PFNWC10HDDIGITAL CABLE SETTOP-BOX (ZIGBEE EMBEDDED)

Digital Multimedia Technology Co., Ltd

Click to zoom

Application Details

Equipment Class: HID - Part 15 TV Interface Device
Date of Grant: Apr 11, 2012
Application Purpose: Original Equipment
Date of Application: Apr 11, 2012
Equipment Note: DIGITAL CABLE SETTOP-BOX (ZIGBEE EMBEDDED)
Frequency Range: 61.25000000 - 67.25000000
Company: Digital Multimedia Technology Co., Ltd
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Instruction Manual For WC10HD Digital Multimedia Technology Co., Ltd HDuDTA Manual 2 Contents I. Installing WC10HD 1. Component .......................................................................................... 3 2. Name of parts and role ....................................................................... 3 2-1. Remote control ................................................................................ 5 3. Installing .............................................................................................. 7 II. Notice 1. Dolby ................................................................................................... 8 2. UL ........................................................................................................ 9 3. FCC .................................................................................................... 11 HDuDTA Manual 3 I. Installing WC10HD 1. Component The following parts are included in the product package. Make sure that you received all the parts.  Main body of WC10HD  Remote Control  Power adaptor  RF Cable  User Manual  HDMI Cable 2. Name of parts and role  LED : LED Lights up green when power is on. Lights up red when in Stand-By Mode. 1 HDuDTA Manual 4 Cable In (Coax Cable) Connects the All Digital Device to a TV, VCR or receiver using a coax cable. TV Out (Coax Cable) Connects the All Digital Device to a TV, VCR or receiver using a coax cable. HDMI Out (HDMI Cable) Connects All Digital Device to a high definition TV, VCR or receiver. CH3/CH4 Selects TV Channel 3 or 4 as the output channel to your TV when the All Digital Device is connected using a coax cable from TV Out. Power In Connects the All Digital Device to a power source. HDuDTA Manual 5 2-1. Remote control ► Pressing the MUTE button on your remote control will mute the audio. ► Use the VOLUME UP/DOWN buttons (V +/-) on your remote control to raise and lower the volume. ► Use the CHANNEL UP/DOWN buttons (CH +/-) on your remote control to change channels. ► Press the NUMERIC buttons (0-9) on your remote control to tune directly to a specific channel. HDuDTA Manual 6 ► If the All Digital Device does not tune immediately after entering channel numbers, press the ENTER button on your remote control. POWER Switches the All Digital Device’s power on or into Stand-By Mode. MUTE Mutes the audio. 0~9 Enters Channel Numbers. In text windows, enters PIN-Code Numbers and various characters. LAST Switches between the current and previous channel. In the MENU SYSTEM LAST returns to the previous screen. VOLUME +/- Increases or decreases volume levels. CHANNEL +/- Selects the previous and next available channels. INFO Displays various information about the current program. ARROWS Moves to highlight items in respective direction. OK Confirms a selection. MENU Opens the MENU FEATURES screen of the MENU SYSTEM. EXIT Returns video to full screen from any INFO or MENU SYSTEM screen. HDuDTA Manual 7 3. Installing 1) Peripheral device setting A. Connect the All Digital Device to the TV. Use a coaxial cable to connect TV OUT on the All Digital Device to the ANT jack on the TV B. Connect the All Digital Device to the TV. Use an HDMI cable (not included) to connect HDMI OUT on the All Digital Device to the HDMI input on the TV C. Connect the wall cable source to CABLE IN on the All Digital Device. D. Connect the AC Adaptor to the POWER input on the All Digital Device. Connect the AC Adaptor to a power outlet on the wall. (A surge protected power outlet is recommended.) HDuDTA Manual 8 II. Notice 1. Dolby Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. HDuDTA Manual 9 2. UL Care and Maintenance Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Ensure that the power cord receptacle is accessible such that power can be easily disconnected if required. 11. Only use the attachments/accessories specified by the manufacturer. 12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicingis required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. The shock Hazard Marking and Associated Graphical Symbol is provided on the back panel of unit. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. HDuDTA Manual 10 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GR…

Text truncated - open the document above for the full version.

Cover Letter(s)

Digital Multimedia Technology Co.,Ltd. 2nd Fl., 926, Gwanyang-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea TEL : +82-31-420-7501 FAX : +82-31-420-7502 March 22, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 In re : Digital Multimedia Technology Co., Ltd. FCC ID : PFNWC10HD Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Digital Multimedia Technology Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Digital Multimedia Technology Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name Schematics CONF APPENDIX PFNWC10HD SCH DIA.pdf Parts list CONF APPENDIX PFNWC10HD PL.pdf Block diagram CONF APPENDIX PFNWC10HD BLK DIA.pdf CONFIDENTIAL Operational description CONF APPENDIX PFNWC10HD OpDes.pdf External Photos SHORT-TERM CONF PFNWC10HD EXT Photo.pdf Internal Photos SHORT-TERM CONF PFNWC10HD INT Photo.pdf Test-Setup Photos SHORT-TERM CONF PFNWC10HD Test Photo.pdf SHORT-TERM CONFIDENTIAL User’s Manual SHORT-TERM CONF PFNWC10HD Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Kee-Chul Lee/ Manager Digital Multimedia Technology Co., Ltd.

External Photos

FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 1 of 4 Model Name: WC10HD Upper FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 2 of 4 Front FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 3 of 4 Side FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 4 of 4

ID Label/Location Info

Internal Photos

FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 1 of 1 MainBoard - Front MainBoard - Rear

Test Report

Certification No. : LR500111203K Copyright 2012, LTA CO., LTD.Page 1 of 22 TEST REPORT Test Report No. : LR500111203K FCC ID : PFNWC10HD Issue Date : March 26, 2012 Applied Standard : FCC Part 15, Subpart B: (October 1,2010) Trade Name : Digital Multimedia Technology Co., Ltd. Category : QAM-B Model Name : WC10HD Variant Model name : DMS2004UHD W Serial Number : Identification This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. This laboratory is accredited by Radio Research Laboratory and National Voluntary Laboratory Accreditation Program. The tests reported herein have been performed in accordance with its terms of accreditation. Certification No. : LR500111203K Copyright 2012, LTA CO., LTD.Page 2 of 22 TABLE OF CONTENTS Text Page Contents ---------------------------------------------------------------------------------------------------------- 2 LTA Certification ----------------------------------------------------------------------------------------------- 3 General Information ----------------------------------------------------------------------------------------------- 5 Brief Information --------------------------------------------------------------------------------------------------- 6 Test site description -------------------------------------------------------------------------------------------------- 9 Test Procedure ------------------------------------------------------------------------------------------------------ 10 List of test equipment used for the test ----------------------------------------------------------------------- 13 Radiated disturbance measurement (Result & Graph) ----------------------------------------------------- 14 Conducted disturbance measurement (Result & Graph) --------------------------------------------------- 15 Antenna Conducted power Emissions Measurement --------------------------------------------------------- 17 Output Conducted level Emissions Measurement ----------------------------------------------------------- 18 Conducted Spurious Emissions ---------------------------------------------------------------------------------- 20 Conclusions --------------------------------------------------------------------------------------------------------- 22 Certification No. : LR500111203K Copyright 2012, LTA CO., LTD.Page 3 of 22 LTA Certification Applicant & Manufacture Company name : Digital Multimedia Technology Co.,Ltd. Address : 2nd Fl., 926, Gwanyang-dong, Dongan-gu, Anyang-si, Gyeonggi-do, Korea Telephone / Facsimile : TEL : +82-31-420-7501 / FAX : +82-31-420-7502 Equipment Under Test (EUT) Trade name : Digital Multimedia Technology Co., Ltd. Category : QAM-B Brand : - FCC ID : PFNWC10HD Model name : WC10HD Varient Model name : DMS2004UHD W Serial number : Identification Intended environment : Residential area Date of receipt : March 05, 2012 EUT condition : Pre-production, not damaged Operating Mode : QAM-B mode Interface Ports : CABLE IN, RF OUT, A/V OUT, IR IN, DC 5V IN Power Source : DC 5V – 2A Crystal/Oscillator(s) : 25MHz Firmware version : V1.0.0 Model Description - Model WC10HD is basic model, which was tested. - Model DMS2004UHD W is identical to model WC10HD except for model name. Model Specification - NONE Test Performed Test started & completed : March 19-26 , 2012 Location : LTA Co., Ltd. *** To be continued next page *** Certification No. : LR500111203K Copyright 2012, LTA CO., LTD.Page 4 of 22 LTA Certification –cont.- Test Specification Purpose of the test : Compliance test to the following standard Applied standard : FCC Part 15, Subpart B: (October 1,2010) Classification : Class B Deviations from Standard Test Method : N/A Test Results Measurement Results* Test method Radiated disturbance Complies ANSI C 63.4:2003: (October 1,2009) Conducted disturbance Complies ANSI C 63.4:2003: (October 1,2009) Antenna Conducted Power Emissions Complies ANSI C 63.4:2003 Output Conducted level Emissions Complies ANSI C 63.4:2003 Conducted Spurious Emissions Complies ANSI C 63.4:2003 * : The compliance statement is based on nominal value only. Modification performed by the lab.; - N.A -We were performed the test according to LTA procedure LTA-QI-04. Laboratory’s Certificate Report number : LR500111203K Issue date : March 26, 2012 This test report is issued under the authority of: The test was supervised by: Kyu-Hyun Lee, Manager Ki-Hun Cho, Test Engineer The results in this report apply only to the sample(s) tested. It is not allowed to copy this report even partly without the allowance of the test laboratory. Certification No. : LR500111203K Copyright 2012, LTA CO., LTD.Page 5 of 22 General information’s Purpose This document is based on the Electromagnetic Interference (EMI) tests performed on the “DC10HD”. The measurements were performed according to the measurement procedure described in ANSI C 63.4:2003. The tests were carried out in order to confirm whether the electromagnetic emissions from the EUT( Equipment Under Test), are within the class B limits defined in FCC Part 15, Subpart B- “Section 15.107- Conducted limits” and “Section 15.109-Radiated emission limits”. Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Measurement uncertainty Radiated disturbance (30 – 1000MHz) : +4.52 [dB] ,-4.43 [dB] (k=2) Conducted disturbance (0.15 – 30MHz) : +1.45 [dB] ,-1.45 [dB] (k=2) ANT. Conducted Emission (30 – 2150MHz) : ±0.54 [dB] (k=2) The coverage factor k=2 yields approx. a 95% level of confidence for near-normal distribution typical of most measurement results. Accredited agencies LTA Co., Ltd. Is approved to perform EMC testing by the following agencies: Agency C…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 1 of 3 Radiated Emission (30MHz – 1GHz) FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 2 of 3 Radiated Emission (Below 1GHz) FCC ID: PFNWC10HD Copyright c 2012, LTA Co., Ltd. Page 3 of 3 Conducted Emission
