PD5LMWU200Wireless USB Adapter

Wireless USB Adapter User Manual Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interfere nce received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna, (2) Increase the separation between the equipment and receiver, (3) Connect the equipment into an outlet on a circuit different from that to wh ich the receiver is connected, (4) Consult the dealer or an experienced radio/TV technician for help. Federal Communications Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation. Wireless USB Adapter iii TABLE OF CONTENT INTRODUCTION ............................................................................. 1 CONNECT THE USB ADAPTER TO YOUR DESKTOP PC ..... 2 H ARDWARE I NSTALLATION ............................................................... 2 DRIVER INSTALLATION............................................................... 2 I NSTALL D RIVER U NDER W INDOWS 98 ............................................ 2 I NSTALL D RIVER U NDER W INDOWS ME .......................................... 6 I NSTALL D RIVER U NDER W INDOWS 2000 ........................................ 9 I NSTALL D RIVER U NDER W INDOWS XP ......................................... 13 CONFIGURATION UTILITY .... ................... ................... ............. 16 I NSTALL THE C ONFIGURATION U TILITY .......................................... 16 C ONFIGURE THE C ONFIGURATION U TILITY .................................... 20 Wireless USB Adapter 1 Introduction The Wireless USB Adapter solution overcomes the limitations of wired networks by providing fast, simple, mobile and reliable access. It is designed for desktop computers running Windows 98, 2000, Millennium and XP. Features ƒ Complies with the IEEE 802.11b Direct Sequence Spread Spectrum ƒ Complies with USB specification 1.0 ƒ Supports 1, 2, 5.5 and 11Mbps Data Rates ƒ Wired Equivalent Privacy (WEP) 40-bit data encryption ƒ Provides Firmware upgrade utility via USB port ƒ Uses USB Bus power with no external power supply needed ƒ Dipole antenna ƒ Driver Supports Microsoft®Windows®98/2000, Millennium and XP Wireless USB Adapter 2 Connect the USB Adapter to Your Desktop PC Hardware Installation ƒ Power on your desktop PC. ƒ Connect the USB Adapter to the USB port of your desktop PC. ƒ Insert the driver CD into your CD-ROM. ƒ The Hardware Installation is complete. Driver Installation Install Driver Under Windows 98 1. Connect the Wireless USB adapter into your PC. Windows 98 automatically recognize a new USB device. Click the Next button to proceed. Wireless USB Adapter 3 2. Select “Search for the best driver for your device” and click the Next button to continue. 3. Make sure that Specify a location is selected and click the Browse button. At this point, Windows will ask you to browse for the folder. Simply select the folder in which the driver is located and click the Next button. Wireless USB Adapter 4 4. Windows is now ready to install the driver. Click the Next button to continue. 5. After Windows copies the files from your CD, you will be notified that installation has been complete. Click the Finish button to continue. Wireless USB Adapter 5 6. Windows will now ask you to restart your computer. Click the Ye s button to restart your PC. 7. Click right on My computer and select Properties. Select Device Manager and click on the Network adapters. You will find the LM-WU200 Wireless LAN USB Adapter, if it has been installed successfully. The USB adapter driver installation is complete. You can continue on to Utility Installation. Wireless USB Adapter 6 Install Driver Under Windows ME 1. Windows automatically recognizes that a new USB has been added. Select Automatic search for a better driver [Recommended] and click the Next button to proceed. 2. At this point, Windows will ask you for new drivers. Click the Browse button, simply select the folder in which the driver is located and click the OK button to proceed. Wireless USB Adapter 7 3. Windows will indicate that the installation has been complete. Click the Finish button to continue. 4. Windows will now ask you to restart your computer. Click the Ye s button to restart. Wireless USB Adapter 8 5. To verify the driver installation, move cursor on the “ My computer ” icon and right click your mouse. Select Propertie s. The System Properties window appears. Click Network adapters on the Device Manager folder. LM-WU200 Wireless LAN USB Adapter will be listed if the driver installation was successful. Wireless USB Adapter 9 Install Driver Under Windows 2000 1. Install Wireless USB Adapter to your PC. Windows 2000 will automatically identify the USB Adapter. Click the Next button to proceed. 2. Sele…

Text truncated - open the document above for the full version.

FCC ID:PD5LMWU200 DELTA NETWORKS, INC. No. 8, Kon Jan West road, Liutu industrial Zone, Keelung 206,, Taiwan, R.O.C Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commissionís Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Parts Lists Operational Descriptions The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Alex Shen Engineer

Advance Data Technology Corporation誠信科技股份有限公司 誠信科技股份有限公司誠信科技股份有限公司 誠信科技股份有限公司 13-1 Lane 19, Wen Shan 3rd St., Kweishan, Taoyuan, Taiwan, R.O.C. 桃園縣龜山鄉文㆔㆔街19巷13-1號 http://www.adt.com.tw/ E-mail: [email protected] TEL: 886-3-3270910 FAX: 886-3-3270892 服務項目 EMC/ SAFETY/ RADIO CERTIFICATION、ID/ MECH. DESIGN、GRAPHICS/TECH. WRITING SERVICES 您產品開發的最佳伙伴 YOUR BEST PARTNER IN PRODUCT DEVELOPMENT 誠信確實•專業第㆒•顧客至㆖ INTEGRITY•PROFESSIONALISM•CUSTOMER SATISFACTION FCC ID: PD5LMWU200 To whom it may concern, I hereby declare that this product should be classified as Digital Transmission System (DTS). If you have any question, please do not hesitate to contact me. Thank you. Regards, Dr. Alan Lane Manager, ADT [email protected]

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

FCC ID LABEL LOCATION

Page 3 Page 4

FCC ID: PD5LMWP200 ADT No.900809R01 Operational Description The transmitter of the EUT (WLAN PCMCIA Card) is powered by notebook and connected with notebook through RJ45 port. The antenna is patch antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PD5LMWU200 Report No.: RF900817R01 1 Issued: August 31, 2001 FCC TEST REPORT REPORT NO.: RF900817R01 MODEL NO.: LM-WU200 RECEIVED: August 17, 2001 TESTED: August 24 ~ August 28, 2001 APPLICANT: DELTA NETWORKS, INC. ADDRESS: 8, Kon Jan West Road, Liutu Industrial Zone, Keelung, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: PD5LMWU200 Report No.: RF900817R01 2 Issued: August 31, 2001 Table of Contents 1CERTIFICATION ...........................................................................................4 2SUMMARY OF TEST RESULTS...................................................................5 3GENERAL INFORMATION ...........................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................6 3.2DESCRIPTION OF TEST MODES................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ...............................7 3.4DESCRIPTION OF SUPPORT UNITS..........................................................8 4TEST TYPES AND RESULTS.......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.................................................... 9 4.1.2TEST INSTRUMENTS....................................................................................................... 9 4.1.3TEST PROCEDURES..................................................................................................... 10 4.1.4TEST SETUP .................................................................................................................. 10 4.1.5EUT OPERATING CONDITIONS..................................................................................... 11 4.1.6TEST RESULTS ..............................................................................................................12 4.2RADIATED EMISSION MEASUREMENT ...................................................18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 18 4.2.2TEST INSTRUMENTS..................................................................................................... 19 4.2.3TEST PROCEDURES..................................................................................................... 20 4.2.4TEST SETUP .................................................................................................................. 21 4.2.5EUT OPERATING CONDITIONS..................................................................................... 21 4.2.6TEST RESULTS ..............................................................................................................22 4.36DB BANDWIDTH MEASUREMENT ..........................................................26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT.............................................................. 26 4.3.2TEST INSTRUMENTS..................................................................................................... 26 4.3.3TEST PROCEDURE........................................................................................................ 27 4.3.4TEST SETUP .................................................................................................................. 27 4.3.5EUT OPERATING CONDITIONS..................................................................................... 27 4.3.6TEST RESULTS ..............................................................................................................28 4.4MAXIMUM PEAK OUTPUT POWER ..........................................................32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................. 32 4.4.2INSTRUMENTS...............................................................................................................32 4.4.3TEST PROCEDURES..................................................................................................... 33 4.4.4TEST SETUP .................................................................................................................. 33 4.4.5EUT OPERATING CONDITIONS..................................................................................... 33 4.4.6TEST RESULTS ..............................................................................................................34 4.5POWER SPECTRAL DENSITY MEASUREMENT......................................35 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ......................................... 35 4.5.2TEST INSTRUMENTS..................................................................................................... 35 4.5.3TEST PROCEDURE........................................................................................................ 36 4.5.4TEST SETUP .................................................................................................................. 36 4.5.5EUT OPERATING CONDITION ....................................................................................... 36 4.5.6TEST RESULTS ..............................................................................................................37 4.6BAND EDGES MEASUREMENT ................................................................41 FCC ID: PD5LMWU200 Report No.: RF900817R01 3 Issued: August 31, 2001 4.6.1LIMITS OF BAND EDGES MEASUREMENT .............................…
