Wireless PC Card User Manual Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interfere nce received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna, (2) Increase the separation between the equipment and receiver, (3) Connect the equipment into an outlet on a circuit different from that to wh ich the receiver is connected, (4) Consult the dealer or an experienced radio/TV technician for help. Federal Communications Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation. Wireless PC Card iii TABLE OF CONTENT INTRODUCTION ............................................................................. 1 CONNECT THE NETWORK PC CARD TO YOUR NOTEBOOK PC.......... .......................... .......................... .................. 2 H ARDWARE I NSTALLATION ............................................................... 2 DRIVER INSTALLATION............................................................... 2 I NSTALL D RIVER U NDER W INDOWS XP ........................................... 2 I NSTALL D RIVER U NDER W INDOWS 98 ............................................ 5 I NSTALL D RIVER U NDER W INDOWS ME .......................................... 9 I NSTALL D RIVER U NDER W INDOWS 2000 ...................................... 11 I NSTALL D RIVER U NDER W INDOWS NT ......................................... 15 CONFIGURATION UTILITY .... ................... ................... ............. 30 I NSTALL THE C ONFIGURATION U TILITY .......................................... 30 C ONFIGURE THE C ONFIGURATION U TILITY .................................... 33 Wireless PC Card 1 Introduction The Wireless PC card helps you create a wireless network for sharing your broadband cable or DLS internet access among multiple PCs in and around your home of office. It is designed for notebook computers running Microsoft Windows 98, 2000, NT, Millennium and XP. It is 16-bit PCMCIA and 32-bit CardBus compatible and works in any available PCMCIA or CardBus slot. Its auto-sensing capability allows packet transfer in 11Mbps for maximum throughput, or speed reduction to the lower 1Mbps speed for distance or working in a noisy environment. Features ƒ 11 Mbps High-Speed Transfer Rate ƒ Interoperable with IEEE 802.11b(DSSS) 2.4GHz-compliant Equipment ƒ Plug-and Play Operation Provides Easy Setup ƒ Utilizes Intersil HFA3841/HFA3842 chip sets ƒ Advanced Power Management Features Conserve Valuable Notebook PC Battery Life ƒ Direct Sequence Spread Spectrum Compatible to Prevent Lost Connections ƒ Rugged Metal Design with Integrated Antenna ƒ Wired Equivalent Privacy (WEP) 40-bit data encryption Driver Supports Windows 98, Millennium, NT v.4, 2000 and XP Wireless PC Card 2 Connect the Network PC Card to Your Notebook PC Hardware Installation ƒ Locate an available Type II PCMCIA slot on your notebook computer. ƒ With the PCMCIA adapter’s 68-pin connector facing the PCMCIA slot and the “Network PC Card” label facing up, slide the PCMCIA adapter completely into the PCMCIA slot. ƒ Insert the driver CD into your CD drive. ƒ The Hardware Installation is complete. Driver Installation Install Driver Under Windows XP 1. Connect the Wireless PC card into your Notebook PC. Windows XP will automatically recognize a new Intersil PRISM_2_5_ PCMCIA_ADAPTER . Select Install the software automatically [Recommended] and click the Next button to proceed. Wireless PC Card 3 2. Windows will notify you that it has not passed Windows Logo testing to verify its compatibility with Whistler. Click the Continue Anyway button to continue. 3. Windows has now completed installing the network. Click the Finish button to continue. Wireless PC Card 4 4. Click right on My computer and select properties . Select Device Manager and click on the Network adapters . You will find the Intersil PRISM2.5 PCMCIA Adapter if it is installed successfully. The PC card adapter driver installation is finished. Wireless PC Card 5 Install Driver Under Windows 98 1. Connect the Wireless PC card into your Notebook PC. Windows 98 will automatically recognize a new Intersil-PRISM 2_5 PCMCIA ADAPTER . Click the Next button to proceed. 2. Make sure Search for the best driver for your device is selected and click the Next button. Wireless PC Card 6 3. Make sure the Specify a location is selected and click the Browse button. At this point, Windows will ask you to browse for the folder. Simply select the folder in which the driver is located and click the OK button. 4. Windows is now ready to install the driver. Click the Next button to continue. Wireless PC Card 7 5. Windows has now completed installing the network. Click the Finish button to continue. 6. After ins…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

FCC LABEL LOCATION

Page 3 Page 4

Page 3 Page 4

FCC ID: PD5LMWP200 ADT No.: 900809R01 FCC TEST REPORT REPORT NO.: RF900809R01 MODEL NO.: LM-WP200 (for DELTA) MA401 rev.B (for Netgear) ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:DELTA NETWORKS, INC. ADDRESS: 8, Kon Jan West Road, Liutu Industrial Zone Keelung, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 FCC ID: PD5LMWP200 ADT No.: 900809R01 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: PD5LMWP200 ADT No.: 900809R01 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: PD5LMWP200 ADT No.: 900809R01 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is -1 dBi or 0.79 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241268.872.08 6243764.572.01 11246266.072.04 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: PD5LMWP200 Report No.: RF900809R01 1 Issued: August 24, 2001 FCC TEST REPORT REPORT NO.: RF900809R01 MODEL NO.: LM-WP200 (for DELTA) MA401 rev.B (for Netgear) RECEIVED: August 9, 2001 TESTED: August 17~ August 22, 2001 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 8, Kon Jan West Road, Liutu Industrial Zone Keelung, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: PD5LMWP200 Report No.: RF900809R01 2 Issued: August 24, 2001 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS ................................................................... 5 3GENERAL INFORMATION............................................................................ 6 3.1GENERAL DESCRIPTION OF EUT.............................................................. 6 3.2DESCRIPTION OF TEST MODES ................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................... 7 3.4DESCRIPTION OF SUPPORT UNITS .......................................................... 8 4TEST TYPES AND RESULTS ....................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .............................. 9 4.1.2TEST INSTRUMENTS................................................................................... 9 4.1.3TEST PROCEDURES ................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS ................................................................ 11 4.1.6TEST RESULTS .......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................. 18 4.2.2TEST INSTRUMENTS................................................................................. 19 4.2.3TEST PROCEDURES ................................................................................. 20 4.2.4TEST SETUP .............................................................................................. 21 4.2.5EUT OPERATING CONDITIONS ................................................................ 21 4.2.6TEST RESULTS .......................................................................................... 22 4.36DB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 27 4.3.2TEST INSTRUMENTS................................................................................. 27 4.3.3TEST PROCEDURE.................................................................................... 28 4.3.4TEST SETUP .............................................................................................. 28 4.3.5EUT OPERATING CONDITIONS ................................................................ 28 4.3.6TEST RESULTS .......................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 33 4.4.2TEST INSTRUMENTS................................................................................. 33 4.4.3TEST PROCEDURES ................................................................................. 34 4.4.4TEST SETUP .............................................................................................. 34 4.4.5EUT OPERATING CONDITIONS ................................................................ 34 FCC ID: PD5LMWP200 Report No.: RF900809R01 3 Issued: August 24, 2001 4.4.6TEST RESULTS .......................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ...................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 36 4.5.2TEST INSTRUMENTS................................................................................. 36 4.5.3TEST PROCEDURE.................................................................................... 37 4.5.4TEST SETUP .............................................................................................. 37 4.5.5EUT OPERATING CONDITIONS ................................................................ 37 4.5.6TEST RESULTS .......................................................................................... 38 4.6BAND EDGES MEASUREMENT ................................................................ 42 4.6.1LIMITS OF BAND EDGES MEASUREMENT .............................................. 42 4.6.2TEST INSTRUMENTS................................................................................. 42 4.6.3TEST PROCEDURE.................................................................................... 42 4.6.4EUT OPERATING CONDITION .................................................................. 43 4.6.5TEST RESULTS .......................................................................................... 43 4.7ANTENNA REQUIREMENT ........................................................................ 46 4.7.1ST…

Text truncated - open the document above for the full version.

FCC ID: PD5LMWP200 Report No.: RF900809R01 36 Issued: August 24, 2001 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Dec. 28, 2001 HP ATTENUATOR8496B3247A18505Cal. on use HP PLOTTER7475A2641V27755N/A NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: PD5LMWP200 Report No.: RF900809R01 37 Issued: August 24, 2001 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP 4.5.5 EUT OPERATING CONDITIONS Same as 4.3.5 EUT SPECTRUM ANALYZER Attenuator FCC ID: PD5LMWP200 Report No.: RF900809R01 38 Issued: August 24, 2001 4.5.6 TEST RESULTS EUT WLAN PCMCIA Card MODEL LM-W P200 INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 27 deg. C, 70%RH, 1005 hPa TESTED BY: Gary Chang CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 KHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-9.958PASS 62437-9.448PASS 112462-10.718PASS FCC ID: PD5LMWP200 Report No.: RF900809R01 39 Issued: August 24, 2001 CH1 FCC ID: PD5LMWP200 Report No.: RF900809R01 40 Issued: August 24, 2001 CH6 FCC ID: PD5LMWP200 Report No.: RF900809R01 41 Issued: August 24, 2001 CH11 FCC ID: PD5LMWP200 Report No.: RF900809R01 42 Issued: August 24, 2001 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 848926/005 846839/018 Dec 28, 2001 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: PD5LMWP200 Report No.: RF900809R01 43 Issued: August 24, 2001 4.6.4 EUT OPERATING CONDITION Same as Item 4.3.5 4.6.5 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following 2 pages shows 20.0dB delta between carrier maximum power and local maximum emission in restrict band (2.4889GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.6 (Page 26) is 98.3dBuV/m, so the maximum field strength in restrict band is 98.3-50.08=48.22 dBuV/m which is under 54 dBuV/m limit. FCC ID: PD5LMWP200 Report No.: RF900809R01 44 Issued: August 24, 2001 FCC ID: PD5LMWP200 Report No.: RF900809R01 45 Issued: August 24, 2001

FCC ID: PD5LMWP200 Report No.: RF900809R01 46 Issued: August 24, 2001 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is patch antenna. There is no antenna connector. And the maximum Gain of this antenna is only -1dBi. FCC ID: PD5LMWP200 Report No.: RF900809R01 47 Issued: August 24, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PD5LMWP200 Report No.: RF900809R01 48 Issued: August 24, 2001 RADIATED EMISSION TEST FCC ID: PD5LMWP200 Report No.: RF900809R01 49 Issued: August 24, 2001 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USA FCC, NVLAP Germany TUV Rheinland Japan VCCI New Zealand MoC Norway NEMKO R.O.C. BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: PD5LMWP200 Report No.: RF900809R01 47 Issued: August 24, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PD5LMWP200 Report No.: RF900809R01 48 Issued: August 24, 2001 RADIATED EMISSION TEST
