximately 280.83 kbps. To minimize spreading of the spectrum, GSM standards require that the RF output spectrum meet the mask shown in Figure E6.1. In the Core Engine, modulation accuracy is maintained through the use of direct digital synthesis techniques. Figure E6.1. GSM terminal modulation mask. Means for Limiting Power As a GSM-compliant terminal, the Core Engine is capable of transmitting at any of the 16 defined nominal RF output power levels, ranging from 30.0 dBm to 0.0 dBm, during its assignedTDMA frame. Core Engine transmitter operation (output power level) is controlled by the GSM network, and specifically by the base station to which the Core Engine is attached. Maximum RF output power of the Core Engine is set at the factory and cannot be altered or increased. Furthermore, the temporal variation in power level within each transmission (i.e., transmission burst time mask) is in accordance with GSM requirements. This is accomplished by adjusting transmitter gain through a discrete time power control loop and ramping the transmitter on and off at the beginning and ending of each burst. The power control loop is implemented using an open loop technique proven to have little effect on output power versus temperature. Maximum RF power is adjusted to within the specified tolerance during each burst, at the output power level specified by the base station.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 CALIBRATION DATA – PART 1 FOR RFI TEST REPORT SERIAL NO: RFI/SARB4/RP15341A Test Of: Danger Inc. Hiptop Mobile Telephone Handset To: OET Bulletin 65 Supplement C: (2001-01) RADIO FREQUENCY INVESTIGATION LTD.Calibration Data S.No. RFI/SARB4/RP15341A Conformance Testing DepartmentIssue Date: 06 August 2002 Test Of:Danger Inc. Hiptop Mobile Telephone Handset To:OET Bulletin 65 Supplement C: (2001-01) Calibration Data This section contains the calibration data and certificates.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 CALIBRATION DATA – PART 2 FOR RFI TEST REPORT SERIAL NO: RFI/SARB4/RP15341A Test Of: Danger Inc. Hiptop Mobile Telephone Handset To: OET Bulletin 65 Supplement C: (2001-01) RADIO FREQUENCY INVESTIGATION LTD.Calibration Data S.No. RFI/SARB4/RP15341A Conformance Testing DepartmentIssue Date: 06 August 2002 Test Of:Danger Inc. Hiptop Mobile Telephone Handset To:OET Bulletin 65 Supplement C: (2001-01) Calibration Data This section contains the calibration data and certificates.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Danger Inc. Hiptop Mobile Telephone Handset To: OET Bulletin 65 Supplement C: (2001-01) Test Report Serial No: RFI/SARB4/RP15341A This Test Report supersedes RFI Test Report No.: RFI/SARB1/RP15341A, RFI/SARB2/RP15341A and RFI/SARB3/RP15341A This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 09 August 2002Test Dates: 31 July 2002 It should be noted that the standard, OET Bulletin 65 Supplement C: (2001-01) is not listed on RFIs current UKAS schedule and is therefore “not UKAS accredited”. This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No. RFI/SARB4/RP15341A EMC DepartmentPage 2 of 45 Issue Date: 09 August 2002 Test Of:Danger Inc. Hiptop Mobile Telephone Handset To:OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No. RFI/SARB4/RP15341A EMC DepartmentPage 3 of 45 Issue Date: 09 August 2002 Test Of:Danger Inc. Hiptop Mobile Telephone Handset To:OET Bulletin 65 Supplement C: (2001-01) Table of Contents 1. Client Information..........................................................................................................4 2. Equipment Under Test (EUT) ........................................................................................ 5 3. Test Specification, Methods And Procedures ............................................................. 8 4. Deviations From The Test Specification ...................................................................... 9 5. Operation Of The EUT During Testing ....................................................................... 10 6. Summary Of Test Results ........................................................................................... 11 7. SAR Measurement System......................................................................................... 14 8. SAR Safety Limits........................................................................................................ 15 9. Details of SAR Evaluation........................................................................................... 16 10. Evaluation Procedures.............................................................................................. 17 11. System Validation...................................................................................................... 18 12. Simulated Tissues ..................................................................................................... 19 13. Tissue Parameters..................................................................................................... 20 14. DASY3 Systems Specifications................................................................................ 21 15. Validation results – 1900 MHz................................................................................... 22 16. Measurement Uncertainty......................................................................................... 23 Appendix 1. Test Equipment Used.................................................................................. 25 Appendix 2. Measurement Methods................................................................................ 26 Appendix 3. SAR Distribution Scans .............................................................................. 28 Appendix 4. Test Configuration Photograph.................................................................. 29 Appendix 5. Photographs of EUT.................................................................................... 31 Note: This Test Report supersedes RFI Test Report No.: RFI/SARB1/RP15341A, RFI/SARB2/RP15341A and RFI/SARB3/RP15341A. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No. RFI/SARB4/RP15341A EMC DepartmentPage 4 of 45 Issue Date: 09 August 2002 Test Of:Danger Inc. Hiptop Mobile Telephone Handset To:OET Bulletin 65 Supplement C: (2001-01) 1. Client Information 1.1. Client Details Company Name: Danger Inc Address: 124 University Avenue Palo Alto Ca 94301 USA Contact Name: Mr M Walgren 1.2. Test Laboratory Company Name: Radio Frequency Investigation Ltd. Address: Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ. Contact Name: Mr G Taylor RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No. RFI/SARB4/RP15341A EMC DepartmentPage 5 of 45 Issue Date: 09 August 2002 Test Of:Danger Inc. Hiptop Mobile Telephone Handset To:OET Bulletin 65 Supplement C: (2001-01) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name Danger Model Name or Number Hiptop Unique Type Identification None Stated by Client IMEI Number 001022000028620 Battery Serial Number None Stated by Client FCC ID Number: P5J-FYMASMBD-01 Country Of Manufacture Thailand Date Of Receipt 06 February 2002 2.2. Modifications Incorporated In EUT The EUT has not been modified from what is described by the Model Name stated above. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No. RFI/SARB4/RP15341A EMC DepartmentPage 6 of 45 Issue Date: 09 August 2002 Test Of:Danger Inc. Hiptop Mobil…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Danger Inc. Hiptop GSM 1900 Mobile Phone To: FCC Part 24: 2001 (Sections: 24.232, 24.235, 24.238) and FCC Part 15: 2001 (Sections: 15.107 and 15.109) Test Report Serial No: RFI/MPTB3/RP15341A This Test Report supersedes RFI Test Report No’s.: RFI/MPTB1/RP15341A and RFI/MPTB2/RP15341A This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 10 April 2002Test Dates: 11 February 2002 to 15 February 2002 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This r…
