A-013-05-C Page 1 of 18 FCC ID: PAXPMV107G KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan KANSAI ELECTRONIC INDUSTRY DEVELOPMENT CENTER HEAD OFFICE IKOMA TESTING LABORATORY 6-8-7 NISHITENMA 12128 TAKAYAMA-CHO KITA-KU OSAKA 530-0047 JAPAN IKOMA-CITY NARA 630-0101 JAPAN Corporate Juridical Person TEST REPORT Report No.A-013-05-C Date: 15 September 2005 This test report is to certify that the tested device properly complies with the requirements of: FCC Rules and Regulations Part 15 Subpart C Intentional Radiators. All the tests necessary to show compliance to the requirements were performed and these results met the specifications of requirement. The results of this report should not be construed to imply compliance of equipment other than that, which was tested. Unless the laboratory permission, this report should not be copied in part. 1. Applicant Company Name : Pacific Industrial Co., Ltd. TPMS DEPT. Mailing Address : Godo-cho, Ampachi, GIFU, 503-2397 2. Identification of Tested Device Type of Device : Transmitter Kind of Equipment Authorization : : DoC : Certification : Verification FCC ID : PAXPMV107G Device Name : Tire Pressure Monitoring System Transmitter Trade Name : PACIFIC Model Number : PMV-107G Serial Number : No.1 : Production : Pre-production : Prototype Date of Manufacture : August 2005 3. Test Items and Procedure : AC Power Line Conducted Emission Measurement : Radiated Emission Measurement : Emission Bandwidth Measurement Above all tests were performed under: ANSI C63.4 – 2003 : without deviation, : with deviation (details are found inside of this report) 4. Date of Test Receipt of Test Sample : 12 September 2005 Condition of Test Sample : : Damage is not found on the set. : Damage is found on the set. (Details are described in this report) Test Completed on : 14 September 2005 Seiichi Izumi General Manager / Ikoma Testing Laboratory A-013-05-C Page 2 of 18 FCC ID: PAXPMV107G KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Table of Contents 0. LABORATORY ACCREDITATION AND MEASUREMENT UNCERTAINTY .........................3 0.1. Laboratory Accreditation................................................................................................................3 0.2. Measurement Uncertainty ..............................................................................................................3 1. CERTIFICATION OF THE COMPLIANCE ...................................................................................3 2. GENERAL INFORMATION ..............................................................................................................4 2.1. Product Description ........................................................................................................................4 2.2. Description for Equipment Authorization ......................................................................................5 2.3. Test Facility ....................................................................................................................................5 3. TESTED SYSTEM...............................................................................................................................6 3.1. Test Mode .......................................................................................................................................6 3.2. Characteristics of transmitting train ...............................................................................................6 3.3. Characterization and condition of EUT System .............................................................................8 4. RADIATED EMISSION MEASUREMENT .....................................................................................9 4.1. Test Procedure ................................................................................................................................9 4.2. Test Results ..................................................................................................................................10 5. EMISSION BANDWIDTH MEASUREMENT...............................................................................16 5.1. Test Configuration ........................................................................................................................16 5.2. Test Results ..................................................................................................................................16 6. USED TEST EQUIPMENTS AND CALIBRATION STATUS ......................................................18 A-013-05-C Page 3 of 18 FCC ID: PAXPMV107G KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 0. LABORATORY ACCREDITATION AND MEASUREMENT UNCERTAINTY 0.1. Laboratory Accreditation KEC is accredited by the National Voluntary Laboratory Accreditation Program (NVLAP) for the specific scope of accreditation under Lab Code: 200207-0. When the test report concerns with the NVLAP accreditation test, the first page of the test report is signed by NVLAP Approved Signatory accompanied by the NVLAP logo. The report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. 0.2. Measurement Uncertainty The result of a measurement is only an approximation or estimate of the value of a specific quantity. And thus the measured is complete only when a statement of uncertainty is given. KEC quotes Measurement Uncertainty (U) of +/- 4.9dB for Radiated Emissions of +/- 2.2dB for Conducted Emissions 1. CERTIFICATION OF THE COMPLIANCE This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart C Intentional Radiators. A-013-05-C Page 4 of 18 FCC ID: PAXPMV107G KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 2. GENERAL INFORMATION 2.1. Product Description The PACIFIC Model No.: PMV-107G (referred to as …

Text truncated - open the document above for the full version.

A-013-05-C Page 1 of 2 FCC ID: PAXPMV107G KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 1. APPENDIX Photographs of EUT System Configuration Tested Item ・Radiated Emission measurement Horizontally Place Vertically Place A-013-05-C Page 2 of 2 FCC ID: PAXPMV107G KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan - Continued - Tested Item ・Emission Bandwidth measurement
