PKRNVWMIFI4082Cellular/ PCS CDMA Wireless Router with WiMAX and WLAN

©2010 Novatel Wireless, Inc. All rights reserved. The information contained in this document is subject to change without notice and should not be construed as a commitment by Novatel Wireless, Inc. Patents and Licenses Visit www.novatelwireless.com/patents for a complete list of all Novatel Wireless patents. Software License Proprietary Rights Provisions: The software drivers provided with this product are copyrighted by Novatel Wireless and/or Novatel Wireless’ suppliers. Although copyrighted, the software drivers are unpublished and embody valuable trade secrets proprietary to Novatel Wireless and/or Novatel Wireless’ suppliers. The disassembly, decompilation, and/or Reverse Engineering of the software drivers for any purpose is strictly prohibited by international law. The copying of the software drivers, except for a reasonable number of back-up copies is strictly prohibited by international law. It is forbidden by international law to provide access to the software drivers to any person for any purpose other than processing the internal data for the intended use of the software drivers. U.S. Government Restricted Rights Clause: The software drivers are classified as “Commercial Computing device Software” and the U.S. Government is acquiring only “Restricted Rights” in the software drivers and their Documentation. U.S. Government Export Administration Act Compliance Clause: It is forbidden by US law to export, license or otherwise transfer the software drivers or Derivative Works to any country where such transfer is prohibited by the United States Export Administration Act, or any successor legislation, or in violation of the laws of any other country. Trademarks and Service Marks Novatel Wireless is a trademark of Novatel Wireless, Inc., and the other trademarks, logos, and service marks (collectively the “Trademarks”) used in this user manual are the property of Novatel Wireless or their respective owners. Nothing contained in this user manual should be construed as granting by implication, estoppel, or otherwise, a license or right of use of Novatel Wireless or any other Trademark displayed in this user manual without the written permission of Novatel Wireless or its respective owners. • MobiLink, Novatel Wireless, and the Novatel Wireless logo are all trademarks of Novatel Wireless, Inc. • MiFi and the MiFi logo are registered trademarks of Novatel Wireless, Inc. • Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. • Apple®, Mac®, and Mac OS® are trademarks of Apple, Inc., registered in the U.S. and other countries. • Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries. • ExpressCard is a registered trademark and PC Card is a trademark of PCMCIA. • SDHC, SD Card, and the SD logo are trademarks of SD-3C LLC. The names of actual companies and products mentioned in this user manual may be the trademarks of their respective owners. FCC ID: PKRNVWMIFI4082 IC ID: _____________________ PN: 90026289_R1_Draft6_24Sep2010 Please visit www.novatelwireless.com for the latest information about your device. Contents Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MiFi 4082 Device Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Your MiFi 4082 Intelligent Mobile Hotspot Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 LED States. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 eInk Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Caring for Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Power Sources for Your MiFi Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Install and Charge Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Remove the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Battery Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Initial Connection and Setup — Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 MiFi Landing Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Login to the MiFi 4082 Device for the First Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Wi-Fi Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Set Up a Wi-Fi Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Set Up Wireless Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Using Mi…

Text truncated - open the document above for the full version.

NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 External Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 1 of 4 © 2010 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 External Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 2 of 4 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 External Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 3 of 4 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 External Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 4 of 4 © 2010 PCTEST Engineering Laboratory Inc.

Text *QUALCOMM 3G CDMA ” Arial Narrow – 5pt Symbols for “ FCC ”, “ CSA ”, and “ Recycling ” to be displayed here. LABEL ASSY, MiFi4082 MEID-HEX Chuck Morningstar Barcode 128-B “ XXXXXXXXXXXX ” Text: “ WIMAX MAC: XX:XX:XX:XX:XX:XX “ XXXXXXXXXXXX is modem’s WIMAX MAC ID Calibri – 6pt bold “MiFi 4082” Logo Text *Patents:www.nvtl.com/patents ” Verdana – 5pt Bold July 9, 2010 Novatel Wireless, Inc. (42.90 mm) Blank Label Stock 2501X TBD ( 42.90 mm X 57.35 mm) (57.35 mm) Text:MODEL: MIFI4082 FCC ID: PKRNVW MIFI4082 IC: 3229 B -MIFI4082 Arial Black - 4pt Text *YYMMDD ” Date Code“ YY ” – Last 2 digits of year “ MM ” – Month “ DD ”-Day Arial Black – 5pt BOLD Barcode 128-B “ YYYYYYYYYYYYYY ” Text: “ MEID-HEX: YYYYYYYYYYYYYY “ YYYYYYYYYYYYY is modem’s 14 digit MEID-HEX Calibri – 6pt bold Barcode 128-B “ XXXXXXXXXXXXXXXXXX ” Text: “ MEID-DEC: XXXXXXXXXXXXXXXX “ XXXXXXXXXXXXXXXX is modem’s 18 digit Decimal MEIDCalibri – 6pt bold “Novatel Wireless “ logo PART NUMBER: DA.01019137 Rev 1 PKRNVWMIFI4081 - Label Location The label will be located inside the battery well. When the device is packaged the battery will be located outside of the device.

NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 1 of 9 © 2010 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 2 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 3 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 4 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 5 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 6 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 7 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 8 of 9 © 2010 PCTEST Engineering Laboratory Inc. NOVATEL WIRELESS INC. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Internal Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 9 of 9 © 2010 PCTEST Engineering Laboratory Inc.

© 2010 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Novatel Wireless Dates of Test: Aug. 30, Sept. 2, 3, 7, Nov. 12, 20, 2010 9645 Scranton Road, Suite 205 Test Report Number: SAR.20100806 San Diego, CA 92121 Revision K This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003, OET Bulletin 65 Supp. C, RSS-102 and Safety Code 6 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Certificate # 2387.01 FCC ID: PKRNVWMIFI4082 IC Certificate: 3229B-MIFI4082 Model(s): MiFi4082 Test Sample: Engineering Unit Same as Production Serial No.: Eng 9 Equipment Type: Wireless Personal Router Classification: PCS Licensed Transmitter (PCB) TX Frequency Range: 824.7–848.3 MHz, 1851.25–1908.75 MHz, 2501–2685 MHz, 2412–2462 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 835 MHz – 24.55 dB, 1900 MHz – 24.11 dB , 2600 MHz – 24.76 dB, 2450 MHz – 17.85 dB Conducted Signal Modulation: CDMA, QPSK, 16QAM, DSSS, OFDM Antenna Type (Length): Internal Application Type: Certification FCC Rule Parts: Part 15, 22, 24, 27 KDB Issued for Test: KDB 869935 Industry Canada: RSS-102 FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 2 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ........................................................................................................................... 3 SAR Definition [5] ...................................................................................................................... 3 2. SAR Measurement Setup ..................................................................................................... 4 Robotic System ......................................................................................................................... 4 System Hardware ..................................................................................................................... 4 System Description ................................................................................................................... 4 E-Field Probe ............................................................................................................................ 5 3. Robot Specifications ............................................................................................................. 7 4. Probe and Dipole Calibration ................................................................................................ 8 5. Phantom & Simulating Tissue Specifications ........................................................................ 9 SAM Phantom ........................................................................................................................... 9 Head & Body Simulating Mixture Characterization ................................................................... 9 Device Holder ........................................................................................................................... 9 Body Worn Configurations ...................................................................................................... 10 6. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] ............................................................... 11 Uncontrolled Environment ....................................................................................................... 11 Controlled Environment .......................................................................................................... 11 7. Measurement Uncertainty ................................................................................................... 12 8. System Verification ............................................................................................................. 13 Tissue Verification ................................................................................................................... 13 Test System Verification ......................................................................................................... 13 9. SAR Test Data Summary .................................................................................................... 15 Procedures Used To Establish Test Signal ............................................................................. 15 Device Test Condition ............................................................................................................. 15 10. FCC 3G Measurement Procedures – Oct. 2007 (revised) .............................................. 16 10.1 Procedures Used to Establish RF Signal for SAR ....................................................... 16 10.2 SAR Measurement Conditions for CDMA2000, 1xEV-DO .......................................... 16 SAR Data Summary – 835 MHz Body – Rev 0 ....................................................................... 27 SAR Data Summary – 1900 MHz Body – Rev 0 ..................................................................... 28 SAR Data Summary – 2450 MHz B…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: PKRNVWMIFI4082 FCC Pt. 15.247 WLAN 802.11b/g/n TEST REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1005240868.PKR May 25 - June 7, 2010 Cellular/PCS CDMA/EvDO, WLAN, and WiMAX Mobile Hotspot Page 1 of 38 © 2010 PCTEST Engineering Laboratory, Inc. REV 1.1WBGNFI 04/19/2010 Applicant Name: Date of Testing: Novatel Wireless Inc. May 25 - June 7, 2010 9645 Scranton Road, Suite 205 Test Site/Location: San Diego, CA 92121-3030 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0Y1005240868.PKR FCC ID: PKRNVWMIFI4082 IC CERTIFICATION NO.: 3229B-MIFI4082 APPLICANT: Novatel Wireless Inc. Application Type: Certification Model(s): MiFi 4082 EUT Type: Cellular/PCS CDMA/EvDO, WLAN, and WiMAX Mobile Hotspot Max. RF Output Power: 125.03 mW (20.97 dBm) Peak Conducted (b) 138.68 mW (21.42 dBm) Peak Conducted (g) 132.43 mW (21.22 dBm) Peak Conducted (n) Frequency Range: 2412 - 2462 MHz (DSSS/OFDM) FCC Classification: Digital Transmission System (DTS) FCC Rule Part(s): Part 15.247 IC Specification(s): RSS-210 Issue 7 Test Device Serial No.: UNIT 1 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2003. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is conducted. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.247 / IC RSS-210 WLAN 802.11b/g/n Reviewed by: FCC ID: PKRNVWMIFI4082 FCC Pt. 15.247 WLAN 802.11b/g/n TEST REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1005240868.PKR May 25 - June 7, 2010 Cellular/PCS CDMA/EvDO, WLAN, and WiMAX Mobile Hotspot Page 2 of 38 © 2010 PCTEST Engineering Laboratory, Inc. REV 1.1WBGNFI 04/19/2010 TABLE OF CONTENTS FCC PART 15.247 MEASUREMENT REPORT...................................................................................3 1.0 INTRODUCTION......................................................................................................................................4 1.1 SCOPE....................................................................................................................................................... 4 1.2 PCTEST TEST LOCATION........................................................................................................................ 4 2.0 PRODUCT INFORMATION .....................................................................................................................5 2.1 EQUIPMENT DESCRIPTION..................................................................................................................... 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS.................................................................................. 5 2.3 LABELING REQUIREMENTS .................................................................................................................... 5 3.0 DESCRIPTION OF TEST ........................................................................................................................6 3.1 EVALUATION PROCEDURE..................................................................................................................... 6 3.2 CONDUCTED EMISSIONS........................................................................................................................ 6 3.3 RADIATED EMISSIONS ............................................................................................................................ 7 4.0 ANTENNA REQUIREMENTS ..................................................................................................................8 5.0 TEST EQUIPMENT CALIBRATION DATA..............................................................................................9 6.0 TEST RESULTS ....................................................................................................................................10 6.1 SUMMARY ............................................................................................................................................... 10 6.2 6DB BANDWIDTH MEASUREMENT – 802.11B/G/N.............................................................................. 11 6.3 OUTPUT POWER MEASUREMENT – 802.11B...................................................................................... 14 6.4 OUTPUT POWER MEASUREMENT – 802.11G/N .................................................................................. 15 6.5 POWER SPECTRAL DENSITY (802.11B/G/N) ....................................................................................... 16 6.6 CONDUCTED EMISSIONS AT THE BAND EDGE.................................................................................. 19 6.7 CONDUCTED SPURIOUS EMISSIONS .................................................................................................. 23 6.8 RADIATED SPURIOUS EMISSION MEASUREMENTS.......................................................................... 27 6.9 RADIATED RESTRICTED BAND EDGE MEASUREMENTS .................................................................. 31 6.10 LINE-CONDUCTED TEST DATA............................................................................................................. 32 7.0 CONCLUSION ........................................…

Text truncated - open the document above for the full version.

Novatel Wireless Inc. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Test Set-Up Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 1 of 2 © 2010 PCTEST Engineering Laboratory Inc. TEST SETUP PHOTOGRAPHS Novatel Wireless Inc. FCC ID: PKRNVWMIFI4082 Model: MIFI4082 Test Set-Up Photos EUT Type: Cellular/PCS CDMA/EvDO Mobile Hotspot with WiMAX and WLAN Page 2 of 2 © 2010 PCTEST Engineering Laboratory Inc.

FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 186 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Appendix C – SAR Test Setup Photos System Body Configuration Body Tissue Depth FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 187 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Test Position Locations The testing was conducted on top, bottom and edges closest to each antenna. The top, bottom, end, left and right testing was conducted for the WWAN antenna. The sixth side of the unit was not tested as the WWAN antenna was more than 2.5 cm from the side. The right, top and bottom was tested for the WLAN antenna. The remain three sided were not tested as the antenna was more than 2.5 cm from the three sides. The WiMax testing was conducted on the left, top and bottom for each antenna. The remaining three sides were not tested as the antenna is located more than 2.5 cm from the side. All testing was conducted per TCB Workshop October 2010 presentation. KDB inquiry number 869935 provided guidance to the sides and bands tested. See the photo in Appendix C for a pictorial of the setups, labeling of the sides tested and antenna locations. Top Test Position 12 mm Gap FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 188 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Bottom Test Position 12 mm Gap Right Test Position 12 mm Gap FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 189 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Left Test Position 12 mm Gap Front of Device FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 190 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Back of Device Front Battery FCC ID: PKRNVWMIFI4082 © 2010 RF Exposure Lab, LLC Page 191 of 285 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Antenna Locations
