P9IWGDC58-158kHz Tag and Label Checker

WG Security Products, Inc

Click to zoom

Application Details

Equipment Class: DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant: May 04, 2003
Application Purpose: Original Equipment
Date of Application: May 04, 2003
Equipment Note: 58kHz Tag and Label Checker
Frequency Range: 0.05800000 - 0.05800000
Company: WG Security Products, Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Page: 1 58kHz DOUBLE CHECKER MANUAL WG SECURITY PRODUCT INC. 161 San Lazaro Ave. Sunnyvale, CA 94086 USA Tel: 1-877-494-2288 (Toll Free) 1-408-530-8070 Fax: 1-408-530-8074 Website: www.wgspi.com E-mail:[email protected] Page: 2 TABLE OF CONTENTS SECTION ONE SYSTEM DESCRIPTION........................................................................................P1 SECIFICATIONS ..................................................................................................P2 PARTS LIST ........................................................................................................P4 SECTION TWO INPUT POWER NOTICES...........................................................................................P5 QUICK START INSTRUCTIONS .............................................................................P6 PROBLEMS ........................................................................................................P8 SECTION THREE IMPORTANT SAFEGUARDS AND REGULATORY NOTICES......................................P9 Page: 1 Overview SYSTEM DESCRIPTION Double checker is a compact size Electronic Article Surveillance detector that works with any 58kHz accousto-magnetic tags and labels. This device is plug and play, which eliminates the need for expensive technicians in installation. Double checker has the latest signal processing technology that constantly checks the environment and can operate at a higher level of sensitivity, resulting in an excellent detection height of 15cm above the device surface. Technical DataEuropeUnited States Length32mm13.4" Width24mm9.5" Thickness2.5mm1" Weight0.7Kg0.3lbs Power220-240vac110-120vac Operating Frequency58kHz58kHz Maximum Detection Height15 cm6 inches Page: 2 SPECIFICATIONS Deactivation Pad Alarm Indicator Page: 3 Mechanical Dimensions (L x W x H) Double checker box ................. 34 x 24 x 2.5 cm (13.4 x 9.5 x 1 in) Unit weight ............................. 0.70 kg ( 0.3 lbs) Power supplier......................... 65 x 51 x 8 cm (25.6x20x3.1 in) Unit weight .............................. 0.3 kg ( 0.14 lbs) Electrical AC Voltage for power supply..........100-120VAC 220-240VAC @ 50-60Hz Current Draw ............................. 0.027Arms Input Power ............................... < 6 watts AC Voltage for double checker....... 10VAC x 2 Current Draw ............................. 0.1Arms Input Power ............................... < 3 watts Environmental Operating Temperature ................. 0 to 50 °C (32 to 122 °F) Relative Humidity.......................... 0 to 90% (non-condensing) Regulatory Safety ........................................ CE **** EMC ...................................... FCC P9I WGDC58K Page: 4 PARTS LIST WGDC58K ............................... Double checker box 1 PC WGDCPS110 ............................ Double checker power supplier 110VAC (USA) WGDCPS220 ............................ Double checker power supplier 220VAC (Europe) WGDC58K Manual 1 PC INPUT POWER NOTICES Double checker requires two of 10VAC 0.1Arms power. Customer can use transformer provided within the package. 1 OF 2 PC Power Supply (1 of 2 types) CHECK THE TYPE WITH LOCAL POWER VOLTAGE l WGDCPS110 110VAC input for US l WGDCPS220 220VAC input for Europe Page: 5 PLEASE CHECK THE TYPE OF TRANSFORMER WITH LOCAL POWER VOLTAGE BEFORE APPLYING AC TO DOUBLE CHECKER AC Voltage for power supply..........100-120VAC @ 60Hz 220-240VAC @ 50Hz Current Draw ............................. 0.027Arms Input Power ............................... < 6 watts AC Voltage for double checker....... 10VAC x 2 Current Draw ............................. 0.1Arms Input Power ............................... < 3 watts No dedicated power line is needed and neither is special grounding necessary, but if there are multiple devices used, PLEASE PLUG THE DEVICE ONTO THE SOCKETS FROM SAME POWER LINE, otherwise please adjust phase switch to place multiple devices of double checker into the same working phase. QUICK START INSTRUCTIONS Same power line with same phase Page: 6 Before You Install Congratulations on your purchase of one of the finest EAS devices on the market. This is the Installation Instructions manual. Receiving Inspection Inspect all shipping containers for any signs of damage. If any is found, notify the shipping company. If there is no obvious damage, continue with the unpacking instructions. Unpacking Instructions Carefully remove the contents of container and place on a flat level surface. Compare the contents with the Part List to ensure that there no missing items. Make a note of any discrepancies. Equipment Inspection Inspect all equipment for damage. Items to specifically check, and damage to look for, are listed below: l Connectors for bent or broken pins l Cables for crimped or broken wires l Plastic housing for any obvious signs of damage If any damage is found, contact Customer Service at the telephone number in the front of this manual. If any item is damaged, DO NOT make any power or signal connections to the unit unless otherwise advised to do so by Customer Service. If there are any discrepancies between the Manual Set Inventory sheet and the manuals received, or between the Packing List and items received, contact Customer Service at the telephone number at the front of this manual. If there are no discrepancies and either no damage, or GVG-advised correction action is made, continue with this manual. OPEERATION INSTRUCTION Page: 7 How to deactivate labels l Label alive Place label with merchandise within detection range (vertical detection is preferred) of double checker to make sure it’s not yet deactivated. l Deactivate Secondly, place label onto the deactivation area, making sure that label fully lies on the surface of the area. Wait 1 second. l Double check Then lift label to proper detection range again (vertical detection is preferred) to make sure that the label is fully deactivated. Detection Range LE labels Vertical Detection ......... 10cm (4…

Text truncated - open the document above for the full version.

Cover Letter(s)

March 7, 2003 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: P9IWGDC58-1, and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics, Block Diagrams, Theory of Operation . These documents contain detailed system and equipment description and related information about the product that WG Security Products, Inc. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, WG Security Products, Inc. considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market.

Cover Letter(s)

From: Claire Hoque Sent: Monday, May 05, 2003 10:43 AM To: Mike Kuo Subject: RE: WG SECURITY PRODUCTS, INC., FCC ID:P9IWGDC58-1, AN03T2708 Hi Mike, Pls see the answers as belows: Question #1: Please provide additional internal photo to show the solder side of PCB. Answer: Pls see revised internal photos as attached. Question #2: Request for confidentiality letter mentioned Operational Description, Schematic Diagram, BOM and PCB layout diagram as confidential document. However, only schematic diagram and operational description are submitted. There is no BOM and PCB layout diagram. For your information, BOM and PCB layout diagram are not required for certification review. You may: 1) modify request for confidentiality letter by removing BOM and PCB layout diagram or 2) submit BOM and PCB layout diagram. Answer: Pls see revised letter as attached. Question #3: Test report was not signed. Please provide the approval signature on the test report. Answer: Pls see revised report as attached. Thanks, Claire Hoque

ID Label/Location Info

PROPOSED FCC ID LABEL AND LOCATION WG SECURITY PRODUCTS INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: P9IWGDC58-1 FCC ID LABEL LOCATION

Test Report

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT FOR 58KHZ TAG AND LABEL CHECKER MODEL NAME: WG DC58 FCC ID: P9IWGDC58-1 Prepared For WG SECURITY PRODUCTS, INC 3031 TISCH WAY, STE 602 SAN JOSE, CA 95128 USA Prepared By Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 USA Report No : 03U1827-1 Revision A Date : 3/3/03 Report No:03U1827-1 FCC ID: P9IWGDC58-1 Date: 3/3/03 EUT: 58KHZ TAG AND LABEL CHECKER, WG DC58 Page 2 of 2 Compliance Certification Services CCS Document No: EMC01.A 561F Monterey Road , Morgan Hill CA 95037 Tel: ( 408 )463-0885, Fax: ( 408 )463-0888 This report shall not be reproduced except in full without the written approval of CCS. TABLE OF CONTENTS SECTION 1: LABORATORY INFORMATION......................................................................4 1.1 GENERAL CONDITION:...........................................................................................................4 1.2 MEASUREMENT FACILITIES....................................................................................................4 1.3 LABORATORY ACCREDITATIONS AND LISTINGS....................................................................5 1.4 MEASUREMENT UNCERTAINTY..............................................................................................6 1.5 DEVIATION FROM MEASUREMENT SPECIFICATION.................................................................6 1.6 MEASUREMENT INSTRUMENT CALIBRATION.........................................................................6 SECTION 2: PRODUCT INFORMATION...............................................................................7 2.1 PRODUCT DESCRIPTION:........................................................................................................7 2.2 POWER REQUIREMENTS.........................................................................................................7 2.3 LOCAL OSC. OR CRYSTAL:....................................................................................................7 2.4 SERIAL NUMBER....................................................................................................................7 SECTION 3: TEST SUMMARY.................................................................................................8 3.1 APPLICABLE ELECTROMAGNETIC INTERFERENCE REQUIREMENTS:......................................8 3.2 SAMPLE RECEIVED DATE AND TEST PERIOD:.........................................................................8 3.3 MODIFICATIONS...............................................................................................................9 SECTION 4 ELECTROMAGNETIC INTERFERENCE TEST........................................10 4.1 RADIATED EMISSION TEST PROCEDURES............................................................................12 4.1.1 Instrument Setting...........................................................................................................12 4.1.2 Measurement Instrument Configuration........................................................................13 4.1.3 Measurement Equipment Used.......................................................................................14 4.1.4 Radiated Emission Test Setup Photos............................................................................15 4.1.5 Radiated Emission Test Result.......................................................................................18 4.2 CONDUCTED EMISSION TEST PROCEDURES.........................................................................19 4.2.1 Instrument Settings.........................................................................................................19 4.2.2 Measurement Instrument Configuration........................................................................19 4.2.3 Measurement Equipment Used.......................................................................................20 4.2.4 Conducted Emission Test Setup Photos.........................................................................21 4.2.5 Conducted Emission Test Result....................................................................................23 4.3.1 Instrument Settings.........................................................................................................26 4.3.2 Measurement Instrument Configuration........................................................................26 4.3.3 Measurement Equipment Used...........................................................................................27 4.3.4 Below 30MHz Emission Test Setup photos....................................................................27 4.3.5 Below 30MHz Emission Test Results.............................................................................29 Report No:03U1827-1 FCC ID: P9IWGDC58-1 Date: 3/3/03 EUT: 58KHZ TAG AND LABEL CHECKER, WG DC58 Page 3 of 3 Compliance Certification Services CCS Document No: EMC01.A 561F Monterey Road , Morgan Hill CA 95037 Tel: ( 408 )463-0885, Fax: ( 408 )463-0888 This report shall not be reproduced except in full without the written approval of CCS. Verification Of Compliance COMPANY NAME : WG SECURITY PRODUCTS, INC. 3031 TISCH WAY, STE 602 SAN JOSE, CA 95128, USA CONTACT PERSON : GRAHAM HANDYSIDE / VICE PRESIDENT TELPHONE NO : (408) 241-8070 MODEL NAME : WG DC58 DATE TESTED : 2/20/2003 – 2/26/2003 LIMIT APPLY TO : FCC PART 15 SECTION 15.209 TECHNICAL LIMITS TEST RESULT Radiated Emission No non-compliance noted LIMIT APPLY TO : FCC PART 15 SECTION 15.207 AC Line Conducted Emission No non-compliance noted The above equipment was tested by Compliance Engineering Services Inc. for compliance with the requirement set forth in the requirements of CFR 47 PART 15 SUBPART C. This said equipment in the configuration described in this report, shows the maximum emission levels emanating from equipment are within the compliance requirements. Tested By: Approved…

Text truncated - open the document above for the full version.
