1/2 Infinition Inc. BR-10XX Doppler Radar Tuning Procedure Transmitter Power Tuning The transmitter of the radar unit can operate at two different power levels. The power level can be selected by the operator using the toggle switch located on the antenna function panel. The transmitter can be set either to low or high power. There is a LED indicator on the function panel to warn the operator when the transmitter is in high power mode. The tuning of the transmitter power is done by adjusting the amount of attenuation applied on the microwave signal in the Power Amplifier (PA). The attenuation is set by the voltage applied on the PA attenuator terminal. This function is under the control of the antenna controller board (assy# 1000090-001). This board has two miniature potentiometers that are used to fine-tune the output power. Picture 1. Assy# 1000090-001 Antenna Controller board This document presents the procedure to adjust the transmitter power at the antenna port for both transmitter levels supported by the radar (see table 1). Radar Function Panel Transmitter Power Switch Position DescriptionOutput Power DownLow Transmitter Power20 dBm (100 mW) UpHigh Transmitter Power33 dBm (2 W) Table 1. Radar Output Power. R9 Low Power Potentiometer R13 High Power Potentiometer 2/2 The signal level can be measured using either a spectrum analyzer or a microwave power meter. First, the antenna must be connected to the main supply and switched off. The semi-rigid cable between the antenna and the PA must be removed. Then, the measuring instrument (a spectrum analyzer or a power meter) must be connected to the PA output. For measuring at high power level, it can be required to use a high power attenuator in order to bring the signal level in the usable range of the measuring instrument. To tune the output power at the “Low” setting, the transmitter power control switch on the antenna function panel must be set to “Low”. Once the measuring instrument is properly connected to the PA output, the antenna as well as the transmitter can be swithed on using the appropriate control switches on the function panel. The potentiometer R9 can then be used to fine tune the PA output to obtain 20dBm at the antenna port. To tune the output power at the “High” setting, the transmitter power control switch on the antenna function panel must be set to “High”. Once the measuring instrument is properly connected to the PA output, the antenna as well as the transmitter can be swithed on using the appropriate control switches on the function panel. The potentiometer R13 can then be used to fine tune the PA output to obtain 33dBm at the antenna port. Transmit Antenna Port Semi-rigid Cable PA Output Power Amplifier (PA) Antenna Controller Board Picture 2. Radar Transmitter

In respones to the dc voltages applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range: Final radio frequency amplifying device 1. Operates at 12 VDC, 2.5 A max. 2. Power ON/OFF control is via TTL (+5 V = OFF) applied to the Power ON/OFF terminal of the device 3. Gain Control is via 0 - 10 VDC (15 dB variation min.) applied to the Gain Control terminal of the device

Test setup photo – FCC ID: PDGBR-1022
