P9I-TAGAPSLYDAsset Protection System

WG Security Products, Inc
Asset Protection System - FCC ID P9I-TAGAPSLYD - WG Security Products, Inc
Click to zoom

Application Details

Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant
Mar 30, 2011
Application Purpose
Original Equipment
Date of Application
Mar 30, 2011
Equipment Note
Asset Protection System
Frequency Range
902.14000000 - 927.73000000
Company
WG Security Products, Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Sentinel Installation Manual September 2010 Manual Part Number: WG-(TBD) (Ver.) WG SECURITY PRODUCTS INC. 3031 Tisch Way, Suite 602, San Jose, CA 95128 (USA) http://www.wgspi.com Technical Support Contact Information North America South America Caribbean Tel: 888-633-5095 (Toll Free) 408-946-1113 Fax: 949-545-6011 Email: [email protected] Rest of World Tel: 4+49 8654 7715-21 Fax: 4+49 8654 7715-21 Email: [email protected] WARRANTY DISCLAIMER WG Security Products Inc. makes no representation or warranty with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. Further, WG Security Products Inc. reserves the right to revise this publication and make changes from time to time in the content hereof without obligation of WG Security Products Inc. to notify any person of such revision or changes. CRITICAL NOTE As specified by FCC Regulations 15.21, any changes or modifications not expressly approved by the party responsible for compliance of this equipment, will void the user’s permission and authority to operate this equipment. TABLE OF CONTENTS OVERVIEW ................................................................................................................................................... 1 SENTINEL OVERVIEW................................................................................................................................... 1 SPECIFICATIONS ........................................................................................................................................ 2 RAD & TAG DESCRIPTIONS ...................................................................................................................3 GENERAL RECOMMENDED RAD ARRANGEMENT ................................................................................ 4 GENERAL TIPS............................................................................................................................................ 4 TUNING & USER INSTRUCTION ................................................................................................................ 7 HANDHELD REMOTE BUTTONS..................................................................................................................... 7 FIELD AND EAS RAD TUNING...................................................................................................................... 7 TAG AND POS RAD OPERATION.................................................................................................................. 8 IMPORTANT NOTES...................................................................................................................................... 9 APPENDIX .................................................................................................................................................. 10 RAD’S DIP SWITCH CONFIGURATION......................................................................................................... 10 DUAL BACKUP POWERS CONNECTION DIAGRAM......................................................................................... 11 Sentinel Installation Manual 1 OVERVIEW Sentinel Overview Sentinel represents the most advanced Asset Protection System on the market today. Sentinel is the perfect fit for applications requiring protection of critical assets, be they items for retail, research, or other property. Additional applications include protection of individuals in assisted living establishments, infants in hospitals, incarcerated people, etc. A Sentinel system is comprised of Field RAD, EAS RAD, POS RAD, Sentinel tags and other optional accessories. The quantities of each will vary depending on the number of items to be protected, size of the area to be protected, the number exits and the number of controlling stations (e.g. registers). This description assumes a retail establishment with a rectangular sized area, one egress point and a single register. Sentinel tags are available in a variety of physical styles, all designed to protect specific type items such as apparel, fishing equipment, firearms, tools, electronics, people, etc. Field /EAS RAD POS RAD Lanyard Tag Handheld Remote Sentinel Installation Manual 2 SPECIFICATIONS RAD Detection Performance (Field and EAS) Europe USA RAD Field Distance 20 m 65 ft RAD Cone Angle 120º 120º Electromechanical Specifications Europe USA Field/EAS RAD Dimensions 155x155x60mm 6”x6”2.4” POS RAD Dimensions 200x120x47mm 7.9”x4.7”x1.9” Field RAD Weights 0.343 Kg 0.76 lb EAS RAD Weight 0.388 Kg 0.86 lb POS RAD Weight 0.678 Kg 1.5 lb Power Supply Adaptor 85-275vac 50/60Hz, <1W RAD Power Input 24vac 50/60Hz Keep in consistence with AC24v wiring order when powering all field RAD. Also suggest to use a dual backup 24vac Power supplies connection to power all the Field RAD. See appendix (Dual Backup Powers Connection Diagram) Product Codes Field RAD WG APS RAD EAS RAD WG APS RAD-EAS POS RAD WG APS RAD-POS Sentinel Lanyard Tag Tag APS Lyrd BS Sentinel Installation Manual 3 RAD & TAG DESCRIPTIONS Field RAD Field RADs are the readers installed in the room over the area to be protected. It radiates the area outward with a fixed 120º cone with strength adjustment range of up to 20 meters (65 feet). And it can be mounted on ceilings to cover an area below its conical beam or on walls to point to a direction and cover a conical space as well. Area Field is dependent on the height of the ceiling and signal strength. It periodically radiates the area with an RF coded signal and when the tags detect the signal they will keep their alarms silent. This type of RADs synchronise with 24vac power source for optimum operation. So all the field RADs must powered from one 24vac power source. EAS RAD RF protection signals are radiated in a conical fashion and therefore can easily extend past the exit. This means that someone removing an item from the protected zone could possibly be wel…

Text truncated - open the document above for the full version.

Cover Letter(s)

2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 WG Security Products, Inc February 23, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ WG Security Products, Inc____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description: Asset Protection System model name: Tag APS Lyrd BS FCC ID: P9I-TAGAPSLYD) We affirm that between SIEMIC and WG Security Products, Inc, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s name / title: Graham Handyside/Manger Company Name: WG Security Products, Inc Address: 3031 Tisch Way Suite 602, San Jose, CA 95128 USA TEL: 408-241-8000 FAX: 408-241-8082 Email: [email protected]

Cover Letter(s)

WG Security Products, Inc Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject:Request for Confidentiality FCC ID: P9I-TAGAPSLYD To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until May 22,2011 External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Name/Title: Graham Handyside/Manger Company Name: WG Security Products, Inc Address: 3031 Tisch Way Suite 602, San Jose, CA 95128 USA TEL: 408-241-8000 FAX: 408-241-8082 Email: [email protected]

External Photos

FCC ID: P9I-TAGAPSLYD Report No: KS101021B03 EXTERNAL PHOTOGRAPHS OF EUT FCC ID: P9I-TAGAPSLYD Report No: KS101021B03 FCC ID: P9I-TAGAPSLYD Report No: KS101021B03

ID Label/Location Info

Label LABEL LOCATION FCC ID: P9I-TAGAPSLYD

Internal Photos

FCC ID: P9I-TAGAPSLYD Report No: KS101021B03 6 INTERNAL PHOTOGRAPHS OF EUT FCC ID: P9I-TAGAPSLYD Report No: KS101021B03 6

Test Report

Compliance Certification Services Inc. Report No.: KS101021B03 FCC ID: P9I-TAGAPSLYD Date of Issue: November 10, 2010 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 30 Rev. 00 FCC 47 CFR PART 15 Subpart C TEST REPORT For Asset Protection System Model Number: Tag APS Lyrd BS Tra d e Na me: W G Issued to WG Security Products, Inc. 3031 Tisch Way, Suite 602, San Jose, CA 95128 USA Issued by Compliance Certification Services Inc. No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China http://www.ccsrf.com [email protected] Compliance Certification Services Inc. Report No.: KS101021B03 FCC ID: P9I-TAGAPSLYD Date of Issue: November 10, 2010 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION................................................................................................................ 3 2. EUT DESCRIPTION...................................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................................... 5 3.1 EUT CONFIGURATION................................................................................................................. 5 3.2 EUT EXERCISE............................................................................................................................. 5 3.3 GENERAL TEST PROCEDURES...................................................................................................... 5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.................................................. 6 3.5 DESCRIPTION OF TEST MODES.................................................................................................... 6 4. INSTRUMENT CALIBRATION................................................................................................................... 7 4.1 MEASURING INSTRUMENT CALIBRATION............................................................................... 7 4.2 MEASUREMENT EQUIPMENT USED .................................................................................. 7 4.3 MEASUREMENT UNCERTAINTY ........................................................................................ 8 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 9 5.1 FACILITIES 9 5.2 EQUIPMENT................................................................................................................................. 9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS.............................................................................. 10 6. SETUP OF EQUIPMENT UNDER TEST ...................................................................................................11 6.1 DESCRIPTION OF SUPPORT UNITS................................................................................... 11 6.2 CONFIGURATION OF SYSTEM UNDER TEST ................................................................. 11 7. FCC PART 15.249 REQUIREMENTS ........................................................................................................ 12 7.1 BAND EDGES MEASUREMENT ......................................................................................... 12 7.2 SPURIOUS EMISSION .......................................................................................................... 18 7.3 POWERLINE CONDUCTED EMISSIONS ........................................................................... 27 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................................29 Compliance Certification Services Inc. Report No.: KS101021B03 FCC ID: P9I-TAGAPSLYD Date of Issue: November 10, 2010 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: WG Security Products, Inc. 3031 Tisch Way, Suite 602, San Jose, CA 95128 USA Equipment Under Test: Asset Protection System Tr a d e N a m e : WG Model Number: Tag APS Lyrd BS Date of Test: September 26 ~ October 10, 2010 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements emission limits of FCC Rules Part 15.107, 15.109,15.207, 15.209 and 15.249. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Spring Zhou Jeff Fang RF Manager RF Section Manager Compliance Certification Service Inc. Compliance Certification Service Inc. Compliance Certification Services Inc. Report No.: KS101021B03 FCC ID: P9I-TAGAPSLYD Date of Issue: November 10, 2010 Page 4 Rev. 00 2. EUT DESCRIPTION Product Asset Protection System Trade Name WG Model Number Tag APS Lyrd BS Model Discrepancy N/A Power Supply DC/3V Frequency Range 902.14MHz ~ 927.73MHz(TX) Modulation Technique MSK EUT Type Engineering Sample. Product Sample, Mass Product Sample. Antenna Gain -6.02dBi Antenna Designation PCB Antenna Remark: 1. The sample selected for test was production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: P9I-TAGAPSLYD filing to comply with Section 15.107 & 15.109 (FCC Part 15, Subpart B) and Section 15.207, 15.209, 15.249. Compliance Certification Services Inc. Report No.: KS101021B03 FCC ID: P9I-TAGAPSLYD Date of I…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: P9I-TAGAPSLYD Report No.: KS101021B03 Conducted Emission Set Up Photo FCC ID: P9I-TAGAPSLYD Report No.: KS101021B03 Radiated Emission Set up Photos FCC ID: P9I-TAGAPSLYD Report No.: KS101021B03 Powerline Conducted Emissions Setup Photos

Contact Information

Applicant

Graham Handyside(Vice President)
[email protected]408-530-8070Fax: 408-530-8074

Test Firm

Compliance Certification Services (KunShan) Inc.Kurt Chen
[email protected]88633240332Fax: 88633246110

Technical Specifications

#Rule PartsFrequency RangePower Output
115C902.14 MHz - 927.73 MHz-
