Page 11 Dynamco Pty. Ltd. Remote Relay (Transmitter) FCC ID. : PJ9TX23 Block Diagram [NOTE]: (1). These buttons are normally open (i.e. spring loaded to remain open and only close when pushing) (2). There is no latching circuit to lock on transmitter after initial button is pushed.

From: shelene Sent: Monday, February 24, 2003 9:53 PM To: TCB Mike Kuo Cc: Leon Liu Subject: Dynamco Pty. Ltd. FCC ID: PI9TX23, ANT03T2603 Dear Mike : For above project, please see the following red word, if there is any problems please let me know soon, because our customer is urgent to get the grant letter ! Question #1: Please provide operational description. ---> please see attached file (Operational.doc) Question #2: The EUT in the test setup photo does not agree with the external photos. Please explain. ---> Sorry, we made a mistake when our engineer took the external photo, he put the wrong project no. paper ! please see my revise file ! Question #3: For Pulsed modulation, the average reading=peak+(20logM%) based upon section 15.35( C ). Since the reported peak readings above 1GHz are below average limits, additional average measurements or justification is not necessary. Please provide revised test report by removing all average measurement above 1GHz. ---> please see the revised test report. Question #4: Proposed FCC ID label format does not contain FCC ID number. Please provide revised FCC ID label format ---> Sorry, our word file can see the FCC ID, but I don't know why PDF can not, anyway, I revised them already, please see revised file ! Shelene Hou / Audix Corp. (Technical Div. EMC Dept.)

Page 6 Dynamco Pty. Ltd. Remote Relay (Transmitter) FCC ID. : PJ9TX23 Photographs Photos 1 General Appearance (Front View) Photos 2 General Appearance (Rear View)

Page 4 Dynamco Pty. Ltd. Remote Relay (Transmitter) FCC ID. : PJ9TX23 Label Drawing z Label Placement Location (Bottom Side of EUT) FCC LABEL 20mm FCC ID : PJ9TX23 10mm

Page 7 Dynamco Pty. Ltd. Remote Relay (Transmitter) FCC ID. : PJ9TX23 Photos 3 Internal View (Removed Case) Photos 4 PCB View (Component Side) Page 8 Dynamco Pty. Ltd. Remote Relay (Transmitter) FCC ID. : PJ9TX23 Photos 5 PCB View (Solder Side)

NOSTART USER MANUAL & PROGRAMMING INSTRUCTIONS GENERAL DESCRIPTION The NOSTART relay system is designed to replace existing vehicle relays in order to provide vehicle immobilisation. No installation work is required, all compatible vehicle relays are removed from the factory designed socket and a NOSTART relay is simply inserted into the empty socket. Specific vehicle notes may be found at www.nostart.com . DISARMING Remote systems: to disarm a NOSTART relay, simply turn the vehicle’s ignition switch to the ON position and press the main button on a valid remote control. On some vehicles the system can be disarmed without the ignition being on. PROGRAMMING NEW REMOTE CONTROL 1. NOSTART Relay must be armed 2. Turn ignition to full crank position. 3. Press small button on master remote control. 4. Press large button on new remote control to be coded vehicle should start immediately. Note: Please ensure manual vehicles are in neutral and place foot on the clutch. EMERGENCY OVERRIDE An individual override procedure card is provided with every NOSTAR Relay.

Page 12 Dynamco Pty. Ltd. Remote Relay (Transmitter) FCC ID. : PJ9TX23 Schematics Diagram

FCC ID.PJ9TX23 Page 1 of 21 APPLICATION FOR CERTIFICATION On Behalf of Dynamco Pty. Ltd. Remote Relay (Transmitter) Model : TX23 FCC ID：PJ9TX23 Prepared for : Dynamco Pty. Ltd. 10 Brown Street, East Perth, Western Australia 6004 Australia Prepared by : Audix Corporation No. 53-11, Tin-Fu Tsun, Lin-Kou, Taipei Hsien, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax: (02) 2609-9303 File Number ： ATM-G920155 Report Number ： TTEMC-F92033 Date of Test ： Feb. 14 ~ 17, 2003 Date of Report ： Feb. 20, 2003 Audix Corporation Report No.: TTEMC-F92033 FCC ID.PJ9TX23 Page 2 of 21 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION .......................................................................................................3 1. GENERAL INFORMATION..........................................................................................................4 1.1. Description of Device (EUT) ............................................................................................................. 4 1.2. Description of Test Facility ................................................................................................................ 5 1.3. Measurement Uncertainty .................................................................................................................. 5 2. POWERLINE CONDUCTED TEST ..............................................................................................6 3. RADIATED EMISSION TEST.......................................................................................................7 3.1. Test Equipment................................................................................................................................... 7 3.2. Test Setup ........................................................................................................................................... 7 3.3. Radiation Limit (§15.231) .................................................................................................................. 8 3.4. EUT’s Configuration during Compliance Measurement.................................................................... 8 3.5. Operating Condition of EUT .............................................................................................................. 8 3.6. Test Procedure .................................................................................................................................... 9 3.7. Radiated Emission Noise Measurement Results .............................................................................. 10 4. EMISSION BANDWIDTH TEST ................................................................................................13 4.1. Test Equipment................................................................................................................................. 13 4.2. Block Diagram of Test Setup ........................................................................................................... 13 4.3. Specification Limits (§15.231-(c)) ................................................................................................... 13 4.4. EUT’s Configuration during Compliance Measurement.................................................................. 13 4.5. Emission Bandwidth Measurement Results ..................................................................................... 13 5. PERIODIC OPERATED TEST.....................................................................................................15 5.1. Test Equipment................................................................................................................................. 15 5.2. Block Diagram of Test Setup ........................................................................................................... 15 5.3. Specification Limits [§15.231-(a)-(1)] ............................................................................................. 15 5.4. EUT’s Configuration during Compliance Measurement.................................................................. 15 5.5. Periodic Operated Measurement Results..........................................................................................15 6. DEVIATION TO TEST SPECIFICATIONS................................................................................17 7. PHOTOGRAPHS ..........................................................................................................................18 7.1. Photos of Radiated Measurement at Semi-Anechoic Chamber (30~1000MHz) ............................ 18 7.2. Photos of Radiated Measurement at Semi-Anechoic Chamber (1~5GHz) ..................................... 19 7.3. Photos of Emission Bandwidth Measurement.................................................................................. 21 7.4. Photos of Periodic Operated Measurement ...................................................................................... 21 Audix Corporation Report No.: TTEMC-F92033 FCC ID.PJ9TX23 Page 3 of 21 TEST REPORT CERTIFICATION Applicant ： Dynamco Pty. Ltd. Manufacturer ： Tesor Plus Corp. EUT Description ： Remote Relay (Transmitter) FCC ID ： PJ9TX23 (A) MODEL NO. ： TX23 (B) SERIAL NO. ： N/A (C) POWER SUPPLY：DC 12V Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C, MAY 2002 AND ANSI C63.4/1992 (FCC CFR 47 Part 15C, §15.207 and §15.231) The device described above was tested by AUDIX COPORATION. to determine the maximum emission levels emanating from the device. The maximum emission levels were compared to the FCC Part 15 subpart C limits both radiated and conducted emissions. The measurement results are contained in this test report and AUDIX CORPORATION. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in par…
