PJV-VTE102USB Receiver

*** USER’S MANUAL *** FCC ID : PJV-VTE102 The Federal Communication Commission Statement This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of more of the following measures: - - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced Radio/TV technician for help. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that change or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1 This device may not cause harmful interference and 2 This device must accept any interference received, including interference that may cause undesired operation. The antenna used for this transmitter must not be collocated or operation in conjunction with any other antenna or transmitter. OVERVIEW ARS2010 is an interactive learning and response system from Globalnet Technology Corporation designed for all users within education or the corporate and training sector. It can be used in a wide range of environments such as the classroom/training room, at conferences and seminars, at sales meetings and product presentations, and for market research, staff training and recruitment. It is designed to improve the level of learning, understanding, and motivation from delegates by enabling them to participate more fully in all activities by interacting with the facilitator and being more deeply involved with the whole process. It can not only be used for question and answer sessions and tests, but also for making assessments and gathering opinions, for surveys and voting, for promoting debate, and for quizzes and games. The facilitator is able to obtain individual and group results in real time with live feedback as well as having an extended series of reports and statistics for subsequent analysis. Individual and group strengths, weaknesses, progression and interaction can be monitored. Using modern sophisticated software running on a standard PC, the ARS2010 system enables delegates to respond to the facilitator using their own personal handsets. The system consists of two broad areas of equipment, the hardware and the software. THE HARDWARE There are three components to the hardware:, 1 Delegate Handsets Each delegate in the session has a personal handset which is used to make the responses. 2 Master Handset This is used by the facilitator to run the activities in the sessions. 3 USB Receiver The receiver accepts the responses from all handsets and passes them on to the software. THE HARDWARE AND SOFTWARE INSTALLATION 1. Your ARS2010 installation file will be located either within an accompanying memory stick or CD. 2. Run the installation file: 3. Select the most relevant version of ARS2010 as shown below. 4. Select the destination where you would like to install the software to 5. Follow the remaining 2 steps, selecting whether you require a desktop icon and allow the software to install. 6. Plug in the ARS2010 receiver into any available USB port, the computer should automatically detect the receiver and load the drivers. THE SOFTWARE The software can be run on a standard PC and is normally projected onto a screen or interactive whiteboard. Alternatively, the computer screen or a television can be used. The JustVote software has five parts:, 1 Group Manager Within this part, the facilitators maintain the database of each separate group of participants, including the number and identification of delegates, the assignment of handsets to individuals, the division into sub,groups (teams) if required, and other information concerning the individuals and facilitators in the sessions. This is also the utility to split a system in to two or more system by reassigning handsets to different participants (note: to split a system an additional receiver is required for each extra system required). 2 Editor This part enables the facilitators to write and prepare all instructional material and organise it into files for running in the activity sessions. Although the editor gives the most functionality the built in PowerPoint add on (See page 11) allows any current material to be edited within minutes to make a fully functional questionnaire/survey. 3 Activity This part covers the range of options available for actually running an interactive session. There are five Evaluation and five other activity types. To run an activity the facilitator chooses the database for the relevant group (part 1 of the software). 4 Reports This part provides a permanent record of the results of the activity sessions and includes a wide range of text, tables, charts, and statistics. This includes reports such as summary reports, historical reports, comparison reports and attendance. DESKTOP ICONS There are icons to open both the ARS2010 console and the editor, the console provides shortcuts to the Group Manager, Activity, Editor and Reports windows. Getting Started The best place to start is to see how simple it is to write your own set of questions. THE BASIC P…

Text truncated - open the document above for the full version.

DOC Letter Mar. 12, 2012 Federal Communications Commission Authorization and Evaluation Division Dear Regulatory Authority, We, the undersigned, hereby declare that FCC Part 15B Declaration of Conformity procedures will be applied to the digital device portion of the following product: Product: StarBoard VT-E1 Model: StarBoard VTE1-R FCC Part 15B DoC report number: F210603 This Device complies with Part 15B DoC of the FCC rules, operation is subject to the following two conditions. This device may not cause harmful interference and, This device must accept any interference received, Including interference that may cause undesired operation TEST LABORATORY Global Certification Corp. No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221, Taiwan (R.O.C.). Accredited Lab. Assigned under FCC number: TW1030 Sincerely, Hitachi Solutions, Ltd. Hitachi Solutions Tower A, 4-12-7, Higashishinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan

Hitachi Solutions, Ltd. Hitachi Solutions Tower A, 4-12-7, Higashishinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Tel: +81-3-5780-2268 Fax: +81 3-5780-2342 Date: Mar. 12, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: PJV-VTE102 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, DEXIN Corporation here by requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Block Diagrams Description of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer Shigeru Kano / Interactive Media Solutions Division manager Telephone Number: +81-3-5780-2268 E-Mail: [email protected]

Global Certification Corp. PHOTO OF EUT PHOTOS OF EUT Report No. : 210603 01 Front view of EUT 02 Rear view of EUT

Label location

FCC Label Hitachi Solutions, Ltd. Product Name : StarBoard VT-E1 Model No.: StarBoard VTE1-R Input : 5 Vdc Made in Taiwan FCC ID: PJV-VTE102

Global Certification Corp. PHOTO OF EUT PHOTOS OF EUT Report No. : 210603 03 Front view of PCB 04 Rear view of PCB

Global Certification Corp. Date of Issue: Feb. 10, 2012 Report No. : F210603 Page1/28 FCC 47 CFR PART 15 SUBPART C TEST REPORT FOR Product Name: StarBoard VT-E1 Model : StarBoard VTE1-R Trade Name: Hitachi Solutions, Ltd. Issued to Hitachi Solutions, Ltd. Hitachi Solutions Tower A, 4-12-7, Higashishinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Issued by Global Certification Corp. EMC Test Site Xizhi office and Lab No.146, Sec. 2, Xiangzhang Rd., Xizhi Dist., New Taipei City 221, Taiwan (R.O.C.) Note: This test refers exclusively to the test presented test model and sample. This report shall not be reproduced except in full, without the written approval of Global Certification Corporation. This document may be altered or revised by Global Certification Corporation. Personnel only, and shall be noted in the revision section of the document. Global Certification Corp. Date of Issue: Feb. 10, 2012 Report No. : F210603 Page2/28 TABLE OF CONTENTS ----------------------------------------------------------------------------------------------------- 2 1. GENERAL INFORMATION -------------------------------------------------------------------------------------------------------- 3 1.1 DESCRIPTION OF THE TESTED SAMPLES ----------------------------------------------------------------------------------------------- 4 2. TEST METHODOLOGY ------------------------------------------------------------------------------------------------------------- 6 2.1 GENERAL TEST PROCEDURES --------------------------------------------------------------------------------------------------- 6 2.2 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ----------------------------------------------------------------- 6 2.3 DESCRIPTION OF TEST MODES -------------------------------------------------------------------------------------------------- 7 2.4 DESCRIPTION OF THE SUPPORT EQUIPMENTS ----------------------------------------------------------------------------- 8 3. TEST AND MEASUREMENT EQUIPMENT ----------------------------------------------------------------------------------- 9 3.1 CALIBRATION ----------------------------------------------------------------------------------------------------------------------- 9 3.2 EQUIPMENT -------------------------------------------------------------------------------------------------------------------------- 9 4. SECTION 15.249 REQUIREMENTS (FUNDAMENTAL/ HARMONICS) ---------------------------------------------- 10 4.1 TEST SETUP ------------------------------------------------------------------------------------------------------------------------ 10 4.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------- 10 4.3 RESULT: PASSED -------------------------------------------------------------------------------------------------------------- 10 4.4 TEST DATA: ------------------------------------------------------------------------------------------------------------------------ 10 5. SECTION 15.205 REQUIREMENTS (BAND EDGE) ------------------------------------------------------------------------- 19 5.1 TEST SETUP ------------------------------------------------------------------------------------------------------------------------ 19 5.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------- 19 5.3 RESULT: PASSED -------------------------------------------------------------------------------------------------------------- 20 5.4 TEST DATA: ------------------------------------------------------------------------------------------------------------------------ 20 6. SECTION 15.209 REQUIREMENTS (GENERAL RADIATED EMISSION) ------------------------------------------- 24 6.1 TEST SETUP ------------------------------------------------------------------------------------------------------------------------ 24 6.2 LIMIT ------------------------------------------------------------------------------------------------------------------------------- 25 6.3 TEST PROCEDURE ----------------------------------------------------------------------------------------------------------------- 26 6.4 RESULT: PASSED ---------------------------------------------------------------------------------------------------------------- 26 6.5 TEST DATA: ------------------------------------------------------------------------------------------------------------------------ 27 7. SECTION 15.207 REQUIREMENTS (POWERLINE CONDUCTED EMISSIONS) ---------------------------------- 28 APPENDIX 1 PHOTOS OF TEST CONFIGURATION APPENDIX 3 PHOTOS OF EUT Global Certification Corp. Date of Issue: Feb. 10, 2012 Report No. : F210603 Page3/28 1. GENERAL INFORMATION Applicant : Hitachi Solutions, Ltd. Address : Hitachi Solutions Tower A, 4-12-7, Higashishinagawa, Shinagawa-ku, Tokyo, 140-0002, Japan Manufacturer : Cannex Technology Inc. Address : No. 182, Sec. 2, Yuanlu Rd., Sihu Town 514, Changhua County, Taiwan EUT : StarBoard VT-E1 Model Name : StarBoard VTE1-R Model Differences : N/A Is here with confirmed to comply with the requirements set out in the FCC Rules and Regulations Part 15 Subpart C and the measurement procedures were according to ANSI C63.4-2003. The said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. FCC part 15 subpart C Receipt Date : 01/06/2012 Final Test Date : 02/06/2012 Taipei, Taiwan FEB. 10, 2012 Jason Yeh / Vice Manager (Place) (Date) (Signature) Designation Number: TW1030 Global Certification Corp. Date of Issue: Feb. 10, 2012 Report No. : F210603 Page4/28 1.1 DESCRIPTION OF THE TESTED SAMPLES EUT Name : StarBoard VT-E1 Model Number : StarBoard VTE1-R Receipt Date : 01/06/2012 FCC ID : PJV-VTE102 Input Voltage : ; DC 5 V Power From †Inside ;Outside †Adaptor †BATTERY †Power Supply †DC Power Source ;Support Unit PC Operate Frequency : Refer to the chann…
