PBWDT19R42DECT PSTN CORDLESS PHONE - BASE

Ascalade Technologies, Inc.

Click to zoom

Application Details

Equipment Class: PUB - Part 15 Unlicensed PCS Base Station
Date of Grant: Jan 31, 2007
Application Purpose: Original Equipment
Date of Application: Jan 30, 2007
Equipment Note: DECT PSTN CORDLESS PHONE - BASE
Frequency Range: 1921.53600000 - 1928.44800000
Company: Ascalade Technologies, Inc.
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

www.philips.com/support ENTelephone Product photo XL340 WARNING Never use non-rechargeable batteries ! 1 Table of contents Table of contents Important Safety Instructions 3 1Environment and safety 5 1.1Safety information 5 1.2Power requirements 5 1.3Battery requirements 5 1.4Telephone connection 5 1.5Environmental care 5 1.6Precautions 5 2Important information 6 2.1For your safety 6 2.2Telephone connection 6 2.3Need help? 6 2.4Safety information 6 2.5Conformity 6 2.6Safety precautions 6 2.7Digital security system 6 3Your phone 7 3.1What’s in the box 7 3.2Overview of the phone 8 3.3Overview of the base 9 3.4Display icons 9 4Getting started 10 4.1Connect the base 10 4.2Connect the charger 10 4.3Insert the batteries in the handset 10 4.4Charge batteries 10 4.5Using GAP standard compliance 11 4.6Standby mode 11 4.7Verify the signal 11 5Using your phone 12 5.1Call 12 5.2Answer a call 12 5.3Loudspeaker phone 12 5.4Adjust the audio volume 12 5.5End a call 12 5.6Make a second call 13 5.7Answer a second call 13 5.8Conference call 13 5.9Use intercom 13 5.10 Text or number entry 13 Table of contents 2 Table of contents 6Use more of your phone 15 6.1Phonebook memory 15 6.2Personalizing your phone 15 6.3Advanced features 16 6.4Use the headset 19 7Default settings 20 8Quick reference table for phone menus 21 9Technical data 22 10Frequently asked questions 23 11Appendix 24 11.1 Equipment approval Information 24 11.2 Notification to the local telephone company 24 11.3 Notes 24 11.4 Rights of the Phone Company 24 11.5 Interference Information 24 11.6 Noise 25 11.7 FCC RF Radiation Exposure Statement 25 11.8 Hearing Aid Compatibility (HAC) 25 11.9 Privacy 25 11.10 Additional Information 25 11.11 Terminal Equipment 26 11.12 Radio Equipment 26 11.13 Do not attempt to repair or modify this equipment 26 12Index 27 13Contact information 29 13.1 Personalizing your phone 13 13.2 Advanced features 14 14Default settings 18 15Quick reference table for menus 19 16Technical data 20 17Frequently asked questions 21 18Index 22 19Contact information 24 3 Important Safety Instructions Important Safety Instructions Some of the following information may not apply to your particular product; however, when using telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Telephones should not be used while you are in a bathtub, shower or pool. Immersion of the telephone or handset in water could cause an electrical shock. 5. Slots and openings in the cabinet back or bottom are provided for ventilation, to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on the bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation unless proper ventilation is provided. 6. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 7. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it. 8. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 9. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. 10. To reduce the risk of electric shock, do not disassemble this product, but take it to a qualified service personnel when service or repair work is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used. 11. Do not expose the product to extreme temperatures such as areas near a hot radiator or stove or in a hot car. 12. Do not place lighted candles, cigarettes, cigars, etc., on the telephone. 13. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. 14. Never install or modify telephone wiring during a lightning storm. 15. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. 16. Use caution when installing or modifying telephone lines to prevent electrical shock and/or fire. 17. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If the product has been exposed to rain or water. C. If the product does not operate normally by following the operating instructions. D. If the product’s cabinet has been damaged. E. If the product exhibits a distinct change in performance. 18. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 19. Do not use the telephone to report a gas leak in the vicinity of the leak. 20. Do not place this product on an unstable cart, stand or table. The product may fall, causing serious damage to the product. 4 Important Safety Instructions IF YOUR PRODUCT UTILIZES BATTERIES, THE FOLLOWING ADDITIONAL PRECAUTIONS SHOULD BE OBSERVED: 1. Use only the type and size of battery(ies) specified in the user manual. 2. Do not dispose of the battery(ies) in fire. They may explode. Check with local codes for possible special disposal instructions. 3. Do not open or mutilate the battery(ies). Released electrolyte is corrosive and may cause damage to the e…

Text truncated - open the document above for the full version.

Cover Letter(s)

Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: January 26, 2007 Ref: FCC ID: PBWDT19R42 Request for Confidentiality Dear Sirs: With regard to the referenced application, Ascalade Technologies Inc. is requesting confidentiality of certain sections of the accompanying documents. The documents for which Ascalade is requesting confidentiality are: 1. Block Diagram / File Name: B209EI06Blk10.pdf 2. Block Diagram / File Name: R042EI01Blk10.pdf 3. Schematic / File Name: R042JB01Bs10.pdf 4. Schematic / File Name: B209JB05Lp31.pdf 5. Schematic / File Name: B209JB27Bs33.pdf 6. Bill of Materials / File Name: B209MTLR10TC.pdf 7. Theory of Operation / File Name: R042EI02The10.pdf 8. Theory of Operation / File Name: R042ComPtc10.pdf 9. Theory of Operation / File Name: B209EI05The10.pdf This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. The material for which confidentiality is requested falls within the scope of Section 552(b)(4) as trade secrets and includes material covered by Section 0.459 of the Commission’s Rules. Sincerely, Kevin Yau Quality Manager

External Photos

Doc Sec. Exterior Photo – B209 Complete set Revision 1.0 Page(s) 1 of 1 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Exterior Photo – B209 Base Revision 1.0 Page(s) 1 of 2 Top View This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Exterior Photo – B209 Base Revision 1.0 Page(s) 2 of 2 Bottom View This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Exterior Photo – XL340 Complete set Revision 1.0 Page(s) 1 of 1 XL340 Complete Set This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Exterior Photo – XL340 Base Revision 1.0 Page(s) 1 of 2 Top View This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Exterior Photo – XL340 Base Revision 1.0 Page(s) 2 of 2 Bottom View This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd.

External Photos

ID Label/Location Info

Doc Sec. Marking – B209 Base Label Revision 1.0 Page(s) 1 of 2 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Marking – B209 Base Label Revision 1.0 Page(s) 2 of 2 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Marking – XL340 Base Label Revision 1.0 Page(s) 1 of 2 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. Marking – XL340 Base Label Revision 1.0 Page(s) 2 of 2 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd.

ID Label/Location Info

Internal Photos

Doc Sec. PCBA Photo – R042 Base Revision 1.0 Page(s) 1 of 2 Top View This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. PCBA Photo – R042 Base Revision 1.0 Page(s) 2 of 2 Bottom View This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Doc Sec. PCBA Photo – B209 Loop Compensation board Revision 1.0 Page(s) 1 of 2 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Top View Doc Sec. PCBA Photo – B209 Loop Compensation board Revision 1.0 Page(s) 2 of 2 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Bottom View Doc Sec. PCBA Photo – B209 Base Revision 1.0 Page(s) 1 of 3 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Top View (Original Design) Doc Sec. PCBA Photo – B209 Base Revision 1.0 Page(s) 2 of 3 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Top View (Alternate Design) Doc Sec. PCBA Photo – B209 Base Revision 1.0 Page(s) 3 of 3 This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Electronics Co. Ltd. Bottom View

RF Exposure Info

Company: Ascalade Technologies Inc. FCC ID: PBWDT19R42H IC ID: 3842A-B209 Model(s): B209, B209H DUT: Portable UPCS/LE-PCS DECT Handset 1921.536 - 1928.448 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 44 Date(s) of Evaluation December 19, 2006 Test Report Serial No. 121306PBW -T801-S15T Report Revision No. Revision 1.0 Report Issue Date January 11, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category General Population Certificate No. 2470.01 R R F F E E X X P P O O S S U U R R E E E E V V A A L L U U A A T T I I O O N N S S P P E E C C I I F F I I C C A A B B S S O O R R P P T T I I O O N N R R A A T T E E S S S A A A R R R T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T FOR ASCALADE TECHNOLOGIES INC. PORTABLE 1.9 GHz UPCS/LE-PCS DECT HANDSET MODEL(S): B209, B209H Test Report Serial No. 121306PBW-T801-S15T Test Report Revision No. Revision 1.0 (Initial Release) Test Lab and Location Celltech Compliance Testing & Engineering Lab (Celltech Labs Incorporated) 1955 Moss Court Kelowna, BC Canada V1Y 9L3 FCC ID: PBWDT19R42H DEVICE IDENTIFIERS IC ID: 3842A-B209 TEST STANDARD(S) & PROCEDURE(S) APPLIED FCC OET Bulletin 65, Supplement C (01-01) Industry Canada RSS-102 Issue 2 IEEE 1528-2003 Certificate No. 2470.01 Test Report Prepared By: Cheri Frangiadakis Test Report Writer Celltech Labs Inc. Test Report Reviewed By: Jonathan Hughes General Manager Celltech Labs Inc. Company: Ascalade Technologies Inc. FCC ID: PBWDT19R42H IC ID: 3842A-B209 Model(s): B209, B209H DUT: Portable UPCS/LE-PCS DECT Handset 1921.536 - 1928.448 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 44 Date(s) of Evaluation December 19, 2006 Test Report Serial No. 121306PBW -T801-S15T Report Revision No. Revision 1.0 Report Issue Date January 11, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category General Population Certificate No. 2470.01 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab and Location CELLTECH LABS INCORPORATED Testing and Engineering Services 1955 Moss Court Kelowna, BC V1Y 9L3 Canada Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Company Information ASCALADE TECHNOLOGIES INC. 12051 Riverside W ay Richmond, BC V6W 1K7 Canada FCC IDENTIFIER: PBWDT19R42H IC IDENTIFIER: 3842A-B209 Device Model(s): B209, B209H Test Requirement(s): FCC 47 CFR §2.1093; Health Canada Safety Code 6 Test Procedure(s): FCC OET Bulletin 65, Supplement C (Edition 01-01) Industry Canada RSS-102 Issue 2 IEEE Standard 1525-2003 Device Classification: Part 15 Unlicensed PCS portable Tx held to ear (PUE) Device Description: Portable 1.9 GHz UPCS/LE-PCS DECT Handset Transmit Frequency Range: 1921.536 - 1928.448 MHz Mode of Operation: TDMA (Time Division Multiple Access) Modulation Type: GFSK (Gaussian Frequency Shift Keying) Max. RF Output Power Level Tested: 18.35 dBm (68.39 mW) EIRP (1924.992 MHz) Source-Based Time-Av. Duty Cycle Tested: 4 % (Crest Factor: 1:25) Max. Source-Based Time-Av. Power Tested: 4.37 dBm (2.74 mW) EIRP (1924.992 MHz) Antenna Type(s) Tested: Internal (pre-formed wire soldered on PCB) Battery Type(s) Tested: NiMH 1.2 V, 750 mAh AAA (x2) Body-worn Accessories Tested: Plastic Belt-Clip (4 mm spacing) Audio Accessories Tested: Ear-Microphone (P/N: WDCP045) Max. SAR Level(s) Evaluated: Head: 0.0372 W/kg (1g average) Body: 0.0123 W/kg (1g average) Celltech Labs Inc. declares under its sole responsibility that this wireless portable device is compliant with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 2 and IEEE Standard 1528-2003 for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Test Report Approved By: Sean Johnston SAR Lab Manager Celltech Labs Inc. Company: Ascalade Technologies Inc. FCC ID: PBWDT19R42H IC ID: 3842A-B209 Model(s): B209, B209H DUT: Portable UPCS/LE-PCS DECT Handset 1921.536 - 1928.448 MHz 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 3 of 44 Date(s) of Evaluation December 19, 2006 Test Report Serial No. 121306PBW -T801-S15T Report Revision No. Revision 1.0 Report Issue Date January 11, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category General Population Certificate No. 2470.01 TABLE OF CONTENTS 1.0 INTRODUCTION ___________________________________________________________________ 4 2.0 DESCRIPTION OF DEVICE UNDER TEST (DUT)_________________________________________ 4 3.0 SAR MEASUREMENT SYSTEM ______________________________________________________ 5 4.0 MEASUREMENT SUMMARY _________________________________________________________ 6 MEASUREMENT SUMMARY (CONT.) _____________________________________________________ 7 5.0 DETAILS OF SAR EVALUATION______________________________________________________ 8 DETAILS OF SAR EVALUATION (CONT.) __________________________________________________ 9 6.0 EVALUATION P…

Text truncated - open the document above for the full version.

Test Report

________________________________ ________________________________ COMPLIANCE TEST REPORT PER STANDARD (s): FCC Part 15, Subparts B, C, and D IC RSS-213 & ICES-003 UPCS / LE-PCS Isochronous Device Base & Handset: 1921.536 – 1928.448 MHz ANSI C63.17 - 1998 (or 2005 Draft where applicable) ANSI C63.4 – 2003 APPLICANT: ASCALADE TECHNOLOGIES INC. 12051 RIVERSIDE WAY RICHMOND BC V6W 1K7 CANADA DESCRIPTION OF 1.9GHz DECT PSTN Cordless Phone w/ VoIP Features PRODUCT: FCC IDs: PBWDT19R42(Base), PBWDT19R42H (Handset) IC LABEL: IC: 3842A-B209 Model Number: B209 (Base), B209H (Handset) DATE SAMPLE 11/29/2006 RECEIVED FOR TESTING: DATE TESTED: 12/20/2006 REPORT NO.: 3246AUT6TestReport.PDF TEST RESULTS: PASS FAIL PLEASE NOTE: THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 PO Box 370 Newberry, FL 32669 APPLICANT: ASCALADE TECHNOLOGIES INC. FCC IDs: PBWDT19R42, PBWDT19R42H IC: 3842A-B209 MODEL #: B209 REPORT #: A\ASCALADE\3246AUT6\3246AUT6TestReport.doc PAGE 2 of 21 TABLE OF CONTENTS 1 GENERAL INFORMATION ................................................................... 3 1.1 COMPLIANCE STATEMENT ........................................................................... 3 1.2 EQUIPMENT UNDER TEST SPECIFICATION.................................................. 4 1.2.1 Transmitter Technical Characteristics..................................... 4 1.2.2 Power Source (s) ..................................................................... 5 1.3 RATIONAL FOR SELECTING TEST CONFIGURATION(S) ................................ 6 1.4 DESCRIPTION ON HOW THE EUT WAS EXERCISED DURING TESTING ....... 6 1.5 TEST STANDARDS ........................................................................................ 6 1.6 TEST ENVIRONEMENT.................................................................................. 6 2 TEST RESULTS................................................................................... 7 2.1 RADIATED PEAK TRANSMIT POWER ............................................................ 7 2.2 TRANSMITTER SPURIOUS EMISSIONS ......................................................... 9 2.3 GENERAL RADIATED SPURIOUS EMISSIONS............................................... 11 2.3.1 Radiated Spurious Emissions ................................................. 11 2.3.2 AC Power Lines Conducted Spurious Emissions ..................... 14 3 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS................... 21 APPLICANT: ASCALADE TECHNOLOGIES INC. FCC IDs: PBWDT19R42, PBWDT19R42H IC: 3842A-B209 MODEL #: B209 REPORT #: A\ASCALADE\3246AUT6\3246AUT6TestReport.doc PAGE 3 of 21 1 GENERAL INFORMATION The test results relate only to the items tested. 1.1 COMPLIANCE STATEMENT This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report and demonstrate that the equipment complies with the appropriate standards. No modifications were made to the equipment during testing in order to demonstrate compliance with these standards. Certificate #0955-01 I attest that the necessary measurements were made, under my supervision, at TIMCO ENGINEERING, INC. located at 849 N.W. State Road 45, Newberry, Florida 32669. Authorized Signatory Name: Mario de Aranzeta Signature: On File Function: Chief Engineer Date: January 10, 2006 Tester: Nam Nguyen Signature: On File Date: 12/28/2006 APPLICANT: ASCALADE TECHNOLOGIES INC. FCC IDs: PBWDT19R42, PBWDT19R42H IC: 3842A-B209 MODEL #: B209 REPORT #: A\ASCALADE\3246AUT6\3246AUT6TestReport.doc PAGE 4 of 21 1.2 EQUIPMENT UNDER TEST SPECIFICATION Description of Equipment Under Test UPCS / LE-PCS Isochronous Device, Base & Handset, 1921.536 – 1928.448 MHz Characterization of Test Item Prototype Pre-production Production Construction of Equipment Single unit Multiple units (If multiple units describe each one clearly) Type of Equipment Fixed Mobile Portable Station Transmitter Simplex Integral antenna (Handset and Base) Receiver Duplex Single antenna connector Transceiver Two antenna connector Battery Charger Vehicle battery adaptor Remote Control Head Family Model Numbers Original Family: Trade Name: Ascalade Model Number: B209, B209H Alternative Family 1: Trade Name: Philips Model Number: XL340XY/ZZ (XY, ZZ – any combination of wild digits from 0 –9 and/or wild numbers from A – Z) 1.2.1 Transmitter Technical Characteristics Frequency characteristics (Method of frequency generation): Crystal Synthesizer Other State the maximum number of channels over which the equipment can operate: N/A Maximum rated transmitter output power: 70mW for the Base and 72mW for the Handset APPLICANT: ASCALADE TECHNOLOGIES INC. FCC IDs: PBWDT19R42, PBWDT19R42H IC: 3842A-B209 MODEL #: B209 REPORT #: A\ASCALADE\3246AUT6\3246AUT6TestReport.doc PAGE 5 of 21 1.2.2 Power Source (s) AC Supply: State voltage: ______ Single phase: ____ Three phase: ____ AC supply frequency (Hz) _____________________________________ External DC supply: Nominal voltage 2.4VDC NiMH rechargeable battery for Handset and 9VDC via a power adapter for Base Battery: Nickel Cadmium Lead acid Leclanche Lithium [The following space is left bland on purpose) APPLICANT: ASCALADE TECHNOLOGIES INC. FCC IDs: PBWDT19R42, PBWDT19R42H IC: 3842A-B209 MODEL #: B209 REPORT #: A\ASCALADE\3246AUT6\3246AUT6TestReport.doc PAGE 6 of 21 1.3 RATIONAL FOR SELECTING TEST CONFIGURATION(S) No deviation from technical specifications 1.4 DESCRIPTION ON HOW THE EUT WAS EXERCISED DURING TESTING (e.g software description, test signal, etc.) The EUT was set in continuous transmit mode of operation. 1.5 TEST STANDARDS FCC Part 15, Subparts B, C, and D IC RSS-213 & ICES-003 ANSI C63.17 - 1998 (or 2005 Draft where applicable) ANSI C63.4 - 2003 1.6 TEST ENVIRONEMENT Temperature Normal test temperature (Tnom): 22 °C Extreme test temperatures (Tmax…

Text truncated - open the document above for the full version.

Test Report

Doc Sec. Test of Monitoring & Access Criteria Revision 1.0 Page(s) 1 of 12 _________________________________________________________________________________________________________________________________ This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Eectronics Co. Ltd. TEST REPORT FCC ID: PBWDT19R42 (Base) PBWDT19R42H (Handset) IC: 3842A–B209 (Base & Handset) Equipment Under Test: 1.9 GHz DECT Device / Telephone Model(s): B209, B209H EUT S/N: TS060413008 TS060413029 In Accordance With: FCC Part 15, Subpart D / IC RSS-213 UPCS / LE-PCS Isochronous Device ANSI C63.17 – 1998 (or 2005 Draft where applicable) Tested By: Bill / Ronnie Reviewed By: Kevin Yau Date: November 28, 2006 Doc Sec. Test of Monitoring & Access Criteria Revision 1.0 Page(s) 2 of 12 _________________________________________________________________________________________________________________________________ This document contains confidential and proprietary information of Ascalade. Its use is under the terms and conditions of Proprietary. Ascalade in this document means Ascalade Technologies Inc., Ascalade Communications Ltd., or Dongguan Ascalade Eectronics Co. Ltd. TEST EQUIPMENT LIST ITEM EQUIPMENT MAKE MODEL S/N LAST CAL. 1. Spectrum Analyzer AGILENT 8560E 3337A00704 07 April 2005 2. Scope TEKTRONIX TDS-220 B051826 02 April 2004 3. 3-Port Combiner MINI CIRCUITS ZESC-2-11 15542 N/A 4. Selectable Attenuator KAY ELEMETRICS 839 20902-34 N/A 5. Attenuator In-house built Fixed 15 dB N/A N/A 6. Attenuator In-house built Fixed 22 dB N/A N/A 7. Attenuator In-house built Fixed 33 dB N/A N/A Doc Sec. Test of Monitoring & Access Criteria Revision 1.3a Page(s) 3 of 12 TIMCO Ref: 3246AUT6 & 3247AUT6 1 OVERVIEW This report reviews the RF channel monitoring and access criteria employed in the subject DECT-based device. Results indicate the subject device(s) are meeting the requirements of FCC Part 15 Subpart D or Industry Canada specification RSS-213 for UPCS / LE-PCS Isochronous Devices. Details follow by sub-sections of the FCC rules or IC spec. 2 15.319 (c) / 6.5 The peak transmit power P is rated 20 dBm, within the limit of 100 μW x B under this clause and numerically derived in 15.323 (a). See relevant Section in another report for measured power. 3 15.319 (f) / 4.3.4 (a) The device system will automatically discontinue transmission in case of either absence of information to transmit or operational failure. However, control and signaling information is transmitted every frame by the base even when there are no links established. This information is in broadcast during 1 time slot. This kind of control signaling is permitted under this clause. The information is also in broadcast on all transmit bearers from the base in duplex connections. See paragraph 6 below for details of verification tests. 4 15.323 (a) / 6.5 The emission bandwidth B of the device is rated 1.5 MHz maximum, limiting the peak transmit power to P max = 5 logB - 10 dBm = 20.8 dBm as per 15.319 (c). See relevant Section in another report for measured emission bandwidth. 5 15.323 (e) / 4.3…
