PKKES315V2Electronic Container Seal Transmitter (315MHz)

The brief description for the Eseal(315MHz) Figure 1. Simplified Eseal(315MHz) Block Diagram POWER SUPPLY (2 AA size battery) ENCODER (2.048KHz to 16.384KHz) 315MHz FSK TRANSMITTER MEMORY

EUT Front View EUT Rear View

EUT with FCC ID Label

EUT FCC ID Label Location

EUT Circuit Component View EUT Circuit Solder View

The brief description for the Eseal (315 MHz) 1. The Eseal (315MHz) consists of the block as shown above 2. The controller provides the interface to the Memory. With the ECS’s information stored in the memory, the controller will encode the number into FSK data before sending them to the transmitter to be modulated. 3. The memory provides storage space for the ECS’s information. 4. The transmitter is responsible for modulating the FSK data into FM signal. 5. The power supply shall come form a 3-Volt battery. The followings are the specifications fro the transmitter S/N Parameter Specification Remark 1 Carrier Frequency 315 MHz 2 Output Power -10dBm@50Ù 3 Spurious Harmonics >=-28dBc 4 Frequency Deviation >32kHz±1kHz 40kHz±1kHz in phase 2 5 Max. Data Baud Rate 16.384kbps 6 Output Impedance Better than 13dBm into a 50 Ù load 7 Temperature Stability ±50ppm at operating temperature 8 Modulation Mode Frequency Modulation Power Supply FM Transmitter Controller Memory

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC ID PER PART 15.231 EMI MEASUREMENT AND TEST REPORT For eLogicity International Pte Ltd Blk 1093 Lower Delta Road, Tiong Bahru Industrial Estate #07/05-08, Singapore 169204 FCC ID: PKKES315V2 March 26, 2001 This Report Concerns: Original Report Equipment Type: Electronic Container Seal Transmitter (315 MHz), ITE Test Engineer: Jeff Lee Test Date: March 19, 2001 Reviewed By: John Y. Chan – Engineering Manager Prepared By: Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 Tel: (408) 732-9162 Fax: (408) 732-9164 eLogicity International Pte Ltd FCC ID: PKKES315V2 Report # Test Report Page 2 of 18 FCC ID Per 15.231 Report TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................................3 1.2 OBJECTIVE................................................................................................................................................................................3 1.3 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................3 1.4 TEST METHODOLOGY..............................................................................................................................................................3 1.5 TEST FACILITY.........................................................................................................................................................................3 1.6 TEST EQUIPMENT LIST............................................................................................................................................................4 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................................4 2 - SYSTEM TEST CONFIGURATION..................................................................................................................................5 2.1 JUSTIFICATION..........................................................................................................................................................................5 2.2 BLOCK DIAGRAM.....................................................................................................................................................................5 2.3 TEST SETUP BLOCK DIAGRAM...............................................................................................................................................6 2.4 EQUIPMENT MODIFICATIONS.................................................................................................................................................7 3 - CONDUCTED EMISSIONS TEST DATA........................................................................................................................8 4 - RADIATED EMISSION DATA............................................................................................................................................9 4.1 EUT SETUP...............................................................................................................................................................................9 4.2 SPECTRUM ANALYZER SETUP................................................................................................................................................9 4.3 TEST PROCEDURE....................................................................................................................................................................9 4.4 CORRECTED AMPLITUDE & MARGIN CALCULATION.........................................................................................................9 4.5 SUMMARY OF TEST RESULTS...............................................................................................................................................10 4.6 RADIATED EMISSIONS TEST RESULT DATA.......................................................................................................................10 APPENDIX A:.................................................................................................................................................................................11 APPENDIX B:.................................................................................................................................................................................13 APPENDIX C:.................................................................................................................................................................................15 APPENDIX D – AGENCY AUTHORIZATION LETTER...............................................................................................17 eLogicity International Pte Ltd FCC ID: PKKES315V2 Report # Test Report Page 3 of 18 FCC ID Per 15.231 Report 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The eLogicity International Pte. Ltd., model ES315V2 or the "EUT" as referred to in this report is a 315MHz RF transmitter which is a part of the Electronic Container Seal (ECS) designed to be used by all shippers, aimed to improve the efficiency of port operation. The EUT transmits 315MHz FM signal. The EUT output impedance shall be 50Ù. The EUT measures approximately 2.25” L x 1.25” W x 4.35” H. 1.2 Objective This Type approval report is prepared on behalf of eLogicity International Pte Ltd in accordance with Part 2, Subpart J, and Part …
