P5NSWU-R1-01Silwatch
Tokyo Shinyu Co., Ltd.
Click to zoom
Application Details
- Equipment Class
- CYY - Communications Receiver used w/Pt 15 Transmitter
- Date of Grant
- Mar 06, 2002
- Application Purpose
- Original Equipment
- Date of Application
- Mar 06, 2002
- Equipment Note
- Silwatch
- Frequency Range
- 425.60000000 - 426.05000000
- Company
- Tokyo Shinyu Co., Ltd.
- Country
- Japan
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Test Report
JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 400-10614 Issue Date : February 4, 2002 Page 1 of 18 EMI TEST REPORT JQA APPLICATION NO. : 400-10614 Model No. : SWU-R1-01 Type of Equipment : Silwatch Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : P5NSWU-R1-01 Applicant : Tokyo Shinyu Co., Ltd. Address : Shinjuku KM Building, 1-14-5 Shinjuku, Shinjuku-ku, Tokyo 160-0022, Japan Manufacture : Tokyo Shinyu Co., Ltd. Address : Shinjuku KM Building, 1-14-5 Shinjuku, Shinjuku-ku, Tokyo 160-0022, Japan Received date of EUT : December 7, 2001 Final Judgment : Passed Test results in this report are obtained in use of equipment that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and Communication Research Laboratory (CRL) of Japan. The test results only respond to the tested sample. This report should not be reproduced except in full, without the written approval of JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 2 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 6 1.4 EUT Modifications / Deviation from Standard 7 1.5 Test results / Uncertainty 8 1.6 Summary 9 1.7 Test Configuration / Operation of EUT 10 1.8 EUT Arrangement (Drawings) 11 1.9 Preliminary Test and Test-setup (Drawings) 12 – 14 1.10 EUT Arrangement (Photographs) 15 - 16 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N/A 2.2 Radiated Emission (Electric Field) 30 MHz – 1000 MHz 17 – 18 C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 3 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and B (June 23, 1989) All other receivers subject to part 15 Test procedure : AC power line conducted emission and radiated emission tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers( 3 meters Site ). - Shielded Enclosure. Expiration date of FCC test facility filing : June 04, 2002 2) EMC Engineering Dept. Testing Div. is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2002) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : Silwatch 2) Product Type : Production 3) Category : All other receivers subject to part 15 4) EUT Authorization : Certification 5) FCC ID : P5NSWU-R1-01 6) Trade Name : Silwatch 7) Model No. : SWU-R1-01 8) Tuning Frequency Range : 426.05 MHz 9) Highest Frequency Used in the EUT : 425.6 MHz 10) Serial No. : 00064 11) Date of Manufacture : None 12) Power Rating : DC 3.0V 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 4 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety & EMC Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan - Shielded Enclosure - Anechoic Chamber No. 2 (portable Type) Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 June 2001 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/030 May 2001 1 Year - Test Receiver ESHS10 Rohde & Schwarz 835871/004 Aug. 2001 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-6 Apr. 2001 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-855-2 Apr. 2001 1 Year - LISN KNW-407 Kyoritsu Electrical 8-757-1 Apr. 2001 1 Year - RF Cable 3D-2W Fujikura 155-21-006E0 Apr. 2001 1 Year - RF Cable 3D-2W Fujikura 155-21-007E0 Apr. 2001 1 Year - 50ohm Termination - SUHNER 154-06-501E0 Jan. 2002 1 Year - 50ohm Termination - SUHNER 154-06-502E0 Jan. 2002 1 Year C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 5 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(30 MHz – 1000 MHz) x - was performed in the following test site. - was not applicable. Test location : Safety & EMC Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan x - Anechoic Chamber No. 2 (3 meters) - Anechoic Chamber No. 3 (3 meters) Validation of Site Attenuation : 1) Last Confirmed Date :March, 2001 2) Interval :1 year Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Spectrum Analyzer 8560E Hewlett Packard 3240A00189 Nov. 2001 1 Year - Spectrum Analyzer 8566B Hewlett Packard 2140A01091 Apr. 2001 1 Year - RF Pre-selector 85685A Hewlett Packard 2648A00522 Apr. 2001 1 Year - Spectrum Analyzer 8566B Hewlett Packard 2747A05855 June 2001 1 Year - RF Pre-selector 85685A Hewlett Packard 2091A00933 June 2001 1 Year - Test Receiver ESV Rohde & Schwarz 872148/039 June 2000 1 Year x - Test Receiver ESVS10 Rohde & Schwarz 826148/002 May 2001 1 Year - Test Receiver ESVS10 Rohde…
Text truncated - open the document above for the full version.
Test Setup Photos
JAPAN QUALITY ASSURANCE ORGANIZATION 21-25, KINUTA 1-CHOME, SETAGAYA-KU, TOKYO 157-8573 JAPAN PHONE (03) 3416-0111, TELEX 242-2531 JQA J FAX (03) 3416-9691 JQA APPLICATION NO.: 400-10614 Issue Date : February 4, 2002 Page 1 of 18 EMI TEST REPORT JQA APPLICATION NO. : 400-10614 Model No. : SWU-R1-01 Type of Equipment : Silwatch Regulations Applied : CFR 47 FCC Rules and Regulations Part 15 FCC ID : P5NSWU-R1-01 Applicant : Tokyo Shinyu Co., Ltd. Address : Shinjuku KM Building, 1-14-5 Shinjuku, Shinjuku-ku, Tokyo 160-0022, Japan Manufacture : Tokyo Shinyu Co., Ltd. Address : Shinjuku KM Building, 1-14-5 Shinjuku, Shinjuku-ku, Tokyo 160-0022, Japan Received date of EUT : December 7, 2001 Final Judgment : Passed Test results in this report are obtained in use of equipment that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and Communication Research Laboratory (CRL) of Japan. The test results only respond to the tested sample. This report should not be reproduced except in full, without the written approval of JQA EMC Engineering Dept. Testing Div. C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 2 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1 Documentation 1.1 Test Regulation 3 1.2 General Information 3 1.3 Test Condition 4 – 6 1.4 EUT Modifications / Deviation from Standard 7 1.5 Test results / Uncertainty 8 1.6 Summary 9 1.7 Test Configuration / Operation of EUT 10 1.8 EUT Arrangement (Drawings) 11 1.9 Preliminary Test and Test-setup (Drawings) 12 – 14 1.10 EUT Arrangement (Photographs) 15 - 16 2 Test Data 2.1 AC Power Line Conducted Emission 0.45 MHz – 30 MHz N/A 2.2 Radiated Emission (Electric Field) 30 MHz – 1000 MHz 17 – 18 C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 3 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION 1 DOCUMENTATION 1.1 TEST REGULATION FCC Rules and Regulations Part 15 Subpart A and B (June 23, 1989) All other receivers subject to part 15 Test procedure : AC power line conducted emission and radiated emission tests were performed according to the procedures in ANSI C63.4-1992. 1.2 GENERAL INFORMATION 1.2.1 Test facility : 1) Test Facility located at EMC Engineering Dept. Testing Div. : - No.2 and 3 Anechoic Chambers( 3 meters Site ). - Shielded Enclosure. Expiration date of FCC test facility filing : June 04, 2002 2) EMC Engineering Dept. Testing Div. is recognized under the National Voluntary Laboratory accreditation Program for satisfactory compliance established in title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200189-0 (Effective through : June 30, 2002) 1.2.2 Description of the Equipment Under Test (EUT) : 1) Type of Equipment : Silwatch 2) Product Type : Production 3) Category : All other receivers subject to part 15 4) EUT Authorization : Certification 5) FCC ID : P5NSWU-R1-01 6) Trade Name : Silwatch 7) Model No. : SWU-R1-01 8) Tuning Frequency Range : 426.05 MHz 9) Highest Frequency Used in the EUT : 425.6 MHz 10) Serial No. : 00064 11) Date of Manufacture : None 12) Power Rating : DC 3.0V 13) EUT Grounding : None 1.2.3 Definitions for symbols used in this test report : x - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 4 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITION 1.3.1 The measurement of the AC Power Line Conducted Emission - was performed in the following test site. x - was not applicable. Test location : Safety & EMC Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan - Shielded Enclosure - Anechoic Chamber No. 2 (portable Type) Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Test Receiver ESH-2 Rohde & Schwarz 880370/016 June 2001 1 Year - Test Receiver ESH-3 Rohde & Schwarz 881460/030 May 2001 1 Year - Test Receiver ESHS10 Rohde & Schwarz 835871/004 Aug. 2001 1 Year - LISN(for Peripheral) KNW-407 Kyoritsu Electrical 8-833-6 Apr. 2001 1 Year - LISN(for EUT) KNW-407 Kyoritsu Electrical 8-855-2 Apr. 2001 1 Year - LISN KNW-407 Kyoritsu Electrical 8-757-1 Apr. 2001 1 Year - RF Cable 3D-2W Fujikura 155-21-006E0 Apr. 2001 1 Year - RF Cable 3D-2W Fujikura 155-21-007E0 Apr. 2001 1 Year - 50ohm Termination - SUHNER 154-06-501E0 Jan. 2002 1 Year - 50ohm Termination - SUHNER 154-06-502E0 Jan. 2002 1 Year C O P Y JQA Application No. :400-10614 FCC ID : P5NSWU-R1-01 Model No. :SWU-R1-01 Issue Date :February 4, 2002 Standard :CFR 47 FCC Rules Part 15 Page 5 of 18 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the Radiated Emission(30 MHz – 1000 MHz) x - was performed in the following test site. - was not applicable. Test location : Safety & EMC Center EMC Engineering Dept. Testing Div. 21-25, Kinuta 1-chome, Setagaya-ku, Tokyo 157-8573, Japan x - Anechoic Chamber No. 2 (3 meters) - Anechoic Chamber No. 3 (3 meters) Validation of Site Attenuation : 1) Last Confirmed Date :March, 2001 2) Interval :1 year Used test instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval - Spectrum Analyzer 8560E Hewlett Packard 3240A00189 Nov. 2001 1 Year - Spectrum Analyzer 8566B Hewlett Packard 2140A01091 Apr. 2001 1 Year - RF Pre-selector 85685A Hewlett Packard 2648A00522 Apr. 2001 1 Year - Spectrum Analyzer 8566B Hewlett Packard 2747A05855 June 2001 1 Year - RF Pre-selector 85685A Hewlett Packard 2091A00933 June 2001 1 Year - Test Receiver ESV Rohde & Schwarz 872148/039 June 2000 1 Year x - Test Receiver ESVS10 Rohde & Schwarz 826148/002 May 2001 1 Year - Test Receiver ESVS10 Rohde…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Ken Takanashi(General Manager)
Test Firm
Japan Quality Assurance Org.Katsumi Nishii
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 425.6 MHz - 426.05 MHz | - |
Other Applications from Tokyo Shinyu Co., Ltd.
P5NSWU-T1-01
Mar 06, 2002Silwatch Base Transmitter
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
