PD5LMWP210WLAN PCMCIA Card

Wireless PC Card User Manual Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interfere nce received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna, (2) Increase the separation between the equipment and receiver, (3) Connect the equipment into an outlet on a circuit different from that to wh ich the receiver is connected, (4) Consult the dealer or an experienced radio/TV technician for help. Federal Communications Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation. Wireless PC Card iii TABLE OF CONTENT INTRODUCTION ............................................................................. 1 CONNECT THE NETWORK PC CARD TO YOUR NOTEBOOK PC.......... .......................... .......................... .................. 2 H ARDWARE I NSTALLATION ............................................................... 2 DRIVER INSTALLATION............................................................... 2 I NSTALL D RIVER U NDER W INDOWS XP ........................................... 2 I NSTALL D RIVER U NDER W INDOWS 98 ............................................ 5 I NSTALL D RIVER U NDER W INDOWS ME .......................................... 9 I NSTALL D RIVER U NDER W INDOWS 2000 ...................................... 11 I NSTALL D RIVER U NDER W INDOWS NT ......................................... 15 CONFIGURATION UTILITY .... ................... ................... ............. 30 I NSTALL THE C ONFIGURATION U TILITY .......................................... 30 C ONFIGURE THE C ONFIGURATION U TILITY .................................... 33 Wireless PC Card 1 Introduction The Wireless PC card helps you create a wireless network for sharing your broadband cable or DLS internet access among multiple PCs in and around your home of office. It is designed for notebook computers running Microsoft Windows 98, 2000, NT, Millennium and XP. It is 16-bit PCMCIA and 32-bit CardBus compatible and works in any available PCMCIA or CardBus slot. Its auto-sensing capability allows packet transfer in 11Mbps for maximum throughput, or speed reduction to the lower 1Mbps speed for distance or working in a noisy environment. Features ƒ 11 Mbps High-Speed Transfer Rate ƒ Interoperable with IEEE 802.11b(DSSS) 2.4GHz-compliant Equipment ƒ Plug-and Play Operation Provides Easy Setup ƒ Utilizes Intersil HFA3841/HFA3842 chip sets ƒ Advanced Power Management Features Conserve Valuable Notebook PC Battery Life ƒ Direct Sequence Spread Spectrum Compatible to Prevent Lost Connections ƒ Rugged Metal Design with Integrated Antenna ƒ Wired Equivalent Privacy (WEP) 40-bit data encryption Driver Supports Windows 98, Millennium, NT v.4, 2000 and XP Wireless PC Card 2 Connect the Network PC Card to Your Notebook PC Hardware Installation ƒ Locate an available Type II PCMCIA slot on your notebook computer. ƒ With the PCMCIA adapter’s 68-pin connector facing the PCMCIA slot and the “Network PC Card” label facing up, slide the PCMCIA adapter completely into the PCMCIA slot. ƒ Insert the driver CD into your CD drive. ƒ The Hardware Installation is complete. Driver Installation Install Driver Under Windows XP 1. Connect the Wireless PC card into your Notebook PC. Windows XP will automatically recognize a new Intersil PRISM_2_5_ PCMCIA_ADAPTER . Select Install the software automatically [Recommended] and click the Next button to proceed. Wireless PC Card 3 2. Windows will notify you that it has not passed Windows Logo testing to verify its compatibility with Whistler. Click the Continue Anyway button to continue. 3. Windows has now completed installing the network. Click the Finish button to continue. Wireless PC Card 4 4. Click right on My computer and select properties . Select Device Manager and click on the Network adapters . You will find the Intersil PRISM2.5 PCMCIA Adapter if it is installed successfully. The PC card adapter driver installation is finished. Wireless PC Card 5 Install Driver Under Windows 98 1. Connect the Wireless PC card into your Notebook PC. Windows 98 will automatically recognize a new Intersil-PRISM 2_5 PCMCIA ADAPTER . Click the Next button to proceed. 2. Make sure Search for the best driver for your device is selected and click the Next button. Wireless PC Card 6 3. Make sure the Specify a location is selected and click the Browse button. At this point, Windows will ask you to browse for the folder. Simply select the folder in which the driver is located and click the OK button. 4. Windows is now ready to install the driver. Click the Next button to continue. Wireless PC Card 7 5. Windows has now completed installing the network. Click the Finish button to continue. 6. After ins…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 3 Page 4

Page 5 Page 6

64 x 39 mm Tested To Comply With FCC Standards FOR HOME OR OFFICE USE WLAN PC Card This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MAC SERIAL FCC ID: PD5LMWP210

Page 7 Page 8

Page 9 Page 10

FCC ID: PD5LMWP210 ADT No.900906R03 Operational Description The transmitter of the EUT (WLAN Detached PCMCIA Card) is powered by notebook and connected with notebook. The EUT has three sets of antennas, two dipole antennas and one patch antenna. The antenna connector is MMCX. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PD5LMWP210 ADT No.: 900906R03 FCC TEST REPORT REPORT NO.: RF900906R03 MODEL NO.: LM-WP210 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 8, Kon Jan West Road, Liutu Industrial Zone Keelung, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 FCC ID: PD5LMWP210 ADT No.: 900906R03 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. Classification The antenna of the product, under normal use condition, is at least 20 cm away from the body of the user. Warning statement for keeping 20 cm separation distance and the prohibition of operating next to a person has been printed on the users manual. So, this product is classified as the Mobile Device. 3. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: PD5LMWP210 ADT No.: 900906R03 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 5. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: PD5LMWP210 ADT No.: 900906R03 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 3 dBi or 2 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241240.742.55 6243747.532.75 11246244.162.65 The minimum allowable distance is very close to the enclosure of the antenna and is very far away from the human being under normal use condition.

FCC ID: PD5LMWP210 Report No.: RF900906R03 1 Issued: October 24, 2001 FCC TEST REPORT REPORT NO.: RF900906R03 MODEL NO.: LM-WP210 RECEIVED: September 6, 2001 TESTED: Sep. 26~ Oct. 23, 2001 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 8, Kon Jan West Road, Liutu Industrial Zone Keelung, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 69 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: PD5LMWP210 Report No.: RF900906R03 2 Issued: October 24, 2001 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS ................................................................... 5 3GENERAL INFORMATION............................................................................ 6 3.1GENERAL DESCRIPTION OF EUT.............................................................. 6 3.2DESCRIPTION OF TEST MODES ................................................................ 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................... 7 3.4DESCRIPTION OF SUPPORT UNITS .......................................................... 8 4TEST TYPES AND RESULTS ....................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .............................. 9 4.1.2TEST INSTRUMENTS................................................................................... 9 4.1.3TEST PROCEDURES ................................................................................. 10 4.1.4TEST SETUP .............................................................................................. 10 4.1.5EUT OPERATING CONDITIONS ................................................................ 11 4.1.6TEST RESULTS (A) .................................................................................... 12 4.1.7TEST RESULTS (B) .................................................................................... 18 4.1.8TEST RESULTS (C) .................................................................................... 24 4.2RADIATED EMISSION MEASUREMENT ................................................... 30 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................. 30 4.2.2TEST INSTRUMENTS................................................................................. 31 4.2.3TEST PROCEDURES ................................................................................. 32 4.2.4TEST SETUP .............................................................................................. 33 4.2.5EUT OPERATING CONDITIONS ................................................................ 33 4.2.6TEST RESULTS (A) .................................................................................... 34 4.2.7TEST RESULTS (B) .................................................................................... 38 4.2.8TEST RESULTS (C) .................................................................................... 42 4.36DB BANDWIDTH MEASUREMENT .......................................................... 47 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................ 47 4.3.2TEST INSTRUMENTS................................................................................. 47 4.3.3TEST PROCEDURE.................................................................................... 48 4.3.4TEST SETUP .............................................................................................. 48 4.3.5EUT OPERATING CONDITIONS ................................................................ 48 4.3.6TEST RESULTS .......................................................................................... 49 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 53 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 53 FCC ID: PD5LMWP210 Report No.: RF900906R03 3 Issued: October 24, 2001 4.4.2TEST INSTRUMENTS................................................................................. 53 4.4.3TEST PROCEDURES ................................................................................. 54 4.4.4TEST SETUP .............................................................................................. 54 4.4.5EUT OPERATING CONDITIONS ................................................................ 54 4.4.6TEST RESULTS .......................................................................................... 55 4.5POWER SPECTRAL DENSITY MEASUREMENT ...................................... 56 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 56 4.5.2TEST INSTRUMENTS................................................................................. 56 4.5.3TEST PROCEDURE.................................................................................... 57 4.5.4TEST SETUP .............................................................................................. 57 4.5.5EUT OPERATING CONDITIONS ................................................................ 57 4.5.6TEST RESULTS .......................................................................................... 58 4.6BAND EDGES MEASUREMENT ................................................................ 62 4.6.1LIMITS OF BAND EDGES MEASUREMENT .............................................. 62 4.6.2TEST INSTRUMENTS................................................................................. 62 4.6.3TEST PROCEDURE.....…

Text truncated - open the document above for the full version.

FCC ID: PD5LMWP210 Report No.: RF900906R03 67 Issued: October 24, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PD5LMWP210 Report No.: RF900906R03 68 Issued: October 24, 2001 RADIATED EMISSION TEST
