PJRGDM-100Dual-Mode Cellular Phone (AMPS/CDMA)

Giga Telecom, Inc.

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: Sep 27, 2001
Application Purpose: Original Equipment
Date of Application: Jul 09, 2001
Equipment Note: Dual-Mode Cellular Phone (AMPS/CDMA)
Frequency Range: 824.70000000 - 848.31000000
Company: Giga Telecom, Inc.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 GDM-100 USER MANUAL This is a draft version printed in Korea. - 2001/8/13 - 5 th Floor Sewha Bldg., 156-3 Samsung-Dong, Kangnam-Gu, Seoul, Korea Http://www.gigatelecom.com 2 TABLE OF CONTENTS FCC RF EXPOSURE INFORMATION...................................................................... 7 SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES..........................................................................................8 PRECAUTIONS...................................................................................................11 SYSTEM CONFIGURATIONS...................... ....................................................... .12 • Phone Layout................................................................................................13 USING THE BATTERY.................................................................................... ....14 • Installing the Battery Pack................................................................................14 • Removing the Battery Pack...............................................................................15 • Recharging the Battery.................................................................................... 16 IMPORTANT BATTERY INFORMATION ..................................................................17 FUNCTION KEYS........................................................................................................19 LCD DISPLAY INDICATORS ............................................................................................20 GETTING STARTED............................................................................................21 • Turning the phone On/Off.................................................................................21 • Locking or Unlocking the phone.........................................................................21 • Antenna Position................................................................................. ...........21 • Network Service.............................................................................. ...............21 • How to input the characters...............................................................................22 BASIC OPERATIONS...........................................................................................23 • Making and Ending Calls......................................................................................23 • Receiving Calls........................................................................................................ 24 • Emergency Dialing ........................................................................................ 25 USING VARIABLE FUNCTIONS............................................................................ 25 • Making Calls From a Phone Book...................................................................... 25 • Using Speed Dialing ................................................................. ......................29 • Voice Dialing ............................................................................................. ... 30 • Missed Call Notification.....................................................................................30 • Auto Machine (Automatic Answering Mode)...........................................................31 IN-CALL OPTIONS................................................................................................31 • Sending my phone number.................................................................................31 • Number Memo................................................................................................31 • Mute / Unmute.................................................................................................32 • Phone Book. ......................................................................... .........................32 • Indicating My Phone Number. ............................................................................32 • Voice Recording..............................................................................................32 • Adjusting the Volume during conversation............................................................ 32 3 USING NETWORK SERVICE FEATURES...............................................................32 • Call Waiting .................................................................................................. 33 • Three-way Calling........................................................................................... 33 • Using Caller ID ...............................................................................................33 VOICE MAIL AND SHORT MESSAGE SERVICES (SMS)......................................... 33 • About Short Message Indicators........................................................................ 33 • Knowing When the phone has Messages............................................................ 34 • Receiving Messages ...................................................................................... . . 34 • Checking Voice Messages............................................................................... 34 • Checking Short Messages............................................................................... 35 • Sending Messages.......................................................................................... 35 • Managing Call History.......................................................................................37 SCHEDULE.......................................................................................................38 • Appointed Time.............................................................................................. 38 • Alarm............................................................................................................38 • Anniversary....................................................................................................38 • Schedule........…

Text truncated - open the document above for the full version.

Attestation Statements

March 6, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: GIGA TELECOM FCC ID: PJRGDM-100 Users Manual RF Exposure Warning Statement Gentlemen: GIGA TELECOM hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact PCTEST Lab or me at (410) 290-6652. Sincerely,

Cover Letter(s)

July 6, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: GIGA TELECOM FCC ID: PJRGDM-100 Part 22 Certification Gentlemen: Attached herewith, on behalf of GIGA TELECOM, is an application for Part 22 Certification of the following Dual-Mode Cellular Phone (AMPS/CDMA): FCC ID: PJRGDM-100 TRADE / MODEL(s): GIGA / GDM-100 EUT TYPE: Non-Broadcast transmitter Held to Ear (TNE) Tx Freq. Range: 824.04 — 848.97 MHz 824.70 — 848.31 MHz Rx Freq. Range: 869.04 — 893.31 MHz 869.70 — 893.31 MHz Max. RF Output Power: 0.461 W ERP AMPS (26.633 dBm) 0.322 W ERP CDMA (25.083 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: GIGA TELECOM

Cover Letter(s)

September 18, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Giga Telecom, Inc. FCC ID: PJRGDM-100 731 Confirmation No.: EA101663 Correspondence Reference No.: 20483 Request for Tech. Info.: 08/31/01 Dear Martin: Transmitted herewith, on behalf of Giga Telecom, Inc., is an amendment provided in response to the request for technical information dated August 31, 2001. 1. Please find the attached user’s manual. 2. We confirm that the maximum emissions occurred for horizontal polarization as stated in sections 5.1 and 6.1. 3. We confirmed that the radiated spurious and harmonic emission measurements were ERP. 4. Please find the attached occupied bandwidth plots for AMPS mode. 5. Please find the attached audio plots for sections 4.1, 4.3 and 4.4. 6. Please find the revised CDMA band edge plot showing Ch. 1013 and Ch. 777 as the low and high channel respectively. 7. The power of the unit was controlled be software supplied by the applicant and measured by PCTEST. 8. Please find the attached revised section 2-1-1 of the operational description. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: Giga Telecom, Inc.

External Photos

ID Label/Location Info

© 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION • LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) According to the requirement section 2.925 an 2.926, the sample label shown below shall be permanently affixed at a conspicuous location on the device supplied to the user and be readily visible to the purchaser at the time purchase. 8 giga telecom co., Ltd. Model No. : GDM-100 FCC ID PJRGDM-100: Serial No. : Made in Korea

Internal Photos

© 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA) © 2001 PCTEST Lab FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 GIGA Dual-Mode Cellular Phone (AMPS/CDMA)

Operational Description

“ONFIDENTIA cr L Level 3 Level 4 Level 5 Level 6 2. Section 2.983 (d)(3). Range of Operating Power Levels and Description of Means for Variation of Operating Power 24dBm +2/-4dBni 20dBm +2/-4dBm 16dBm +2/-4dBm 12dBm +2/-4dBm 2-1. Range of Operating Power Levels 2-1-1. FM Mode H Tx Power Level and Range I Level 0 I 27dBm +.5/-2dBm I I Level 1 I 27dBm +.5/-2dBm I I Level 2 I 27dBm +.5/-2dBm I I Level 7 I 8dBm +2/-4dBm I 2-1-2. CDMA Mode Range of Open Loop Output Power Open loop average output power of Mobile Station is estimated from the average input power. The estimation value is as follows. Average Output Power (dBm) = - Mean Input Power (dBm) - 73 + NOM-PWR (dB) + INIT-PWR (dB) Range of CIosed Loop Power Control Range of closed loop power control should be at least within -5OdBm - +23dBm. Range of maximum power output should be in the range of +23dBm - +26dBm. Maximum power is recommended from manufacturer of Mobile Station and this means the output power that expresses the maximum permissible ERP per every grade of Mobile Station using antenna gain. 2-2. Means for Variation of Operating Power The RF interface of MSM communicates with the RF analog circuitry. This RF interface performs gain controls of AGC (automatic gain control) amplifier using digital control signals. The mid -range transmission fi-equency generated in IFT (Tx Base band-IF converter) is designed to be gain controlled for 84dB dynamic range. The 84dB dynamic range is 39dB when the voltage is 3.0V and -45dB in 0.1V. The 8OdB range (0.1V - 3.0V) gain is used in this hand -held device. The RF power output level is detected and then this information is sent to the MSM. The software controlled power management in MSM controls the Tx AGC adjust signal.

RF Exposure Info

© 2001 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) GIGA TELECOM, Inc. Dates of Tests: Mar. 8-9, 2001 (135-091)#156-3, Sewha Bldg. 4F, Samsung-Dong Test Report S/N: SAR.210309132.PJR Kangnam-Gu, Seoul, KOREA Test Site: PCTEST Lab, Columbia, MD USA Attn: M. J. Woo President FCC ID PJRGDM-100 APPLICANT GIGA Telecom, Inc. EUT Type: Dual-Mode Cellular Phone (AMPS/CDMA) Tx Frequency: 824.04 – 848.97 MHz (AMPS) / 824.70 – 848.31 MHz (CDMA) Rx Frequency: 869.04 – 893.97 MHz (AMPS) / 869.70 – 893.31 MHz (CDMA) Max. RF Output Power: 0.461W ERP AMPS (26.633 dBm) 0.322W ERP CDMA (25.083 dBm) Trade Name/Model(s): GIGA GDM-100 FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) Application Type: Certification FCC Rule Part(s): §2.1093; ET Docket 96.326 Maximum SAR: 1.3512 W/kg AMPS Brain SAR; 0.6940 W/kg AMPS Body SAR 1.1173 W/kg CDMA Brain SAR; 0.5541 W/kg CDMA Body SAR This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210309132.PJR Test Report S/N: SAR.210309132.PJR SAR Measurement Report Test Dates: MAR. 8-9, 2001 FCC Part 22 Certification Table of Contents 1.1 SCOPE....................................................................................................1 2.1 INTRODUCTION.......................................................................................2 3.1 SAR MEASUREMENT SET-UP.................................................................3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM.....................................................4 5.1 E-field PROBE CALIBRATION PROCESS.................................................5 6.1 PHANTOM AND EQUIVALENT TISSUES..................................................7 7.1 SYSTEM SPECIFICATIONS......................................................................8 8.1 MEASUREMENT PROCESS.....................................................................9 9.1 TEST POSITION OF THE PHONE..........................................................10 10.1 BODY-WORN TEST SETUP.................................................................11 11.1 ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS....................................12 12.1 MEASUREMENT UNCERTAINTIES.......................................................13 13.1 SAR TEST DATA SUMMARY................................................................14 14.1 SAR TEST EQUIPMENT.......................................................................16 15.1 CONCLUSION......................................................................................17 Test Report S/N: SAR.210309132.PJR SAR Measurement Report Test Dates: Mar. 8-9, 2001 FCC Part 22 Certification FCC ID: PJRGDM-100 (Model: GDM-100) © 2001 PCTEST Lab GIGA Dual-Mode Cellular Phone (AMPS/CDMA) 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant Name: GIGA TELECOM, Inc. Address: (135-091)#156-3, Sewha Bldg. 4F, Samsung-Dong Kangnam-Gu, Seoul, KOREA Attention: M. J. Woo President • EUT Type: Dual-Mode Cellular Phone (AMPS/CDMA) • Trade Name: GIGA • Model(s): GDM-100 • FCC IDENTIFIER: PJRGDM-100 • Tx Frequency: 824.04 – 848.97 MHz (AMPS) 824.70 – 848.31 MHz (CDMA) • Rx Frequency: 869.04 – 893.97 MHz (AMPS) 869.70 – 893.31 MHz (CDMA) • Application Type: Certification • FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Modulation(s): AMPS/CDMA • Max RF. Output Power: 0.461W ERP AMPS (26.633 dBm) 0.322W ERP CDMA (25.083 dBm) • Date(s) of Tests: Mar. 8-9, 2001 • Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.210309132.PJR 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.210309132.PJR SAR Measurement Report Test Dates: Mar. 8-9, 2001 FCC Part 22 Certification FCC ID: PJRGDM-100 (Model: GDM-100) © 2001 PCTEST Lab GIGA Dual-Mode Cellular Phone (AMPS/CDMA) 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. © 1992 by the Institute of Electrical and Electronics Engineers, Inc., Ne…

Text truncated - open the document above for the full version.

RF Exposure Info

Peak SAR Location © 2001 PCTEST Lab GIGA FCC ID: PJRGDM-100 (Model: GDM-100) NVLAP Lab Code: 100431-0 Dual-Mode Cellular Phone (AMPS/CDMA) Head SAR File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01030810_ZOOM.VLT Start : 8-Mar-101 11:15:46 am End : 8-Mar-101 11:26:02 am Radio Type : GIGA TELECOM Model Number : GDM-100 Serial Number : 1 Frequency : 824.04 MHz Peak Trans. Pwr : 0.560 W Start Trans. Pwr: 0.560 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : GIGA TELECOM DUAL-MODE PHONE - AMPS MODE CHAN 0991 Conducted 27.5 dBm GIGA TELECOM DUAL-MODE PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 2.500, Y = -5.250, Z = 0.000 (cm) Value = 15.204 Measured Values (volts) = 1.460E-002 1.190E-002 1.024E-002 9.221E-003 8.194E-003 7.333E-003 6.215E-003 5.202E-003 4.094E-003 3.218E-003 2.327E-003 1.773E-003 1.418E-003 1.350E-003 1.505E-003 1.756E-003 2.104E-003 2.281E-003 2.225E-003 1.748E-003 1.094E-003 Calc. Voltage @ Surface (Vs) = 0.0174 Voltage @ 1.00 cm (Vt) = 0.0092 Ave. Voltage (Vs+Vt)/2 = 0.0133 Ave. SAR over 1 g (mW/g) = 0.9727 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 mW/g -1012345 Z centimeters SAR Scan File : 01030810_ZOOM Start : 8-Mar-101 11:15:46 am End : 8-Mar-101 11:26:02 am GIGA TELECOM/GDM-100/1;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01030810_ZOOM Start : 8-Mar-101 11:15:46 am End : 8-Mar-101 11:26:02 am GIGA TELECOM/GDM-100/1;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.109 1.038 0.967 0.895 0.824 0.752 0.681 0.610 0.538 0.467 File : 01030810_ZOOM Start : 8-Mar-101 11:15:46 am End : 8-Mar-101 11:26:02 am GIGA TELECOM/GDM-100/1;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.109 1.038 0.967 0.895 0.824 0.752 0.681 0.610 0.538 0.467 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01030813_ZOOM.VLT Start : 8-Mar-101 11:50:03 am End : 8-Mar-101 12:00:15 pm Radio Type : GIGA TELECOM Model Number : GDM-100 Serial Number : 1 Frequency : 824.04 MHz Peak Trans. Pwr : 0.560 W Start Trans. Pwr: 0.560 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : GIGA TELECOM DUAL-MODE PHONE - AMPS MODE CHAN 0991 Conducted 27.5 dBm GIGA TELECOM DUAL-MODE PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 2.500, Y = -5.250, Z = 0.000 (cm) Value = 10.826 Measured Values (volts) = 1.007E-002 8.401E-003 7.315E-003 6.478E-003 6.291E-003 5.473E-003 4.427E-003 3.556E-003 3.069E-003 2.454E-003 1.718E-003 1.415E-003 1.086E-003 1.020E-003 1.132E-003 1.309E-003 1.623E-003 1.638E-003 1.587E-003 1.252E-003 9.869E-004 Calc. Voltage @ Surface (Vs) = 0.0118 Voltage @ 1.00 cm (Vt) = 0.0065 Ave. Voltage (Vs+Vt)/2 = 0.0091 Ave. SAR over 1 g (mW/g) = 0.6672 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 mW/g -1012345 Z centimeters SAR Scan File : 01030813_ZOOM Start : 8-Mar-101 11:50:03 am End : 8-Mar-101 12:00:15 pm GIGA TELECOM/GDM-100/1;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01030813_ZOOM Start : 8-Mar-101 11:50:03 am End : 8-Mar-101 12:00:15 pm GIGA TELECOM/GDM-100/1;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 0.790 0.739 0.689 0.638 0.588 0.537 0.486 0.436 0.385 0.335 File : 01030813_ZOOM Start : 8-Mar-101 11:50:03 am End : 8-Mar-101 12:00:15 pm GIGA TELECOM/GDM-100/1;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 0.790 0.739 0.689 0.638 0.588 0.537 0.486 0.436 0.385 0.335 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01030806_ZOOM.VLT Start : 8-Mar-101 10:21:53 am End : 8-Mar-101 10:32:09 am Radio Type : GIGA TELECOM Model Number : GDM-100 Serial Number : 1 Frequency : 836.49 MHz Peak Trans. Pwr : 0.560 W Start Trans. Pwr: 0.560 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : GIGA TELECOM DUAL-MODE PHONE - AMPS MODE CHAN 0383 Conducted 27.5 dBm GIGA TELECOM DUAL-MODE PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 2.500, Y = -5.000, Z = 0.000 (cm) Value = 20.566 Measured Values (volts) = 2.033E-002 1.610E-002 1.405E-002 1.255E-002 1.136E-002 1.007E-002 8.706E-003 7.244E-003 5.777E-003 4.486E-003 3.250E-003 2.412E-003 1.936E-003 1.824E-003 1.981E-003 2.346E-003 2.772E-003 3.126E-003 3.087E-003 2.507E-003 1.623E-003 Calc. Voltage @ Surface (Vs) = 0.0245 Voltage @ 1.00 cm (Vt) = 0.0125 Ave. Voltage (Vs+Vt)/2 = 0.0185 Ave. SAR over 1 g (mW/g) = 1.3512 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 mW/g -1012345 Z centimeters SAR Scan File : 01030806_ZOOM Start : 8-Mar-101 10:21:53 am End : 8-Mar-101 10:32:09 am GIGA TELECOM/GDM-100/1;836.49MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01030806_ZOOM Start : 8-Mar-101 10:21:53 am End : 8-Mar-101 10:32:09 am GIGA TELECOM/GDM-100/1;836.49MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.501 1.411 1.321 1.231 1.141 1.051 0.961 0.871 0.781 0.691 File : 01030806_ZOOM Start : 8-Mar-101 10:21:53 am End : 8-Mar-101 10:32:09 am GIGA TELECOM/G…

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification GIGA TELECOM, Inc. Dates of Tests: Mar. 8-9, 2001 (135-091)#156-3, Sewha Bldg. 4F, Samsung-Dong Test Report S/N: 22.210309131.PJR Kangnam-Gu, Seoul, KOREA Test Site: PCTEST Lab, Columbia, MD USA Attn: M. J. Woo President FCC ID PJRGDM-100 APPLICANT GIGA Telecom, Inc. Classification: Non-Broadcast Transmitter held to ear (TNE) FCC Rule Part(s): §22(H), §22.901(d), §2 EUT Type: Dual-Mode Cellular Phone (AMPS/CDMA) Trade Name/Model(s): GIGA GDM-100 Tx Frequency Range: 824.04 ~ 848.97MHz (AMPS) / 824.70 ~ 848.31 MHz (CDMA) Rx Frequency Range: 869.04 ~ 893.31MHz (AMPS) / 869.70 ~ 893.31 MHz (CDMA) Max. RF Output Power: 0.461W ERP AMPS (26.633 dBm) / 0.322W ERP CDMA (25.083 dBm) Max. SAR Measurement: 1.3512 mW/g AMPS Head SAR; 1.1173 mW/g CDMA Head SAR; 0.6940 mW/g AMPS Body SAR; 0.5541 mW/g CDMA Body SAR Frequency Tolerance: 0.00025% (2.5 ppm) Emission Designators: 40K0F8W, 40K0F1D, 1M25F9W This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in § 2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210309131.PJR FCC Part 22 Certification © 2001 PCTEST Engineering Laboratory, Inc. FCC Part 22 TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION 2 3.1 INSERTS PER §2.1033(d) 3 4.1 DESCRIPTION OF TESTS 4-6 5.1 EFFECTIVE RADIATED POWER OUTPUT 7-8 6.1 RADIATED MEASUREMENTS 9-14 7.1 FREQUENCY STABILITY 15-16 8.1 PLOTS OF EMISSIONS 17 9.1 LIST OF TEST EQUIPMENT 18 10.1 SAMPLE CALCULATIONS 19 11.1 CONCLUSION 20 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: CIRCUIT DIAGRAMS & DESCRIPTION ATTACHMENT K: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT L: OPERATIONAL DESCRIPTION ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS Test Report S/N: 22.210309131.PJR FCC Part 22 Dates of Tests: March 8-9, 2001 Certification GIGA FCC ID: PJRGDM-100 (Model: GDM-100) © 2001 PCTEST Lab Dual-Mode Cellular Phone (AMPS/CDMA) 1 MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant: GIGA Telecom, Inc. Address: (135-091)#156-3, Sewha Bldg. 4F, Samsung-Dong Kangnam-Gu, Seoul, Korea Attention: M. J. Woo President • FCC ID: PJRGDM-100 • Trade Name(s): GIGA • Model(s): GDM-100 • Quantity: Quantity production is planned • Emission Designator: 40K0F8W, 40K0F1D, 1M25F9W • Tx Freq. Range: 824.04 — 848.97 MHz (AMPS) / 824.70 ~ 848.31 (CDMA) Rx Freq. Range: 869.04 — 893.31 MHz (AMPS) / 869.70 ~ 893.31 (CDMA) • Equipment Class: Non-Broadcast Transmitter Held to Ear (TNE) • Equipment Type: Dual-Mode Cellular Phone • Modulation(s): AMPS / CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • Max. RF Output Power: 0.461W ERP AMPS (26.633 dBm) / 0.322W ERP CDMA (25.083dBm) • Ma…

Text truncated - open the document above for the full version.
