PD5LMWA200WLAN PCI Adapter

Wireless PCI Adapter User Manual Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interfere nce received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna, (2) Increase the separation between the equipment and receiver, (3) Connect the equipment into an outlet on a circuit different from that to wh ich the receiver is connected, (4) Consult the dealer or an experienced radio/TV technician for help. Federal Communications Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation. Wireless PCI Adapter iii TABLE OF CONTENT INTRODUCTION ............................................................................. 1 CONNECT THE PCI ADAPTER TO YOUR DESKTOP PC ...... 2 H ARDWARE I NSTALLATION ............................................................... 2 DRIVER INSTALLATION............................................................... 3 I NSTALL D RIVER U NDER W INDOWS 98 ............................................ 3 I NSTALL D RIVER U NDER W INDOWS ME .......................................... 7 I NSTALL D RIVER U NDER W INDOWS 2000 ...................................... 10 I NSTALL D RIVER U NDER W INDOWS NT ......................................... 14 I NSTALL D RIVER U NDER W INDOWS XP ......................................... 28 CONFIGURATION UTILITY .... ................... ................... ............. 31 I NSTALL THE C ONFIGURATION U TILITY .......................................... 31 C ONFIGURE THE C ONFIGURATION U TILITY .................................... 34 Wireless PCI Adapter 1 Introduction The Wireless PCI Adapter solution overcomes the limitations of wired networks by providing fast, simple, mobile and reliable access. It is designed for desktop computers running Windows 98, 2000, NT V4.0 SP6, Millennium and XP. Features ƒ 11 Mbps High-Speed Transfer Rate ƒ Interoperable with IEEE 802.11b(DSSS) 2.4GHz-compliant Equipment ƒ Plug-and Play Operation Provides Easy Setup ƒ Utilizes Intersil Prism 2.5 chip sets ƒ Advanced Power Management Features Conserve Valuable Notebook PC Battery Life ƒ Direct Sequence Spread Spectrum Compatible to Prevent Lost Connections ƒ Rugged Metal Design with Integrated Antenna ƒ Wired Equivalent Privacy (WEP) 64-bit or 128-bit data encryption ƒ Driver Supports Windows 98, Millennium, NT V4.0 SP6, 2000 and XP Wireless PCI Adapter 2 Connect the PCI Adapter to Your Desktop PC Hardware Installation ƒ Shut down your desktop PC. ƒ With the PC Card’s 68-pin connector facing the PCI Adapter’s slot and the “Network PC Card” label facing up, slide the PC Card completely into the PCI Adapter. ƒ Open your PC case and locate an available PCI slot in the motherboard. ƒ Slide the PCI Adapter into the PCI slot. Make sure that all of its pins are touching the slot’s contacts. You may have to apply a bit of pressure to slide the card all the way in. After the card is firmly in place, secure its fastening tab to your PC’s chassis with a mounting screw. Then, close your PC. ƒ Power on your desktop PC. ƒ Insert the driver CD into your CD drive. ƒ The Hardware Installation is complete. Wireless PCI Adapter 3 Driver Installation Install Driver Under Windows 98 1. Windows 98 will automatically recognize a new PCI Network Controller device. Click the Next button to proceed. 2. Windows will notify you that it is unable to locate the driver and will ask you to specify where the driver is located. Click the Other Location button to select the driver’s location. Wireless PCI Adapter 4 3. This will bring you to the Select Other Location screen. Click the Browse button to select the driver’s location. At this point, Windows will ask you to browse for the driver’s folder. Simply select the folder in which the driver is located. 4. Windows is now ready to install the driver. Click the Next button to continue. Wireless PCI Adapter 5 5. Windows has now completed installing the network. Click the Finish button to continue. 6. After installing the drivers, the System Setting Change screen will show you that installation is complete. Click the Ye s button to finish. Wireless PCI Adapter 6 7. Click right on My computer and select properties . Select Device Manager and click on the Network adapters . You will find the LM-WA200 IEEE 802.11 PCI Card if it is installed successfully. The PCI Adapter driver installation is finished. Wireless PCI Adapter 7 Install Driver Under Windows ME 1. Windows automatically recognizes a new PCI Adapter added. Select Automatic search for a better driver [Recommended] and click the Next button to proceed. 2. At this point, Windows will ask for the cw10.sys file. Browse the driver of the CD-ROM. Wireless PCI Adapter 8 3. Windows will n…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 4

FCC ID Label Location

50 x 50 mm Tested To Comply With FCC Standards FOR HOME OR OFFICE USE WLAN PCI Adapter This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PD5LMWA200 SERIAL MAC

Page 2 Page 3

FCC ID: PD5LMWA200 ADT No.901005R01 Operational Description The transmitter of the EUT (WLAN PCI Adapter) is powered by host equipment from PCI Slot. The antenna is Monopole antenna, and the antenna connector is Reversed SMA. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PD5LMWA200 Report No.: RF901005R01 1 Issued: October 25, 2001 FCC TEST REPORT REPORT NO.: RF901005R01 MODEL NO.: LM-WA200 RECEIVED: October 4, 2001 TESTED: October 16 ~ October 23, 2001 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 8, Kon Jan West Road, Liutu Industrial Zone, Keelung, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 58 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: PD5LMWA200 Report No.: RF901005R01 2 Issued: October 25, 2001 Table of Contents 1CERTIFICATION ...........................................................................................4 2SUMMARY OF TEST RESULTS...................................................................5 3GENERAL INFORMATION ...........................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................6 3.2DESCRIPTION OF TEST MODES................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ...............................7 3.4DESCRIPTION OF SUPPORT UNITS..........................................................8 4TEST TYPES AND RESULTS.......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.................................................... 9 4.1.2TEST INSTRUMENTS....................................................................................................... 9 4.1.3TEST PROCEDURES..................................................................................................... 10 4.1.4TEST SETUP .................................................................................................................. 10 4.1.5EUT OPERATING CONDITIONS..................................................................................... 11 4.1.6TEST RESULTS (A) ........................................................................................................ 12 4.1.7TEST RESULTS (B) ........................................................................................................ 18 4.2RADIATED EMISSION MEASUREMENT ...................................................24 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 24 4.2.2TEST INSTRUMENTS..................................................................................................... 25 4.2.3TEST PROCEDURES..................................................................................................... 26 4.2.4TEST SETUP .................................................................................................................. 27 4.2.5EUT OPERATING CONDITIONS..................................................................................... 27 4.2.6TEST RESULTS (A) ........................................................................................................ 28 4.2.7TEST RESULTS (B) ........................................................................................................ 32 4.36DB BANDWIDTH MEASUREMENT ..........................................................36 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT.............................................................. 36 4.3.2TEST INSTRUMENTS..................................................................................................... 36 4.3.3TEST PROCEDURE........................................................................................................ 37 4.3.4TEST SETUP .................................................................................................................. 37 4.3.5EUT OPERATING CONDITIONS..................................................................................... 37 4.3.6TEST RESULTS ..............................................................................................................38 4.4MAXIMUM PEAK OUTPUT POWER ..........................................................42 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................. 42 4.4.2INSTRUMENTS...............................................................................................................42 4.4.3TEST PROCEDURES..................................................................................................... 43 4.4.4TEST SETUP .................................................................................................................. 43 4.4.5EUT OPERATING CONDITIONS..................................................................................... 43 4.4.6TEST RESULTS ..............................................................................................................44 4.5POWER SPECTRAL DENSITY MEASUREMENT......................................45 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ......................................... 45 4.5.2TEST INSTRUMENTS..................................................................................................... 45 4.5.3TEST PROCEDURE........................................................................................................ 46 4.5.4TEST SETUP .................................................................................................................. 46 4.5.5EUT OPERATING CONDITION ....................................................................................... 46 4.5.6TEST RESULTS ................................................................................…

Text truncated - open the document above for the full version.

FCC ID: PD5LMWA200 Report No.: RF901005R01 56 Issued: October 25, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PD5LMWA200 Report No.: RF901005R01 57 Issued: October 25, 2001 RADIATED EMISSION TEST
