PKRNVWFB2CPCS CDMA MODEM

User Guide Freedom Box 200C TM Wireless Ruggedized Modem For Windows 2000 and XP Warning: You must install the modem software before inserting the FB200C modem. Notice: Restricted Proprietary Information © Copyright Novatel Wireless Inc. (2003) The information contained in this document is the exclusive property of Novatel Wireless Inc. All rights reserved. Unauthorized reproduction of this manual in any form without the expressed written approval of Novatel Wireless Inc. is strictly prohibited. This manual may not, in whole or in part, be copied, reproduced, translated, or reduced to any electronic or magnetic storage medium without the written consent of a duly authorized officer of Novatel Wireless Inc. The information contained in this document is subject to change without notice and should not be construed as a commitment by Novatel Wireless Inc. unless such commitment is expressly given in a covering document. Novatel Wireless Inc. makes no warranties, either expressed or implied, regarding this document, its merchantability, or its fitness, for any particular purpose. Microsoft ® and Windows ® are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All other brand names and product names used in this document are trade names, service marks, trademarks, or registered trademarks of their respective owners. The Novatel Wireless logo and Freedom Box 200C are trademarks of Novatel Wireless, Inc. Produced in the USA. Table of Contents3 Manual Revision A for Windows Table of Contents Table of Contents Technical Support Safety and Regulatory Notices .............................................................................................................. 3 Regulatory Notices................................................................................................................................. 3 Technical Support .................................................................................................................................. 3 System Requirements............................................................................................................................ 3 FB200C Overview and Installation............................................................ 5 FB200C front panel................................................................................................................................ 5 FB200C Rear Panel............................................................................................................................... 6 Connecting the power cable .................................................................................................................. 7 Installing the Wireless Connection Manager Software on Windows .... 9 Uninstalling the Wireless Connection Manager Software .................................................................... 12 Getting Started With the Wireless Connection Manager...................... 13 Connecting to the Network................................................................................................................... 13 Disconnecting From the Network......................................................................................................... 17 Quitting the Wireless Connection Manager Application....................................................................... 17 System Tray Icons ............................................................................................................................... 18 Getting to Know the Wireless Connection Manager for Windows ...... 19 The Wireless Connection Manager Main Window ............................................................................... 19 The Modem Configuration Window...................................................................................................... 20 The Modem Properties Window........................................................................................................... 21 The Detailed Status Report Window.................................................................................................... 23 The About Wireless Connection Manager Window ............................................................................. 24 Additional Menu Commands................................................................................................................ 25 Troubleshooting Troubleshooting a Connection Failure ................................................................................................. 27 Error Messages.................................................................................................................................... 28 Frequently Asked Questions................................................................................................................ 29 Index .......................................................................................................... 31 4Table of Contents Manual Revision A for Windows This Page Intentionally Left Blank Technical Support — Manual Revision A for Windows Technical Support Safety and Regulatory Notices This product is not to be used in any environment where radio frequency equipment is prohibited or restricted in its use. To ensure that your modem is deactivated you should remove it from your computer under the above conditions. Regulatory Notices Federal Communications Commission Radio Frequency Interference Statement This equipment has been certified to comply within the limits of a class B digital device pursuant to part 15 and 24 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential situations. This equipment generates, uses, and can radiate radio frequency energy, and, if not properly installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turn…

Text truncated - open the document above for the full version.

FB200C Perspective FB200C Bottom FB200C Connector Side FB200C Indicator Side FB200C Top

Novatel Wireless Technologies Ltd. Suite 200, 6715 - 8th St NE Calgary, AB Canada T2E 7H7 Phone: 403 295 4800 TITLE: Label bottom FCC Freedom Box FB200C P/N: 25015651 NOTES: >Rev.D 2003-11-26 Lawrence Zalasky >REV B: Corrected Freedom Box title, model number and FCC ID >REV C: Adjusted height of numbers to match characters >REV D: Deleted FCC logo and added ICC and country origin HISTORY: (indicate: REV / DATE / ARTIST / REV. CHANGES FREEDOM BOX 200C TM TM C D MA b y Q u a l c o m m THIS PRODUCT COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE CONDITION THAT THIS DEVICE DOES NOT CAUSE HARMFUL INTERFERANCE . FCC ID: PKRNVWFB2C MODEL: FB 200C IC: 3229B-FB 200C COUNTRY OF ORIGIN: USA

FB200C Inner Assembly - Top FB200C Inner Assembly - Bottom FB200C Motherboard - Top FB200C Motherboard - Bottom FB200C Radio Module Assembly - Top FB200C Radio Module Assembly - Bottom FB200C Radio Module Open - Top FB200C Radio Module Open - Bottom

FCC ID: PKRNVWFB2C Environmental Assessment for Mobiles/Fixed Base Station for FCC ID: FCC ID: PKRNVWFB2C Model:FB200C to Federal Communications Commission 47 Cfr 1.1310 (MPE) Radiofrequency Radiation Exposure Limits Date Of Report: November 20, 2003 On the Behalf of the Applicant: Novatel Wireless Inc. At the Request of: P.O. NWS09386 Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 Attention of: John Ross 858-812-0614; FAX:-2888 Email: [email protected] Supervised By: Morton Flom, P. Eng. MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Table of Contents Rule Description Page . Test Report 1 . Identification of the Equipment Under Test 2 . Standard Test Conditions and Engineering Practices 4 1.1310 Environmental Assessment 5 MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 1 of 7. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report (Supplemental) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d03b0031 d) Client: Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 e) Identification: FB200C FCC ID: PKRNVWFB2C Description: PCS CDMA Modem f) EUT Condition: Not required unless specified in individual tests. g) Report Date: November 20, 2003 EUT Received: November 17, 2003 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 2 of 7. Identification of the Equipment Under Test (EUT) Name and Address of Applicant: Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 Manufacturer: Applicant FCC ID: PKRNVWFB2C Model Number: FB200C Description: PCS CDMA Modem Type of Emission: 1M25F9W Frequency Range, MHz: 1850 to 1910 Power Rating, Watts: 0.250 Switchable Variable x N/A Modulation: AMPS TDMA x CDMA OTHER Antenna: Helical Monopole x Whip Other Note: For RF Safety test antenna gain taken at the upper range of expected gain (i.e. 0 dBd) and RF Power set to highest nominal power across all channels. MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 3 of 7. M. Flom Associates, Inc. is accredited by the American Association for Laboratory Association (A2LA) as shown in the scope below. "This laboratory is accredited by the American Association for Laboratory Accreditation (A2LA) and the results shown in this report have been determined in accordance with the laboratory's terms of accreditation unless stated otherwise in the report." Should this report contain any data for tests for which we are not accredited, or which have been undertaken by a subcontractor that is not A2LA accredited, such data would not covered by this laboratory's A2LA accreditation. MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 4 of 7. Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992/2000, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst-case measurements. MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 5 of 7. Name of Test: Environmental Assessment Specification: FCC: 47 CFR 1.1310 Measurement Guide: ANSI/IEEE C95.1 1992 Test Equipment: Maximum Permissible Exposure (MPE) measurement system, consisting of: Narda 8717-1174R, Radiation meter Narda 8761D, E-field probe (300 kHz – 3 GHz) (Calibrated Nov-98) Measurement Procedure: 1. The following measurements were performed with a Narda probe using ANSI/IEEE C95.1 as a guide. 2. Prior to making any measurements, the measurements system was calibrated in accordance with the manufacturer’s procedures. 3. The EUT’s radiating element (antenna) was placed on a 1 m tall table for ease of testing. For equipment normally operated on a metal surface, a ground plane was used. 4. The remaining equipment necessary to operate the EUT was maintained at a distance from the measurement arrangement suitable to minimize interference with the measurements. 5. The minimum safe distance was calculated from the formula Power Density = EIRP / 4πR 2 (Peak Watts/m 2 ). The calculation is shown with the measurement data. 6. With the EUT operating at maximum power, a search was initiated for worst case emissions with the probe raised and lowered over a range of 0.2 to 2 meters in height and over a horizontal plane of 0 o to 360 o . 7. Average values were calculated for the whole body (0.2- 2.0m), lower body (0.2-0.8m) and upper body (1.0-2.0m). Results: Attached. MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 6 of 7. Test Setup: Maximum Permissible Exposure (MPE) MFA p03b0004, d03b0031 FCC ID: PKRNVWFB2C Page Number 7 of 7. Name of Test: R.F. Radiation Exposure FCC Rules: 1.1307, 1.1310, 1.1311, 2.1091 Description, EUT: See page 2 of Test Report 0.3-1.234 MHz: Limit [mW/cm 2 ] = 100 1.34-30 MHz: Limit [mW/cm 2 ] = (180/f 2 ) 30-300 MHz: Limit [mW/cm 2 ] = 0.2 Limits: Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 300-1500 MHz Limit [mW/cm 2 ] = f/1500 …

Text truncated - open the document above for the full version.

FCC ID: PKRNVWFB2C Transmitter Certification of FCC ID: PKRNVWFB2C Model: FB200C to Federal Communications Commission Rule Part(s) 24E, Confidentiality Date Of Report: November 20, 2003 On the Behalf of the Applicant: Novatel Wireless Inc. At the Request of: P.O. NWS09386 Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 Attention of: John Ross 858-812-0614; FAX:-2888 Email: [email protected] Supervised By: Morton Flom, P. Eng. MFA p03b0004, d03b0029 FCC ID: PKRNVWFB2C List of Exhibits (FCC Certification (PCS Transmitters) - Revised 9/28/98) Applicant: Novatel Wireless Inc. FCC ID: PKRNVWFB2C By Applicant: 1. Letter of Authorization x 2. Identification Drawings, 2.1033(c)(11) x ID Label x Location of Label x Compliance Statement x Location of Compliance Statement 3. Photographs, 2.1033(c)(12) x 4. Confidentiality Request: 0.457 And 0.459 x 5. Documentation: 2.1033(c) (3) User Manual x (9) Tune Up Info x (10) Schematic Diagram x (10) Circuit Description x Block Diagram x Parts List x Active Devices x 6. MPE Report x By M.F.A. Inc. A. Testimonial & Statement of Certification MFA p03b0004, d03b0029 FCC ID: PKRNVWFB2C The applicant has been cautioned as to the following: 15.21 Information to User. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) Special Accessories. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. MFA p03b0004, d03b0029 FCC ID: PKRNVWFB2C Table of Contents Rule Description Page . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 . Standard Test Conditions and Engineering Practices 6 2.1046(a), 24.232(b) Carrier Output Power (Conducted) 7 2.1046(a), 24.232(b).Carrier Output Power (Radiated) 8 2.1051, 2.1049(c), 24, 24.238(b). . Transmitter Conducted Measurements 10 2.1053(a) Field Strength of Spurious Radiation 17 2.1055(a)(1), 24.235 . . Frequency Stability (Temperature Variation) 21 2.1055(d)(1) Frequency Stability (Voltage Variation) 23 2.202(g) Necessary Bandwidth and Emission Bandwidth 24 MFA p03b0004, d03b0029 FCC ID: PKRNVWFB2C Page Number 1 of 24. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) Test Report b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d03b0029 d) Client: Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 e) Identification: FB200C FCC ID: PKRNVWFB2C Description: PCS CDMA Modem f) EUT Condition: Not required unless specified in individual tests. g) Report Date: November 20, 2003 EUT Received: November 17, 2003 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. Accessories Used During Testing: Test Equipment 1 CDMA Call Box Supplied by Applicant Test Equipment 1 RF Interface Cable Supplied by Applicant MFA p03b0004, d03b0029 FCC ID: PKRNVWFB2C Page Number 2 of 24. List of General Information Required for Certification In Accordance with FCC Rules and Regulations, Volume II, Part 2 and to 24E, Confidentiality Sub-Part 2.1033 (c)(1): Name and Address of Applicant: Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 Manufacturer: Novatel Wireless Inc. 9255 Towne Centre Dr., Suite 225 San Diego, CA 92121-3030 (c)(2): FCC ID: PKRNVWFB2C Model Number: FB200C (c)(3): Instruction Manual(s): Please See Attached Exhibits (c)(4): Type of Emission: 1M25F9W (c)(5): FREQUENCY RANGE, MHz: 1850 to 1910 (c)(6): Power Rating, Watts: 0.250 Switchable Variable x N/A FCC Grant Note: BD - The output power is continuously variable from the value listed in this entry to 10%-15% of the value listed. (c)(7): Maximum Power Rating, Watts: 2 MFA p03b0004, d03b0029 FCC ID: PKRNVWFB2C Page Number 3 of 24. Subpart 2.1033 (continued) (c)(8): Voltages & Currents in All Elements in Final RF Stage, Including Final Transistor or Solid State Device: Collector Current, A = 350 ma Collector Voltage, Vdc = 12 Supply Voltage, Vdc = 12 (c)(9): Tune-Up Procedure: Please See Attached Exhibits (c)(10): Circuit Diagram/Circuit Description: Including description of circuitry & devices provided for determining and stabilizing frequency, for suppression …
