December 11, 2001 Encore Communication Laboratories Inc. Attn: Mr. Mike Khadivar 7129 N. Austin Niles, IL 60714 UL Reference:File MC3791, Project 01NK49002 Subject:EMC Test and Measurement Report for Model CT-P5000 Coby 900MHz Cordless Phone Dear Mr. Khadivar: We have provided with this letter your EMC Test Report for the above referenced model. The product was determined to comply with the requirements noted in the report. Please review the attached report and direct any questions or comments to me. Samples will be returned to your attention. We appreciate your interest in UL’s EMC Services, and encourage you to contact us in the future should you need EMC test services. This closes Project 01NK49002. Best regards,Reviewed by: Bart Mucha (Ext 41216)Jack Steiner Associate Project EngineerEngineering Group Leader International EMC ServicesInternational EMC Services UL International EMC Services 333 Pfingsten Road Northbrook, Illinois 60062-2096 (800) 873-8536 Fax No. (847) 272-8864 http://www.ul.com/emc/ FCC ID: P5UCHN-43019WT File: MC3791 Project: 01NK49002 Page 1 of 9 UL International EMC Services www.ul.com/emc (800) USE UL EMC EMC – TEST REPORT Issue Date: December 11, 2001
EMISSIONS IMMUNITY Test Report File No.: MC3791 Project No.: 01NK49002 Model / Type: CT-P5000 Kind of Product: Coby 900MHz Cordless Phone Applicant: Encore Communication Laboratories Inc. License Holder: Encore Communication Laboratories Inc. Address: 7129 N. Austin : Niles, IL 60714 Manufacturer: Coby Electronic Co. Ltd. : Unit C – E, 8 th Floor, Po Shau Center : 115 How Ming Street, Kwun Tong, H.K. Test Result : COMPLIANT This report without appendices consists of 9 pages. Appendix A contains test photos, Appendix B contains original test data, Appendix C contains sample calculations and Appendix D contains a block diagram of the measurement system. The data contained in this report reflects only the items tested in the configurations and mode of operations described. An attempt has been made to arrange the EUT, with the equipment provided, into a test configuration which maximizes the observed emissions of the EUT while simulating, as close as practical, a typical end-use installation. The photos and data provided in this report document that configuration. Underwriters Laboratories Inc. authorizes the above company to reproduce this report provided it is reproduced in its entirety. Underwriters Laboratories Inc.333 Pfingsten Rd. Northbrook, IL 60062 Fax: (847) 272-8864 FCC ID: P5UCHN-43019WT File: MC3791 Project: 01NK49002 Page 2 of 9 UL International EMC Services www.ul.com/emc (800) USE UL EMC REPORT DIRECTORY SECTION TITLE GENERAL 1.0 General Product Description 1.1 Model Differences 1.2 Environmental Conditions in Test Lab 1.3 Calibration Details of Equipment Used for Measurement 1.4 EUT (Equipment Under Test) Configuration 1.5EUT Operating Mode 1.6Device Modifications EMISSIONS 2.0Emissions Test Regulations Conducted Voltage Radiated Electric Field Emissions IMMUNITY 3.0Immunity Test Regulations CONCLUSION 4.0General Remarks 4.1Summary APPENDICIES ATest Setups (Photos, Diagrams and Drawings) BTest Data CSample Calculations DBlock Diagram of the Measurement System FCC ID: P5UCHN-43019WT File: MC3791 Project: 01NK49002 Page 3 of 9 UL International EMC Services www.ul.com/emc (800) USE UL EMC 1.0GENERAL PRODUCT DESCRIPTION The Equipment Under Test (EUT) was a analog 900MHz cordless phone 1.0.1 Equipment Mobility: The base unit is either table-top or wall-mount therefore it was tested in two axis (X and Y). The handset is a portable unit therefore it was tested in three axis (X, Y, and Z). See Appendix A for configuration photos. 1.0.2Test Voltage and Frequency: Voltage (V) Frequency (Hz) 12060 1.1MODEL DIFFERENCES Any other model(s) represented by the models tested in this investigation will be documented by the manufacturer. 1.2ENVIRONMENTAL CONDITIONS IN TEST LAB Temperature:20-25
C Relative Humidity:30-60% RH Atmospheric Pressure:860-1060 mbar 1.3CALIBRATION OF EQUIPMENT USED FOR MEASUREMENT All test equipment and test accessories are calibrated on a regular basis. The maximum time between calibrations is one year or what is recommended by the manufacturer, whichever is less. All test equipment calibrations are traceable to the National Institute of Standards and Technology (NIST), therefore, all test data recorded in this report is traceable to NIST. FCC ID: P5UCHN-43019WT File: MC3791 Project: 01NK49002 Page 4 of 9 UL International EMC Services www.ul.com/emc (800) USE UL EMC 1.4EUT CONFIGURATION(s) See Appendix A for individual set-up configuration(s). In addition to the EUT, the following peripheral devices and/or cables were connected during the measurement: DeviceManufacturerModelSerial #FCC ID EUTCOBYCT-P5000-- Power SupplyCOBYU120020D-- CableManufacturerLengthTypeShield Type Shield Termination 1.5 EUT OPERATING MODE(s) The equipment under test was operated during the measurements under the following conditions: The telephone receiver was tested in the following modes:
IDLE mode (On-Hook), Charging.
Operating mode (Off-Hook), Base and Handset individually. Since the transmitter operates over a frequency range greater than 1MHz but less than 10MHz, measurements must be performed on low and high channels per 15.31(m). 1.6DEVICE MODIFICATIONS The following modifications were necessary for compliance: None. FCC ID: P5UCHN-43019WT File: MC3791 Project: 01NK49002 Page 5 of 9 UL International EMC Services www.ul.com/emc (800) USE UL EMC 2.0EMISSIONS TEST REGULATIONS The EUT was considered to be a Class B device. Emissions testing was performed according to the following regulations: 47 CFR Part 15 Subpart C: 2000 + ANSI C63.4 – 1992 47 CFR Part 15.205(a) 47 CFR Part 15.207(a) 47 CFR Part 15.209(a)(d) 47 CFR Part 15.249(a)(b)(c)(d) FCC ID: P5UCHN-43019WT File: MC3791 Project: 01NK49002 Page 6 of 9 UL International EMC Services www.ul.com/emc (800) USE UL EMC CONDUCTED VOLTAGE EMISSIONS Test Location G…

Text truncated - open the document above for the full version.

FCC ID: BBBCHN-43019WT File: MC3791 Project: 01NK49002Page A2 of A2 UL International EMC Services www.ul.com/emc (800) USE UL EMC Conducted Emissions GP3 Radiated Emissions – Base X – Axis 10M Chamber Radiated Emissions – Base Y – Axis 10M Chamber FCC ID: BBBCHN-43019WT File: MC3791 Project: 01NK49002Page A3 of A3 UL International EMC Services www.ul.com/emc (800) USE UL EMC Radiated Emissions – Handset X – Axis 10M Chamber Radiated Emissions – Handset Y – Axis 10M Chamber Radiated Emissions – Handset Z – Axis 10M Chamber
