PD4PP10Pet Door Chime

Lentek International

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Apr 19, 2001
Application Purpose: Original Equipment
Date of Application: Feb 19, 2001
Equipment Note: Pet Door Chime
Frequency Range: 315.00000000 - 315.00000000
Company: Lentek International
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 51 EXHIBIT 5 User Manual Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 Intertek Testing Services FCC ID: PD4PP10EXHIBIT 52 User Manual Attached is a preliminary copy of the Instruction Manual. The following information will be included in the next revision of the manual: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Sentrol, Inc. could void the user's authority to operate the equipment. This manual will be provided to the end-user with each unit sold/leased in the United States.

External Photos

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 71 EXHIBIT 7 External Photographs Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 Intertek Testing Services FCC ID: PD4PP10EXHIBIT 72 External Photographs (PP10) Front Intertek Testing Services FCC ID: PD4PP10EXHIBIT 73 External Photographs (PP10) Back

ID Label/Location Info

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 31 EXHIBIT 3 ID Label & Location Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 Intertek Testing Services FCC ID: PD4PP10EXHIBIT 32 Label Artwork / Location An engineering drawing of the label will be permanently affixed to the unit is shown below. Please note that due to the size of the device, the model number and trade name will be placed on a separate label. The Photo below shows the actual location and label used. Model# :PP10 Pet Chime FCC ID: PD4PP10 Lentek Orlando, Florida, USA Tel: 407-857-8786 CE Made In China

Internal Photos

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 81 EXHIBIT 8 Internal Photographs Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 Intertek Testing Services FCC ID: PD4PP10EXHIBIT 82 Internal Photographs PC Board (Internal Top of Enclosure) Intertek Testing Services FCC ID: PD4PP10EXHIBIT 83 Internal Photographs PC Board (Internal Bottom of Enclosure) Intertek Testing Services FCC ID: PD4PP10EXHIBIT 84 Internal Photographs PC Board (Top View #1) Intertek Testing Services FCC ID: PD4PP10EXHIBIT 85 Internal Photographs PC Board (Top View #2) Intertek Testing Services FCC ID: PD4PP10EXHIBIT 86 Internal Photographs PC Board (Bottom View)

Operational Description

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 11 EXHIBIT 1 Operational Description / Letter of Agency Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 Intertek Testing Services FCC ID: PD4PP10EXHIBIT 12 The Lentek International Pet chime (Model Number: PP10) is a portable wireless Electronic Pet Doorbell. The Pet Chime consists of two units, one transmitter (Pet Paw) and a receiver (Chime).It has a one-button Pet Paw transmitter to activate the chime. The Pet Paw transmitter operates on one 9V battery. The Chime receiver has two tone settings, which are controlled by a switch on the back of the unit. The Chime operates on three AA batteries.

Schematics

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 91 EXHIBIT 9 Schematics Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10

Test Report

Intertek Testing Services EXHIBIT 2 Test Report Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet CHime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 November 30, 2000 Report prepared by:Jeffrey D. Hiday Intertek Testing Services 1950 Evergreen Blvd., Suite 100 Duluth, GA 30096 Phone: 678-775-2400 FAX: 678-775-2401 E-mail: [email protected] Intertek Testing Services FCC ID: PD4PP10Test Report i TABLE OF CONTENTS 1.0General Description.............................................................................................................1 1.1Product Description..............................................................................................................................................1 1.2Related Submittals / Grants................................................................................................................................1 1.3Test Methodology.................................................................................................................................................2 1.4Test Facility............................................................................................................................................................2 1.5Test Equipment List..............................................................................................................................................3 2.0System Test Configuration..................................................................................................4 2.1Justification............................................................................................................................................................4 2.2EUT Exercising Software.....................................................................................................................................4 2.3Special Accessories................................................................................................................................................4 2.4Equipment Modification......................................................................................................................................4 2.5Support Equipment List and Description.........................................................................................................5 2.6Test Configuration Block Diagram.....................................................................................................................5 3.0Emission Results...................................................................................................................6 3.1Field Strength Calculation...................................................................................................................................6 3.2Radiated Emission Test Data...............................................................................................................................7 3.3Line Conducted Emission Test Data..................................................................................................................9 4.0Miscellaneous Information................................................................................................10 4.1Emissions Test Procedures................................................................................................................................10 4.2Measured Bandwidth.........................................................................................................................................11 4.3Calculation of Average Factor..........................................................................................................................12 4.4Operating Characteristics and Holdover Time...............................................................................................13 Intertek Testing Services FCC ID: PD4PP10Test Report 1 1.0General Description 1.1Product Description The Lentek International Pet chime (Model Number: PP10) is a portable wireless Electronic Pet Doorbell. The Pet Chime consists of two units, one transmitter (Pet Paw) and a receiver (Chime).It has a one-button Pet Paw transmitter to activate the chime. The Pet Paw transmitter operates on one 9V battery. The Chime receiver has two tone settings, which are controlled by a switch on the back of the unit. The Chime operates on three AA batteries. 1.2Related Submittals There are no related submittals for this application. Intertek Testing Services FCC ID: PD4PP10Test Report 2 1.3Test Methodology Radiated emission measurements were performed according to the procedures in ANSI C63.4 (1992). All measurements were performed at Open Area Test Sites. The procedures for maximizing emissions as described in this report were followed. All radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise in the "Justification Section" of this Application. 1.4Test Facility Sugar Hill Site #1 is constructed on a 50-foot by 70-foot concrete pad with a remote building for test and measurement equipment. The entire pad is covered with a ground plane of ¼” galvanized wire mesh soldered at the seams. The ground plane is tied to earth at six locations with ground rods. A steel two-meter flush-mount, remotely controlled turntable is installed in the pad. A 15’ x 15’ vinyl enclosure is installed over the turntable. The enclosure is constructed of all non- metallic materials. A non-conductive, remotely controlled antenna mast is used to raise the antenna from 1 to 4 meters during radiated emissions testing. A portable 2.0 meter vertical ground plane is used for line-conducted emissions measurements. Intertek Testing Services FCC ID: PD4PP10Test Report 3 1.5Test Equipment List The following test equipment was used during testing: DescriptionManufacturerModel NumberSerial NumberCalibration Date EMI ReceiverHewlett Packard8546A33410A001733/17/00 Bicon Log antenna…

Text truncated - open the document above for the full version.

Test Setup Photos

Intertek Testing Services FCC ID: PD4PP10EXHIBIT 61 EXHIBIT 6 Test Setup Photographs Lentek International FCC Part 15 Application For Certification (Low Power Transmitter) Pet Chime (Portable Wireless Electronic Pet Doorbell) Models: PP10 FCC ID: PD4PP10 Intertek Testing Services FCC ID: PD4PP10EXHIBIT 62 Radiated Emission Configuration Photograph X View Intertek Testing Services FCC ID: PD4PP10EXHIBIT 63 Radiated Emission Configuration Photograph Y View Intertek Testing Services FCC ID: PD4PP10EXHIBIT 64 Radiated Emission Configuration Photograph Z View
