Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Tested To Comply With FCC Standards FOR HOME OR OFFICE USE This device complies with Part 15 of the FCC Rules. Operation is subject to The following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WLAN CF Card FCC ID: PD5LMWCF210 SERIAL MAC

Page 3

Page 4 Page 5

FCC ID: PD5LMWCF210 ADT No.901009R03 Operational Description The transmitter of the EUT (WLAN Compact Flash Card) is powered by notebook and plugged in PCMCIA Slot. The antenna is Inverted F Antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PD5LMWCF210 ADT No.: 901009R03 FCC TEST REPORT REPORT NO.: RF901009R03 MODEL NO.: LM-WCF210 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 252,Shang Ying Road,Kuei San Taoyuan Shien 333,Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PD5LMWCF210 ADT No.: 901009R03 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: PD5LMWCF210 ADT No.: 901009R03 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: PD5LMWCF210 ADT No.: 901009R03 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -1dBi or 0.79 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241264.422.01 6243765.612.03 11246264.122.00 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

55 44 33 22 11 D D C C B B A A ISL3873 PIN NUMBERS NOTED 5MA NOTE:HRESET IS ACTIVE HIGH AND TIED HIGH INTERNALLY IN THE ISL3873 NO POP EEPROM (U2,C1 ,AND R101) WHEN USING PARAL LEL FLASH NO POP R41,R23,R26,R27,R29WHEN USING PARALLEL FLASH NO POP ISL3873 PIN NUMB ERS NOTED ISL3873 PIN NUM BERS NOTE ANALOG DIGITAL LM-WCF210.DSN CHECKED DRAWN WLAN CF+ CARD APPROVED SCHEMATICS OF FILES NAME DESIGNEDED 2976168701 01 LM-WCF210 13 Wednesday, August 01, 2001 TitleSize Document Number Rev Date: Sheet of MA16 HD3 HC5 MA10 HC5 MA7 HC1 MA2MA12 MA16MA3MA8 HC6 MA10 MA8 MA2 HD1 MA5 HC2 HA9 HC11 MA9 MA7 HD9 HD12HD13HD6 MA11 MA9 HC7 MA14 HA6 MA5 HC2 HD6 MA3 MA14 HD14 MA5 MA9 HC0 MA4 HC3 MA4 HC7 MA17 HD0HA4 HC10 HA5 HA2 MA[17..1] HC10 MA1 HC4 HD7 HD1HD12 MA6 HD[15..0] HD9 HA3 XTAL_IN HA1 HC4 HA7 MA7MA8 HC0 MA6 MA2 HC9 HA8 HA1 HC1 HC8 MA11 MA14 MA3 HD2HD4 MA17 XTAL_OUT HD15 HD2 HA6 MA12 MA13 MA6 HA2HA0 HC[11..0] HD14HD13 MA15 MA1 MA13 HD7 HC8 HD5 HD10 HA4 HD11 HD11 MA1 HD0 HA3HA8 HD8 MA15 HC3HC6 HC9 HC11 MA10 HA0 HD8 MA15 MA16 HD15 HD5 MA13 HA[9..0] MA12 MA11 HD3 HA5 HD10 MA4 HA9HA7 HD4 MEM_CTRL0MEM_CTRL1 MD10MD13 MEM_CTRL[5..0] MD2 MEM_CTRL3 MD0 MD1 MD3MD5 MEM_CTRL2MEM_CTRL3 MD12MD14 MEM_CTRL[5..0] MD1MD12 MD4 MD6 MD[15..0] MD9 MEM_CTRL2 MD9 MEM_CTRL4 MD4 MD0 MD10 MD7 MD7 MEM_CTRL5 MD6 MD8 MEM_CTRL1 MEM_CTRL4 MD15 MD13MD15 MEM_CTRL0 MD3 MD2 MD6 MD0MD11 MD8MD14MD11 MD1 MD3 MEM_CTRL2 MEM_CTRL3 MD7 MEM_CTRL5MEM_CTRL1 MD2 MD4 MD5 MD5 MD[15..0] MA[17..1] IF_DETVREFTX_DET LED1 RX_RF_AGCRXQ- 44MHZ_REF RX_IF_AGCLE_RFPE2RXQ+T/R_SWPE1SD_RF_IFRXI-RXI+TXI+ LED1 RADIO_PESCLK_RF_IFLE_IFTX_IF_AGCT/R_SW*CAL_ENTXQ-TXQ+PA_PE 44MHZ_REF TXI- VCCS VCCS VCCS VCCS VCCS VCCS +3.3V VCCS VCCS +3.3V +3.3V VCCS VCCS VCCS VCCS R101 NC 47K C5 0.1UF C20 0.1UF C30 0.1UF TP5 U3 32KHZ 1 2 3 12 CASE R57 10K C3 0.1UF L3 BLM21P300SPT TP4 R33 19.1K C9 10UF R4 220K R1110K R27 NC 10K C250.01UF R29NC 10K C10 0.1UF C70.1UF U1 EM128L16B E4 F4F3 G4G3 H5H4H3H2D4C4C3 B4B3A5A4A3 G1F1F2E2D2C2C1B1G6F6F5E5D5C5C6 D1 E6 E1 D6 B5A2 G5 A1B2 H6H1G2E3D3A6B6 A16A15A14A13A12A11A10A9A8A7A6A5A4A3A2A1A0 I/O15I/O14I/O13I/O12I/O11I/O10 I/O9I/O8I/O7I/O6I/O5I/O4I/O3I/O2I/O1 VSS VSS VCC VCC CE*OE*WE*LB*UB* NCNCNCNCNCNC I/O0 R30976 C4 0.1UF R34 19.1K C8 0.1UF TP3 R26 NC 10K C34 10UF R1 10K C138 220PF U4 ISL3873 A13B12 C12 A15 D13 B14E13 F15F16 H15 A12 C9C6 B8 C10 F14F13 H16C11 C8D8C7 A9 H13H14 G15 D11D16 B11 D10 B9 A10E15 D9 G14 D14 B13 C16 B16 C14 A7B7 D6 K13 P3P2 T3T1 R1 T15 P13 R13 C5 K1 J1J2 G16 M14 E4 C2R2N5R3 P14 R15 T16 P15 R16N14 P16 C15 A16B15 D12 A1B2 K14 K15 P9 P5 M15 M3 L13 K4 G13 E16 E3 E1 D7 C13 A11 A5 N10 P10 T11 T13 N13 N9 F2G4D1E2F4C1D3D2B3A2C3B4A3D4C4A4D5B6A6N2P1N4N3N1M1M4L2L1L4L3H3G1H4G2F1K2K3H2J4J3F3P11N12R14T14R12T12R9T9R7T7T4P6T6N15L14N16R10T10P7N6P4R5R4T5N7R6L16L15J16J15J13 D15 P8 N8 M13 T8 R11 R8 P12 N11 T2 M16 M2 K16 J14 H1 G3 E14 B10 B5 B1 A14 A8 HA9HA8HA7HA6HA5HA4HA3HA2HA1HA0HD15HD14HD13HD12HD11HD10HD9HD8HD7HD6HD5HD4HD3HD2HD1HD0HOEHREGHIORDHIOWRHCE1HCE2HINPACKHRDY/HIREQHSTSCHGHWAITHWERESETDBG4DBG3DBG2DBG1DBG0TESTMODETCLKIN(CS)EEPROMPJ2(MISO)EEPROMPJ6(LED1)PJ0(SCLK)EEPROMPJ1(SDATA)EEPROMCOMPRES1COMPRES2COMPCAP2CLKOUTCLKINXTALINXTALOUTBBP_CLKCOMPCAP1NCNCNCNCNCNCNCNCNCNCNCNCNCNCNCNCNCNC GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND GND VSUB VSUB VSSA VSSA VSSA VSSA MA1MA2MA3MA4MA5MA6MA7MA8MA9 MA10MA11MA12MA13MA14MA15MA16MA17MA18MA19 MD0MD1MD2MD3MD4MD5MD6MD7MD8MD9 MD10MD11MD12MD13MD14MD15MOE* MWEL* MLBE* NVCS* RAMCS* MWEH_MA0* VREF IREF TXQ+ TXQ- TXI+ TXI- RXQ+ RXQ- RXI+ RXI- PK1(SYNTHCLK) PL7(TR_SW)PL3(TR_SW) RX_IF_AGC RX_RF_AGC TX_IF_AGC RX_IF_DET TX_AGC_IN PK7(CAL_EN) PJ7(RADIO_PE) PJ5(LE_IF) PK0(LE_RF) PJ4(PE1) PK4(PE2) PK2(SYNTHDATA) PK3(PA_PE) ANT_SEL ANT_SEL* PL5-USB+ PL6-USB- USB_DET SUPPLY/5V VDDA VDDA VDDA VDDA VDDA VDDA VDDA VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD VDD C81 0.1UF R3212.1K TP1 C26 0.1UF C102 10UF C21 0.1UF C6 0.1UF P1 CON50 1234567891011121314151617181920212223242526272829303132333435363738394041424344454647484950 GND D03D04D05D06D07 #CE1 A10 #OE A09A08A07 VCC A06A05A04A03A02A01A00 D00D01D02 #IOIS16 #CD2#CD1 D11D12D13D14D15 #CE2 #VS1 #IORD #IOWR #WE IREQ VCC #CSEL #VS2 RESET #WAIT #INPACK #REG #SPKR #STSCHG D08D09D10 GND D4 LED C1220.1UF C31 0.1UF C14 0.1UF R102 NC C32 0.1UF TP2 R310M C131 10PF C18 0.1UF R41 NC 10K R14560 L17 BLM21P300SPT C2 0.1UF R23 NC 10K R2560 R6 470 C1 NC 0.1UF U5 SST39VF010 1011 54 12 1 31 23 13141516171819203032 7 24 292827262523222196 8 A16A15A14A13A12A11A10A9A8A7A6A5A4A3A2A1A0CE*OE*WE* VSS DQ7DQ6DQ5DQ4DQ3DQ2DQ1DQ0 NCNC VDD R28619 C11 0.1UF U2 AT24C08A 8765 1234 VCC WP SCL SDA A0A1A2GND D5LED R103 470 C149 0.1UF C150 0.1UF C151 0.1UF R104 0 R105 0 CC11 NC 0.1UF CC8 NC 0.1UF CC1 NC 0.1UF CC5 NC 0.1UF CC7 NC 0.1UF CC9 NC 0.1UF CC3 NC 0.1UF CC2 NC 0.1UF CC6 NC 0.1UF CC10 NC 0.1UF CC4 NC 0.1UF 55 44 33 22 11 D D C C B B A A NO POP L22 WHEN USING EPCOS FILTER NOTE: CALCULATED FOR ICP=250UA APPROVED WLAN CF+ CARD FILES NAME DESIGNEDED CHECKED SCHEMATICS OF DRAWN LM-WCF210.DSN 2976168701 01 LM-WCF210 23 Wednesday, August 15, 2001 TitleSize Document Number Rev Date: Sheet of TXI-TXQ+TXQ-TXI+RXI-RXQ+RXQ-VREFRXI+ RADIO_PEPE2CAL_ENRX_IF_AGCTX_IF_AGCPE1 IF_DET SCLK_RF_IFLE_IFSD_RF_IF 44MHZ_REF 44MHZ_CW VCCA +3.3V VCCB VCCB VCCB U6 F4106-44.000M 412 3 VDDENBGND OUT FL1 B3677 32 76 1 5 4 8 ININRTN OUT OUTRTN GROUNDS GROUNDS GROUNDS GROUNDS C45 220PF C46 220PF L6 39NH L9 33NH L10 33NH C5210PFC5110PFC53 0.01UF R40 2K R45 2.87K C70 0.1UF C72 0.1UF L22 NC 15NH L5 39NH C39220PFC44 220PF R49100 R47100 C88 100PF C85 100PF C93 0.1UF C110 68PF C120 68PF C121 0.1UF R58124 R59536 R62124 R67124 R70536 R66124 C134 10UF C136 10UF C133 0.1UF C137 0.1UF C124100PFC1030.01UF C91 0.022UF C100 0.22UF C107 3900PF R553.92K R52 2K C890.1UF C84 0.1UF C76 1000PF C801000PF C27 1000PF C33 0.1UF C24 22PF R24 0 R82 0 R151.5K L1 560NH L21 BLM21P300SPT C135 0.1UF U9 HFA3783 123456789 101112 13 14 15 16 17 18 19 20 21 22 23 24 363534333231302928272625 48 47 46 45 44 43 42 41 40 39 38 37 RX_AGC_VCCSPAREIF_RX+IF_RX-TX_BI…

Text truncated - open the document above for the full version.

FCC ID: PD5LMWCF210 Report No.: RF901009R03 1 Issued: October 16, 2001 FCC TEST REPORT REPORT NO.: RF901009R03 MODEL NO.: LM-WCF210 RECEIVED: September 25, 2001 TESTED: Sep.26 ~ Oct. 15, 2001 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 252,Shang Ying Road,Kuei San Taoyuan Shien 333,Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PD5LMWCF210 Report No.: RF901009R03 2 Issued: October 16, 2001 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS ................................................................... 5 3GENERAL INFORMATION............................................................................ 6 3.1GENERAL DESCRIPTION OF EUT.............................................................. 6 3.2DESCRIPTION OF TEST MODES ................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................... 7 3.4DESCRIPTION OF SUPPORT UNITS .......................................................... 8 4TEST TYPES AND RESULTS ....................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .............................. 9 4.1.2TEST INSTRUMENTS................................................................................... 9 4.1.3TEST PROCEDURES ................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS ................................................................ 11 4.1.6TEST RESULTS .......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................. 18 4.2.2TEST INSTRUMENTS................................................................................. 19 4.2.3TEST PROCEDURES ................................................................................. 20 4.2.4TEST SETUP .............................................................................................. 21 4.2.5EUT OPERATING CONDITIONS ................................................................ 21 4.2.6TEST RESULTS .......................................................................................... 22 4.36DB BANDWIDTH MEASUREMENT .......................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 26 4.3.2TEST INSTRUMENTS................................................................................. 26 4.3.3TEST PROCEDURE.................................................................................... 27 4.3.4TEST SETUP .............................................................................................. 27 4.3.5EUT OPERATING CONDITIONS................................................................ 27 4.3.6TEST RESULTS .......................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 32 4.4.2TEST INSTRUMENTS................................................................................. 32 4.4.3TEST PROCEDURES ................................................................................. 33 4.4.4TEST SETUP .............................................................................................. 33 4.4.5EUT OPERATING CONDITIONS ................................................................ 33 FCC ID: PD5LMWCF210 Report No.: RF901009R03 3 Issued: October 16, 2001 4.4.6TEST RESULTS .......................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ...................................... 35 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 35 4.5.2TEST INSTRUMENTS................................................................................. 35 4.5.3TEST PROCEDURE.................................................................................... 36 4.5.4TEST SETUP .............................................................................................. 36 4.5.5EUT OPERATING CONDITIONS ................................................................ 36 4.5.6TEST RESULTS .......................................................................................... 37 4.6BAND EDGES MEASUREMENT ................................................................ 41 4.6.1LIMITS OF BAND EDGES MEASUREMENT .............................................. 41 4.6.2TEST INSTRUMENTS................................................................................. 41 4.6.3TEST PROCEDURE.................................................................................... 41 4.6.4EUT OPERATING CONDITION .................................................................. 42 4.6.5TEST RESULTS .......................................................................................... 42 4.7ANTENNA REQUIREMENT ........................................................................ 45 4.7.1STANDARD APPLICABLE ...........…

Text truncated - open the document above for the full version.

FCC ID: PD5LMWCF210 Report No.: RF901009R03 46 Issued: October 16, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PD5LMWCF210 Report No.: RF901009R03 47 Issued: October 16, 2001 RADIATED EMISSION TEST
