PGE-XEU23Energy Saving Lamp

U SER ’ S M ANUAL User’s Manual The RF lighting device complies with part 18 of the FCC rules. 1. Use only on 120V, 60Hz. 2. Never disassemble or modify, any changes could void the user’s authority to operate this device. 3. Not for use in totally enclosed fixtures. 4. Risk of electric shock-do not use where directly exposed to water. 5. This device is not intended for use with emergency exit fixtures or emergency exit lights. 6. This product could produce interference when used near a TV, radio, wireless remote control or maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45~30MHz. If interference should occur, move the lamp away from the appliance into a different outlet. 7. To prevent burns, do not touch the bulb during operation or immediately after switching off. 8. Not for use with dimmers, electronic timers or photocell devices or occupancy sensors.

F IGURE 1 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-9T) G ENERAL A PPEARANCE FIGURE 2 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-11T) GENERAL APPEARANCE F IGURE 3 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-14T) G ENERAL A PPEARANCE F IGURE 4 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-9W) G ENERAL A PPEARANCE F IGURE 5 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-11W) GENERAL APPEARANCE F IGURE 6 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-14W) G ENERAL A PPEARANCE

9T XEU23-9T 155mA 120v/60Hz E215138 FCC ID: PGE-XEU23 76BN 9W XEU23-9W 155mA 120v/60Hz E215138 FCC ID: PGE-XEU23 76BN 11W XEU23-11W 170mA 120v/60Hz E215138 FCC ID: PGE-XEU23 76BN 11T XEU23-11T 170mA 120v/60Hz E215138 FCC ID: PGE-XEU23 76BN 14T XEU23-14T 200mA 120v/60Hz E215138 FCC ID: PGE-XEU23 76BN 14W XEU23-14W 200mA 120v/60Hz E215138 FCC ID: PGE-XEU23 76BN Label Drawing (XEU23-T, XEU23-W Series are in the size of 2:1)

Label Location Information Refer to the below red arrow: (for example)

F IGURE 1 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-9T) C OVER R EMOVED F IGURE 2 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-9T) M AIN B OARD (C OMPONENT S IDE ) FIGURE 3 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-9T) MAIN BOARD (SOLDERED SIDE) F IGURE 4 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-11T) C OVER R EMOVED F IGURE 5 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-11T) M AIN B OARD (C OMPONENT S IDE ) FIGURE 6 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-11T) MAIN BOARD (SOLDERED SIDE) Figure 7 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-14T) C OVER R EMOVED F IGURE 8 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-14T) M AIN B OARD (C OMPONENT S IDE ) FIGURE 9 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-14T) MAIN BOARD (SOLDERED SIDE) F IGURE 10 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-9W) C OVER R EMOVED F IGURE 11 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-9W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-9W) MAIN BOARD (SOLDERED SIDE) Figure 13 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-11W) C OVER R EMOVED F IGURE 14 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-11W) M AIN B OARD (C OMPONENT S IDE ) FIGURE 15 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-11W) MAIN BOARD (SOLDERED SIDE) Figure 16 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-14W) C OVER R EMOVED Figure 17 E LECTRONIC E NERGY S AVING L AMP (M/N: XEU23-14W) M AIN B OARD (C OMPONENT S IDE ) FIGURE 18 ELECTRONIC ENERGY SAVING LAMP (M/N: XEU23-14W) MAIN BOARD (SOLDERED SIDE)

Schematics

Firefly Lighting Co., Ltd. FCC ID: PGE-XEU23 Page 1 of 33 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01084 Application for FCC Certificate On Behalf of Firefly Lighting Co., Ltd. Energy Saving Lamp Model No.: XEU23-9W XEU23-11W XEU23-14W XEU23-9T XEU23-11T XEU23-14T FCC ID : PGE-XEU23 Prepared For: Firefly Lighting Co., Ltd. Firefly Building, Jinzhongyuan Industrial Area, Zhongzhai, Xiamen, China Prepared By: Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +8621-64955500 Fax: +8621-64955491 Report No.: ACI-F01084 Date of Test: Oct 09 -17, 2001 Date of Report: Oct 19, 2001 Firefly Lighting Co., Ltd. FCC ID: PGE-XEU23 Page 2 of 33 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01084 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test ........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration ...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures........................................................................................................................... 7 2.7 Test Results................................................................................................................................. 8 3 FIELD STRENGTH TEST ........................................................................................................... 14 3.1 Test Equipment......................................................................................................................... 14 3.2 Block Diagram of Test Setup ................................................................................................... 14 3.3 Test Configuration .................................................................................................................... 14 3.4 Operating Condition of EUT .................................................................................................... 14 3.5 Test Procedure .......................................................................................................................... 15 3.6 Test Result ................................................................................................................................ 15 Firefly Lighting Co., Ltd. FCC ID: PGE-XEU23 Page 3 of 33 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01084 TEST REPORT FOR FCC CERTIFICATE Applicant : Firefly Lighting Co., Ltd. Manufacturer : Firefly Lighting Co., Ltd. EUT Description : Energy Saving Lamp (A) Model No.: XEU23-9W XEU23-11W XEU23-14W XEU23-9T XEU23-11T XEU23-14T (B) Serial No.: E092001 E092002 E092003 E092004 E092005 E092006 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Oct 09 ~ 17, 2001 Prepared by : Test Engineer : LOUISE LU (Assistant) WINSTON HUA (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) Firefly Lighting Co., Ltd. FCC ID: PGE-XEU23 Page 4 of 33 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01084 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : XEU23-9W, XEU23-11W, XEU23-14W XEU23-9T, XEU23-11T, XEU23-14T Serial No. : E092001, E092002, E092003, E092004, E092005, E092006 FCC ID : PGE-XEU23 Applicant : Firefly Lighting Co., Ltd. Firefly Building, Jinzhongyuan Industrial Area, Zhongzhai, Xiamen, China Manufacturer : Firefly Lighting Co., Ltd. Firefly Building, Jinzhongyuan Industrial Area, Zhongzhai, Xiamen, China M/N Input Power (VA) Output Power (W) XEU23-9W 18.3 10.7 XEU23-11W 21.0 12.7 XEU23-14W 24.8 14.9 XEU23-9T 17.9 10.0 XEU23-11T 21.4 12.1 XEU23-14T 26.9 15.3 Firefly Lighting Co., Ltd. FCC ID: PGE-XEU23 Page 5 of 33 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01084 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Fede…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test (M/N: XEU23-9T) (M/N: XEU23-9W) (M/N: XEU23-11T) (M/N: XEU23-11W) (M/N: XEU23-14T) (M/N: XEU23-14W) 2. Radiated electromagnetic emission Test (M/N: XEU23-T SERIES) (M/N: XEU23-W S ERIES)
