PCB-SS225ATraffic radar

SmartSensor Matrix USER GUIDE www.wavetronix.com • 78 East 1700 South Provo, Utah 84606 • 801.734.7200 © 2013 Wavetronix LLC. All Rights Reserved. Wavetronix, SmartSensor, Click, Command, and all associated product names and logos are trademarks of Wavetronix LLC. All other products or brand names as they appear are trademarks or registered trademarks of their respective holders. Protected by US Patent Nos. 6,556,916; 6,693,557; 7,426,450; 7,427,930; 7,573,400; 7,889,097; 7,889,098; 7,924,170; 7,991,542; 8,248,272; Canadian Patent Nos. 2461411; 2434756; 2512689; and European Patent Nos. 1435036; 1438702; 1611458. Other US and international patents pending. The Company shall not be liable for any errors contained herein or for any damages arising out of or related to this document or the information contained therein, even if the Company has been advised of the possibility of such damages. This document is intended for informational and instructional purposes only. The Company reserves the right to make changes in the specifications and other information contained in this document without prior notification. FCC Part 15 Compliance: The Wavetronix SmartSensor sensors comply with Part 15 of the Federal Communications Commission (FCC) rules which state that operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. FCC compli- ance statements for applicable optional modules are to be found in the module specifications. Unauthorized changes or modifications not expressly approved by the party responsible for compliance with the FCC rules could void the user’s authority to operate this equipment. Disclaimer: The advertised detection accuracy of the Wavetronix SmartSensor sensors is based on both external and internal testing, as outlined in each product’s specification document. Although our sensors are very accurate by industry standards, like all other sensor manufacturers we cannot guarantee perfection or assure that no errors will ever occur in any particular applications of our technology. Therefore, beyond the express Limited Warranty that accompanies each sensor sold by the company, we offer no additional representa- tions, warranties, guarantees or remedies to our customers. It is recommended that purchasers and integrators evaluate the accuracy of each sensor to determine the acceptable margin of error for each application within their particular system(s). WX-500-0053 1/2013 Contents Introduction 5 SmartSensor Matrix Package 6 • Selecting a Mounting Loca- tion 7 Part I Installing the SmartSensor Matrix Chapter 1 Installing the SmartSensor Matrix 13 Sensor Mounting Guidelines 14 • Attaching the Mount Bracket to the Pole 15 • Attaching the Sensor to the Mount Bracket 16 • Aligning the Sensor to the Roadway 16 • Ap- plying the Silicon Dielectric Compound 18 • Connecting the SmartSensor 6-conductor Cable 18 • Grounding the Sensor 19 Chapter 2 Connecting Power and Surge Protection 21 Mounting the Backplate 22 • Connecting AC Power 22 • Providing System Surge Protection 26 • Terminating Smart- Sensor 6-conductor Cables 28 Chapter 3 Contact Closure Communication 31 Using the Click 112/114 DIP Switches 32 • Using the Click 104 Rotary Switch 34 • Attaching and Programming the Click 112/114 35 • Attaching and Programming the Click 104 37 • Channel Mapping 39 Part II Using SmartSensor Manager Matrix Chapter 4 Installing SmartSensor Manager Matrix 45 Installing SSMM 47 • Microsoft .NET Framework 49 Chapter 5 Communication 51 Serial Connection 53 • Internet Connection 56 • Virtual Connection 58 • Viewing Connection Information 60 • Up- grading the Sensor’s Embedded Software 62 Chapter 6 Sensor Settings 65 General Sensor Settings 65 • Sensor Info Screen 67 Chapter 7 Lanes & Stop Bars 69 Display Options 70 • Menu Bar 73 • Automatic Configura- tion 76 • Manual Configuration 77 Chapter 8 Zones & Channels 81 Menu Bar 82 • Placing Zones 83 • Channel Type 84 • Map- ping Zones to Channels 86 • Measuring Zones 89 Chapter 9 Verification 91 Channel Indicators 92 • Verification Menu Bar 93 Chapter 10 Tools 95 Backup/Restore 96 • Rack Cards Tools 97 • Sensor Self Tests 101 Appendix 103 Appendix A – Cable Connector Definitions 103 • Appendix B – Cable Lengths 105 • Appendix C – Click 221 User Ref- erence Guide 106 • Appendix D – Click 600 Installation 107 • Appendix E – Matrix Extended Range 111 In this chapter ˽SmartSensor Matrix Package ˽Selecting a Mounting Location The Wavetronix SmartSensor Matrix™ is a stop bar presence detector designed for use at signalized intersections (see Figure I.1). The SmartSensor Matrix detects vehicles through the use of a 24.125 GHz (K band) operating radio frequency. Using what is classified as frequency modulated continuous wave (FMCW ) radar, SmartSensor Matrix detects and reports vehicle presence in as many as 10 lanes simultaneously. Figure I.1 – Wavetronix SmartSensor Matrix SmartSensor Matrix is a first-of-its-kind radar stop bar detector with Radar Vision™. It delivers the reliability of radar and the simplicity of non-intrusive detection for stop bar presence detection. In many situations, the sensor is installed on the roadside in order to prevent the need for lane closures and traffic control. Once the unit is installed, the configu- Introduction 6 INTRODUCTION • SMARTSENSOR MATRIX USER GUIDE ration process is quick and easy. After installation, the sensor will require little or no on-site maintenance and can be remotely configured. This user guide outlines the step-by-step process of installing and configuring the Smart- Sensor Matrix. Any questions about the information in this guide should be directed to Wavetronix or your distributor. SmartSensor Matrix Package A standard SmartSensor Matrix package may contain the following items: ˽SmartSensor Matrix SS225 detector(s) with installed sensor backpla…

Text truncated - open the document above for the full version.

Technical Description The system is shown below: Figure 1 As shown in figure 1, the DDS generates an a linear frequency modulated chirp from 0 to 7.8 MHz. This signal is mixed up and filtered to leave a chirp from 750 MHz to 757.8 MHz. The signal then goes through the 16 times multiplier, filter and amplifier to create a linear frequency modulated chirp that ramps the signal from 12 GHz to 12.125 GHz. The doubler and filter then move the signal to the 24 to 24. 25 Linear Frequency Modulated (LFM) chirp, or Freuqency Modulated Continuous Wave (FMCW) signal. The signal is then amplified and goes through the switch network to be transmitted out of only one antenna at a time. The up chirp takes 255 micro seconds and the down chirp takes 5 microseconds. The Pulse Repetition Frequency (PRF) is then 3846 Hz, or roughly 4 KHz. The transmitted frequency is controlled using a DDS, VCO, 16X multiplier and Doubler as shown in the block diagram and discussed above. To suppress spurious signals, stripline RF filters are built into the printed circuit board. Additionally, 2 pieces of RF absorbing foam are used. The first is placed between the RF board and the DSP board and the second piece of absorbing material is attached to the back of the RF board (the side with the antennas). The system does not send information, but transmits an LFM chirp and listens for the echoes from objects in its antenna pattern. The frequency modulation is used so that when the delayed return chirp is mixed with the transmit signal, the resulting frequency corresponds to a range.

Nemko Test Report: 10237632RUS1 Applicant: Wavetronix, LLC 78 East 1700 South Provo, UT 84606 USA Equipment Under Test: SS225 (E.U.T.) In Accordance With: FCC Part 15, Subpart C, 15.249 and Industry Canada RSS-310, Issue 3 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz. Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, Texas 75057-3136 TESTED BY: DATE: 21 February 2013 David Light, Senior Wireless Engineer APPROVED BY: DATE: 22 February 2013 Mike Cantwell, Reviewer Total Number of Pages: 13 Nemko USA, Inc. CFR 47, PART 15, Paragraph 15.249 and Industry Canada RSS-310 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz EQUIPMENT: SS225 REPORT NO.: 10237632RUS1 Page 2 of 13 Table Of Contents SECTION 1. SUMMARY OF TEST RESULTS 3 SECTION 2. GENERAL EQUIPMENT SPECIFICATION 5 SECTION 3. POWERLINE CONDUCTED EMISSIONS 6 SECTION 4. RADIATED EMISSIONS 8 SECTION 5. TEST EQUIPMENT LIST 10 ANNEX A TEST DIAGRAMS 11 Nemko USA, Inc. CFR 47, PART 15, Paragraph 15.249 and Industry Canada RSS-310 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz EQUIPMENT: SS225 REPORT NO.: 10237632RUS1 Page 3 of 13 Section 1. Summary Of Test Results Manufacturer: Wavetronix, LLC Model No.: SS225 Serial No.: None General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 15.249 and Industry Canada RSS-310, Issue 3. All tests were conducted using measurement procedure ANSI C63.4-2003. Radiated Emissions were made on an open area test site. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Nemko USA, Inc. is a NVLAP accredited laboratory. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Inc. CFR 47, PART 15, Paragraph 15.249 and Industry Canada RSS-310 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz EQUIPMENT: SS225 REPORT NO.: 10237632RUS1 Page 4 of 13 Summary Of Test Data NAME OF TEST PARA. NO. RESULT Conducted Emissions 15.207 / RSS-General 7.2.4 Complies Radiated Emissions 15.245 / RSS-310 3.10 Complies Nemko USA, Inc. CFR 47, PART 15, Paragraph 15.249 and Industry Canada RSS-310 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz EQUIPMENT: SS225 REPORT NO.: 10237632RUS1 Page 5 of 13 Section 2. General Equipment Specification Frequency Range: 24.0 to 24.25 GHz Operating Frequency(ies) of Sample: 24.0 to 24.25 GHz User Frequency Adjustment: None Integral Antenna Yes No Description of EUT Traffic radar System Diagram Nemko USA, Inc. CFR 47, PART 15, Paragraph 15.249 and Industry Canada RSS-310 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz EQUIPMENT: SS225 REPORT NO.: 10237632RUS1 Page 6 of 13 Section 3. Powerline Conducted Emissions NAME OF TEST: Powerline Conducted Emissions PARA. NO.: 15.207 / 7.2.4 TESTED BY: David Light DATE: 19 February 2013 Minimum Standard: Conducted limits. (a) Except as shown in paragraphs (b) and (c) of this section, for an intentional radiator that is designed to be connected to the public utility (AC) power line, the radio frequency voltage that is conducted back onto the AC power line on any frequency or frequencies, within the band 150 kHz to 30 MHz, shall not exceed the limits in the following table, as measured using a 50 mH/50 ohms line impedance stabilization network (LISN). Compliance with the provisions of this paragraph shall be based on the measurement of the radio frequency voltage between each power line and ground at the power terminal. The lower limit applies at the boundary between the frequency ranges. Frequency of Conducted Limit (dBmV) Emission (MHz) Quasi-peak Average 0.15-0.5 66 to 56* 56 to 46* 0.5-5 56 46 5-30 60 50 * Decreases with the logarithm of the frequency. Test Results: Complies . See attached graph(s). Measurement Data: See attached graph(s). Method of Measurement: (Procedure ANSI C63.4-2003) Measurements were made using a spectrum analyzer with 10 kHz RBW, Peak Detector. Any emissions that are close to the limit are measured using a test receiver with 10 kHz bandwidth, CISPR Quasi-Peak Detector. Nemko USA, Inc. CFR 47, PART 15, Paragraph 15.249 and Industry Canada RSS-310 Operation within the bands 902-928 MHz, 2400-2483.5 MHz, 5725-5875 MHZ, and 24.0-24.25 GHz EQUIPMENT: SS225 REPORT NO.: 10237632RUS1 Page 7 of 13 Test Data – Powerline Conducted Emissions Nemko Conducted Emissions FCCB 150Khz-30 Mhz LI N E 1 150.0K1.0M10.0M30.0M Fr equency (MH Z) 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 Am plitude (dBuv) C om pany: W avetr onix Model N um ber : S S 225 03:34:21 P M, Thur sday, Febr uar y 21, 2013 Oper ator : Light C onducted E m i ssi ons Fully Oper ational S can Measur ed P ks FCCB QP FCCB AVG Nemko C onducted E m i ssi ons FC C B 150Khz-30 Mhz LIN E 2 150.0K1.0M10.0M30.0M Fr equency (MH Z) 0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 A m pli tude (dB uv) C om pany: W avetr onix Model N um ber : S S 225 03:35:34 P M, Thur sday, Febr uar y 21, 2013 O per ator : L…
