PD5EASYWIFIWiFi Router for EasyST

IP-based Broadband Wireless Access (BWA) System EasyWiFi WiFi Extension Module for the EasyST Unit Hardware Installation Guide The Innovation Behind Broadband Wireless Connecting the World Revision Record: EasyWiFi Pub. No. Date Update Description 01 Dec-05 First edition. Author: MD 02 03-06 Additional Input: Author: MF Publication No. : 18120511-01 © Copyright by Airspan Networks Inc., 2005. All rights reserved worldwide. The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreement protecting Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this document or the information contained herein for any purposes other than those for which it was disclosed is strictly forbidden. Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use thereof. Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s) are for informational purposes only and are not warranties of future performance, either express or implied. Airspan Networks Inc. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks Inc. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks Inc. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks Inc. All specifications are subject to change without prior notice. Headquarters: Airspan Networks Inc. 777 Yamato Road Suite 105 Boca Raton, FL 33431 USA Tel: (+1) 561 893 8670 Fax: (+1) 561 893 8671 Main Operations: Airspan Communications Ltd. Cambridge House Oxford Road Uxbridge Middlesex UB8 1UN United Kingdom Tel: (+44) 1895 467 100 Web site: www.airspan.com EasyWiFi This page is intentionally left blank. EasyWiFi Contents 18120511-01 Airspan Networks Inc. i Contents About this Guide .................................................................................................... iii 1. Introduction .............................................................................................. 1-1 2. Physical Description ................................................................................ 2-1 2.1. Physical Dimensions ........................................................................... 2-1 2.2. Ports .................................................................................................... 2-2 2.3. WiFi Antenna....................................................................................... 2-4 2.4. Mounting Parts .................................................................................... 2-5 2.5. LEDs ................................................................................................... 2-6 3. Attaching EasyST..................................................................................... 3-1 4. Connecting to LAN................................................................................... 4-1 5. Mounting ................................................................................................... 5-1 5.1. Desktop Mounting ............................................................................... 5-2 5.2. Wall Mounting...................................................................................... 5-3 6. Connecting Power.................................................................................... 6-1 6.1. Changing the AC/DC Power Adapter's Prongs ................................... 6-2 6.2. Connecting AC/DC Power Adapter ..................................................... 6-3 7. Resetting EasyWiFi .................................................................................. 7-1 A. FCC Interference Statement ....................................................................A-1 B. Glossary ....................................................................................................B-1 C. EasyWiFi Specifications ..........................................................................C-1 D. Power Adapter Specifications.................................................................D-1 EasyWiFi Contents 18120511-01 Airspan Networks Inc. ii This page is intentionally left blank. 18120511-01 Airspan Networks Inc. iii About this Guide This chapter describes the purpose, targeted audience, referenced documentation, and typographical conventions of this document. Purpose This guide provides a description of the EasyWiFi extension module as well as instructions for installing the module. Targeted Audience This guide is intended for the end-user installing the EasyWiFi extension module for the EasyST. This device requires no professional installation. Typographical Conventions This guide uses the following typographical conventions: Convention Meaning Example Bold Command, menu, icon, button, and field Click the Next button. "To" in bold face and at the beginning of a sentence Introduces a numbered procedure To download a SW file: Warning that provides information that can prevent and avoid bodily or mechanical harm -- Note that provides useful information -- EasyWiFi Contents 18120511-01 A…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: 60302002 Date of Issue: March 20, 2006 Page 1 Total Page: 6 Rev. 00 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 60302002 Date of Issue: March 20, 2006 Page 2 Rev.00 Compliance Certification Services Inc. Report No: 60302002 Date of Issue: March 20, 2006 Page 3 Rev.00

Compliance Certification Services Inc. Report No: 60302002 Date of Issue: March 20, 2006 Page 4 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: 60302002 Date of Issue: March 20, 2006 Page 5 Rev.00 Compliance Certification Services Inc. Report No: 60302002 Date of Issue: March 20, 2006 Page 6 Rev.00 Dipole Antenna PIFA Antenna

承認圖案 APPROVAL DRAWING 客 戶 名 稱 : DELEA NETWORKS, INC. CUSTOMER NAME 製 品 類 別 : ANTENNA 日期: 2006/03/08 DESCRIPTION DATE 貴 社 機 種 名 : COSTOMER’S MODEL NO. 貴 社 部 品 ( 圖面 ) 番 號 : PA RT S (DRAWING) N O. 本 公 司 製 品 名 : ANTB98-058 OUR MODEL NO. 本 公 司 圖 面 番 號 : C94M0191 整理番號 : TT98058 D R A W I N G NO. FILE NO. 簽 章 處: TONE-SHINE ELECTRONICS INDUSTRIAL CO., LTD. HEAD OFFICE 東 省 電 機 股 份 有 限 公 司 SANSEI ELETTRIC CO., LTD. NO.6.496 LANE, KUAN-SHIN ROAD, 12 KUAN-LUN, 三省電機株式會社 T TAI-PIN AICHUNG TAIWAN 東京都品川區荏原 5 丁目 11 番 13 號 臺灣 臺中縣太平市光興路 496巷6號 TEL:886-4-2271 2765 TEL:03-37845151 〒1420036 FAX:886-4-2271 5021 FAX :03-37858851 天 線 產 品 規 格 TT98056 (ANTB98-056) ANTENNA SPECIFICATION PERFORMANCE 1. 一般事項(Generation) 1.1 適用範圍 此樣式表適用於2.4GHz 無線通訊系統所使用之天線。 Application Field: This approval sheet only use for Wireless Communication antenna of 2.4GHz Band. 1.2 使用溫度範圍 -20 ~ 65 °C Operation : -20 ~ 65 °C 1.3 保存溫度範圍 -30 ~ 75 °C Storage : -30 ~ 75 °C 1.4 測試狀態 溫度 5 ~ 35 °C、相對濕度 45 ~ 85%、氣壓 860 ~ 1060 hpa 的標準狀態下進行測試。 但是若對測試結果有質疑的話，可以於溫度 20 ± 2 °C、相對濕度 65 ± 5%、氣壓 860 ~ 1060hpa 的基準狀態進行測試。 Test Condition: T=5 ~ 35 °C , Humidity=45 ~ 85%. If any doubt and you could test under the following standard T= 20 ±2°C , Humidity = 65±5% , Atmosphere=860 ~1060hpa 2. 外觀、構造、尺寸 (Appearance , Construction , Dimension) 2.1 外觀 各部位的修飭加工良好，沒有對於機能有害的生銹、裂痕、瑕疵等等情形。 Appearance : Good manufacture of each parts and without rusting,cracking,defect...etc to damage product. 2.2 機能、尺寸 依據各個製品圖。 Construction, Dimension: According to each product drawing 3. 機械性能 Mechanical Performance 項目 ITEM 測試條件 TEST CONDITION 規格 SPECIFICATION 3.1 同軸電纜的抗拉 在同軸電纜的拉出方向，施加 1 kgf 的靜止負荷 同軸電纜不會脫落 重量一分鐘。 強度 No fall of Coaxial cable. Tensile of Coaxial To load 1Kgf weight within 1 minute. Cable Remarks: This test only for pigtail type. 4. 電氣的性能 Electrical Properties 項目 ITEM 測試條件 TEST CONDITION 規格 SPECIFICATION 4.1 駐波比 VSWR 4.2 反射損失 Return Loss 4.3 特徵阻抗 Impedance 4.4 指向性 Certain direction 4.5 最大增益 Max GAIN 放置在自由空間進行檢測。To test on free space. (VSWR & Return Loss 使用網路分析儀檢測） (VSWR & Return Loss testing by Network Analyzer .) 2.0 以下 @ (2.4 GHz ~ 2.5 GHz) -10 dB 以下@ (2.4 GHz ~ 2.5 GHz) 50Ω 公稱 Omni 2.1dBi @2..5GHz of H-Plane pattern 5. 耐氣候性 Environmental Performance 項目 ITEM 測試條件 TEST CONDITION 規格 SPECIFICATION 5.1 耐熱性 放置在溫度 60 ±2°C中，96 小時後在正常溫濕度下放 外觀、構造無異常 Temperature Life 置 1 小時進行檢測。 To put antenna at 60±2°C within 96 hrs then take it out to put at normal environment within 1 hour later to detect. 機械性能無異常 符合電氣性能（4.1& 4.2 項） No abnormal of appearance, construction, mechanical. 5.2 耐寒性 Cold Life 5.3 耐溫性 ( 穩定狀態） Humidity ( Stable ) 5.4 熱沖擊測試 Thermal Shock 放置在 -10 ±2°C中，96 小時以後，再置於正常溫濕度 1 小時進行檢測。 To keep in -10±2°C within 96hrs and take out to put at normal environment within 1 hour later to detect. 放置在+40 ±2°C，相對濕度 90 ~ 95%的狀態，96 小時 以後，再置於正常溫濕度 1 小時進行檢測。 To keep in +40±2°C , damp=90~95% within 96 hrs and take it out to put at normal environment within 1 hour later to detect. -20°C，+60°C的狀態各放置 1 小時視為 1 週期，測試 10 週期後，再放置於正常溫濕度 1 小時後進行檢測。 To put antenna at -20°C & +60°C and eac h degree for 1 hour as a cycle , totally need to repeat 10 cycles then put at normal environment within 1 hour later to detect. Meet electrical request( Item 4.1& 4.2) (註）電氣性能項目的檢測機器 (Remarks) Testing equipments for electrical properties test. 檢測器：Agilent Network Analyzer E8358A 1. VSWR Antenna Center freg. @MHz BW @MHz VSWR 2.4GHz 2.45GHz 2.5GHz TT98058 2450 100 1.313 1.144 1.328 Test results Test results 1. Return Loss Antenna Center freg. BW Return Loss @MHz @MHz 2.4GHz 2.45GHz 2.5GHz TT98058 2450 100 -17.352 -23.456 -17.017 - 天 線 名 称 ： NO : TT98058 天 線 名 称 : NO : TT98058 ： 2400-2500MHz ： 2400-2500MHz ： H-Plane ： H-Plane 測 定 頻 率 ： 2400 MHz 測 定 頻 率 ： 2450 MHz 標準天線電平 ： -50.6 dBm 標準天線電平 ： -51.2 dBm 天 線 増 益 ： -0.2 dBd ( 1.9 dBi ) 天 線 増 益 ： -0.8 dBd ( 1.3 dBi ) 平 均 増 益 ： -2.6 dBd 平 均 増 益 ： -2.7 dBd 水 平 面 方向図 90 ゚ 水 平 面 方向図 90 ゚ (X-Y PLANE) (X-Y PLANE) 180 ゚ 0 ゚ 180 ゚ 0 -10 -20 -30dB 0 -10 -20 -30dB 270 ゚ 270 ゚ F ILE NAME = 0603061304.dat FILE NAME = 0603061304a.dat 天 線 名 称 ： NO : TT98058 ： 2400-2500MHz ： H-Plane 測 定 頻 率 ： 2500 MHz 標準天線電平 ： -52.6 dBm 天 線 増 益 ： 0.0 dBd ( 2.1 dBi ) 平 均 増 益 ： -1.9 dBd 水 平 面 方向図 90 ゚ (X-Y PLANE) 180 ゚ 0 ゚ 0 -10 -20 -30dB 270 ゚ F ILE NAME = 0603061305.dat (1). Radiation Pattern of H-Plane 3.Free Space 天線輻射場形 天 線 名 称 ： NO : TT98058 天 線 名 称 ： NO : TT98058 ： 2400-2500MHz ： 2400-2500MHz ： E-Plane ： E-Plane 測 定 頻 率 ： 2400 MHz 測 定 頻 率 ： 2450 MHz 標準天線電平 ： -50.6 dBm 標準天線電平 ： -51.2 dBm 天 線 増 益 ： -0.8 dBd ( 1.3 dBi ) 天 線 増 益 ： -1.2 dBd ( 0.9 dBi ) 平 均 増 益 ： -5.4 dBd 平 均 増 益 ： -5.3 dBd 垂直面 前／後 方向図 90 ゚ 垂直面 前／後 方向図 90 ゚ (Z-X PLANE) (Z-X PLANE) 180 ゚ 0 ゚ 180 ゚ 0 ゚ 0 -10 -20 -30dB 0 -10 -20 -30dB 270 ゚ 270 ゚ F ILE NAME = 0603061410.dat FILE NAME = 0603061410a.dat 天 線 名 称 ： NO : TT98058 ： 2400-2500MHz ： E-Plane 測 定 頻 率 ： 2500 MHz 標準天線電平 ： -52.6 dBm 天 線 増 益 ： -1.3 dBd ( 0.8 dBi ) 平 均 増 益 ： -4.5 dBd 垂直面 前／後 方向図 90 ゚ (Z-X PLANE) 180 ゚ 0 ゚ 0 -10 -20 -30dB 270 ゚ FILE NAME = 0603061411.dat (2). Radiation Pattern of E-Plane

Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 73 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For WiFi Router for EasyST Model: EasyWiFi Trade Name: Airspan Issued to DELTA NETWORKS, INC. 252, Shang Ying Road, Kuei San Industrial Park, Taoyuan Shien 33341,Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. http://www.ccsemc.com.tw [email protected] Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................3 2. EUT DESCRIPTION ........................................................................................................................4 3. TEST METHODOLOGY .................................................................................................................5 3.1 EUT CONFIGURATION.....................................................................................................................5 3.2 EUT EXERCISE.................................................................................................................................5 3.3 GENERAL TEST PROCEDURES..........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.....................................................6 3.5 DESCRIPTION OF TEST MODES........................................................................................................7 4. INSTRUMENT CALIBRATION.....................................................................................................8 4.1 MEASURING INSTRUMENT CALIBRATION...................................................................................8 4.2 MEASUREMENT EQUIPMENT USED......................................................................................8 5. FACILITIES AND ACCREDITATIONS .......................................................................................9 5.1 FACILITIES .... .................................................................................................................................9 5.2 EQUIPMENT.....................................................................................................................................9 5.3 TABLE OF ACCREDITATIONS AND LISTINGS..................................................................................10 6. SETUP OF EQUIPMENT UNDER TEST ....................................................................................11 6.1 SETUP CONFIGURATION OF EUT....................................................................................................11 6.2 SUPPORT EQUIPMENT ............................................................................................................11 7. FCC PART 15.247 REQUIREMENTS..........................................................................................12 7.1 6 DB BANDWIDTH..........................................................................................................................12 7.2 PEAK POWER.................................................................................................................................16 7.3 A VERAGE POWER.........................................................................................................................20 7.4 BAND EDGES MEASUREMENT .............................................................................................24 7.5 PEAK POWER SPECTRAL DENSITY.................................................................................................41 7.6 SPURIOUS EMISSIONS .............................................................................................................46 7.7 POWERLINE CONDUCTED EMISSIONS............................................................................................66 APPENDIX 1 RADIO FREQUENCY EXPOSURE ...........................................................................69 APPENDIX 2 PHOTOGRAPHS OF TEST SETUP ...........................................................................71 Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Page 4 Rev. 00 2. EUT DESCRIPTION Product WiFi Router for EasyST Trade Name Airspan Model Number EasyWiFi Model Discrepancy N/A Power Supply Power Adapter YCL / PWA-024060G I/P: AC 100-240V, 50-60Hz O/P: DC 6V, 4A Frequency Range 2412 ~ 2462 MHz Transmit Power IEEE 802.11b: 19.26 dBm IEEE 802.11g: 19.27 dBm Modulation Technique IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: DSSS (CCK, DQPSK, DBPSK) + OFDM (QPSK, BPSK, 16-QAM, 64-QAM) Transmit Data Rate IEEE 802.11b: 11, 5.5, 2, 1 Mbps IEEE 802.11g: 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps Number of Channels 11 Channels Antenna Specification DELTA NETWORKS, INC. External Antenna: Dipole Antenna / Gain: 2.1 dBi Internal Antenna: PIFA Antenna / Gain: 1.77 dBi Remark: 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. This submittal(s) (test report) is intended for FCC ID: PD5EASYWIFI filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance wi…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Page 71 Rev. 00 APPENDIX 2 PHOTOGRAPHS OF TEST SETUP Conducted Emissions Setup Photos Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Page 72 Rev. 00 Radiated Emissions Setup Photos Compliance Certification Services Inc. Report No.: 60302002-RP1 FCC ID: PD5EASYWIFI Date of Issue: March 20, 2006 Page 73 Rev. 00 Powerline Conducted Emissions Setup Photos
