PAXPMV108PLow Power Transmitter for monitoring tire pressure

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Compliance Statement in Car Manual / FCC ID: PAXPMV108P Dear Sirs, Our client’s products with the above FCC ID code are low frequency transmitters. The products will be installed in cars before they will be placed into the market. Hereby our client assures that the following caution statement as per CFR 47, Part 15, § 15.21 will be included in the owner’s manual of the cars: The title “CAUTION TO USERS” or “FCC Warning:” “NOTE:” or relevant title and “Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” In addition our client also assures that the following statement will be included in the manual as per CFR 47, Part 15, § 15.19 (a) (3). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Strasskirchen, 11.05.2007 Sincerely, Thomas Ring Manager Certification mikes-testingpartners gmbh Ohmstrasse 2-4 94342 Strasskirchen, Germany Phone: ++49 9424 9481 0 Fax: ++49 9424 9481 240

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re: Request of Confidentiality Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying as outlined below for the following FCC ID: PAXPMV108P 1. Schematics 2. Parts List 3. Operating Description 4. Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Strasskirchen, 11.05.2007 Sincerely, Thomas Ring Manager Certification mikes-testingpartners gmbh Ohmstrasse 2-4 94342 Strasskirchen, Germany Phone: ++49 9424 9481 0 Fax: ++49 9424 9481 240

Top view of Transmitter 2/4 Bottom view of Transmitter Front view of Transmitter 3/4 Rear view of Transmitter Right side view of Transmitter Left side view of Transmitter

7/ 8 5. Marking location and layout Fig 5. Marking location and dimension Notes: Compliance statement of marking will not be changed. But marking layout and size may be changed.

4/4 Internal photos Antenna

A-005-07-C Page 1 of 15 FCC ID: PAXPMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan KANSAI ELECTRONIC INDUSTRY DEVELOPMENT CENTER HEAD OFFICE IKOMA TESTING LABORATORY 6-8-7 NISHITENMA 12128 TAKAYAMA-CHO KITA-KU OSAKA 530-0047 JAPAN IKOMA-CITY NARA 630-0101 JAPAN Corporate Juridical Person TEST REPORT Report No. A-005-07-C Date: 26 April 2007 This test report is to certify that the tested device properly complies with the requirements of: FCC Rules and Regulations Part 15 Subpart C Intentional Radiators. All the tests necessary to show compliance to the requirements were performed and these results met the specifications of requirement. The results of this report should not be construed to imply compliance of equipment other than that, which was tested. Unless the laboratory permission, this report should not be copied in part. 1. Applicant Company Name : Pacific Industrial Co., Ltd. TPMS DIV. Mailing Address : Godo-cho, Ampachi, GIFU, 503-2397 Japan 2. Identification of Tested Device Type of Device : Transmitter Kind of Equipment Authorization : DoC Certification Verification FCC ID : PAXPMV108P Device Name : Tire Pressure Monitoring System Transmitter Trade Name : PACIFIC Model Number : PMV-108P Serial Number : 01 Production Pre-production Prototype Date of Manufacture : April 2007 3. Test Items and Procedure AC Power Line Conducted Emission Measurement Radiated Emission Measurement Emission Bandwidth Measurement Above all tests were performed under: ANSI C63.4-2003 without deviation, with deviation (details are found inside of this report) 4. Date of Test Receipt of Test Sample : 16 April 2007 Condition of Test Sample : Damage is not found on the set. Damage is found on the set. (Details are described in this report) Test Completed on : 23 April 2007 Seiichi Izumi General Manager / Ikoma Testing Laboratory A-005-07-C Page 2 of 15 FCC ID: PAXPMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Table of Contents 0. LABORATORY ACCREDITATION AND MEASUREMENT UNCERTAINTY ...................................... 3 0.1. Laboratory Accreditation ............................................................................................................................. 3 0.2. Measurement Uncertainty ........................................................................................................................... 3 1. CERTIFICATION OF THE COMPLIANCE ................................................................................................ 3 2. GENERAL INFORMATION ........................................................................................................................... 4 2.1. Product Description ..................................................................................................................................... 4 2.2. Description for Equipment Authorization ................................................................................................... 5 2.3. Test Facility ................................................................................................................................................. 5 3. TESTED SYSTEM ............................................................................................................................................ 6 3.1. Test Mode .................................................................................................................................................... 6 3.2. Characteristics of transmitting train ............................................................................................................ 6 4. RADIATED EMISSION MEASUREMENT .................................................................................................. 7 4.1. Test Procedure ............................................................................................................................................. 7 4.2. Test Results ................................................................................................................................................. 8 5. EMISSION BANDWIDTH MEASUREMENT ............................................................................................ 13 5.1. Test Configuration ..................................................................................................................................... 13 5.2. Test Results ............................................................................................................................................... 13 6. USED TEST EQUIPMENTS AND CALIBRATION STATUS ................................................................... 15 A-005-07-C Page 3 of 15 FCC ID: PAXPMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 0. LABORATORY ACCREDITATION AND MEASUREMENT UNCERTAINTY 0.1. Laboratory Accreditation KEC is accredited by the National Voluntary Laboratory Accreditation Program (NVLAP) for the specific scope of accreditation under Lab Code: 200207-0. When the test report concerns with the NVLAP accreditation test, the first page of the test report is signed by NVLAP Approved Signatory accompanied by the NVLAP logo. The report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. 0.2. Measurement Uncertainty The result of a measurement is only an approximation or estimate of the value of a specific quantity. And thus the measurand is complete only when a statement of uncertainty is given. KEC quotes Measurement Uncertainty (U) of +/- 4.9dB for Radiated Emissions and of +/- 2.2dB for Conducted Emissions. 1. CERTIFICATION OF THE COMPLIANCE This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart C Intentional Radiators. A-005-07-C Page 4 of 15 FCC ID: PAXPMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan …

Text truncated - open the document above for the full version.

A-016-06-C/A-049-07-B Page 1 of 3 FCC ID: PAXPMV108P/IC: 3729A-PMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan TESTED SYSTEM Characteristics of transmitting train The transmission of EUT is less than 1.0 second and the intervals are greater than 10 seconds. See plot figure 1. Figure 1. normal transmission . A-016-06-C/A-049-07-B Page 2 of 3 FCC ID: PAXPMV108P/IC: 3729A-PMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan - Continued - Figure 2. Alert status transmission Figure 3. Alert status transmission . . A-016-06-C/A-049-07-B Page 3 of 3 FCC ID: PAXPMV108P/IC: 3729A-PMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan - Continued - Figure 4. Transmission interval [Note] (1) In figure 3, the duration of each transmission is not greater than one second. (2) In figure 4, the silent period between transmissions shall be at least 30 times the duration of the transmission but in no case less than 10 seconds. .

A-005-07-C Page 1 of 2 FCC ID: PAXPMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 1. APPENDIX Photographs of EUT System Configuration Tested Item ・Radiated Emission measurement Horizontally Place Vertically Place A-005-07-C Page 2 of 2 FCC ID: PAXPMV108P KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan - Continued - Tested Item ・Emission Bandwidth measurement
