PER-DBM1001TXWINNIE THE POOH BABY PHONE

DBM1001-RWP Baby Monitor Picture Frame User’s Guide Monitor de Bebé con Cuadro Para Fotos Manual del Usuario Moniteur de Bébé en Forme de Cadre Guide d'utilisation For additional set-up or operating assistance, please visit our website at www.disneyelectronics.com or contact customer service at (954) 660-7026. Please keep all packaging material for at least 90 days in case you need to return this product to your place of purchase or Memcorp. For parts and accessories, contact Fox International at 1-800-321-6993. Distributed by Memcorp Inc., Weston, FL, Disney Elements © Disney 2005. Para informacion adicional sobre la configuracion o si necesita asistencia con la operacion del equipo, por favor visitenos en nuestra pagina web www.disneyelectronics.com o si requiere asistencia directa, comuniquese con nuestro departamento de servicio al cliente al numero (954) 660-7026. Por favor mantenga todo el material de empaque por lo menos por 90 dias, en caso que usted necesite devolver el producto donde lo compro a directamente a Memcorp Inc. Para Accesorios o Partes en general, por favor comuniquese con Fox International al numero 1-800-321-6993. Distribuido por Memcorp Inc. Weston, FL, Disney Elements ©Disney 2005. Pour obtenir des informations supplémentaires sur l’installation ou une assistance concernant l’emploi de votre produit, veuillez visiter notre site Web sur www.disneyelectronics.com ou contacter notre service clientèle au (954) 660-7026. Veuillez conserver tout matériel d’emballage pendant au moins 90 jours au cas où vous devriez renvoyer votre produit à votre revendeur ou directement à Memorex. Pour les pieces et les accessoires, contactez Fox International at au 1-800-321-6993. Éléments Disney ©Disney 2005. Distribué par MEMCORP. Inc. Weston, Floride Job # DBM1001-RWP Colors: 1-color print Pantone 659c 5.5”wideFO LD FO LD 8” high

The Quick Reference guide is given to provide basic operation of the unit. Please completely read the user’s guide to take advantage of all the features this unit has to offer. QUICK REFERENCE GUIDE 1 Lights when the power is on Built-In Mic detects sounds Slide to turn the unit On or Off Slide to select a Channel to transmit the sound Insert a 6V Adapter Antenna Lights when the power is on Lights when sound is received Speaker Rotate to turn the unit on and adjust the volume Lights when the batteries are low Slide to select a Channel to receive the sound SIMPLIFIED OPERATION 1. For the Monitor (Transmitter), connect the AC adapter (included) to the DC 6V IN jack. For the Receivers, connect the AC adapter (included) to the DC 6V IN jack or insert batteries. Place the transmitter in the same room as the child. Point the micro- phone toward the crib or play area. Place the receiver(s) in the room where you will be or if using batteries, connect to your belt using the belt clip. 2. Slide the POWER switch on the transmitter to the ON position; the POWER indicator will light. 3. Slide the CHANNEL switch on the transmitter to the 1 or 2 position. 4. Slide the CHANNEL switch on one or both of the receivers to the 1 or 2 position to match the transmitter’s setting made in step 3. 5.Rotate the Power/VOLUME control on one or both receivers counterclockwise until a click is heard; the POWER indicator will light. Then, adjust the volume as desired. When a sound is heard, the SOUND LEVEL indicators will light (the more lights, the louder the sound) and the sound will be heard through the speaker(s). Rotate the Power/VOLUME control clockwise until a click is heard to turn the unit of f; the POWER indicator will turn off. Dear Customer, Please read this manual thoroughly before operating the unit to become more famil- iar with it and obtain the performance that will bring you continued enjoyment for many years. Keep these instructions handy for future reference. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. For future reference, record the serial number of the unit printed on the rear of the cabinet. Serial Number _______________________________________ 2 FCC INFORMATION Warning: Modifying, tampering and/or adjusting this unit or replacement of any transmitter component (crystal, semiconductor, etc.) in this unit could result in a violation of the rules. RF EXPOSURE This Baby Monitor contains a low power transmitter. When the power is on, it send out radio frequency (RF) signals. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure compliance guidelines with safety lev- els for wireless devices. IMPORTANT NOTE: To adhere to the FCC RF exposure compliance require- ments, no change to the antenna or the unit is permitted. Any change to the anten- na or the unit could result in the system exceeding the RFexposure requirements. IMPORTANT To maintain compliance with the FCC’s RF exposure guidelines hold the transmit- ter and antenna at least 1 inch (2.5 centimeters) away from your face, with anten- na pointed up and away from your face. Ensure that the antenna is at least 1 inch (2.5 centimeters) from your body when using your Baby Monitor’s transmitter. Use only the supplied antenna. Unauthorized antennas, modifications or attachments could damage the transmitter and may violate FCC regulations. Warning:Changes or modifications not expressly approved by the party respon- sible for compliance could void the user’s authority to operate the equipment. 3 INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. ADDITIONAL PRECAUTIONS • Non-Use Periods: When the units are not in use, unplug the AC adapters from the wall outlets and remove the batteries from the units until they are ready to be used again. • Adapters: Make sure cords are free of any entanglements and are not in areas where people might come in con- tact with them. Please use only those AC adapters that are included with the product. Do not use AC adapters which are damaged or which have frayed or worn cords. •Positioning: Do not place the unit in cribs, playpens or anywhere within the child's reach. Keep adapter cords out of child’s reach. Do not place the units or adapters where a child could use them as a step. •Safety: Please be careful when locat- ing the monitor and camera that the cord is situated in an area that will elim- inate the chance of tripping over the cord. Also, make sure the antenna is in an area that will eliminate the possibility of poking your eye, etc. IMPORTANT SAFETY INSTRUCTIONS WARNING Choking Hazard–Small Parts and Packaging Materials. Not for children under 8 years. •All materials for fastening or packing purposes are not part of the unit and should be discarded for children’s safety. • Please keep all information for future reference. • This is not a toy. CAUTION! ELECTRONICALLY OPERATED PRODUCT:…

Text truncated - open the document above for the full version.

1 2 34 ABCD 4 3 2 1 D CBA 1 TSUEN SHING ELECTRONICS LTD 1 BLK-DBM1001-01A A Title Size: Model No.: Rev.: Sheet of A4 BABY PHONE(TX) DWG.: Drawing No.: CHK.:APP.: DBM1001 ENG-015-B NOTE: REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE: $ )  $ 0 3 $ * & + MIC 9 2 ; CH116.610MHzCH216.620MHz SWA CHANNEL SWITCH 7 ;  < 2 8 1 * ( 5  7 ;  3 2 : ( 5  $ 0 3 BB721 3 2 : ( 5  6 : , 7 & + 2 6 & ANT 6.0V INPUT VDD 5.0V 3 2 : ( 5  $ ' - 8 6 7 2 5 $ 66=+$1* ᇍᑨ⬉ॳ⧚೒ 6&+'%0$ 1 23 Sw1POWER NO/OFF CH1 49.830MHz CH1 49.830MHz CH2 49.860MHz CH2 49.860MHz   2005/08/05

Technical Description TRANSMITTER UNIT C. CIRCUIT OPERATION : 1. FM RF TRANSMITTER MODULE ,OPERATION FREQUENCY CHANNEL 1 49.830MHz, CHANNEL 2 49.860MHz. 2. DC VOLTAGE REGULATOR. 3. MIC AMPLIFIER. 4. TX MUTE TONE SQUELCH. D. COMPONENT DESCRIPTION CATEGORY NUMBER NAME DESCRIPTION INTEGRATED CIRCUIT LM324 QUAD OPOERATION AMPLIFIER MIC AMPLIFIER , AUDIO AGC.,TX MUTE TONE SQUELCH. INTEGRATED CIRCUIT 7805 VOLTAGE REGULATOR REGULATED THE DC OUTPUT VOLTAGE QUARTZ CRYSTAL X1 16.610MHz X2 16.630MHz OSCILLATOR MODULATION AND OSCILLATOR CIRCUIT TRANSISTOR 9018H AMPLIFIER TRANSISTOR TX POWER AMPLIFIER TRANSISOR 3906 ,9014 SWITCH TRANSISTOR TX POWER CONTROL CIRCUIT INDUCTANE COIL L3 T2 T3 T4 INDUCTANE COIL CIRCUIT FILTER CHOOSE FREQUENCY CIRCUIT

1 2 34 ABCD 4 3 2 1 D CBA 1 TSUEN SHING ELECTRONICS LTD 1 SCH-DBM1001-01A A Title Size: Model No.: Rev.: Sheet of A4 BABY PHONE(TX) DWG.: Drawing No.: CHK.:APP.: DBM1001TX ENG-015-B NOTE: REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE:REV:NAME:DATE: + MIC1 R91K R74.7K + C810uF C1 47N C2100N R271M R11100K R101K R410K R281M C17 100P C15100N C9 100N R24.7K D2 1N4148 D11N4148 + C101uF Q39014 R30510K R2939K C18100P C16100N R31CN R132.2K R1539KR16100 R1412K C310N + C12100uF R310K R3222K Q49014 Q5 3906 C710N R26100 R38150K R3656K R40270 T2 C2118P R372.2K C191N Q79018 Q99018 C2933PC3068P C610N + C13100uF D5 HVU350B R51.5K R354.7K R34330KR6100K L3 C1147N C2410P C22 22P T3 T4 C2510P Q89018 R12100K C2312P C510N C2725P C2625P T1 C201N + C14220uF C4 10N D3 1N4001 JK16.0V L1 6.8uH L2 6.8uH ANT1 X1 16.610MHz X2 16.620MHz 56 7 U1B LM324 32 1 411 U1A LM324 10 9 8 U1C LM324 1213 14 U1D LM324 R25100 R17100 R231.5K R84.7K DZ1CN L4 SW2A Channel Selection VDD 5.0V C3110N R1856K C3210N C3333P R39 56 C341N C DZ23.6V + C35 0.47uF R20560K VR1 20K L5 1uH C37 0.22uF SW2B Channel Selection L6 Q1 9014 R1956KR2212K R335.6K VCC A 首次发行 ZHCHANG2005.09.02 LED1GREEN VCC 1 23 Sw1 POWER NO/OFF R1 56K B 1 2 3 U27805 TP1 TEST C28 2P

TEST REPORT Report No. : AF020964-001 Date : 2005 September 07 For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 12 Danny Chui EMC Engineer - EL. Division FCC ID : PER-DBM1001TX This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF213743(9) Applicant : Tsuen Shing Enterprises Ltd. 19/F., Billion Plaza, No. 8 Cheung Yue Street, Cheung Sha Wan, Kowloon, Hong Kong. Sample Description : One(1) submitted sample stated to be Winnie The Pooh Baby Phone of Model No. DBM1001-RWP, DBM1001-CWP Rating : DC 6V AC 120V No. of submitted sample : Two (2) piece(s)*** Date Received : Test Period : Test Requested : Test Method : Test Result : Conclusion : 2005 August 25 2005 August 25 – 2005 September 06 FCC Part 15 Certification FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 See attached sheet(s) from page 2 to 12. The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. Remark : All two models are the same in circuitry and components and construction, and therefore model DBM1001-RWP was chosen to be the representative of the test sample. TEST REPORT Report No. : AF020964-001 Date : 2005 September 07 Page 2 of 12 FCC ID : PER-DBM1001TX This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information .................................................................................................................................. 3 1.1 General Description ........................................................................................................................... 3 1.2 Location of the test site ...................................................................................................................... 4 1.3 List of measuring equipment.............................................................................................................. 5 2 Description of the radiated emission test .................................................................................................. 6 2.1 Test Procedure ................................................................................................................................... 6 2.2 Test Result ......................................................................................................................................... 6 2.3 Radiated Emission Measurement Data .............................................................................................. 7 3 Description of the Line-conducted Test .................................................................................................... 9 3.1 Test Procedure ................................................................................................................................... 9 3.2 Test Result ......................................................................................................................................... 9 3.3 Graph and Table of Conducted Emission Measurement Data ........................................................... 9 4 Photograph .............................................................................................................................................. 10 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission........................... 10 4.2 Photographs of the External and Internal Configurations of the EUT............................................. 10 5 Supplementary document ......................................................................................................................... 11 5.1 Bandwidth ........................................................................................................................................ 11 5.2 Duty cycle ........................................................................................................................................ 11 6 Appendices ............................................................................................................................................... 12 TEST REPORT Report No. : AF020964-001 Date : 2005 September 07 Page 3 of 12 FCC ID : PER-DBM1001TX This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for Winnie The Pooh Baby Phone. Operating at 49.830MHz or 49.860MHz which is controlled by a crystal. The EUT is powered by a AC 120V to DC 6V adaptor. There are a microphone and a channel selector in front of the EUT. When Channel 1 (49.830MHz) or Channel 2 (49.860MHz) is selected, it will transmit a radio signal to receiver. The brief circuit description is listed as follows : - X1, X2 and associated circuit act as oscillator. - U2 7805 and associated circuit act as voltage regulator. - 9018 and associated circuit act as Tx power amplifier. - 3906, 9014 and associated circuit act as Tx power control circuit. - L2, T2, T3, T4 and associated circuit act as filter. TEST REPORT Report No. : AF020964-001 Date : 2005 September 07 Page 4 of 12 FCC ID : PER-DBM1001TX This document shall not be reproduced either in full or in part except with written ap…

Text truncated - open the document above for the full version.
