PBN-EG18000MAGICSING KARAOKE

Additional page User's Manual Information Do not Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, Including interference that may cause undesired operation Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio Frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.

September 27, 2007 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : ENTER TECH CO.,LTD. FCC ID : PBN-EG18000 Request for Confidentiality Gentlemen: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (File name: [PBN-EG18000] SCH.pdf), Parts list(File name: [PBN-EG18000] PL.pdf), Block diagram (File name: [PBN-EG18000] BLK.pdf), and Operational description (File name: [PBN-EG18000] OpDes.pdf). The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, __________________________ H.K.KIM / Assistant Manager Samhwa Bldg. 401-5, Hwagok-7dong, Kangseo-gu, Seoul, 157-887, Korea TEL: +82-2-2605-0884 /, Fax +82-2-2691-5354

Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 4 Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 4 Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 4 Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 4 of 4

Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 4 Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 4 Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 4 Model No.: EG-18000 FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 4 of 4

Ref. No.: LR500190709G Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 29 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: September 13 ~ 19, 2007 Test Report S/N: LR500190709G Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT FCC Classification : FHSS Sequence Spread Spectrum (FHSS) Manufacturing Description : Magicsing Karaoke(Main Station) Manufacturer : ENTER TECH CO.,LTD. Model name : EG-18000 Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2405 ~ 2480MHz RF power Class : 0.00075 W - Conducted Data of issue : September 22, 2007 This test report is issued under the authority of: The test was supervised by: Dong –Min JUNG, Technical Manager Kyung-Taek LEE, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. This report must not be used by the applicant to claim product endorsement by any agency. NVLAP LAB Code.: 200723-0 PBN-EG18000 ENTER TECH CO.,LTD. Ref. No.: LR500190709G Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST ------------------------------------------------------- 3.2.1 CARRIER FREQUENCY SEPARATION ---------------------------------------------------- 3.2.2 NUMBER OF HOPPING FREQUENCIES -------------------------------------------------- 3.2.3 20 dB BANDWIDTH ---------------------------------------------------------------------------- 3.2.4 TIME OF OCCUPANCY (Dwell Time) ------------------------------------------------------- 3.2.5 TTANSMITTER OUTPUT POWER ---------------------------------------------------------- 3.2.6 BAND – EDGE ----------------------------------------------------------------------------------- 3.2.7 FIELD STRENGTH OF HARMONICS ------------------------------------------------------ 3.2.8 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 8 9 11 13 15 20 23 28 Ref. No.: LR500190709G Copyright ○ c 2007, LTA Co., Ltd. Page 3 of 29 1. General information’s 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2007-09-30 ECT accredited Lab. RRL KOREA KR0049 2009-06-20 EMC accredited Lab. FCC U.S.A 610755 2008-03-28 FCC filing VCCI JAPAN R2133, C2307 2008-06-22 VCCI registration IC CANADA IC5799 2008-04-23 IC filing Ref. No.: LR500190709G Copyright ○ c 2007, LTA Co., Ltd. Page 4 of 29 2. Information’s about test item 2-1 Applicant Company name : ENTER TECH CO.,LTD. Address : Samhwa Bldg. 401-5, Hwagok-7dong, Kangseo-gu, Seoul, 157-887, Korea. Tel / Fax : +82-2-2605-0884 / +82-2-2691-5354 2-2 Manufacturer List Company name : ENTER TECH CO.,LTD. Address : Samhwa Bldg. 401-5, Hwagok-7dong, Kangseo-gu, Seoul, 157-887, Korea. 2-3 Equipment Under Test (EUT) Trade name : Magicsing Karaoke(Main Station) FCC ID : PBN-EG18000 Model name : EG-18000 Serial number : Identical prototype Date of receipt : August 27, 2006 EUT condition : Pre-production, not damaged Antenna type : Monopole antenna, Max Gain 2.118dBi Frequency Range : 2405 ~ 2480MHz RF output power Range : 0.00075 W - Conducted Number of channels : 16 Channel spacing : 5MHz Channel Access Protocol : Frequency Hopping Type of Modulation : GFSK Power Source : 8Vdc (by AC/DC Adaptor: M/N: DRS-080500) 2-4 Tested frequency LOW MID HIGH Frequency (MHz) 2405 2445 2480 Ref. No.: LR500190709G Copyright ○ c 2007, LTA Co., Ltd. Page 5 of 29 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.247(a) Carrier Frequency Separation > 25 kHz C 15.247(a) Number of Hopping Frequencies > 15 hops C 15.247(a) 20 dB Bandwidth - C 15.247 Dwell Time < 0.4 seconds C 15.247(b) Transmitter Output Power < 1Watt C 15.247(d) Conducted Spurious emission > 20 dBc C 15.247(d) Band Edge > 20 dBc Conducted C 15.249 / 15.209 Field Strength of Harmonics < 54 dBuV (at 3m) C 15.109 Field Strength - Radiated C 15.207 /15.107 AC Conducted Emissions EN 55022 Line Conducted C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: The data in this test report are traceable to the national or international standards. The sample was tested according to the following specification: FCC Parts 15.247; ANSI C-63.4-2003 Ref. No.: LR500190709G Copyright ○ c 2007, LTA Co., Ltd. Page 6 of 29 3.2 Transmitter requirements 3.2.1 Carrier Frequency Separation Procedure: The carrier frequency separation was measured with a spectrum analyzer connected to the antenna terminal, while EUT had its hopping function enabled. After the trace being stable, the reading value between the peaks of the adjacent channels using the marker-delta function was recorded as the measurement results. The spectrum analyzer is set to: Span = 15 MHz (wide enough to capture the peaks of two adjacent channels) RBW = 30 kHz (1% o…

Text truncated - open the document above for the full version.

FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 1 of 2 Radiated Emission FCC ID: PBN-EG18000 Copyright ○ c 2007, LTA Co., Ltd. Page 2 of 2 Conducted Emission
