PFNDMT1730Digital Cable Set-top Box

1 Important safety instructions & FCC information 1.1 Safety The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. The lighting flash with arrowhead symbol, Within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION :TO REDUCE THE RISK OF ELECTRIC SHOK DO NOT REMOVE COVER(OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. FOR YOUR SAFETY - The space around the receiver should be clear to allow for proper ventilation of the receiver. - Do not cover the receiver or place it on a unit that emits heat - Use a damp soft cloth to clean the casing. - Do not connect or disconnect cables when the receiver is plugged in. - Do not remove the cover. - Do not allow the unit to be exposed to hot, cold or humid conditions. - Never allow liquids, spray or other materials to come into contact with the inside of the receiver. Outdoor Use Marking Warning : To prevent fire of electric shock, do not expose this appliance to rain or moisture. Cable System Installation Marking Note to CATV System Installer: This reminder is provided to call CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical Polarized Attachment plug Marking Caution : To prevent electric shock, match wide blade of plug to wide slot, fully insert. Important Safety Instruction 1) Read Instructions : All the safety and operating instructions should be read before the product is operated. 2) Retain Instructions : The safety and operating instruction should be retained for future reference. 3) Head Warnings : All warnings on the product and in the operating instructions should be adhered to. 4) Follow instructions : All operating and use instructions should be followed. 5) Cleaning : Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaner. Use a damp cloth for cleaning. 6) Exception : A product that is meant or uninterrupted service and that for some specific reason, such as the possibility of the loss of and authorization code for c CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the product in the cleaning description otherwise required in this article. 7) Attachment : Do not use attachments not recommended by the product manufacturer as they may cause hazards. 8) Water and Moisture : Do not use the product near water for example, near a bath, wash bowl, kitchen sink, or laundry tub ; in a wet basement; or rear a swimming pool; and the like. 9) Accessories : Do not place this product on an unstable cart, stand, tripod, bracket, or table. This product may fall, causing serious injury to a child or adult, and serious damage to the product. 10) A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surface may cause the product and cart combination to overturn. Please refer to picture 1 in the end of this chapter. 11) Ventilation : Slot and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protest it from overheating, and these openings must not be blocked by covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. 12) Power sources : This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the perating instructions. 13) Grounding or Polarization : This product may be equipped with a polarized alternating current line plug(a plug having on blade wider than the other). This plug will fit into the power outlet only on way. This is a safety feature. If you are unable to insert the plug gully into the outlet, try reversing the plug. If the plug should still fail to fir, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarizing plug. Alternate Warning : This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug. 14) Power-Cord Protection : Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product. 15) Protective Attachment Plug : The product is equipped with an attachment plug having overload protection. This is a safety feature. See instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the mnufactu- rer that has the same overload protection as the original plug. 16) Outdoor Antenna Grounding : If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so a…

Text truncated - open the document above for the full version.

Appendix E. Block Diagram ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 1 of 1 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730

Appendix C. External Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 1 of 4 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Front side View of The EUT Rear side View of The EUT Appendix C. External Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 2 of 4 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 View of The Power Appendix C. External Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 3 of 4 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 View of Cover Appendix C. External Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 4 of 4 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730

Appendix A. FCC ID Label and Location ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 1 of 2 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Product Label Sample with FCC Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC ID Label and compliance statement are marked in the product label. Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box FCC ID : PFNDMT1730 Model NO : DMT1730 POWER : DC 12V 1.0A, 10W Serial No : N/A Manufacturer : KOBAS ELECTRONICS Co., Ltd. Made in Korea Appendix A. FCC ID Label and Location ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 2 of 2 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Label here

Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 1 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Inside View of The EUT Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 2 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Component side view of Main Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 3 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Solder side view of Main Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 4 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Component side view of Front board Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 5 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Solder side view of Front board Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 6 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Inside view of Power Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 7 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Component side view of Power board Appendix D. Internal Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 8 of 8 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Solder side view of Power board

FCC TEST REPORT ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-880, Korea Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Form NO: ETL(E)004A4001201-0 of 21 2.1 Equipment Description The Equipment Under Test(EUT) is the Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model : DMT1730. 2.2 General Specification - Chassis Type : Metal - List of Each OSC. Or X-Tal. Freq.(>=1MHz) : 27MHz -. CATV Tuner input frequency : 50 ~ 860MHz -. CATV Tuner digital input signal level : -20 to +30 dBmV -. CATV Tuner noise figure : >8dB -. CATV Tuner LO phase noise at 10KHz : -88dBc/Hz -. QAM Demodulation type : 16, 32, 64, 128, 256 QAM -. QAM Simbol rate : 5.5Msps max -. QAM Channel Bandwith : 6MHz -. Video out format : CVBS -. Video out impedance : 75 unbalanced -. Video out bandwidth : 5MHz -. Audio out impedance : 1 unbalanced -. Audio out level : 0.6V rms 2dB into 10 -. S-VHS out Video format : Y, C -. S-VHS out impedance : 75 unbalanced -. S-VHS out bandwidth : 5MHz -. Digital audio output type : Spdif encoded signals with ac-3 -. Digital audio sampling frequency rate : 32, 44.1 or 48KHz -. RF Modulator output signal : NTSC M -. RF Modulator video carrier frequency : 61.25 90KHz(US 3 CH), 67.25 90KHz(US 3 CH) -. Power Supply type : External Adapter(100~240V AC @ 50/60Hz, 3.0A) -. Power Supply input voltage : 100~240V AC @ 50/60Hz, 3.0A -. Power Supply output voltage : 12V DC / 1.0A -. Nominal power consumption : 10W

www.ETL.re.kr E-RAE Testing Laboratory This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the ETL,Inc. Electromagnetic Emission FCC MEASUREMENT REPORT VERIFICATION OF COMPLIANCE FCC Part 15 Certification Measurement This Digital Cable Set-top Box, Model DMT1730 has been tested in accordance with the measurement procedures specified in ANSI C63.4-1992 at the ETL/EMC Test Laboratory and has been shown to complied with the electromagnetic radiated emission limits specified in FCC Rule Part15 Subpart B: TV interface device. I attest to the accuracy of data. All measurement here in was performed by me or was made under my supervision and is correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results of testing in this report apply to the product/system, which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Yo Han, Park / Chief Engineer E-RAE Testing Laboratory Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea PRODUCT : Digital Cable Set-top Box MODEL/TYPE NO : DMT1730 FCC ID : PFNDMT1730 APPLICANT / ADDRESS : Digital Multimedia Technology Co., Ltd. Droorim Bldg.4 th Fl., 164-21 Poi-Dong, Kangnam-Gu, Seoul, 135-260 Korea Attn.: Joo-Hyun Kim / Manager FCC CLASSIFICATION : HID : TV interface device FCC RULE PART(S) : FCC Part 15 Subpart B FCC PROCEDURE : Certification TRADE NAME : TEST REPORT No. : E04.0525.FCC.291N DATES OF TEST : May 06 ~20, 2004 DATES OF ISSUE : May 25, 2004 TEST LABORATORY : ETL Inc (FCC Registration Number: 95422) #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel: (031) 885-0072 Fax: (031) 885-0074 FCC TEST REPORT ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-880, Korea Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Form NO: ETL(E)004A4001201-0 Table of Contents ATTACHMENT A: COVER LETTER(S) FCC Measurement Report 1. Introduction 2. Product Information 3. Description of Tests 4. Test Condition 5. Test Results 5.1 Summary of Test Results 5.2 Conducted Emission Test 5.3 Radiated Emission Test 5.4 Output Signal Level Measurement 5.5 Output Terminal Conducted Spurious Emission Measurement 5.6 Transfer Switch Measurement 6. Sample Calculations 7. List of test Equipment used for Measurement Appendix A. FCC ID Label and Location Appendix B. Test Setup Photographs Appendix C. External Photographs Appendix D. Internal Photographs Appendix E. Block Diagram Appendix F. Operating Manual FCC TEST REPORT ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-880, Korea Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Form NO: ETL(E)004A4001201-0 of 21 FCC MEASUREMENT REPORT Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) General Information l EUT Type : Digital Cable Set-top Box l Model Number : DMT1730 l FCC Identifier : PFNDMT1730 l S/N : N/A l Freq. Range : 50 MHz – 860 MHz l FCC Rule Part(s) : Part 15 Subpart B l Test Procedure : ANSI C63.4-1992 l FCC Classification : TV Interface Device l RF Channels : Ch. 3 / Ch. 4 l Dates of Tests : May 06 ~ 20, 2004 l Place of Tests : ETL Inc 584, Sangwhal-Ri, Kanam-Myun, Yoju-Kun, Kyounggi-Do, Korea Tel : (031) 885-0072 Fax : (031) 885-0074 l Test Report No. : E04.0525.FCC.291N Applicant Name : Digital Multimedia Technology Co., Ltd. Address : Droorim Bldg.4 th Fl., 164-21 Poi-Dong, Kangnam-Gu, Seoul, 135-260 Korea Attention : Joo-Hyun Kim / Manager, R&D Center FCC TEST REPORT ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-880, Korea Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Form NO: ETL(E)004A4001201-0 of 21 The measurement test for radiated and conducted emission test were conducted at the open area test site of E-RAE Testing Laboratiry Inc. facility located at 584, Sangwhal-ri, Ganam-myun, Youju-kun, Kyoungki-do, Korea. The site is constructed in conformance with the requirements of the ANSI C63.4-1992 and CISPR Publication 16. The ETL has site descriptions on file with the FCC for 3 and 10 meter site configurations. Detailed description of test facility was found to be in compliance with the requirements of Section 2.948 FCC Rules according to the ANSI C63.4-1992 and registered to the Federal Communications Commission(Registration Number : 95422 ). The measurement procedure described in American National Standard for Method of Measurement of Radio-Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C.63.4-1992) was used in determining radiated and conducted emissions from the Digital Multimedia Technology Co.,Ltd. Digital Cable Set-top Box, Model : DMT1730. FCC TEST REPORT ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-880, Korea Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Form NO: ETL(E)004A4001201-0 of 21 2.1 Equipment Description The Equipment Under Test(EUT) is the Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model : DMT1730. 2.2 General Specification - Chassis Type : Metal - List of Each OSC. Or X-Tal. Freq.(>=1MHz) : 27MHz -. CATV Tuner input frequency : 50 ~ 860MHz -. CATV Tuner digital input signal level : -20 to +30 dBmV -. CATV Tuner noise figure : >8dB -. CATV Tuner LO phase noise at 10KHz : -88dBc/Hz -. QAM Demodulation type : 16, 32, 64, 128, 256 QAM -. QAM Simbol rate : 5.5Msps max -. QAM Channel Bandwith : 6MHz -. Video out format : CVBS -. Video out impedance : 75 unbalanced -. Video out bandwidt…

Text truncated - open the document above for the full version.

Appendix B. Test Setup Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 1 of 2 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Radiated Emission Test Setup Appendix B. Test Setup Photographs ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea 2 of 2 Digital Multimedia Technology Co., Ltd. Digital Cable Set-top Box Model: DMT1730 Conducted Emission Test Setup
