PBWFH24R162.4 GHz FHSS Conference Phone

1 Owner’s Manual (DRAFT) OLYMPIA OL6010 2.4 GHz WDCT Conference Telephone TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION GETTING STARTED Checklist of Parts Your Conference Telephone POD Base LCD Display on the POD Phone Key Basic Steps to Install Charging the POD To Ensure Better Performance BASIC OPERATIONS During Standby Answering Calls Making Calls Traditional Dialing Making Calls Predialing Redialing Use Traditional Dialing Use Predialing Phonebook Dialing Use Traditional Dialing Use Predialing Services Dialing Service Centre Quick Access Things you can do during a call Adjust Speaker Volume Mute Call Things you can do during a call Change Dial Tone Send Flash Signal Dialing Extra Digits Things you can do during a call Dialing from Phonebook Record Things you can do during a call Displaying User Phone Number Ringer Volume Adjusting Ringer Volume 2 Ringer On/Off Shortcut Add New Number in Phonebook Programming Start Programming Programming Ringer Melody Programming Dialing Mode Flash Duration Programming User Phone Number Programming Network Services Number Programming Service Centre Number Programming Default Setting Additional Features Call Recording Out of Range Paging Additional Features Low Battery QUICK REFERENCE GUIDE QUICK REFERENCE GUIDE TROUBLE SHOOTING TECHNICAL DATA TECHNICAL INFORMATON 3 This telephone is not designed for making emergency telephone calls when the power fails. Make alternative arrangements for access to emergency services. IMPORTANT SAFETY INFORMATION BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOUD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY, INCLUDING THE FOLLOWING. • Read and understand all instructions. • Follow all warnings and instructions marked on the product. • Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. • Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool. • Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. • Slots and openings in the cabinet and the back or bottom are provided for ventilation, to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the product on the bed, sofa, rug, or other similar surface. • This product should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation unless proper ventilation is provided. • This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your office, consult your dealer or local power company. • Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it. • Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. • Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. • To reduce the risk of electric shock, do not disassemble this product. Take the product to a qualified serviceman when it requires repair work or service. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock during subsequent use. • Unplug this product form the wall outlet and battery source and refer servicing to qualified service personnel under the following conditions: a. When the power supply cord or plug is damaged or frayed. b. If liquid has been spilled into the product. c. If the product does not operate normally by following the operating instructions. d. If the product has been dropped or the cabinet has been damaged. e. If the product exhibits a distinct change in performance. • Avoid using a telephone during an electrical storm. There may be a remote risk of electric shock from lightning. • Do not use this product to report a gas leak in the vicinity of the leak. 4 To reduce the risk of fire or injury to persons, read and follow these instructions: TELEPHONE WIRING AND JACK INSTALLATION • Use caution when installing or modifying telephone lines. • Never install telephone wiring during an electrical storm. • Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. • Never touch un-installed telephone wires or terminals unless the telephone line is disconnected at the network interface. SAFETY INSTRUCTIONS FOR POD BATTERY PACK Danger of explosion if battery is incorrectly replaced. Use only an Olympia Phone approved battery pack in the POD of your OL6010 Conference Telephone. To reduce the risk of fire or injury, always do the following when replacing, discarding, or charging battery. When handling the batteries, be careful not to short the battery with conducting materials such as rings, bracelets, and keys. The battery or conducting material may overheat and cause burns. Use only the following type and size of battery pack: FOR POD UNIT: NiMH rechargeable battery 7.2 V 1800 mAh • Do not dispose of the battery in a fire. The cell may explode. Check with local codes for possible special disposal instructions. • Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may be toxic if swallowed. • Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets and keys. The battery or conductor may overheat and cause burns. • Charge the batteries provided with or identified for use with this product only in accordance with the instructions and limitations specified …

Text truncated - open the document above for the full version.

Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: PBWFH24R16 Request for Confidentiality Dear Sirs: With regard to the referenced application, ARKON Networks Inc. is requesting confidentiality of certain sections of the accompanying documents. The documents for which ARKON is requesting confidentiality are: • Block Diagrams • Schematic Diagrams • Circuit Descriptions / Theory of Operation • • This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. The material for which confidentiality is requested falls within the scope of Section 552(b)(4) as trade secrets and includes material covered by Section 0.459 of the Commission’s Rules. Sincerely, Kevin Yau Quality Manager Date: March 10, 2003

CONFIDENTIAL 2002 Copyright Arkon Networks Inc.© Doc No. : Revision : Page(s) : Doc Cat. : Doc Title : Dept./Proj. : A R K O N C004-ID01-A-YY-ZZ 1.0 1 of 2 Industrial Design 2.4GHz WDCT Conference Telephone This document contains confidential and proprietary information of Arkon Technologies Inc. Its use is under the terms and conditions of Non-Disclosure Agreement. CONFIDENTIAL 2002 Copyright Arkon Networks Inc.© Doc No. : Revision : Page(s) : Doc Cat. : Doc Title : Dept./Proj. : A R K O N C004-ID01-A-YY-ZZ 1.0 2 of 2 Industrial Design 2.4GHz WDCT Conference Telephone This document contains confidential and proprietary information of Arkon Technologies Inc. Its use is under the terms and conditions of Non-Disclosure Agreement.

Model / Modele C004 COMPLIES WITH PART 68 OF FCC RULES AND REQUIREMENTS ADOPTED BY ACTA US: PBWWI01BC004 IC: 3842A-C004 REN: 0.1B JACK (USOC): RJ11C / CA11A ARKON Networks Inc. FCC ID: PBWFH24R16 MADE IN CHINA FABRIQUE EN CHINE LISTED I.T.E. 2VF1 E234083 22mm 50mm Model / Modele C004 COMPLIES WITH PART 68 OF FCC RULES AND REQUIREMENTS ADOPTED BY ACTA US: PBWWI01BC004 IC: 3842A-C004 REN: 0.1B JACK (USOC): RJ11C / CA11A ARKON Networks Inc. FCC ID: PBWFH24R16 MADE IN CHINA FABRIQUE EN CHINE LISTED I.T.E. 2VF1 E234083 C004 Base Model Labels TO REDUCE RISK OF FIRE OR PERSONAL INJURY, USE ONLY NiMH RECHARGEABLE BATTERY 7.2 V 1800 mAh. POUR RÉDUIRE LE RISQUE DU FEU OU DE BLESSURES, UTILISEZ SEULEMENT LA BATTERIE RECHARGEABLE 7.2 V 1800 mAh DE NiMH NiMH RECHARGEABLE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. CAUTION 30mm 45mm Model / Modele C004 FCC ID: PBWFH24R16 IC: 3842A-C004 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2. THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATION MAY NOT BE ENSURED WHEN USING THIS PHONE. MADE IN CHINA FABRIQUE EN CHINE ARKON Networks Inc. LISTED I.T.E. 2VF1 E234083 52mm 37mm TO REDUCE RISK OF FIRE OR PERSONAL INJURY, USE ONLY NiMH RECHARGEABLE BATTERY 7.2 V 1800 mAh. POUR RÉDUIRE LE RISQUE DU FEU OU DE BLESSURES, UTILISEZ SEULEMENT LA BATTERIE RECHARGEABLE 7.2 V 1800 mAh DE NiMH NiMH RECHARGEABLE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. CAUTION Model / Modele C004 FCC ID: PBWFH24R16 IC: 3842A-C004 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2. THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATION MAY NOT BE ENSURED WHEN USING THIS PHONE. MADE IN CHINA FABRIQUE EN CHINE ARKON Networks Inc. LISTED I.T.E. 2VF1 E234083 C004 Portable Part Model Labels

FCC RF RADIATION EXPOSURE STATEMENT: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

APPLICANT: ARKON TECHNOLOGIES INC. FCC ID: PBWFH24R16 REPORT #: A \ARKON TECH\325AUT3\325AUT3TestReport.doc TABLE OF CONTENTS LIST APPLICANT: ARKON TECHNOLOGIES INC. FCC ID: PBWFH24R16 TABLE OF CONTENTS FOR A FREQUENCY HOPPING SPREAD SPECTRUM TEST REPORT CONTAINING: PAGE 1-3...........LIST OF TEST EQUIPMENT PAGE 4.............TEST PROCEDURES PAGE 5.............POWER LINE CONDUCTED INTERFERENCE PAGE 6.............POWER LINE CONDUCTED PLOTS – ON HOOK PAGE 7.............POWER LINE CONDUCTED PLOTS – OFF HOOK PAGE 8.............OCCUPIED BANDWIDTH AND POWER OUTPUT PAGE 9.............POWER OUTPUT CONTINUED PAGE 10-11.........20 dB BANDWIDTH PLOTS PAGE 12-13.........# OF CHANNEL PLOTS PAGE 14............RADIATION INTERFERENCE TEST DATA PAGE 15-16.........DWELL TIME PLOT PAGE 17............RADIATED SPURIOUS EMISSIONS INTO ADJ. RESTRICTED BANDS PAGE 18-19.........BANDEDGE PLOTS DENSITY EXHIBIT ATTACHMENTS: EXHIBIT 1...........REQUEST FOR CONFIDENTIALITY LETTER EXHIBIT 2...........FCC ID LABEL SAMPLE EXHIBIT 3...........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 4...........BLOCK DIAGRAM EXHIBIT 5...........SCHEMATICS EXHIBIT 6...........INSTRUCTION MANUAL EXHIBIT 7...........EXTERNAL PHOTOGRAPHS EXHIBIT 8...........INTERNAL PHOTOGRAPHS EXHIBIT 9...........THEORY OF OPERATION EXHIBIT 10..........TEST SETUP UP PHOTOGRAPH APPLICANT: ARKON TECHNOLOGIES INC. FCC ID: PBWFH24R16 REPORT #: A\ARKON TECH\325AUT3\325AUT3TestReport.doc Page 1 of 19 EMC Equipment List DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS X 3-Meter OATS TEI N/A N/A Listed 12/22/99 12/22/02 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 Receiver, Beige Tower Spectrum Analyzer (Tan) HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 RF Preselector (Tan) HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Quasi-Peak Adapter (Tan) HP 85650A 3303A01690 CAL 8/31/01 8/31/03 X Receiver, Blue Tower X Spectrum Analyzer (Blue) HP 8568B 2928A04729 2848A18049 CHAR 10/22/01 10/22/03 X RF Preselector (Blue) HP 85685A 2926A00983 CHAR 10/22/01 10/22/03 X Quasi-Peak Adapter (Blue) HP 85650A 2811A01279 CHAR 10/22/01 10/22/03 X Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Eaton 94455-1 1057 CHAR 3/15/00 3/15/02 BiconiLog Antenna EMCO 3143 9409-1043 X Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CHAR 10/16/01 10/16/03 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CHAR 11/24/00 11/24/03 Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 12/19/01 12/19/03 Horn Antenna Electro-Metrics EM-6961 6246 CAL 3/21/01 3/21/03 Horn Antenna ATM 19-443-6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/03 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 APPLICANT: ARKON TECHNOLOGIES INC. FCC ID: PBWFH24R16 REPORT #: A\ARKON TECH\325AUT3\325AUT3TestReport.doc Page 2 of 19 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/16/01 3/16/03 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 5/25/01 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CAL 12/12/01 12/12/03 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/03 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/03 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 X Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE-77-3 79510405 CAL 9/26/01 9/26/03 Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/03 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/04 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/04 X Temp/Humidity gauge EXTech 44577F E000901 CHAR 1/22/02 1/22/04 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/03 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 1/26/01 1/26/03 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/02 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 11/15/01 11/15/03 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/03 Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/03 APPLICANT: ARKON TECHNOLOGIES INC. FCC ID: PBWFH24R16 REPORT #: A\ARKON TECH\325AUT3\325AUT3TestReport.doc Page 3 of 19 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS BandReject Filter Lorch Microwave 5BR4-2400/ 60-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 6BR6-2442/ 300-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 5BR4-10525/ 900-S Z1 CHAR 3/2/01 3/2/03 High Pas Filter Microlab HA-10N CHAR 10/4/01 10/4/03 Audio Oscillator HP 653A 832-00260 CHAR 3/1/01 3/1/03 Frequency Counter HP 5382A 1620A03535 CHAR 3/2/01 3/2/03 Frequency Counter HP 5385A 3242A07460 CHAR 12/11/01 12/11/03 Preamplifier HP 8449B-H02 3008A00372 CHAR 3/4/01 3/4/03 Amplifier HP 11975A 2738A01969 CHAR 3/1/01 3/1/03 Egg Timer Unk CHAR 8/31/01 8/31/03 Measuring Tape, 20M Kraftixx 0631-20 CHAR 2/1/02 2/1/04 Measuring Tape, 7.5M Kraftixx 7.5M PROFI 2/1/02 2/1/04 Coaxial Cable #51 Insulated Wire Inc. NPS 2251-2880 Timco #51 CHAR 1/23/02 1/23/04 Coaxial Cable #64 Semflex Inc. 60637 Timco #64 CHAR 1/24/02 1/24/04 Coaxial Cable #65 General Cable Co. E9917 RG233/U Timco #65 CHAR 1/23/02 1/23/04 Coaxial Cable #106 Unknown Unknown Timco #106 CHAR 1/23/02 1/23/04 APPLICANT: ARKON TECHNOLOGIES INC. FCC ID: PBWFH24R16 REPORT #: A\ARKON TECH\325AUT3\325AUT3TestReport.doc Page 4 of 19 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in ful…
