PJ4ID-2400TRSpread Spectrum Wireless Recorder - Handset

USER’S MANUAL (IMPORTANT SAFETY INSTRUCTIONS & FCC NOTICE) √ IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basis safety precautions should always be followed to reduce the risk of life electric shock, and injury to persons, including the following. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink, or Laundry tub in a wet Basement or near a swimming pool. 5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to the product. 6. Slots and openings in the cabinet and the back or bottom are provide for ventilation, to protect it from overheating. These openings should never be blocked or covered. The opening should never should never be placed near or over a radiator or heat register. This product should not be placed in a built in installation unless proper ventilation is provided. 7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your dealer or local power company. 8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will be abused by persons walking on it. 9. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock. 10. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a of fire or electric shock. Never spill liquid of any kind on the product. 11. To reduce the risk of electric shock, do not disassemble this product, but take it to a qualified service contractor when some service or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used. 12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating instruction. Adjust only those control that are covered by the operating instructions. Improper adjustments of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation. E. If the product has been dropped or the cabinet has been damaged. F. If the product exhibits a distinctive change in performance. 13. Avoid using a TRANSIMITTER (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. 14. Do not use the TRANSIMITTER to report a gas leak in the vicinity of the leak. √ SAFETY INFORMATIONS FOR ID2400 Your TRANSIMITTER contains a low power transmitter. When the Push-to Talk button is pushed it sends out radio frequency (RF) signals. This device is authorized to operate at a duty factor not to exceed 50% in August 1996, the Federal Communications Commission (FCC) adopted RF exposure guidelines with safety levels for hand-held wireless devices. CAUTION : To maintain compliance with the FCC’s RF exposure guidelines, hold the transmitter and antenna at least 0.5 inches (1.25 centimeters) from your face, with the antenna pointed up and away from the face, if you wear the handset on your body while using the headset accessory, use only the manufacturers supplied belt clip for this product and ensure that the antenna is at least 1 inch (2,5centimeters) from your body when transmitting. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. use only the supplied antenna. Unauthorized antennas, modifications, or attachments could damage the transmitter and may violate FCC regulations. This phone (device) has an output power of max 32mW, which no warning statements required. Now this phone (device) designed to be hold transmitter and antenna at least 0.5inchs from your Face. Therefore this phone (device) satisfies RF exposure compliance. √ IMPORTANT Read this manual before attempting to setup or use this instrument. If contains important Information regarding safe installation and use. Keep this manual for future reference. Also save the carton, packing and proof of purchase to simplify and accelerate any needed action. √ WARNING To prevent fire or shock hazard, do not expose this product to rain or any type of moisture. If accidentally dropped into water, this product should immediately by unplugged from the AC outlet jack. THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE OWNER'S MANUAL. ? INSTALLATION PRECAUTION 1. Never install docking station wiring during a lighting storm. 2. Never install power jacks in wet locations unless the jack is specially designed for wet locations. 3. Never touch insulated power terminals unless the telephone line has been disconnected at the network interface. 4. Use caution when installing or modifying telephone lines. ? MAINTENANCE 1. Use a damp cloth to the plastic cabinet. A mind soap will help to remove grease or oil. Never use polish, solvents, abrasives or strong detergents since these can damage the finish. 2. Your phone should be situated away from heat sources such as radiators, heater, stoves or Any other appliance that produces heat. ? CAUTION ! To reduce the risk of fire or injure to persons, read and follow these instructions: 1. Use only the following type and the size battery : 1200mAh, 3.6V (LI-ION 1200Ma/3.6V, or equiv…

Text truncated - open the document above for the full version.

LABEL MOBILE VISION 90 FANNY RD Boonton,NJ 07005 1-800-336-8475 Model:ID-2400TR FCC ID: PJ4ID-2400TR CANADA NO Patent Pending Made in Korea

LOCATION OF LABEL LOCATION OF LABEL

Circuit Explanation Docking Station Circuit Description a The signal which inputted in LINE into Digital at U200. Data which is transformed into Digital signal is mixed with PN code at U100 (by spread spectrum) and transmitted to RF part. Spreading signal which inputted to RF part is mixed with Carrier supplied to VCO(U903) and create TX frequency of using channel and then is transmitted to ANTENNA through U801 by TX control of U3. a The signal received to antenna is transmitted to U901 by RX/TX control time. The signal inputted at U1 is mixed Carrier of VCO(U903) and got to direct conversion and create Base band signal. And then, create I and Q signal by demodulation (QPSK :quadrature Phase Shift Keying method is phase- shifted by 90° ). I and Q signal (Two signal phase is 90°) is transmitted to U200 and remixed with PN code and generated Digital signal. Digital signal is transformed into Analog at U200. This audio signal is passed through U200 and transmitted to LINE. a ID setting : when transimitter is placed on dockingstation , charge data is transmitted to transmitter by CT2 of docking station. The transimitter is received ID and transmitted ACK signal to RF PART. a X201 is X-TAL generating RF - reference signal and should be adjusted by C201 accurately. a Q205, is charge detector and ID detector circuitry. a Q207 is record signal detector circuitry Transmitter Circuit Description a The signal which is inputted to MIC is transformed Analog into Digital at U100. DATA which is transformed into Digital signal is mixed with PN code at U100 (by spread spectrum) and transmitted to RF part. Spreading signal which inputted to RF part is mixed with Carrier supplied to VCO(903) and create TX frequency of using channel and then is transmitted to ANTENNA through U801 by TX control of U802 a The signal received to antenna is transmitted to U100 by RX/TX control time. The signal inputted at U1 is mixed Carrier of VCO(U903) and got to direct conversion and create base band signal. And then, create I and Q signal by demodulation (QPSK : Quadrature Phase Shift Keying method is phase- shifted by 90° ) I and Q signal (Two signal phase is 90°) is transmitted to U100 and remixed with PN code and generated Digital signal. Digital signal is transformed into Analog at U100. This audio signal is passed through receiver and transmitted. a When the transmitter is low voltage R113,R115,C110 make 77pin of U100 change HIGH to LOW and indicate low voltage. a X101 is X-TAL generating RF - reference signal and should be adjusted by C126 accurately. RF Circuit Description a LO Generation : The LO signal is generated by a programmable PLL frequency synthesizer in the U901(RF109) and the an external 2.4GHz VCO(U903). The RF109 synthesizer requires differential input signals from the external VCO to generate the LO Frequency. Therefore a BALUN(U905) transformer is used to generate differential signals from single- ended VCO output. a Receive Path : The signal is received at the antenna and pass the T/R switch(U802) and an RF bandpass filter. The output of the bandpass filter is ac-coupled to the Low Noise Amplifier (LNA) of the U901. The U901 downconverts the RF signal into In-phase( I) and Quadrature signal(Q) baseband signals. The differential I and Q baseband signals are dc-coupled to the ASIC(U100) RXIP, RXIN, RXQP and RXQN inputs. a Transmit Path : The baseband digital data input signal is shaped by external filter (R920, C925,R919, L901, C924, R918) and inputted to the TXD1 Port of the U901 (RF109). The inputted baseband digital data is mixed with Carrier supplied to VCO (U903) and transmitted to the U801 (RF110) with a phase difference of 180 degreed between the two branch. The inputted a differential signals to the U801 (RF110) are amplified by the U801 (RF110) and the differential output signals of the U801 (RF110) output port are converted to a single-ended signal at the RF matching network. LABEL MOBILE EE 90 FANNY RD Boonton,NJ 07005 1-800-336-8475 VISION Model: FCC: CANADA NO Patent Pending Made in Korea

11 A A ID-900,2400TRDocking StationVer 2.0 ID2400TR.DSN 2.0 Police Talk Link 22 TitleSize Document Number Rev Date: Sheet of RXENSYN DATASYN CLKSYN STBSYN ENTX DATARXIPRXINRXQPRXQNAGCTXENTXPWR1TXPWROREF OSC NVCLKNVCSNVDINVDO LNA ATTNTXRSEL VCCVCC AGND2 VCC AGND2 AGND2 VCC VCC VCC VCC VCC VCC AGND2 VCC VCC VCC VCC VCCVCC VCC VCC VCC VCC VCC VCC VCC VCC R216 1K R217 1K R219 1K C2370.1uF R207100K R218 1K L208 82uH + C26010uF/6.3V(T) R20110K C2020.1uF L204 1mH C20930pF U202B4049 5 4 D2041N4007 R23610K C2510.1uF TP2 C206100pF R200100K TP3 L201 1mH Q205C107S TP4 R243100K TP5TP6 R224 100K R244 100K U200RSST7504M 7940393844374647305127342832293352352341422625 45 88 100 19 62 73 75 7778081828384876869707172676686857892919089 65 15 49 43 24 2 63 22211817141312 9394959697989965354555657585960111098 31 36 45 50 48 3 16 64 1 20 61 74 76 AUXDACMIC_BIASMIC_IN+MIC_IN-LINE0LINE1SPEAKER+SPEAKER-CDCMCLKCDCICLKFSYNCCDCFRAMESINCDCDATAOSOUTCDCDATAI#RESETOCDCPORGPIOB0CDCVREFCDCAGNDART0PARKXINXOUT#RESET1 VDDC0 VDDC1 VCCC2 DVDD AVDD BATTERY GPIOC0 TXDAC RXIP RXIN RXQP RXQN AGC GPIOC6 REFOSC GPIOC7GPIOC5GPIOC4 RXEN GPIOC1 RXREF AGND VRP GPIOC2 TRSW GPIOC3 TXEN VDDP2 VDDP1 CDVDD CAVDD ART1 VDDP0 #TEST GPIOB1GPIOB2GPIOB3GPIOB4GPIOB5GPIOB6GPIOB7 GPIOA0GPIOA1GPIOA2GPIOA3GPIOA4GPIOA5GPIOA6GPIOA7 KEYPADC0KEYPADC1KEYPADC2KEYPADC3KEYPADC4KEYPADC5KEYPADC6KEYPADC7KEYPADR0KEYPADR1KEYPADR2KEYPADR3 CAVSS0 CAVSS1 CAVSS2 CAVSS3 CDVSS VSSP0 VSSP1 VSSP2 VSSC0 VSSC1 VSSC2 DVSS AVSS D202LS4148 R202 1M C203M103J X2019.6MHz + C208100uF/16V J2 MX53014-09 123456789 D201LS4148 C23827pF U20193LC66(TS) 24 65 13 87 SK DO ORGVSS CS DI VCCNC C231 15pF R245 XXX R205 100~ R228OPEN R221100K Q207KTC3875GR Q204KTC3876Y R260 1K C232 33pF C21020pF C2400.01uF Q201C107S R220 1K D203LS4148 R22910~ R223 XXX + C242100uF/16V R24222K T1 VCC 1 U202A4049 3 2 Q202C107S R2650~ T2 MON_IN 1 C2150.1uF T3 MON_OUT 1 R210100K T4 GND 1 + C21633uF/16V U20574LS163 34567 10 291 1413121115 ABCDENPENTCLKLOADCLR QAQB QCQD RCO C241 0.1uF R241 47K R237XXX R2661K Q200C107S R226 4.7K T5 #PARK 1 R262XXX J1 354002-024N 123456789 101112131415161718192021222324 R26710K R261 XXX R238 1K R230 10K C2120.1uF C233100pF C218 0.1uF R20447K R20910~ C227 103(2012) R211 1K U20674LS163 34567 10 291 1413121115 ABCDENPENTCLKLOADCLR QAQB QCQD RCO R246 0~ C226 103(2012) D206LS4148 R206120K C234100pF C211 0.1uF C223 103(2012) C224 103(2012) C220 103(2012) C225 103(2012) C235100pF C2360.1uF R232100K U202C4049 7 6 C222103(2012) C221 103(2012) U202D4049 9 10 Q206KTA1505Y C217 0.1uF R233 1K R264 0~ + C257 33uF/16V C256 1uF(2012) C2050.1uF C2530.1uF C219XXX R234 47~ R235 1K C2001uF(2012) U202F4049 14 15 R2251K +- U203B KA2904 56 7 84 C201 1uF(2012) C255M473J R263XXX R231 100K U202E4049 11 12 R212 1K R248360K R213 1K C213 0.1uF C2140.1uF R222 300~ TP1 R227100K + C25810uF/16V R20368K R214 1K D205KDS181 R215 1K LED 5V_OUT MON_OUT AUDIO_OUT U200.93 U200.9 U200.58 #RESET 5V_IN REC REC #RESET U200.93 U200.9U100.58 LED 5V_IN AUDIO_GNDAUDIO_OUTMON5V_OUT 11 A A ID-900,2400TRTransmitter Ver 2.0 LAMP ID2400TR.DSN 2.0 Police Talk Link 22 TitleSize Document Number Rev Date: Sheet of TXPWROTXPWR1SYN CLKSYN DATARXENRXINRXIPAGCSYN ENRXQN NVCS TX DATA NVDI RXQPTXENTXRXSELREF OSC NVDONVCLK SYN STBLNA ATTN VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT VBAT AGND2 VBAT VBAT VBAT VBAT VBAT VBAT AGND2 VBAT VBAT AGND2 AGND2 VBAT VBAT VBAT D103KDS181 LCD1LCD 1 23456789 10 R15947K T1 VCC 1 Q113KRC107S R142 OPEN T6 A01512 1 R401 XXX R15747K D106 1N4007 C1380.1uF R136 10K R1072K R143OPEN R10410~ T7 1 Q108OPEN R124 1K R106 2.4K R110100K Q104 KTC3876Y R140 1K T5 #PARK 1 SW102 ITS-1105VBACK LIGHT T4 GND 1 R156 1K R125 1K R144OPEN R11556K 1% SW103 SSAB010200POWER 1 2 Q106 KTC3876Y R166 100K + C10810uF/6.3V(T) X1019.6MHz C130100pF R129 1K R171 100~ C1060.1uF R122 1K C1520.22uF R127 1K D102KDS226 C1290.001uF R15512K + C11410uF/6.3V(T) C113 0.1uF R162 120~ TP5 R167 47K R139 10K C115XXX C157 100pF C133 220pF R165 390K C1100.01uF U106B4049 5 4 + BZ1DC-12BP R11356K 1% C156200pF U106C4049 7 6 Q114KTA1505Y U105A4011 12 3 C1190.1uF C155 M103J R111 47~ U105B4011 56 4 C1200.1uF U105C4011 89 10 R10910~ Q115KRC107S C128 100pF R132 47~ R133 1K R170 0~ R168 22K C1050.1uF MICAJ-336 123 R128 1K C122 1uF(2012) R172 4.7K C1320.01uF MIC M101OB-27P40 R126 1K SW101SSST010600TALK U1007505 7940393844374647305127342832293352352341422625 45 88 100 19 62 73 75 7778081828384876869707172676686857892919089 65 15 49 43 24 2 63 22211817141312 9394959697989965354555657585960111098 31 36 45 50 48 3 16 64 1 20 61 74 76 AUXDACMIC_BIASMIC_IN+MIC_IN-LINE0LINE1SPEAKER+SPEAKER-CDCMCLKCDCICLKFSYNCCDCFRAMESINCDCDATAOSOUTCDCDATAI#RESETOCDCPORGPIOB0CDCVREFCDCAGNDART0PARKXINXOUT#RESET1 VDDC0 VDDC1 VCCC2 DVDD AVDD BATTERY GPIOC0 TXDAC RXIP RXIN RXQP RXQN AGC GPIOC6 REFOSC GPIOC7GPIOC5GPIOC4 RXEN GPIOC1 RXREF AGND VRP GPIOC2 TRSW GPIOC3 TXEN VDDP2 VDDP1 CDVDD CAVDD ART1 VDDP0 #TEST GPIOB1GPIOB2GPIOB3GPIOB4GPIOB5GPIOB6GPIOB7 GPIOA0GPIOA1GPIOA2GPIOA3GPIOA4GPIOA5GPIOA6GPIOA7 KEYPADC0KEYPADC1KEYPADC2KEYPADC3KEYPADC4KEYPADC5KEYPADC6KEYPADC7KEYPADR0KEYPADR1KEYPADR2KEYPADR3 CAVSS0 CAVSS1 CAVSS2 CAVSS3 CDVSS VSSP0 VSSP1 VSSP2 VSSC0 VSSC1 VSSC2 DVSS AVSS R130 1K U104A4066 1 2 13 TP3 C125 15pF R123 1K R173 100K U10193LC66(TS) 24 65 13 87 SK DO ORGVSS CS DI VCCNC Q101 KTC3876Y C104 0.1uF C123 220pF J101 MX53048-04 1234 R137100K R141 OPEN C209 XXX C12620pF L101 100uH C109 0.1uF TP6 C134 0.01uF R148 3.3K C1310.01uF Q111KRC107S C1030.1uF C1501uF(2012) C136 0.01uF(2012) C135 0.01uF Q105 KTC3875GR R145 1M U105D4011 1213 11 + C15347uF/16V R15110K R146 100~ R138120K U106A4049 3 2 R117 300~ T2 MON_IN 1 R131 47~ R158 47K D105LS4148 R15422K R15215K + C127100uF/16V C124 33pF R108 1K R121 1K TP1 U104C4066 4 3 5 TP2 U104D4066 8 9 6 C118 27pF C1210.01uF R134 1K C117 27pF TP4 C1110.1uF R153 1.2K L102OPEN C1120.1uF + C10710uF/6.3V(TT_A) J1 354002-024N(Female) 123456789 101112131415161718192021222324 Q107OPEN T3 MON_OUT 1 D101KDS184 R161 47K R135100K C102 0.1uF C116 0.1uF VCR_EN VCR_EN U1…

Text truncated - open the document above for the full version.

Applicant: ID Fone Co., Ltd. FCC ID: PJ4PJ4ID-2400TR Report #: I\ID\890YKT2\890YKT2TestReport.doc Page #: TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: ID FONE CO., LTD FCC ID: PJ4ID-2400TR TEST REPORT: PAGE 1..........SECURITY CODING INFORMATION & PRODUCT DESC. PAGE 2-4........TEST EQUIPMENT LIST PAGE 5..........TEST PROCEDURES PAGE 6..........OCCUPIED BANDWIDTH AND PEAK POWER OUTPUT PAGE 7..........6dB BANDWIDTH PLOT HANDSET PAGE 8..........PULSED CORRECTION FACTOR PLOT PAGE 9..........PEAK TO AVERAGE PLOT PAGE 10.........RADIATED SPURIOUS EMISSIONS HANDSET PAGE 11.........METHOD OF MEASURING RADIATED EMISSIONS PAGE 12.........RADIATED SPURIOUS EMISSIONS INTO ADJACENT RESTRICTED BAND PAGE 13-14......BANDEDGE PLOTS - HANDSET PAGE 15.........POWER SPECTRAL DENSITY PAGE 16.........POWER SPECTRAL DENSITY PLOT HANDSET EXHIBITS: EXHIBIT 1........FCC ID LABEL SAMPLE EXHIBIT 2........FCC ID LABEL LOCATION EXHIBIT 3........BLOCK DIAGRAM EHXIBIT 4........SCHEMATIC EXHIBIT 5........EXTERNAL PHOTOGRAPHS EXHIBIT 6........INTERNAL PHOTOGRAPHS EXHIBIT 7........USERS MANUAL EHXIBIT 8........OPERATIONAL DESCRIPTION EXHIBIT 9........TEST SETUP PHOTOGRAPH Applicant: ID Fone Co., Ltd. FCC ID: PJ4PJ4ID-2400TR Report #: I\ID\890YKT2\890YKT2TestReport.doc Page #: 1 OF 16 APPLICANT: ID FONE CO., LTD FCC ID: PJ4ID-2400TR 15.214(d) THIS DEVICE COMPLIES WITH THE SECURITY CODE REQUIREMENTS OF 15.214(d)(1)(2) AND (3) BY MEANS OF THE FOLLOWING: THIS DEVICE HAS 24 MILLION POSSIBLE SECURITY CODES. ONE SECURITY CODE OUT OF 24 MILLION IS PRE-PROGRAMMED WHEN MANUFACTURED AT THE FACTORY. THE CPU CONTROLS THE RF FREQUENCY CHANNEL. AND THE ASIC CONTROLS ADPCM CODEC AND AUDIO SIGNAL SWITCHING ALSO SET UP THE SPREADING CODE. BEFORE THE COMMUNICATION LINK IS ESTABLISHED, THE DEVICE SEARCHES FOR A VACANT RF CHANNEL AND THEN TRANSMITS RF SIGNAL ON THE VACANT CHANNEL. PRODUCT DESCRIPTION: This device is a 2.4 GHz DSSS wireless system that can be used by the Police Department to record dialog between the police and a suspect. When a policeman arrests a suspect, he must read the Miranda Rights to suspect. At the scene, a camcorder is recording the scene. This device will transmit the audio signal to the receiver which will be connected to the camcorder. Therefore, both the scene and sound can be recorded for further use. Wireless Handset Wireless Base Set Applicant: ID Fone Co., Ltd. FCC ID: PJ4PJ4ID-2400TR Report #: I\ID\890YKT2\890YKT2TestReport.doc Page #: 2 OF 16 APPLICANT: ID FONE CO., LTD FCCID : PJ4ID-2400TR EMC Equipment List DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS X 3-Meter OATS TEI N/A N/A Listed 12/22/99 12/22/02 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 Receiver, Beige Tower Spectrum Analyzer (Tan) HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/03 RF Preselector (Tan) HP 85685A 3221A01400 CAL 8/31/01 8/31/03 Quasi-Peak Adapter (Tan) HP 85650A 3303A01690 CAL 8/31/01 8/31/03 X Receiver, Blue Tower X Spectrum Analyzer (Blue) HP 8568B 2928A04729 2848A18049 CHAR 10/22/01 10/22/03 X RF Preselector (Blue) HP 85685A 2926A00983 CHAR 10/22/01 10/22/03 X Quasi-Peak Adapter (Blue) HP 85650A 2811A01279 CHAR 10/22/01 10/22/03 X Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/03 Biconnical Antenna Eaton 94455-1 1057 CHAR 3/15/00 3/15/02 BiconiLog Antenna EMCO 3143 9409-1043 X Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/03 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/03 Log-Periodic Antenna Electro-Metrics LPA-30 409 CHAR 10/16/01 10/16/03 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/04 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CHAR 11/24/00 11/24/03 Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 12/19/01 12/19/03 Horn Antenna Electro-Metrics EM-6961 6246 CAL 3/21/01 3/21/03 Horn Antenna ATM 19-443-6R None No Cal Required Applicant: ID Fone Co., Ltd. FCC ID: PJ4PJ4ID-2400TR Report #: I\ID\890YKT2\890YKT2TestReport.doc Page #: 3 OF 16 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/03 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/03 Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/16/01 3/16/03 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 5/25/01 Termaline Wattmeter Bird Electronic Corporation 6104 1926 CAL 12/12/01 12/12/03 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/03 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/04 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/03 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/03 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/03 X Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/04 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/04 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/04 Multimeter Fluke FLUKE-77-3 79510405 CAL 9/26/01 9/26/03 Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/03 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/04 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/04 X Temp/Humidity gauge EXTech 44577F E000901 CHAR 1/22/02 1/22/04 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/03 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 1/26/01 1/26/03 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/02 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 5/12/02 5/12/04 Signal Generator HP 8640B 2308A21464 CAL 11/15/01 11/15/03 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/03 Applicant: ID Fone Co., Ltd. FCC ID: PJ4PJ4ID-2400TR Report #: I\ID\890YKT2\890YKT2TestReport.doc Page #: 4 OF 16 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Near Field Probe HP HP11940A 2650A02748 CHAR 2/1/01 2/1/03 BandReject Filter Lorch Microwave 5BR4-2400/ 60-N Z1 CHAR 3/2/01 3/2/03 BandReject Filter Lorch Microwave 6BR6-2442/ 300-N Z1…
