PD5LMWP100Wireless PCMCIA LAN Card

802.11B 11Mbps Wireless PCMCIA Quick setup in Windows 98 Install Driver ! Insert the Wireless PCMCIA into the slot ! Windows98 automatically detects a new device added. ! Follow Windows 98 instructions to do the installation. Please use the driver provided on the Driver CD. Configure the Wireless PCMCIA There are two ways to do the configurations. One is to use the Utility software. The other is to use the Wireless PCMCIA property dialog. (1) Configuration via the Properties of the Wireless PCMCIA adapter: ! Click Start, point to Settings, and then click Control Panel. ! Double click Network icon, point to the Wireless PCMCIA adapter, and then click Properties. ! IEEE 802.11 Properties dialog shows. User can use it to do the configuration like channel, SSID, transmit rate.. and so on. ! (2) Configuration via utility software: ! Find the setup.exe program in the Utility directory of the CD ! Execute Utility setup software. ! Once setup is complete, run the utility program by double-clicking the “Configuration Utility” icon. ! An Utility icon will show at right corner on the screen. Click this icon to prompt the configuration dialog. Users can do the configuration on this dialog. Technical Specification: Standard CompliantIEEE 802.11b Standard Data Transmission Rate11/5.5/2/1Mbps SecurityWired Equivalent Privacy (WEP) data encryption for security Frequency Band2.4GHz ISM frequency band 2400-2483.5MHz for US, Canada 2400~2497MHz for Japan and ETSI Wireless MediumDirect Sequence Spread Spectrum (DSSS) Modulation TechniqueDBPSK@1Mbps DQPSK@2Mbps [email protected] and 11Mbps Operating Channels11 channels for US and Canada 13 channels for ETSI 14 channels for Japan Operating Range (Typical)Outdoor environment: 1Mbps – 1000 feet (305 meters) 2Mbps – 750 feet (228 meters) 5.5Mbps – 600 feet (183 meters) 11Mbps – 400 feet (122 meters) Indoor environment 1Mbps – 300 feet (91 meters) 2Mbps – 240 feet (73 meters) 5.5Mbps – 200 feet (61 meters) 11Mbps – 120 feet (37 meters) AntennaBuilt-in dual diversity antenna Receive Sensitivity (Typical)[email protected] (8% PER) -84dBm@11Mbps (8% PER) InterfacePCMCIA Type II, 3.3Volts/5Volts Output Power (Typical)13dBm Operating SystemWindows 95/98/NT 4.0, Windows 2000 Electromagnetic EmissionFCC Part 15 Operating Environment Operation Temperature: 0~40°C Storage Temperature: -20~70°C Operation Humidity: 10~90% RH

Delta Networks Inc. 1 LM-WU110 Wireless Product Specification -- IEEE 802.11b WLAN USB Note: This document contains proprietary technical information in which is the property of the Delta Networks Inc. and shall not be disclosed to others in whole or in part, reproduced, copied, or used as the basis for design, manufacturing, or sale of apparatus without written permission of Delta Networks Inc. Delta Networks Inc. 2 Table Of Contents 1.REVISION HISTORY.................................................................................................................................................. 3 1.1.Product Revision History ......................................................................................................................3 1.2.Document Revision History ..................................................................................................................3 2.GENERAL DESCRIPTION ........................................................................................................................................ 4 2.1.Features ...............................................................................................................................................4 2.2.Mechanical Design ...............................................................................................................................5 2.3.LED Definitions.....................................................................................................................................6 2.4.IC Solution ............................................................................................................................................7 3.TECHNICAL SPECIFICATIONS .............................................................................................................................. 8 4.DELIVERY PACKAGE ............................................................................................................................................... 9 4.1.Labels for Gift box and Carton .............................................................................................................9 Delta Networks Inc. 3 1. Revision History 1.1. Product Revision History RevisionDateRemark 02000/12/11! Product Initial 1.2. Document Revision History RevisionDateRemark 1.002000/12/11! Preliminary specification 1.012000/12/13! Modify the ID design(antenna) ! Modify RF Link LED definitions ! ! ! ! Delta Networks Inc. 4 2. General Description LM-WU110 is a Wireless-to-USB product which provides a USB-to-wireless seamless connection. The Wireless interface is IEEE802.11b standard compatible. Its data transmission rate is 11Mbps. The USB interface is USB 1.0 compliant. It provides 12Mbps data rate. In this design, no extra power supply needs. 2.1. Features ! Complies with the IEEE 802.11b Direct Sequence Specification ! Complies with USB specification 1.0 ! Supports 1, 2, 5.5 and 11Mbps Data Rate on the wireless interface ! Supports12Mbps Data Rate on the USB interface ! WEP 40-bit data encryption for security ! With Roaming capability ! Provides Firmware upgrade utility to do the upgrade ! No extra power supply needs ! FCC Certified under Part 15 to Operation in 2.4GHz ISM Band ! 2.2 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Delta Networks Inc. 5 2.2. Mechanical Design Delta Networks Inc. 6 2.3. LED Definitions The LEDs on the LM-WU110 provide visual presentation to show the following status:
USB ready
RF Link USB LED Green USB is ready for operation OffSystem is not ready for operation. RF Link LED Solid Green The wireless interface is ready for data transmission. Blinking Green There is a data transmission on the wireless interface OffThe wireless interface is not ready for data transmission RF LED USB LED Delta Networks Inc. 7 2.4. IC Solution The IC solution for LM-WU110 adopts Intersil PRISM II chip set: P/NFunctionalityDescription Atmel AT79C503 USB 11Mbps WLAN medium access controller AT76C503 is a single chip controller that provides all processing and functionality needed for the MAC protocol of wireless LANs. AT76C503 contains a USB Bus interface, a MAC control unit and a physical attachment interface(PAI). The PAI supports the new 5.5 and 11Mbps WLAN physical interfaces, and the IEEE 802.11 DSSS physical interfaces. Intersil HFA3861B Direct Sequence Spread Spectrum Baseband processor HFA3861B Direct Sequence Spread Spectrum (DSSS) baseband processor is part of the PRISM 2.4GHz WLAN Chip set and contains all the functions necessary for a full or half duplex packet baseband transceiver. The HFA3861B has on-board A/D’s and D/A for analog I and Q inputs and outputs for HFA3783. Intersil HFA3783 I/Q Modulator/Demodulator and Sythesizer HFA3783 is a highly integrated and fully differential SiGe baseband converter for half duplex wireless application. It features all the necessary blocks for quadrature modulation and demodulation of “I” and “Q” baseband signals. Intersil HFA3683A 2.4GHz RF/IF Converter and Synhesizer HFA3683A is a monolithic SiGe half-duplex RF/IF transceiver designed to operate in the 2.4GHz ISM band. HFA39832.4GHz Power Amplifier and Detector HFA3983 is a 2.4GHz monolithic SiGe Power Amplifier designed to operate in the ISM Band. It delivers a 18dBm(Typ.) of an output power for the typical DSSS signal. The HFA3983 is housed in a 28 lead exposed paddle EPTSSOP package well suited for PCMCIA board applications. Delta Networks Inc. 8 3. Technical Specifications LM-WU110 Specifications Standard CompliantIEEE 802.11b Standard USB 1.0 Specification Data Transmission Rate11/5.5/2/1Mbps 12Mbps on USB interface SecurityWired Equivalent Privacy (WEP) data encryption for security Frequency Band2.4GHz ISM frequency band 2400-2483.5MHz for US, Canada 2400~2497MHz for …

Text truncated - open the document above for the full version.

D:\Ready_To_Convert\Doc\134589.DOC TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: tei@t imcoengr.com 22 January 2001 Mr. Joe Dichoso FCC SUBJECT: DELTA NETWORKS, INC. FCC ID: PD5LMWP100 REFERENCE: TC99656 Mr. Dichoso, With reference to your letter of 17 January 2001 the answers are as follows; 1. We used Section F of the TCB RF EXPOSURE Procedures for a device used at a distance of 20 cm, not including the hands. The 5 cm in the operational description is with reference to the finger tips. Sincerely, Sid Sanders

RF89120401Page 78 FCC ID: PD5LMWP100 Issued Date: December 18,2000 8 EUT PHOTOS

Label Location

Tested To Comply With FCC Standards FOR HOME OR OFFICE USE FCC ID: PD5LMWP100 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that my cause undesired operation.

RF89120401Page 79 FCC ID: PD5LMWP100 Issued Date: December 18,2000 RF89120401Page 80 FCC ID: PD5LMWP100 Issued Date: December 18,2000

PD5LMWP100 89120401 Operational Description The transmitter of the EUT (Wireless LAN Card) is powered by host notebook and connected with notebook through PCMCIA slot. The antenna is printed on PCB and no antenna connector is used. Under normal use condition, the radiator of this device is at least 20 cm far away from the body of the user, and 5cm from the hands of the user. The other instruction, please have a look at the users manual.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA HFA3841 DECOUPLING CAPSHFA3841 PIN NUMBERS NOTES ANALOG/RF POWER PLANE DIGITAL POWER PLANE LOCATED CLOSE TO MAC AND SRAM DIGITAL GROUND TIE ANALOG AND DIGITAL GROUND CLOSE TO CONNECTOR P1 IOIS16* ASSERTED HCE1* ( PG 4 ) ( PG 2) ( PG 2) ( PG 2) ( PG 3) ( PG 2) ( PG 2) ( PG 3 ,4) ( PG 4) ( PG 3 ,4) ( PG 3 ,4) ( PG 4) ( PG 3) ( PG 3) ( PG 4) ( PG 2) ( PG 2) ( PG 2) ( PG 2) ( PG 2 ,3) ( PG 2) ( PG 2) ( PG 2) PCMCIA WIRELESS LAN CARD Delta Networks Inc., LM-WP100 1 {Doc}1C 4Saturday, January 06, 2001 Title SizeDocument NumberRev Date:Sheetof HC4 HA[9..0] HA2HA5 HC5 HA7 HC1 HC2 HA9 HC0 HC11 HA4HA0 HC3 HA8 HC9 HA3HA1 HD10 HD9 HD8 HD14 HD15 HD12 HD11 HD2 HD7 HD6 HD5 HD4 HD3 HC6 HC0 HC5 HC2 HC3 HC11 HC9 HC4 HA6 HC1 HD0 HD13HD0HD11HD3HD12HD9HD2HD1HD15HD6HD10HD14HD5HD7HD8HD4 HA9 HA8 HA7 HA6 HA5 HA4 HA3 HA2 HA1 HA0 HD1 HD13 MD7 MD8 MD9 MD9 MD11 MD6 MD4 MD2 MD1 MD0 MD[7..0] MD7 MD12 MD4 MD10 MD14 MD13 MD3 MD15 MD13 MD15 MD7 MD1 MD5 MD0 MD14 MD2 MD4 MD0 MD5 MD14 MD11 MD6 MD9 MD13 MD12 MD3 MD10 MD2 MD8 MD3 MD5 MD6 MD15 MD11 MD12 MD[15..0] MD8 MD1 MD10 MA15 MA10 MA13 MA8 MA5 MA14 MA1 MA10 MEM_CTRL[4..0] MA15 MA6 MA6 MA4 MA16 MA13 MA13 MA7 MA6 MA5 MA12 MA13 3 MWEL* 3 MWEL* MA15 MA4 MA17 MA1 MA15 4 NVCS* 1 MOE* MA8 0 RAMCS* MA10 MA16 MA10 4 NVCS* MA11 MA17 MA9 MA2 MA12 MA14 1 MOE* MA8 MA3 MA3 MA9 MA0 MA14 MA7 MA1 0 RAMCS* MA5 MA12 MA16 MA17 MA7 MA[17..0] MA11 MA7 0 RAMCS* MA2 2 MA0 (MWEH*) MA12 MA3 MA0 3 MWEL* MA2 MA14 MA16 MA11 MA8 1 MOE* MA9 MA4 MA11 1 MOE* MA1 MA3 MA9 MA6 MA5 MA2 MA4 HC6 HC8 HC8 MD0 MD1 MD2 MD3 MD4 MD5 MD6 MD7 MD[7..0] MA020 HC10 HC7 HC7 HC10 RX_DATA TX_PE PA_PE SCLK_RF_IF RADIO_PD LE_RF CSB LE_IF RX_PE T/R_SW* PE2 S_DATA MD_RDY CCA 44MHz_REF SD_RF_IF CAL_EN TX_CLK PE1 RESET_BB* RX_CLK TX_DATA T/R_SW S_CLK +3.3V VCCS VCCS VCCS VCCS VCCS VCCS VCCS VCCS VCCS VCCS VCCS C9 10UF 1 2 C14 0.1UF 1 2 D4 LED (GREEN) U2 AM29LV010B 10 11 5 4 12 1 31 2 3 13 14 15 16 17 18 19 20 30 32 7 24 29 28 27 26 25 23 22 21 8 9 6 A16 A15 A14 A13 A12 A11 A10 A09 A08 A07 A06 A05 A04 A03 A02 A01 A00 *CE *OE *WE GND DQ7 DQ6 DQ5 DQ4 DQ3 DQ2 DQ1 DQ0 VCC NC NC R1 22K R4 22K R3 470 R16 22K R18 5.62K R42 5.62K R14 560 R2 22K R8 47K C7 0.1UF 12 C6 0.1UF 12 C1 0.1UF 12 C21 0.1UF 1 2 C10 0.1UF 1 2 C5 0.1UF 1 2 C3 0.1UF 1 2 C2 0.1UF 1 2 C4 0.1UF 1 2 C8 0.1UF 1 2 C19 0.1UF 1 2 R79 22K 12 R6 22K 12 D1 MA2SD10 1 2 GEN_MODE 1 R26 47K 12 R21 47K 12 R17 47K 12 R10 47K 12 R11 47K 12 C20 0.1UF 1 2 R5 47K 12 R78 22K 12 R12 22K P1 CON68 1 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 2 3 4 5 6 7 GND1 A10 OE* A11 A9 A8 A13 A14 WE*/PGM* IREQ* VCC1 VPP1 A16 A15 A12 A7 A6 A5 A4 A3 A2 A1 A0 D0 D1 D2 IOIS16 GND2 GND3 CD1* D11 D12 D13 D14 D15 CE2* RFSH IORD* IOWR* A17 A18 A19 A20 A21 VCC2 VPP2 A22 A23 A24 A25 RFU RESET WAIT* INPACK* REG* SPKR* STSCHG* D8 D9 D10 CD2* GND4 D3 D4 D5 D6 D7 CE1* R72 1K GEN_MODE 1 U4 IS62LV1024L 10 7 11 4 12 1 31 2 13 14 15 16 17 18 19 20 3 5 30 6 32 9 24 29 28 27 26 25 23 22 21 8 A16 A15 A14 A13 A12 A11 A10 A9 A7 A6 A5 A4 A3 A2 A1 A0 A8 *WE *CE1 CE2 *OE NC GND I/O7 I/O6 I/O5 I/O4 I/O3 I/O2 I/O1 I/O0 VCC U1 IS62LV1024L 10 7 11 4 12 1 31 2 13 14 15 16 17 18 19 20 3 5 30 6 32 9 24 29 28 27 26 25 23 22 21 8 A16 A15 A14 A13 A12 A11 A10 A9 A7 A6 A5 A4 A3 A2 A1 A0 A8 *WE *CE1 CE2 *OE NC GND I/O7 I/O6 I/O5 I/O4 I/O3 I/O2 I/O1 I/O0 VCC R7 47K U3 HFA3841 72 73 74 75 76 77 78 79 80 81 84 85 86 87 88 89 90 91 92 61 60 59 58 57 56 55 54 71 70 69 68 101100996543296959412812712612512310610710810911011111211311711811221211161201191041141021033616 51 50 49 48 47 46 45 44 15 27 26 28 43 12 11 35 34 33 63 64 21 22 23 31 30 32 29 65 8 7 38401718192094193105142539536683981241324374252678297115 10 62 MA0 MA1 MA2 MA3 MA4 MA5 MA6 MA7 MA8 MA9 MA10 MA11 MA12 MA13 MA14 MA15 MA16 MA17 MA18 MD0 MD1 MD2 MD3 MD4 MD5 MD6 MD7 #MWEL #MOE #RAMCS #NVCS HD0HD1HD2HD3HD4HD5HD6HD7HD8HD9HD10HD11HD12HD13HD14HD15HA0HA1HA2HA3HA4HA5HA6HA7HA8HA9#ACE1#ACE2#HOE#HWE#HIOR#HIOWR#HWAIT#HIREQ#HREG#HINPACK#HSISCAGRESET MD8 MD9 MD10 MD11 MD12 MD13 MD14 MD15 PL0 PL1 PL2 PL3 PL4 PL5 PL6 PK0 PK1 PK2 PK3 PK4 PK5 PK6 PK7 PJ0 PJ1 PJ2 PJ3 PJ4 PJ5 PJ6 CLKOUT XTAL_I TXDTXCRXDRXC PJ7 XTAL_O PL7 VCC_IO5 VCC_CORE3VCC_CORE3VCC_CORE3VCC_CORE3 VSS_IO3VSS_IO3VSS_IO3VSS_IO3 VSS_CORE3VSS_CORE3VSS_CORE3 VSS_IO3VSS_IO3VSS_IO3VSS_IO3VSS_IO3VSS_IO8 TCLKIN #TRST R9 47K 12 Q10 AME8805AEFT 2 1 3 I/P GND O/P C34 10UF 1 2 L3 BLM21P300S 12 C31 0.1UF 1 2 C102 10UF 1 2 C81 0.1UF 1 2 L17 BLM21P300S 12

5 5 4 4 3 3 2 2 1 1 DD CC BB AA NO POP ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG 1) ( PG3) ( PG3) ( PG3) ( PG3) ( PG3) ( PG 4) ( PG 3 ) ( PG 3 ) ( PG 3 ) ( PG 3 ) ( PG 3 ) ( PG 3 ) ( PG 3 ) ( PG 1, 3 ) ( PG 4 ) ( PG 4 ) ( PG 4 ) Delta Networks Inc., LM-WP100 1 PCMCIA WIRELESS LAN CARD C 24Saturday, January 06, 2001 Title SizeDocument NumberRev Date:Sheetof 6 1 3 0 0 3 5 4 7 1 2 7 5 2 6 4 44MHZ_REF ANTSEL TX_IF_AGC RX_IF_AGC TXQ- TXQ+ TXI- TXI+ IF_DET RX_CLK RX_DATA MD_RDY TX_CLK CCA TX_DATA RX_PE TX_PE RESET_BB* S_CLK CSB RXI- RXQ+ RXQ- TX_DET ANTSEL* RX_RF_AGC VREF RXI+ S_DATA +3.3VVCCS R20 560 12 C25 1000PF 12 C30 0.1UF 1 2 C32 0.1UF 12 C35 0.1UF 12 R29 0 12 R27 0 12 R23 0 12 R19 0 12 C139 0.01UF 1 2 C29 0.1UF 12 C18 0.1UF 1 2 R13 10K 1 2 C12 0.1UF 1 2 C11 10UF 1 2 C15 10UF 1 2 C13 0.1UF 1 2 R22 100 C17 0.1UF 12 R30 976 1 2 R28 619 1 2 TP71 TP21 TP6 1 TP4 1 TP8 1 TP3 1 TP1 1 TP5 1 R33 19.1K 1 2 R32 12.1K 1 2 R34 19.1K 1 2 C140 0.01UF 12 C36 0.1UF 1 2 C26 0.1UF 12 U5 HFA3861 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17181920212223242526272829303132 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49505152535455565758596061626364 GNDD1 VDDD1 SD SCLK R/W CS* GNDD2 VDDD2 GNDA1 IIN+ IIN-- VDDA2 QIN+ QIN- GNDA2 VREF VDDA3TX_AGC_INRX_IF_DETGNDA3IREFVDDA4IOUT+IOUT-GNDA4COMPCAP2COMPRES2GNDA5QOUT+QOUT-VDDA5COMPRES1 COMPCAP1 RX_IF_AGC TX_IF_AGC GNDD3 VDDD3 RX_RF_AGC ANT_SEL* ANT_SEL BYP MCLK GNDD4 TEST0 TEST1 TEST2 TEST3 TEST4 TEST5TEST6TEST7 RXCLK RXD MD_RDY TXCLK GNDD5 VDDD5 TXD TX_RDY CCA RX_PETX_PE RESET* SDI

5 5 4 4 3 3 2 2 1 1 DD CC BB AA VCM=1.2V NO POP ( PG 1, 4 ) ( PG 1 ) ( PG 1, 4 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 1 ) ( PG 4 ) ( PG 4 ) ( PG 1, 4 ) ( PG 1, 4 ) ( PG 1 ) ( PG 1, 2 ) ( PG 4 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) ( PG 2 ) VCM=1.2V Delta Networks Inc., LM-WP100 1 PCMCIA WIRELESS LAN CARD C 34Saturday, January 06, 2001 Title SizeDocument NumberRev Date:Sheetof CAL_EN PE2 IF_DET RX_IF_AGC IF+ RADIO_PD TX_IF_AGC IF- SCLK_RF_IF SD_RF_IF LE_IF 44MHZ_REF 44MHZ_CW PE1 RXQ+ TXQ- TXQ+ VREF RXQ- TXI- TXI+ RXI+ RXI- +3.3V VCCC VCCA VCCC VCCB VCCC FL1 SAWTEK855653 1256 3 4 121187 10 9 CASECASE GROUNDS1GROUNDS2 OUT OUT_RET CASECASEGROUNDS4GROUNDS3 IN_RET IN Q1 IRLML6302 R45 2.87K R57 0 R59 536 R62 124 R58 124 R52 2K R55 3.92K R74 0 R15 1.5K R82 0 R24 0 R49 100 R61 0 R70 536 R66 124 R67 124 R63 0 R56 49.9 R830 L6 22NH 1 2 L1 0.56UH 1 2 L21 BLM21P300S 12 L5 39NH 1 2 C71 0.1UF 1 2 C52 10PF 12 C56 220PF 12 C55 220PF 12 C51 10PF 12 C108 100PF 12 C110 68PF 1 2 C107 3900PF 1 2 C100 0.22UF 1 2 C91 0.022UF 1 2 C80 1000PF 12 C24 22PF 1 2 C27 1000PF 12 C33 0.1UF 12 C88 100PF 1 2 C104 100PF 12 C136 10UF 1 2 C135 0.1UF 1 2 C134 10UF 1 2 C133 0.1UF 1 2 C124 0.1UF 1 2 C137 0.1UF 1 2 C89 0.1UF 12 C72 0.1UF 1 2 C93 0.1UF 12 C112 0.1UF 12 C57 0.1UF 12 C53 0.1UF 12 C46 15PF 12 C39 220PF 12 C44 220PF 12 C45 15PF 12 C85 100PF 1 2 R64 0 C121 0.1UF 12 U13 VCO -748MHz 3 45A5B5C5D 1 2 VT GND0GND1GND2GND3GND4 RF VCC R40 2K C120 68PF 1 2 U6 OSCILLATOR 44MHz 1 4 2 3 END VDD GND OUT C76 1000PF 12 U15 MAX8867 3 1 4 2 5 IN SHDN OUT GND BP R41 1K 12 C70 0.1uF R47 100 C84 0.1UF 12 L10 33NH 1 2 L9 33NH 1 2 U9 HFA3783 1 2 3 4 5 6 7 8 9 10 11 12 131415161718192021222324 25 26 27 28 29 30 31 32 33 34 35 36 373839404142434445464748 RX_AGC_VCC SPARE IF_RX+ IF_RX- TX_BIAS_GND TX_VAGC TX_BIAS_VCC IF_TX+ IF_TX- TX_AGC_VCC TX_AGC_GND TX_AGC_SUB REF_BYREF_INSYNTH_SUBSYNTH_GNDSYNTH_VDDCLKDATALECP_VDDCP_DOCP_GNDLD LO_SUB LO_IN LO_IN+ LO_VCC LO_GND TXQ- TXQ+ 1.2V_OUT TXI- TXI+ RXQ- RXQ+ RXI- RXI+ RXI_BB_GND RX_BB_VCC RX_DEM_GND CAL_EN PE2PE1 IF_DETECT RX_VAGC_SUB RX_VAGC RX_AGC_GND

5 5 4 4 3 3 2 2 1 1 DD CC BB AA NO POP NO POP NO POP SLIDE CALCULATED FOR ICP=250UA NO POP SLIDE ( PG 2 ) ( PG 2 ) ( PG 1 ,3 ) ( PG 1 ,3 ) ( PG 1 ) ( PG 1 ) ( PG 2 ) ( PG 1 ) ( PG 3 ) ( PG 3 ) ( PG 3 ) ( PG 1, 3 ) ( PG 1, 3 ) ( PG 1 ) ( PG 2 ) Delta Networks Inc., LM-WP100 1 PCMICA WIRELESS LAN CARD C 44Saturday, January 06, 2001 Title SizeDocument NumberRev Date:Sheetof PE2 T/R_SW* PE1 TX_DET PA_PE SCLK_RF_IF ANTSEL T/R_SW ANTSEL* RX_RF_AGC 44MHZ_CW SD_RF_IF LE_RF IF+ IF- VCCA+3.3V +3.3V +3.3V VCCB VCCC ANT1 ANTENNA R65 1.5K 12 R69 649 12 ANT2 ANTENNA R81 0 R39 1.1K R53 100 R44 1.1K R43 100 R46 100 R71 1K R80 0 R68 10 R51 100 R48 100 C125 0.01UF 1 2 C37 150PF 12 C105 2.7PF 1 2 C75 4.7PF 12 C111 7PF 1 2 C73 7PF 12 C66 7PF 12 C49 4.7PF 12 C127 7PF 12 C74 220PF 12 C65 7PF 12 C141 150PF 1 2 C123 0.68UF 1 2 C28 7PF 12 C83 7PF 12 C47 220PF 12 L19 6.8NH 1 2 L8 1.8NH 12 L18 BLM10A121S 1 2 L16 BLM10A121S 12 L20 2.2NH 12 L4 1.5NH 12 L12 33NH 1 2 L14 33NH 1 2 L11 1.8NH 12 L13 1.2NH 12 R25 100 12 R73 20 12 C23 1000PF 12 R35 100 12 R31 100 12 C90 0.1UF 1 2 C62 4.7PF 1 2 L15 2.7NH 12 C79 7PF 12 U14 VCO-2074MHz 3 45A5B5C5D 12 VCONT GND0GND1GND2GND3GND4 RFVCC C98 1000PF 12 C43 10UF 1 2 L7 1.2NH 1 2 C87 0.5PF 1 2 FL4 MDR642E 1 2 3 4 GND1 OUT GND0 IN U7 MAX8867 3 1 4 2 5 IN SHDN OUT GND BP C97 7PF 1 2 R84 24.9 1 2 C82 1PF 12 C77 7PF 1 2 C103 0.01UF 12 R38 9.53K 12 FL3 LTF3216L 1 2 3 4 GND1 OUT GND0 IN C130 0.01UF 12 C94 100PF 1 2 R50 3.74K C16 0.01UF 12 C78 7PF 1 2 C117 0.1UF 1 2 C22 0.01UF 1 2 C58 3.3PF 1 2 C42 0.1UF 1 2 C86 0.01UF 12 C118 0.068UF 1 2 C54 0.5PF 1 2 C132 0.1UF 12 C106 1000PF 12 R54 3.74K C48 0.5PF 1 2 C126 270PF 12 U10 AS169-73 1 2 34 5 6 OUT1 GND OUT2VCNT2 IN VCNT1 R60 10 C101 1000PF 12 C114 0.01UF 1 2 U8 AS169-73 1 2 34 5 6 OUT1 GND OUT2VCNT2 IN VCNT1 R37 1.5K 12 C59 7PF 12 C63 0.01UF 1 2 U16 UPC2745 4 6 1 235 OUT VCC IN GNDGNDGND FL5 MDR642E 1 2 3 4 GND1 OUT GND0 IN C128 1000PF 12 C96 0.5PF 1 2 R36 11.5K 1 2 C60 0.01UF 1 2 C109 7PF 1 2 C113 1000PF 12 C61 0.01UF 12 C95 0.01UF 12 C67 7PF 1 2 C40 0.1UF 1 2 C92 0.01UF 12 C129 10UF 12 C41 0.1UF 1 2 L2 4.7NH 1 2 C38 10UF 1 2 C115 1.5PF 1 2 C99 0.01UF 12 U12 HFA3983 1 2 3 4 5 6 7 8 9 10 11 12 13 1415 16 17 18 19 20 21 22 23 24 25 26 27 28 29 GND1 VCC1 PE GND2 VCC2 REXT_OS REXT_DS VCC_DS GND3 GND4 RFOUT GND5 GND6 GND7GND8 GND9 GND10 GND11 GND12 GND13 GND14 RFIN GND15 GND16 GND17 DET_OUT GND18 VCC3 BOTTOM PAD C68 7PF 12 U11 HFA3683A 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17181920212223242526272829303132 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49505152535455565758596061626364 GND1 LNA_VCC1 GND2 RX_IN GND3 BIAS1_VCC1 GND4 H/L PE2 PE1 TX_VCC1 GND5 TXA_OUT GND6 GND7 GND8 TX_VCC1_1GND9TXA_INGND10LEDATACLKREF_BYREF_INGND11SYN_VCC2GND12CP_VCC2CP_DOGND13LD TX_MX_VCC1 TX_MX_OUT TX_MX_VCC2 TX_MX_VCC3 TX_MX_VCC4 TX_LO_DRIVER_VCC1 GND14 LO_IN+ LO_IN- GND15 LO_VCC1 GND16 RX_LO_DRIVER_VCC1 GND17 TX_MX_IN- RX_MX_OUT RX_MX_OUT+ TX_MX_IN+ GND18 RX_MX_IN GND19 PRE_VCC1 GND20 ITAT_RES1 PTAT_RES1 BIAS2_VCC1 ITAT_RES2 GND21 RF_OUT GND22 COL_OUT GND23 J1 BNC 1 2 R75 90.9 1 2 R77 90.9 12 R76 82.5 1 2 C69 22PF 1 2 C50 1000PF 12 C116 1000pF 1 2

RF89120401Page 1 FCC ID: PD5LMWP100 Issued Date: December 18,2000 T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T Wireless PCMCIA Card Model Name LM-WP100 Tested at December 12, 2000 According to 47CFR Part 15C (15.247) &15B Guidance on Measurements for Direct Sequence Spread Spectrum Systems Issued for Delta Networks, Inc. No. 8, Kon Jan West Road, Liutu Industrial Zone, Keelung, Taiwan, R.O.C. PREPARED BY: ADVANCE DATA TECHNOLOGY CORPORATION R & TTE Certification Division 13-1 Lane 19, Wen Shan 3 rd St., Kweishan, TAOYUAN, TAIWAN, R.O.C. This test report consists of 80 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of our laboratory. It should not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. government. The test result in the report only applies to the tested sample. Accredited Laboratory RF89120401Page 2 FCC ID: PD5LMWP100 Issued Date: December 18,2000 REPORT NO:RF89120401 PRODUCT:Wireless PCMCIA Card MODEL NO:LM-WP100 SERIAL NO:N/A APPLICANT:Delta Networks, Inc. ADDRESS:No. 8, Kon Jan West Road, Liutu Industrial Zone, Keelung, Taiwan R.O.C. ISSUED BY:Advance Data Technology Corporation (ADT Corp.) OFFICE ADDRESS:11F, No. 1, Sec. 4, Nan-King East Rd., Taipei, Taiwan, R.O.C. LABORATORY ADDRESS:No. 13-1, Lane 19, Wen Shan 3 rd St., Kweishan, Taoyuan Hsien, Taiwan, R.O.C. TEST STANDARD:47CFR Part 15, Subpart C (15.247) & Subpart B TEST DATE:December 22, 2000 TEST RESULT:Pass This test report consists of 80 pages in total. This test report is the property of ADT Corp. and shall not be reproduced except in full, without the written consent of ADT. ADT hereby returns all rights in data to the client for legal use by the client. The test results contained in this report apply only to the samples tested. Accredited Laboratory RF89120401Page 3 FCC ID: PD5LMWP100 Issued Date: December 18,2000 TABLE OF CONTENTS 1CERTIFICATION ..........................................................................................................6 2SUMMARY OF TEST RESULTS .................................................................................7 3DECLARATION OF COMPLIANCE WITH SUBPART B ..............................................8 4GENERAL DESCRIPTION ..........................................................................................9 4.1G ENERAL D ESCRIPTION OF EUT ................................................................................................................ 9 4.2D ESCRIPTION OF T EST MODE .................................................................................................................... 10 4.3T EST M ETHODOLOGY ...............................................................................................................................10 4.4S UPPORT U NITS L IST .................................................................................................................................11 4.5C ONFIGURATION OF S YSTEM U NDER T EST ................................................................................................11 5GENERAL INFORMATION OF TEST FACILITY........................................................12 5.1T EST L AB . ................................................................................................................................................ 12 5.2C ALIBRATION I NTERVAL ........................................................................................................................... 12 6TEST PROCEDURES AND TEST RESULTS............................................................13 6.1C ONDUCTED E MISSION M EASUREMENT ................................................................................................... 13 6.1.1Test Instruments ......................................................................................................................... 13 6.1.2Test Procedures.......................................................................................................................... 13 6.1.3 Test Setup.................................................................................................................................... 14 6.1.4Photograph of Test Setup........................................................................................................... 15 6.1.5EUT Operating Condition ......................................................................................................... 16 6.1.6Climate Condition ..................................................................................................................... 16 6.1.7Test Results ................................................................................................................................ 17 6.2R ADIATED E MISSION M EASUREMENT ....................................................................................................... 23 6.2.1Test instruments ......................................................................................................................... 23 6.2.2Test Procedures.......................................................................................................................... 24 6.2.3Test Setup ................................................................................................................................... 25 6.2.4Photograph of Test Setup........................................................................................................... 26 6.2.5EUT Operating Condition ......................................................................................................... 27 6.2.6Climate Condition ..................................................................................................................... 27 6.2.7Test Results ..................................................................................................................…

Text truncated - open the document above for the full version.

RF89120401Page 38 FCC ID: PD5LMWP100 Issued Date: December 18,2000 6.4 Maximum Peak Output Power 6.4.1 Test Instruments Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 846839/018 848926/005 Dec. 03, 2001 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A The measurement uncertainty is less than +/- 2.6dB, which is calculated as per NAMAS document NIS81. 6.4.2 Test Procedures 1. The transmitter output was connected to the spectrum analyzer through an attenuator. 2. The center frequency of the spectrum analyzer is set to the fundamental frequency and using 3 MHz RBW and 3 MHz VBW. 3. The span of the spectrum analyzer should be larger than 6dB BandWidth plus 10MHz. 4. Use Peak Search to read the peak power after Maximum Hold function is activated. 5. Shift the marker to +/- 3MHz and +/-6MHz, and record the reading. 6. The Maximum Peak Output Power is the linear summation of the 5 readings in (4) and (5). Note: This measurement is the total power of 15MHz bandwidth which is far more wider than 6dB bandwidth. RF89120401Page 39 FCC ID: PD5LMWP100 Issued Date: December 18,2000 6.4.3 Test Setup 6.4.4 EUT Operating Condition The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel frequencies individually. 6.4.5 Climate Condition The temperature and related humidity is 24Degree C and 80% respectively. 6.4.6 Test Result CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) PA S S / FA I L 1241217.0630PASS 6243717.0830PASS 11246217.4930PASS EUT Spectrum Analyzer Attenuator RF89120401Page 42 FCC ID: PD5LMWP100 Issued Date: December 18,2000 6.6 Power Spectral Density Measurement 6.6.1 Test Instruments Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 846839/018 848926/005 Dec. 03, 2001 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A The measurement uncertainty is less than +/- 2.6dB, which is calculated as per NAMAS document NIS81. 6.6.2 Test Procedure The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 6.6.3 Test Setup 6.6.4 EUT Operating Condition The software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel f…
