PBPB-45C1-01Base radio model B-45C1-01

X-45C1-01-30 Rev 1 User Guide for Model M-45C1-01 Handheld Golf GPS Unit And Model B-45C1-01 Base/Repeater Unit M-45C1-01 B-45C1-01 X-45C1-01-30 Rev 1 1 I. Introduction This guide covers operation of XY Golf’s Handheld Golf GPS unit and Base/Repeater Unit. The operation of either unit is very similar. Specific functionality of the units is defined by software, which utilizes a standard soft-key menu system to access various parameters and functions. NOTE: "THIS EQUIPMENT COMPLIES WITH PART 90 OF THE FCC RULES. ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT." II. Usage The M-45C-01, Hand Held Unit (HHU) is designed to be used by a golfer. It relies on GPS and predefined data to provided assistance to the golfer in the form of distance data, shot advice, and other information. During usage the unit ordinarily resides in a cradle attached to a golf cart or golf bag. The golfer will typically pick up hold the unit and refer to it before making each shot and then place it back in the cradle. The B-45C-01, Base/Repeater Unit (BSU), is designed to operate as a fixed unit in either of two modes. In Base Mode, it serves as the communication controller for all HHUs and Repeaters within a specific area (typically a single golf course). It also provides Differential GPS (DGPS) correction data to HHUs to enhance their positional accuracy. In Repeater Mode, the B-45C-01 is used to extend the radio coverage of the BSU. This may be needed if the size of a particular installation is unusually large, or there are obstacles like hills or large buildings blocking radio coverage to specific areas. A typical Base/Repeater installation utilizes an outdoor fix-mounted antenna no higher than 30 feet above ground level. Appropriate FCC Licensing or Authorization is required prior to station operation. III. Operation This section describes the operation of the units. Since the many options are enabled or disabled via a separate database, the actual menu options available may be slightly different than those shown here. This document will show all options that are currently available. X-45C1-01-30 Rev 1 2 A. Main Menu When the unit is initially powered up or reset the main menu will appear as shown in Figure 1. The actual screen may appear differently than the one shown here, or may not appear at all, depending on options set in the unit initialization database. Figure 1. Main Menu 1) Play Course 2) Settings 3) System Menu 4) FCC Menu X-45C1-01-30 Rev 1 3 I. FCC Menu The FCC Menu contains all of the controls required for Part 15 and Part 90 FCC testing. This screen is only accessible in special in-house firmware builds and is not available to the end user. The FCC Menu is shown below. Figure 9. FCC Menu Five Modes are available here: Receive, CW, Continuous Data, Radio Off, and Normal Operation. Additionally, the operator may set the frequency of the radio to one of three points: The lower and upper band limits of the radio, and the center of the band. A mode may be activated by highlighting it using the Down/Up soft-keys, then pressing the Enter soft key. The mode may be deactivated by pressing the Enter soft key again. NOTE: A status line near the bottom of the display will show the current mode of operation. 1) Radio Receive Activating this function will place the Transceiver in Receive mode at the currently selected frequency. X-45C1-01-30 Rev 1 4 2) Radio CW Activating this mode will cause the transceiver to key-up. No data will be applied to modulate the signal. This function will time out after approximately 3 minutes to protect the transceiver. The unit will revert to Receive Mode after the time-out. CAUTION: The transceiver is designed to operate at a maximum 50% Transmit/Receive duty cycle. Overheating and equipment failure may occur if the Radio CW mode is repeatedly activated. 3) Transmit Data Activating the Transmit Data mode will cause the unit to continuously transmit an ASCII data pattern. This function will time out after approximately 3 minutes to protect the transceiver. The unit will revert to Receive Mode after the time-out. CAUTION: The transceiver is designed to operate at a maximum 50% Transmit/Receive duty cycle. Overheating and equipment failure may occur if the Transmit Data mode is repeatedly activated. 4) Radio Off This mode will shut off the power supplies to both the Transmitter and Receiver sections of the transceiver. 5) Normal Operation Normal Operation Mode will cause the unit to behave as it normally does during operation. This involves transmitting an approximately 90-byte message at regular intervals, then reverting back to receive. The message intervals are as follows: Model Application Typical Message Interval M-45C1-01 Handheld Golfer Unit twice per minute B-45C1-01 Base/Repeater Unit once per second X-45C1-01-30 Rev 1 5 6) Set Frequency This feature allows the user to set the transceiver frequency to any of three points. The unit will initially be set to the center of the radio band (Mid Freq.) upon power-up. The current frequency will be displayed on a status line near the bottom of the display whenever this item is selected. Pressing the Enter soft key causes the frequency to switch to the next frequency. The Set Frequency function may be used while the unit is in any of the above modes (Receive, Transmit, Normal, etc.). J. Radio Menu The Radio Menu contains all of the software-adjustable parameters related to the data radio and radio communication. This screen is only accessible in special in- house firmware builds and is not available to the end user. The Radio Menu is shown in Figure 10 below. Figure 10. Radio Menu 1) Adjust Pot This adjustment controls the DC bias that is applied to receive data signal (from the transceiver) before it enters the threshold detector. Typical adjustment procedures involve injecting a very low-level, modulated signal into the receiver and adjusting this cont…

Text truncated - open the document above for the full version.

FCC ID: PBPB45C101 Response to TCB questions Good Morning Barry, Sorry for the delay in answering your inquiries in an email to Alma Torres dated 2/22/01 as follows: We have conducted our review of the application and the following issues have been found: 1. Excuse us if our ignorance is showing, but please explain the claimed emissions designator of 20K0 and the channel spacing of 12.5 kHz. How is a 20 kHz wide signal compatible with 12.5 kHz channelization? From the table in 90.209 we would have expected an 11K2 request. I guess our ignorance is showing. Response - You are correct about the 11K2 designator. 2. Please comment on the unit's compliance with 90.203 (j) (3). Response - Necessary BW (BN) = (2* Max Deviation) + (2* Baud/2) = (2* 0.2) + 2* 4800/2) = 5.2 kHz Also, see response below that the unit will only transmit at 9600 baud. 3. Please confirm that the plot on page 11 of the test report shows modulated data. The bandwidth appears extremely small. Response - Yes , but the frequency deviation is only 0.2 kHz 4. For information only. The test report claims that the requirement for frequency stability is 5ppm. Our reading of this as a base station in the 421-512 band requires 1.5ppm (see table note 7). The unit has 0.4ppm and thus complies with either requirement. Response - Sorry, you are correct. This just happened to be in the report template and was overlooked during review. 5. For the transient frequency behavior plots presented in the test report we need more detail to understand the information presented. Please confirm that plot one is turn off and plot 2 is turn on. Please tell us the time per division and the voltage per division of each of the oscilloscope plots. Please tell us the relationship between voltage and frequency deviation on the plots (how many kHz per volt). Response - <<rf off.doc>> <<rf on.doc>> 6. We only have a plot for the 9600 baud modulation. Please supply a plot for the 4800 baud modulation. Response - The unit is designed to be operated solely at 9600 Baud. We originally put software control in to switch to 4800 in order to provide compatibility with our older equipment for engineering purposes. However, the analog conditioning circuitry does not operate at 4800. In practice our new system will operate only at 9600 Baud. 7. Do you have an expanded users as we need to check the manual to see if the method of programming the channels complies with the 90.203 (f) and (g). Response - Since our equipment is microprocessor based, all system parameters are software controlled. System parameters include Radio Frequency, Baud Rate, and Transmission Time (key up). These parameters are typically not subject to change. In use, these parameters are programmed in the unit's FLASH memory at our facility before installation at a customer site. We continue to have control of the system parameters via a remote network connection. Neither the end user (golfer) nor the system operator (golf course) has control of any system parameters. 8. Please supply the tune up procedure. Response - Please refer to Section 6 of "DM-3473 Tech manual.pdf" which you should have. 9. Please supply external photos. Response - Please refer to "Flagman II User Manual - 5 Jan 2001 - Abbreviated.pdf" page one for front view. Attached is a file that you should already have showing rear view. <<B-45C1-01 FCC Label.jpg>> Best regards, David Light Senior Wireless Technician Nemko Dallas, Inc. Voice 972-436-9600 Fax 972-436-2667 email mailto:[email protected] Web www.icomply.com

X-45C1-01-30 Rev 1 User Guide for Model M-45C1-01 Handheld Golf GPS Unit And Model B-45C1-01 Base/Repeater Unit M-45C1-01 B-45C1-01

DM-3473 Synthesized UHF Data Module Technical Manual Part Number: 242-3473-XXX DM-3473 Synthesized UHF Data Module 001-3473-202 Revision 1 February 2000 Copyright 2000 by Dataradio COR Ltd. Dataradio COR Ltd. designs and manufactures radios and radio modems to serve a wide variety of data communication needs. The Dataradio Corporation produces equipment for the fixed data market including SCADA systems for utilities, petrochemical, waste and fresh water management markets and RF boards for OEM applications in the Radio Frequency Data Capture market. PRODUCT WARRANTY The manufacturer's warranty statement for this product is available from Dataradio COR Ltd., 299 Johnson Avenue, Box 1733, Waseca, MN 56093-0833. Phone (507) 835-8819. The information in this document is subject to change without notice. is a trademark of Dataradio Inc. 1 TABLE OF CONTENTS 1GENERAL INFORMATION 1.1SCOPE OF MANUAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 1.2EQUIPMENT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 DM-3473 SYNTHESIZER PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.3TRANSCEIVER IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 1.4PART NUMBER BREAKDOWN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 1.5CUSTOMER SERVICE/TECHNICAL SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 1.6PRODUCT WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 1.7REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 1.8IF A PROBLEM ARISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 FACTORY REPAIR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 GENERAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 2INSTALLATION 2.1PRE-INSTALLATION CHECKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 2.2INTERFACING WITH DATA EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 CONNECTOR PIN ASSIGNMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 3PROGRAMMING 3.1INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 3.2DM-3473 SERIAL INTERFACE SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 3.3FRACTIONAL-N SYNTHESIZER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 SYNTHESIZER DATA PROTOCOL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 SYNTHESIZER DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 3.4SYNTHESIZER BIT DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 D-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 C-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 B-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 A0-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 3.5SYNTHESIZER LOAD PARAMETER EXAMPLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4 3.6RECOMMENDED SYNTHESIZER LOAD SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11 RECEIVE TO TRANSMIT SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11 TRANSMIT TO RECEIVE SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12 3.7A0 WORD ALGORITHM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13 4CIRCUIT DESCRIPTION 4.1GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1 INTRODUCTION. . . . . . .…

Text truncated - open the document above for the full version.

DM-3473 Synthesized UHF Data Module Technical Manual Part Number: 242-3473-XXX DM-3473 Synthesized UHF Data Module 001-3473-202 Revision 1 February 2000 Copyright 2000 by Dataradio COR Ltd. Dataradio COR Ltd. designs and manufactures radios and radio modems to serve a wide variety of data communication needs. The Dataradio Corporation produces equipment for the fixed data market including SCADA systems for utilities, petrochemical, waste and fresh water management markets and RF boards for OEM applications in the Radio Frequency Data Capture market. PRODUCT WARRANTY The manufacturer's warranty statement for this product is available from Dataradio COR Ltd., 299 Johnson Avenue, Box 1733, Waseca, MN 56093-0833. Phone (507) 835-8819. The information in this document is subject to change without notice. is a trademark of Dataradio Inc. 1 TABLE OF CONTENTS 1GENERAL INFORMATION 1.1SCOPE OF MANUAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 1.2EQUIPMENT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 DM-3473 SYNTHESIZER PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.3TRANSCEIVER IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 1.4PART NUMBER BREAKDOWN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 1.5CUSTOMER SERVICE/TECHNICAL SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 1.6PRODUCT WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 1.7REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 1.8IF A PROBLEM ARISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 FACTORY REPAIR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 GENERAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 2INSTALLATION 2.1PRE-INSTALLATION CHECKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 2.2INTERFACING WITH DATA EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 CONNECTOR PIN ASSIGNMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 3PROGRAMMING 3.1INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 3.2DM-3473 SERIAL INTERFACE SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 3.3FRACTIONAL-N SYNTHESIZER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 SYNTHESIZER DATA PROTOCOL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 SYNTHESIZER DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 3.4SYNTHESIZER BIT DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 D-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 C-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 B-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 A0-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 3.5SYNTHESIZER LOAD PARAMETER EXAMPLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4 3.6RECOMMENDED SYNTHESIZER LOAD SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11 RECEIVE TO TRANSMIT SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11 TRANSMIT TO RECEIVE SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12 3.7A0 WORD ALGORITHM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13 4CIRCUIT DESCRIPTION 4.1GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1 INTRODUCTION. . . . . . .…

Text truncated - open the document above for the full version.

DM-3473 Synthesized UHF Data Module Technical Manual Part Number: 242-3473-XXX DM-3473 Synthesized UHF Data Module 001-3473-202 Revision 1 February 2000 Copyright 2000 by Dataradio COR Ltd. Dataradio COR Ltd. designs and manufactures radios and radio modems to serve a wide variety of data communication needs. The Dataradio Corporation produces equipment for the fixed data market including SCADA systems for utilities, petrochemical, waste and fresh water management markets and RF boards for OEM applications in the Radio Frequency Data Capture market. PRODUCT WARRANTY The manufacturer's warranty statement for this product is available from Dataradio COR Ltd., 299 Johnson Avenue, Box 1733, Waseca, MN 56093-0833. Phone (507) 835-8819. The information in this document is subject to change without notice. is a trademark of Dataradio Inc. 1 TABLE OF CONTENTS 1GENERAL INFORMATION 1.1SCOPE OF MANUAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 1.2EQUIPMENT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 DM-3473 SYNTHESIZER PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.3TRANSCEIVER IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1 1.4PART NUMBER BREAKDOWN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 1.5CUSTOMER SERVICE/TECHNICAL SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 1.6PRODUCT WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 1.7REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 1.8IF A PROBLEM ARISES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 FACTORY REPAIR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3 GENERAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4 2INSTALLATION 2.1PRE-INSTALLATION CHECKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 2.2INTERFACING WITH DATA EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 CONNECTOR PIN ASSIGNMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 3PROGRAMMING 3.1INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 3.2DM-3473 SERIAL INTERFACE SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 3.3FRACTIONAL-N SYNTHESIZER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 SYNTHESIZER DATA PROTOCOL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 SYNTHESIZER DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 3.4SYNTHESIZER BIT DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 D-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 C-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 B-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 A0-WORD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4 3.5SYNTHESIZER LOAD PARAMETER EXAMPLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4 3.6RECOMMENDED SYNTHESIZER LOAD SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11 RECEIVE TO TRANSMIT SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11 TRANSMIT TO RECEIVE SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12 3.7A0 WORD ALGORITHM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13 4CIRCUIT DESCRIPTION 4.1GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1 INTRODUCTION. . . . . . .…

Text truncated - open the document above for the full version.

KTL Test Report:0L0437RUS2 Applicant:VXT, L.L.C. 3750 Industrial Court Suite H Suwanee, GA 30024 Equipment Under Test:B-45C1-01 Base Radio (E.U.T.) FCC ID:PBPB-45C1-01 In Accordance With:FCC Part 90, Subpart I Private Land Mobile Transmitter Tested By:KTL Dallas Inc. 802 N. Kealy Lewisville, TX 75057-3136 Authorized By: Tom Tidwell, EMC/Wireless Group Manager Date:1/27/01 Total Number of Pages:34 KTL Dallas FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: B-45C1-01 Base Radio PROJECT NO.: 0L0437RUS2 Page 2 of 34 Table of Contents Section 1. Summary of Test Results........................................................................................3 Section 2. General Equipment Specification.............................................................................5 Section 3. RF Power Output....................................................................................................7 Section 4. Modulation Characteristics......................................................................................8 Section 5. Occupied Bandwidth.............................................................................................10 Section 6. Spurious Emissions at Antenna Terminals.............................................................12 Section 7. Field Strength of Spurious Emissions....................................................................15 Section 8. Frequency Stability...............................................................................................18 Section 9. Transient Frequency Behavior...............................................................................20 Section 10. Test Equipment List..............................................................................................23 Annex A - Test Methodologies..................................................................................................24 Annex B - Test Diagrams..........................................................................................................30 KTL Dallas FCC PART 90, SUBPART I PRIVATE LAND MOBILE TRANSMITTER EQUIPMENT: B-45C1-01 Base Radio PROJECT NO.: 0L0437RUS2 Page 3 of 34 Section 1.Summary of Test Results Manufacturer:XY Golf Model No.:B-45C1-01 Serial No.:S01 General:All measurements are traceable to national standards.…
