PAOCB123Walkie Talkie

FCC ID: PAOCB123 TRANSCEIVER

FCC ID: PAOCB123

FCC ID: PAOCB123 FCC ID: PAOCB123

FCC ID: PAOCB123

FCC ID: PAOCB123 FCC ID: PAOCB123

FCC ID: PAOCB123 FRONT VIEW OF DEVICE

PAGE 1 OF 1 MODEL: CB123 CITIZEN BAND TRANSCEIVER FCC ID:PAOCB123 MADE IN CHINA DC 9V CHANNEL 14 This device complies with part 15 of FCC Rules. Operation is subject to the following two condition: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: PAOCB123 BOTTOM VIEW OF DEVICE WITH FCC ID LABEL

FCC ID: PAOCB123 FRONT VIEW OF THE PRINTED WIRING BOARD BOTTOM VIEW OF THE PRINTED WIRING BOARD

Date: 2000-10-05 TEST REPORT Page 1 of 9 No.: HM103167 Law Man KitKitty ChoyPatrick Wong Testing EngineerVerify byPatrick Wong for Managing Director APPLICANT: (CODE: CAT002) CALFORD TECHNOLOGY LIMITED. Unit 409, 4/F., Kinetic Industrial Centre, 7 Wang Kwong Road, Kowloon Bay, Hong Kong. DATE OF SAMPLE(S) RECEIVED: 2000-08-18 DATE OF TESTING: 2000-08-23 to 2000-09-23 DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:CITIZEN BAND TRANSCEIVER Manufacturer:CALFORD TECHNOLOGY LIMITED. Model Number:CB123 Brand Name:N/A Rating: 9V d.c. ("6F22" size battery × 1) Origin:CHINA INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart C - Intentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED after modification by customer with the clause 15.227 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A Date: 2000-10-05 TEST REPORT Page 2 of 9 No.: HM103167 T E S T S U M M A R Y *** INTENTIONAL RADIATOR *** (1) Measurement of Emission of RF energy on the carrier frequency..........Satisfactory (2) Measurement of the out-of band emissions including harmonics...........Satisfactory (3) Measurement of Emission Within Band Edges.......................................Satisfactory (4) Measurement of Line-Conducted Voltage onto AC Power Line............Not applicable T E S T D A T A Please refer to the attached result sheets. Date: 2000-10-05 TEST REPORT Page 3 of 9 No.: HM103167 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference TEST REFERENCE:FCC Rules Part 15 Subpart Section 15.227(26.96-27.28MHz) TEST CONDITION:Normal TEST DATE:2000-09-23 Emission of RF energy on the carrier frequency -- 27.125 MHz (PEAK VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB( μV)H-VdBdB(μV/m)μV/mμV/m 27.152.5V+18.571.03548.1100000.0 ================================================================== Emission of RF energy on the carrier frequency -- 27.125 MHz (AVERAGE VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB( μV)H-VdBdB(μV/m)μV/mμV/m 27.152.1V+18.570.63388.410000.0 ================================================================== ... to be continued Date: 2000-10-05 TEST REPORT Page 4 of 9 No.: HM103167 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference . . Continued .. TEST REFERENCE:FCC Rules Part 15 Subpart Section 15.227(26.96-27.28MHz) TEST CONDITION:Normal TEST DATE:2000-09-23 The out-of-band emissions, including harmonics (25-1000 MHz) (CISPR VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB( μV)H-VdBdB(μV/m)μV/mμV/m ###54.3<1.0+12.9<13.9<5.0100.0 81.4<1.0+8.9<9.9<3.1100.0 108.5<1.0+12.2<13.2<4.6150.0 135.626.6V+10.837.474.1150.0 162.827.3V+9.536.869.2150.0 189.9<1.0+11.1<12.1<4.0150.0 217.021.4V+12.233.647.9200.0 244.1<1.0+13.5<14.5<5.3200.0 271.320.1H+16.036.163.8200.0 298.4<1.0+16.5<17.5<7.5200.0 325.517.7V+16.634.351.9200.0 352.6<1.0+16.7<17.7<7.7200.0 379.8<1.0+17.4<18.4<8.3200.0 406.9<1.0+18.2<19.2<9.1200.0 434.0<1.0+19.5<20.5<10.6200.0 461.1<1.0+20.1<21.1<11.4200.0 488.3<1.0+20.3<21.3<11.6200.0 515.4<1.0+20.9<21.9<12.4200.0 542.5<1.0+22.1<23.1<14.3200.0 569.6<1.0+22.8<23.8<15.5200.0 596.8<1.0+23.3<24.3<16.4200.0 623.9<1.0+23.4<24.4<16.6200.0 ... to be continued Date: 2000-10-05 TEST REPORT Page 5 of 9 No.: HM103167 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference . . Continued .. TEST REFERENCE:FCC Rules Part 15 Subpart Section 15.227(26.96-27.28MHz) TEST CONDITION:Normal TEST DATE:2000-09-23 The out-of-band emissions, including harmonics (25-1000 MHz) (CISPR VALUE) ================================================================== EmissionMeterPolarizationAntennaField Strength FCC Limit FrequencyReadingFactor(at 3m) MHzdB(μV)H-VdBdB(μV/m)μV/mμV/m ###651.0<1.0+23.6<24.6<17.0200.0 678.1<1.0+24.9<25.9<19.7200.0 705.3<1.0+25.1<26.1<20.2200.0 732.4<1.0+25.4<26.4<20.9200.0 759.5<1.0+26.4<27.4<23.4200.0 786.6<1.0+26.8<27.8<24.5200.0 813.8<1.0+26.7<27.7<24.3200.0 840.9<1.0+26.1<27.1<22.6200.0 868.0<1.0+26.8<27.8<24.5200.0 895.1<1.0+27.1<28.1<25.4200.0 922.3<1.0+27.5<28.5<26.6200.0 949.4<1.0+28.1<29.1<28.5200.0 976.5<1.0+28.2<29.2<28.8500.0 ================================================================== ====================SUMMARY=================== All data is within limits ============================================= Broad-band Antennas were used both polarizations of emissions were measured. polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================================= Date: 2000-10-05 TEST REPORT Page 6 of 9 No.: HM103167 *** INTENTIONAL RADIATOR *** (2) Measurement of Emissions Within Band Edges. TEST REFERENCE: FCC Rules Part 15 section 15.227(26.96-27.28MHz) TEST CONDITION: Normal TEST DATE : 2000-09-23 RESULTS AND NOTES L: FCC Lower Band Edge ..........................................................................-> 26.960MHz H: FCC Higher Band Edge .........................................................................-> 27.280MHz C: Unmodulated carrier at frequency .........................................................-> 27.125MHz D: No. of dB from unmodulated carrier .....................................................-> 51.500dB SPECTRUM ANALYZER SETTINGS Resolution bandwidth: 8.0KHz Frequency span: 10.0KHz/div No. of dB/div: 10.0dB/div FCC Limit Minimum No. of dB from unmodulated carrier required : 26.0dB ================SUMMARY================ All data is within limits ========================================= …
