PKRNVWMIFI5510Portable Wireless Router with CDMA, LTE and WLAN

Inseego Corp.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Nov 18, 2012
Application Purpose: Original Equipment
Date of Application: Nov 15, 2012
Equipment Note: Portable Wireless Router with CDMA, LTE and WLAN
Frequency Range: 777.00000000 - 787.00000000
Company: Inseego Corp.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Start Here ©2012 Verizon Wireless. All Rights Reserved. PN: 90026640 Rev.A MiFi® 5510L You’re now connected to Verizon 4G LTE. Lightning fast, Lightning strong. For more information, visit verizonwireless.com/ 4GLTE. My Verizon My Verizon allows you to manage your account, pay your bill, purchase accessories & more. REGISTER at verizonwireless.com/ myverizon, to learn how to use your device. • Go to My Verizon • Click on Support • Click on Get Help with Your • Click on Device • Click on Select Another Device Customer Service is at your disposal at 1-800-922-0204 or at any Verizon Wireless Store. A Device Manual for your Jetpack is available online at verizonwireless.com/ support. Jetpack OverviewWelcome WARNING! Please use only an approved charging accessory to charge your device. Improper handling of the charging port, as well as the use of an incompatible charger, may cause damage to your device and void the warranty. NOTE: Appearance of device may vary. powermicroUSB charging port select button scroll left/ right Jetpack Home Screen Status Display Indicators Network Signal Strength Activity Indicator Extended Network Roaming Messages Connected Devices Battery Wi-Fi Name/Password Mobile Network Software Update About Jetpack Home Data Usage FPO status display FLAT SIZE: 360.0 mm X 121.0 mm (14.17” X 4.76”) FINISHED ASSEMBLED SIZE: 60.0 mm X 121.0 mm (2.36” X 4.76”) QSG PRINTS BLACK AND WHITE COLOR: 2/2 + Varnish MATERIAL: 70# Book or 105 GSM FINISHED: Gloss-oil varnish This Proof indicates Approximate Color Only. For Accurate Color Match, Use Approved Color Standard. DO NOTE USE COLOR FORMULAS ON THIS FILE. Novatel Wireless Technologies Ltd. Suite 200, 6715 - 8th Street NE Calgary, AB Canada T2E 7H7 Phone: 403.295.4800 TITLE: QSG MiFi5510L VZW NOTES P/N: 90026640PRECO: 12200 WHITE (0/0/0/0) BLACK (0/0/0/100) Rev.A 10/10/12 - LZalasky - Initial Draft FONTS All fonts included in ‘FONTS’ folder LINKS All images included in ‘LINKS’ folder FILES 90026640 Rev A Master QSG MiFi5510L VZW.indd (CS5) 90026640 Rev A Print QSG MiFi5510L VZW.pdf (PRINT READY PDF) 90026640 Rev A View QSG MiFi5510L VZW.pdf (VIEW ONLY. DO NOT PRINT) Notes Connecting to the Internet 1. Turn on your Jetpack using the power button and holding for two seconds. The Jetpack display will light up. 2. Open the Wi-Fi application or controls on the computer or Wi-Fi enabled device that you want to connect to your Jetpack and find the Jetpack’s Wi-Fi Name (SSID). 3. When prompted, enter your Wi-Fi Password. The Jetpack screen should now show an additional connected device. Your Wi-Fi enabled device is now connected to the Internet. Resetting Your Jetpack To restore your Jetpack to the factory settings, follow the steps below. 1. Verify that your Jetpack is powered on, and find the master RESET button located under the back cover slightly above and to the right of the battery removal divot. 2. Place one end of an unfolded paper clip into the master reset button and press down until the Jetpack screen shows “resetting to factory defaults.” This will take approximately five seconds. Setting Up Your Jetpack Installing 4G LTE SIM Card* CAUTION: Do not bend or scratch your SIM Card. Avoid exposing your SIM Card to static electricity, water or dirt. 1. Open the cover located on the underside of the MiFi 5510L Jetpack device. 2. Remove SIM Card from the outer card, lift the microSIM tab, and insert the SIM Card as shown below. *Your SIM (Subscriber Identity Module) Card is a small rectangular plastic card that stores your phone number and important information about your wireless service. NOTE: In the event you need to remove your SIM Card from your Jetpack, please reference the Device Manual at verizonwireless.com/support. Installing/Charging Battery 1. Remove the back cover to open the battery compartment. Align the gold- colored contacts. 2. Replace the back cover and connect the charger to the Jetpack device. Charge for a minimum of 3.5 hours. Passwords Your default Wi-Fi Name (SSID) and Wi-Fi Password can be found on the Jetpack display upon powering up. You can access your Wi-Fi Name (SSID) and Wi-Fi Password using the following steps. 1. Power on your Jetpack. 2. Select Menu and scroll to the Wi-Fi icon. 3. Select Open to display the Wi-Fi Name/Password. System Requirements To use Wi-Fi mode, your computer needs Wi-Fi capability and Internet browser software only. • Compatible with all major operating systems. • Works with the latest versions of browsers, including Android™, Chrome™, Firefox®, Internet Explorer®, Safari™ and Mobile Safari™. Web User Interface To access advanced Jetpack settings you can log into the Web User Interface by following the steps below. 1. Connect your Wi-Fi enabled device to the Verizon Jetpack using the steps outlined in the Connecting to the Internet section. 2. Open your web browser and enter http://my.jetpack or http://192.168.1.1. 3. Login using the Jetpack Admin PW which can be found using the following steps: 1. Power on your Jetpack. 2. Select Menu and scroll to the About Jetpack icon. 3. Select Open > More > More to display the Jetpack Admin PW. Monitoring Data Usage You can monitor your Jetpack data usage and setup usage alerts through your My Verizon account. You can also see current data usage details on your Jetpack by scrolling to View Usage on the Home screen and pressing the select button. Your Wireless Device and Third Par ty Ser vices Verizon Wireless is the mobile carrier associated with this wireless device, but many ser vices and features offered through this wireless device are provided by or in conjunction with third par ties. Verizon Wireless is not responsible for your use of this wireless device or any non-Verizon Wireless applications, ser vices and products including any personal information you choose to use, submit or share with others. It is recommended that you use the available encr yption options for added security when provisioning your device for use as a Wi-Fi gatewa…

Text truncated - open the document above for the full version.

Attestation Statements

Date: 11/14/2012 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD FCC ID: PKRNVWMIFI5510 Attestation for FCC Label Location Please be notified that we, the undersigned, Novatel Wireless Inc. declares that the product is compliant with the FCC Labeling Requirements since the following conditions are met: a) The device is handheld b) The FCC ID is visible at the time of purchase. The device is marketed without the battery installed hence the FCC label is located in the battery compartment and visible to the user. c) The FCC label area does not require any special tool for access. The FCC label is placed on a fixed part of the device and not removable. . Sincerely, Roman Olmos Hardware Engineer II Novatel Wireless Inc. Phone: 858-320-8837

Attestation Statements

BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD FCC ID: PKRNVWMIFI5510 Attestation for FCC Part 15B Declaration of Conformity Please be notified that we, the undersigned, Novatel Wireless Inc. declares that the product, which bears the above FCC ID is compliant with the FCC Part 15B requirements for DoC. The DoC procedure shall be carried out prior to marketing the device in the US. . Sincerely, Roman Olmos Hardware Engineer II Novatel Wireless Inc. Phone: 858-320-8837

Cover Letter(s)

Date: October 17, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Novatel Wireless Inc. at 9645 Scranton Road Suite 205 San Diego, CA 92121, hereby authorize Ferdinand Custodio of TÜV SÜD America Inc, 10044 Mesa Rim Road, San Diego, CA 92121 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on June 17, 2013 (180 days). Sincerely Yours, Company Officer: Roman Olmos Telephone Number: 858-320-8837 Email: [email protected]

Cover Letter(s)

Date: October 17, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: PKRNVWMIFI5510 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Novatel Wireless Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: 1. MiFi5510 BOM (Bill of Material) 2. MiFi5510 Tuning Procedure 3. MiFi5510 Schematics Diagrams 4. MiFi5510 Theory of Operation 5. MiFi5510 Block Diagram Novatel Wireless Inc. also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days. 1. MiFi5510 External and Internal Photos 2. MiFi5510 Test photos 3. MiFi5510 Quick Start Guide and Regulatory Statement 4. MiFi5510 User Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Roman Olmos Telephone Number: 858-320-8837 Email: [email protected]

Cover Letter(s)

October 18, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Re: Signing Authority on Form 731 per 852134 D01 Dear Sirs: I herby authorize Roman Olmos to sign all engineering attestations, cover letters and any other correspondence regarding the Grant submittal for the products bearing the FCC ID: PKRNVWMIFI5510. Sincerely, Todd Gallagher Manager – Regulatory Engineering Novatel Wireless Inc.

External Photos

Proprietary and Confidential NOVATEL WIRELESS, INC. 9645 Scranton Road, Suite 205, San Diego, CA 92121 Toll Free: 888.888.9231 Main: 858.812.3400  Fax: 858.812.3402 Internet: www.novatelwireless.com ISO 9001: 2000 Novatel Wireless PKRNVWMIFI5510 EUT Internal & External Photos I. Internal EUT PCB Photos a. Bottom Side (w/Shields) (without Shields) b. Top/LCD Display Side SD Card Slot Proprietary and Confidential NOVATEL WIRELESS, INC. 9645 Scranton Road, Suite 205, San Diego, CA 92121 Toll Free: 888.888.9231 Main: 858.812.3400  Fax: 858.812.3402 Internet: www.novatelwireless.com ISO 9001: 2000 III. External EUT Photos Top View Bottom View Top Side/Edge View Right Side/Edge View Micro USB Power Button Proprietary and Confidential NOVATEL WIRELESS, INC. 9645 Scranton Road, Suite 205, San Diego, CA 92121 Toll Free: 888.888.9231 Main: 858.812.3400  Fax: 858.812.3402 Internet: www.novatelwireless.com ISO 9001: 2000 III. Antenna Information

ID Label/Location Info

Internal Photos

RF Exposure Info

© 2012 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Novatel Wireless Dates of Test: October 3-5, 2012 9645 Scranton Road, Suite 205 Test Report Number: SAR.20121001 San Diego, CA 92121 Revision A This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003, and OET Bulletin 65 Supp. C (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application is subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Certificate # 2387.01 FCC ID: PKRNVWMIFI5510 Model(s): MiFi5510L Test Sample: Engineering Unit Same as Production FID Number: UB3010812700012 Equipment Type: Wireless Hotspot Modem Classification: Portable Transmitter Next to Body TX Frequency Range: 824 – 848 MHz; 1850 – 1909 MHz; 777 – 787 MHz, 1710 – 1755 MHz, 2412 – 2462 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 850 MHz (CDMA) – 24.49 dBm, 1900 MHz (CDMA) – 24.49 dBm, 782 MHz (LTE) – 24.49 dBm, 1735 MHz (LTE) – 24.49 dBm; 2450 MHz – 17.49 dBm Conducted Signal Modulation: CDMA, QPSK, 16QAM, DSSS, OFDM Antenna Type: WWAN – Pulse, P/N W3671 (Main), PIFA Antenna; Pulse, P/N W3672 (Diversity), PIFA Antenna WLAN – Pulse, P/N W3300, PIFA Antenna Application Type: Certification FCC Rule Parts: Part 2, 15C, 22, 24, 27 KDB Test Methodology: KDB 447498, KDB 248227, KDB 941225 D01, D05 & D06 Industry Canada: RSS-102, Safety Code 6 Max. Stand Alone SAR Value: 1.437 W/kg Max. Simultaneous SAR Value: 1.496 W/kg Separation Distance: 10 mm FCC ID: PKRNVWMIFI5510 © 2012 RF Exposure Lab, LLC Page 2 of 143 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ........................................................................................................................... 3 SAR Definition [5] ...................................................................................................................... 4 2. SAR Measurement Setup ..................................................................................................... 5 Robotic System ......................................................................................................................... 5 System Hardware ..................................................................................................................... 5 System Electronics ................................................................................................................... 6 Probe Measurement System ..................................................................................................... 6 3. Probe and Dipole Calibration .............................................................................................. 11 4. Simulating Tissue Specifications ......................................................................................... 12 Head & Body Simulating Mixture Characterization ................................................................. 12 5. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] ............................................................... 13 Uncontrolled Environment ....................................................................................................... 13 Controlled Environment .......................................................................................................... 13 6. Measurement Uncertainty ................................................................................................... 14 7. System Validation ............................................................................................................... 15 Tissue Verification ................................................................................................................... 15 Test System Verification ......................................................................................................... 15 8. LTE Document Checklist ..................................................................................................... 16 9. SAR Test Data Summary .................................................................................................... 20 Procedures Used To Establish Test Signal ............................................................................. 20 Device Test Condition ............................................................................................................. 20 Figure 9.1 .................................................................................................................................... 21 10. FCC 3G Measurement Procedures ................................................................................. 22 10.1 Procedures Used to Establish RF Signal for SAR ....................................................... 22 10.2 SAR Measurement Conditions for CDMA2000, 1xEV-DO .......................................... 22 10.3 SAR Measurement Conditions for LTE Bands ............................................................ 27 SAR Data Summary – 835 MHz Body - CDMA .........................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

FCC ID: PKRNVWMIFI5510 © 2012 RF Exposure Lab, LLC Page 47 of 143 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Appendix A – System Validation Plots and Data ************************************************************ Test Result for UIM Dielectric Parameter Thu 04/Oct/2012 15:19:14 Freq Frequency(GHz) FCC_eH FCC Bulletin 65 Supplement C ( June 2001) Limits for Head Epsilon FCC_sH FCC Bulletin 65 Supplement C (June 2001) Limits for Head Sigma FCC_eB FCC Limits for Body Epsilon FCC_sB FCC Limits for Body Sigma Test_e Epsilon of UIM Test_s Sigma of UIM ************************************************************ Freq FCC_eB FCC_sB Test_e Test_s 0.7000 55.73 0.96 54.98 0.89 0.7100 55.69 0.96 54.92 0.90 0.7200 55.65 0.96 54.87 0.91 0.7300 55.61 0.96 54.81 0.92 0.7400 55.57 0.96 54.77 0.93 0.7500 55.53 0.96 54.69 0.94 0.7600 55.49 0.96 54.62 0.95 0.7700 55.45 0.96 54.58 0.96 0.7800 55.41 0.97 54.57 0.97 0.7900 55.38 0.97 54.50 0.98 0.8000 55.34 0.97 54.45 0.98 ************************************************************ Test Result for UIM Dielectric Parameter Thu 04/Oct/2012 06:18:38 Freq Frequency(GHz) FCC_eH FCC Bulletin 65 Supplement C ( June 2001) Limits for Head Epsilon FCC_sH FCC Bulletin 65 Supplement C (June 2001) Limits for Head Sigma FCC_eB FCC Limits for Body Epsilon FCC_sB FCC Limits for Body Sigma Test_e Epsilon of UIM Test_s Sigma of UIM ************************************************************ Freq FCC_eB FCC_sB Test_e Test_s 0.8050 55.32 0.97 56.05 0.96 0.8150 55.28 0.97 56.00 0.98 0.8250 55.24 0.97 55.95 0.98 0.8350 55.20 0.97 55.91 0.99 0.8450 55.17 0.98 55.86 0.99 0.8550 55.14 0.99 55.84 1.00 0.8650 55.11 1.01 55.80 1.01 0.8750 55.08 1.02 55.78 1.03 0.8850 55.05 1.03 55.73 1.03 0.8950 55.02 1.04 55.70 1.04 FCC ID: PKRNVWMIFI5510 © 2012 RF Exposure Lab, LLC Page 48 of 143 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. ************************************************************ Test Result for UIM Dielectric Parameter Fri 05/Oct/2012 08:18:57 Freq Frequency(GHz) FCC_eH FCC Bulletin 65 Supplement C ( June 2001) Limits for Head Epsilon FCC_sH FCC Bulletin 65 Supplement C (June 2001) Limits for Head Sigma FCC_eB FCC Limits for Body Epsilon FCC_sB FCC Limits for Body Sigma Test_e Epsilon of UIM Test_s Sigma of UIM ************************************************************ Freq FCC_eB FCC_sB Test_e Test_s 1.6900 53.59 1.45 52.89 1.51 1.7000 53.56 1.46 52.85 1.52 1.7100 53.54 1.46 52.81 1.53 1.7200 53.51 1.47 52.78 1.54 1.7300 53.48 1.48 52.74 1.55 1.7400 53.46 1.48 52.70 1.55 1.7500 53.43 1.49 52.68 1.56 1.7600 53.41 1.49 52.66 1.56 1.7700 53.38 1.50 52.65 1.57 1.7800 53.35 1.51 52.61 1.58 1.7900 53.33 1.51 52.58 1.59 ************************************************************ Test Result for UIM Dielectric Parameter Wed 03/Oct/2012 07:58:20 Freq Frequency(GHz) FCC_eH FCC Bulletin 65 Supplement C ( June 2001) Limits for Head Epsilon FCC_sH FCC Bulletin 65 Supplement C (June 2001) Limits for Head Sigma FCC_eB FCC Limits for Body Epsilon FCC_sB FCC Limits for Body Sigma Test_e Epsilon of UIM Test_s Sigma of UIM ************************************************************ Freq FCC_eB FCC_sB Test_e Test_s 1.8200 53.30 1.52 52.47 1.56 1.8300 53.30 1.52 52.47 1.56 1.8400 53.30 1.52 52.46 1.56 1.8500 53.30 1.52 52.45 1.57 1.8600 53.30 1.52 52.44 1.57 1.8700 53.30 1.52 52.42 1.57 1.8800 53.30 1.52 52.38 1.57 1.8900 53.30 1.52 52.37 1.58 1.9000 53.30 1.52 52.35 1.59 1.9100 53.30 1.52 52.32 1.59 1.9200 53.30 1.52 52.30 1.60 FCC ID: PKRNVWMIFI5510 © 2012 RF Exposure Lab, LLC Page 49 of 143 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. ************************************************************ Test Result for UIM Dielectric Parameter Thu 04/Oct/2012 11:54:39 Freq Frequency(GHz) FCC_eH FCC Bulletin 65 Supplement C ( June 2001) Limits for Head Epsilon FCC_sH FCC Bulletin 65 Supplement C (June 2001) Limits for Head Sigma FCC_eB FCC Limits for Body Epsilon FCC_sB FCC Limits for Body Sigma Test_e Epsilon of UIM Test_s Sigma of UIM ************************************************************ Freq FCC_eB FCC_sB Test_e Test_s 2.3900 52.78 1.89 51.83 1.87 2.4000 52.77 1.90 51.81 1.87 2.4100 52.75 1.91 51.79 1.88 2.4200 52.74 1.92 51.76 1.89 2.4300 52.73 1.93 51.74 1.90 2.4400 52.71 1.94 51.70 1.92 2.4500 52.70 1.95 51.68 1.93 2.4600 52.69 1.96 51.65 1.94 2.4700 52.67 1.98 51.62 1.95 2.4800 52.66 1.99 51.59 1.96 FCC ID: PKRNVWMIFI5510 © 2012 RF Exposure Lab, LLC Page 50 of 143 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. RF Exposure Lab Plot 1 DUT: Dipole 750 MHz D750V3; Type: D750V3; Serial: D750V3 - SN 1016 Communication System: CW; Frequency: 750 MHz; Duty Cycle: 1:1 Medium: MSL750; Medium parameters used: f = 750 MHz; σ = 0.94 mho/m; ε r = 54.69; ρ = 1000 kg/m 3 Phantom section: Flat Section Test Date: Date: 10/4/2012; Ambient Temp: Meas. Ambient Temp(celsius)- 23° C; Tissue Temp: Tissue Temp(celsius)- 21° C Probe: EX3DV4 - SN3693; ConvF(8.84, 8.84, 8.84); Calibrated: 8/20/2012; Sensor-Surface: 4mm (Mechanical Surface Detection) Electronics: DAE4 Sn759; Calibrated: 8/15/2012 Phantom: ELI 4.0; Type: QDOVA001BA; Serial: 1065 Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Procedure Notes: 750 MHz Validation/750 MHz Validation/Area Scan (61x101x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.915 W/kg 750 MHz Validation/750 MHz Validation/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 31.622 V/m; Power Drift = -0.14 dB Peak SAR (extrapolated) = 1.240 mW/g SAR(1 g) = 0.850 mW/g; SAR(10 g) = 0.564 mW/g Maximum value of SAR (measured) = 0.915 W/kg FCC ID: PKRNVWMIFI5510 © 2012 RF Exposure Lab, LLC Page 51 of 143 This report shall not be reproduced except in full…

Text truncated - open the document above for the full version.

Test Report

Report No. SC1209591D October 2012 America Report On Application for Grant of Equipment Authorization of the Novatel Wireless Inc. MiFi 5510 Personal Wireless Router FCC CFR 47 Part 2, Part 22 and Part 24 IC RSS-Gen, RSS-132 and RSS-133 FCC ID PKRNVWMIFI5510 IC: N/A Report No. SC1209591D Page 2 of 80 REPORT ON TEST REPORT NUMBER PREPARED FOR Radio Testing of the Novatel Wireless Inc. Personal Wireless Router SC1209591D Novatel Wireless Inc. 9645 Scranton Road, Suite 205 San Diego, CA 92121-3030 USA CONTACT PERSON Todd Gallagher Regulatory Engineering Manager (403) 295-4891 [email protected] PREPARED BY Ferdinand S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED October 24, 2012 FCC ID PKRNVWMIFI5510 IC: N/A Report No. SC1209591D Page 3 of 80 Revision History SC1209591D Novatel Wireless Inc. MiFi 5510 Personal Wireless Router DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 10/24/12 Initial Release Ferdinand Custodio FCC ID PKRNVWMIFI5510 IC: N/A Report No. SC1209591D Page 4 of 80 CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 5 1.1 Introduction ................................................................................................................................... 6 1.2 Brief Summary Of Results ............................................................................................................ 7 1.3 Product Information ...................................................................................................................... 8 1.4 EUT Test Configuration .............................................................................................................. 10 1.5 Deviations From The Standard ................................................................................................... 13 1.6 Modification Record .................................................................................................................... 13 1.7 Test Methodology ....................................................................................................................... 13 1.8 Test Facility ................................................................................................................................. 13 1.9 Sample Calculations ................................................................................................................... 14 2 TEST DETAILS .......................................................................................................................... 15 2.1 Transmitter Conducted Power Measurements ........................................................................... 16 2.2 Effective Radiated Power ........................................................................................................... 17 2.3 Equivalent Isotropic Radiated Power .......................................................................................... 19 2.4 Occupied Bandwidth ................................................................................................................... 21 2.5 Peak-Average Ratio.................................................................................................................... 28 2.6 Band Edge/Conducted Spurious Emissions ............................................................................... 35 2.7 Field Strength Of Spurious Radiation ......................................................................................... 46 2.8 Frequency Stability ..................................................................................................................... 52 2.9 Receiver Spurious Emissions ..................................................................................................... 56 2.10 Power Line Conducted Emissions .............................................................................................. 59 3 TEST EQUIPMENT USED ......................................................................................................... 69 3.1 Test Equipment Used ................................................................................................................. 70 3.2 Measurement Uncertainty .......................................................................................................... 71 4 DIAGRAM OF TEST SETUP ..................................................................................................... 73 4.1 Test Setup Diagram .................................................................................................................... 74 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 79 5.1 Accreditation, Disclaimers and Copyright ................................................................................... 80 FCC ID PKRNVWMIFI5510 IC: N/A Report No. SC1209591D Page 5 of 80 SECTION 1 REPORT SUMMARY Radio Testing of the Novatel Wireless Inc. Personal Wireless Router FCC ID PKRNVWMIFI5510 IC: N/A Report No. SC1209591D Page 6 of 80 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Novatel Wireless Inc. Personal Wireless Router to the requirements of the following: • FCC CFR 47 Part 2, Part 22 and Part 24 • IC RSS-Gen, RSS-132 and RSS-133. Objective To perform Radio Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Novatel Wireless Inc. Model Number(s) MiFi 5510 FCC ID Number PKRNVWMIFI5510 IC Number N/A Serial Number(s) UB010912700038 Number of Samples Tested 1 Test Specification/Issue/Date • FCC CFR 47 Part 2, Part 22 and Part 24 (October 1, 2011). • RSS-132 - Cellular Telephones Employing New …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Roman Olmos(Sr. Staff Regulatory Engineer)

[email protected]858-812-3400Fax: 858-408-4345

Test Firm

TUV SUD America, Inc.Chip Fleury

[email protected]1-858-678-1439Fax: 1-858-546-0364

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	27	777 MHz - 787 MHz	121.00 mW	9M01W7D	7.56 Hz

Confidentiality

Long Term

Grant Notes

Output power for UMTS Band V and LTE Band 13 is ERP, for UMTS Band II and LTE Band 4 is EIRP. This device and its antenna(s) must not be co-located or operated in conjunction with any antenna or transmitter except in accordance with FCC multi-transmitter RF exposure procedures. End-users must be informed of the operating requirements for satisfying RF exposure compliance. The highest reported SAR for hotspot (wireless router) and simultaneous transmission use conditions are 1.44 W/kg, and 1.50 W/kg, respectively.
