PKRNVWMIFI5580Portable Device with Wireless Router Capabilities

Inseego Corp.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Jul 10, 2013
Application Purpose: Original Equipment
Date of Application: Jun 27, 2013
Equipment Note: Portable Device with Wireless Router Capabilities
Frequency Range: 2506.00000000 - 2680.00000000
Company: Inseego Corp.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Important Information for the MiFi ® 500 Important Safety Information – page 3 Manufacturer’s Warranty – page 12 General Terms and Conditions of Ser vice – page 1 4 Important Message from Sprint – page 4 2 500 3 Important Safety Information Important Safety Information 4 Important Safety Information ♦General Precautions (page 3) ♦Maintaining Safe Use of and Access to Your MiFi 500 (page 4) ♦Caring for the Battery (page 6) ♦Radio Frequency (RF) Energy (page 7) ♦Owner’s Record (page 10) ♦User Guide Proprietary Notice (page 10) This booklet contains important operational and safety information that will help you safely use your MiFi 500. Failure to read and follow the information provided in this booklet may result in serious bodily injury, death, or property damage. General Precautions There are several simple guidelines to operating your MiFi 500 properly and maintaining safe, satisfactory service. • Avoid exposing your MiFi 500 and accessories to rain or liquid spills. If your MiFi 500 does get wet, immediately turn the power off and remove the battery. • Do not expose your MiFi 500 to direct sunlight for extended periods of time (such as on the dashboard of a car). • Although your MiFi 500 is quite sturdy, it is a complex piece of equipment and can be broken. Avoid dropping, hitting, bending, or sitting on it. • Any changes or modifications to your MiFi 500 not expressly approved in this document could void your warranty for this equipment and void your authority to operate this equipment. Note: For the best care of your device, only Sprint- authorized personnel should service your MiFi 500 and accessories. Failure to do so may be dangerous and void your warranty. Maintaining Safe Use of and Access to Your MiFi 500 Using Your MiFi 500 While Driving Laws vary as to specific restrictions. Remember that safety always comes first. Following Safety Guidelines To operate your MiFi 500 safely and efficiently, always follow any special regulations in a given area. Turn your MiFi 500 off in areas where use is forbidden or when it may cause interference or danger. 3 Important Safety Information Important Safety Information 4 Note: For the best care of your device, only Sprint- authorized personnel should service your MiFi 500 and accessories. Failure to do so may be dangerous and void your warranty. Maintaining Safe Use of and Access to Your MiFi 500 Using Your MiFi 500 While Driving Laws vary as to specific restrictions. Remember that safety always comes first. Following Safety Guidelines To operate your MiFi 500 safely and efficiently, always follow any special regulations in a given area. Turn your MiFi 500 off in areas where use is forbidden or when it may cause interference or danger. Using Your MiFi 500 Near Other Electronic Devices Most modern electronic equipment is shielded from radio frequency (RF) signals. However, RF signals from wireless devices may affect inadequately shielded electronic equipment. RF signals may affect improperly installed or inadequately shielded electronic operating systems or entertainment systems in motor vehicles. Check with the manufacturer or their representative to determine if these systems are adequately shielded from external RF signals. Also check with the manufacturer regarding any equipment that has been added to your vehicle. Consult the manufacturer of any personal medical devices, such as pacemakers and hearing aids, to determine if they are adequately shielded from external RF signals. 5 Important Safety Information Important Safety Information 6 Note: Always turn off the MiFi 500 in healthcare facilities, and request permission before using the MiFi 500 near medical equipment. Turning Off Your MiFi 500 Before Flying Turn off your MiFi 500 before boarding any aircraft. To prevent possible interference with aircraft systems, the U.S. Federal Aviation Administration (FAA) regulations require you to have permission from a crew member to use your MiFi 500 while the plane is on the ground. To prevent any risk of interference, FCC regulations prohibit using your MiFi 500 while the plane is in the air. Turning Off Your MiFi 500 in Dangerous Areas To avoid interfering with blasting operations, turn your MiFi 500 off when in a blasting area or in other areas with signs indicating two-way radios should be turned off. Construction crews often use remote- control RF devices to set off explosives. Turn your MiFi 500 off when you’re in any area that has a potentially explosive atmosphere. Although it’s rare, your MiFi 500 and accessories could generate sparks. Sparks can cause an explosion or fire, resulting in bodily injury or even death. These areas are often, but not always, clearly marked. They include: • Fueling areas such as gas stations. • Below deck on boats. • Fuel or chemical transfer or storage facilities. • Areas where the air contains chemicals or particles such as grain, dust, or metal powders. • Any other area where you would normally be advised to turn off your vehicle’s engine. Note: Never transport or store flammable gas, flammable liquids, or explosives in the compartment of your vehicle that contains your MiFi 500 or accessories. 5 Important Safety Information Important Safety Information 6 Turn your MiFi 500 off when you’re in any area that has a potentially explosive atmosphere. Although it’s rare, your MiFi 500 and accessories could generate sparks. Sparks can cause an explosion or fire, resulting in bodily injury or even death. These areas are often, but not always, clearly marked. They include: • Fueling areas such as gas stations. • Below deck on boats. • Fuel or chemical transfer or storage facilities. • Areas where the air contains chemicals or particles such as grain, dust, or metal powders. • Any other area where you would normally be advised to turn off your vehicle’s engine. Note: Never transport or store flammable gas, flammable liquids, or explosives in the compartment of your vehicle that contains your MiFi 500 or accessories.…

Text truncated - open the document above for the full version.

Attestation Statements

May 21, 2013 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD FCC ID: PKRNVWMIFI5580 Attestation for FCC Part 15B Declaration of Conformity Please be notified that we, the undersigned, Novatel Wireless Inc. declares that the product, which bears the above FCC ID is compliant with the FCC Part 15B requirements for DoC. The DoC procedure shall be carried out prior to marketing the device in the US. . Sincerely, Todd Gallagher Manager – Regulatory Engineering Novatel Wireless Inc.

Cover Letter(s)

Date: May 21, 2013 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, Novatel Wireless Inc. at 9645 Scranton Road Suite 205 San Diego, CA 92121, hereby authorize Ferdinand Custodio of TÜV SÜD America Inc, 10044 Mesa Rim Road, San Diego, CA 92121 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Sincerely, Todd Gallagher Manager – Regulatory Engineering Novatel Wireless Inc.

Cover Letter(s)

Date: May 27, 2013 Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Subject: Request for Confidentiality FCC ID: PKRNVWMIFI5580 To Whom It May Concern: In accordance with 47CFR0.459, Novatel Wireless Inc. requests long term confidentiality for the following items 1. MiFi5580 BOM (Bill of Material) 2. MiFi5580 Tuning Procedure 3. MiFi55580 Schematics Diagrams 4. MiFi5580 Theory of Operation 5. MiFi5580 Block Diagram 6. MiFi5580 Assembly Drawing In accordance with 47CFR0.457 and 0.459, Novatel Wireless Inc. requests short-term confidentiality for 180 days for the following items 1. MiFi5580 External and Internal Photos 2. MiFi5580 Test photos 3. MiFi5580 User Guide These items contain detailed system and equipment description and related information about the product which Novatel Wireless Inc. considers to be proprietary, confidential, and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Novatel Wireless Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Sincerely, Todd Gallagher Manager – Regulatory Engineering Novatel Wireless

External Photos

Proprietary and Confidential NOVATEL WIRELESS, INC. 9645 Scranton Road, Suite 205, San Diego, CA 92121 Toll Free: 888.888.9231 Main: 858.812.3400 Fax: 858.812.3402 Internet: www.novatelwireless.com ISO 9001: 2000 Novatel Wireless PKRNVWMIFI5580 EUT Internal & External Photos I. Internal EUT PCB Photos a. Bottom Side (w/Shields) (without Shields) b. Top/LCD Display Side SD Card Slot Proprietary and Confidential NOVATEL WIRELESS, INC. 9645 Scranton Road, Suite 205, San Diego, CA 92121 Toll Free: 888.888.9231 Main: 858.812.3400 Fax: 858.812.3402 Internet: www.novatelwireless.com ISO 9001: 2000 II. External EUT Photos Top View Bottom View Top Side/Edge View Right Side/Edge View Micro USB Power Button

ID Label/Location Info

PKRNVWMIFI5580 – Label PKRNVWMIFI5580 – Label Location Label Bottom of Unit Battery Cavity

ID Label/Location Info

Date: May 21, 2013 BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD FCC ID: PKRNVWMIFI5580 Attestation for FCC Label Location Please be notified that we, the undersigned, Novatel Wireless Inc. declares that the product is compliant with the FCC Labeling Requirements. This label appears under the battery well. This approach has been reviewed and approved by the FCC under KDB inquiry 616957 Sincerely, Todd Gallagher Manager – Regulatory Engineering Novatel Wireless Inc.

Internal Photos

RF Exposure Info

802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Novatel Wireless Dates of Test: April 27-May 2, 2013 9645 Scranton Road, Suite 205 Test Report Number: SAR.20130402 San Diego, CA 92121 Revision C This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003, and OET Bulletin 65 Supp. C (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application is subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Certificate # 2387.01 FCC ID: PKRNVWMIFI5580 Model(s): MiFi5580 Test Sample: Engineering Unit Same as Production FID Number: SY16413700029 Equipment Type: Wireless Hotspot Modem Classification: Portable Transmitter Next to Body TX Frequency Range: 824 – 849 MHz; 1850 – 1910 MHz; 816 – 824 MHz, 1850 – 1915 MHz, 814 – 849 MHz, 2496 – 2690 MHz, 2412 – 2462 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 850 MHz (CDMA) – 24.49 dBm, 1900 MHz (CDMA) – 24.41 dBm, 800 MHz (CDMA) – 24.45 dBm 850 MHz (LTE) – 24.33 dBm, 1900 MHz (LTE) – 24.50 dBm; 2600 MHz (LTE) – 23.99 dBm 2450 MHz – 17.00 dBm Conducted Signal Modulation: CDMA, QPSK, 16QAM, DSSS, OFDM Antenna Type: WWAN – Ethertronics, P/N 01019835 (EvDo/LTE B25/B26 Main), Monopole Antenna; Novatel Wireless, P/N N/A (LTE B41 Main), Etched on PCB Monopole Antenna WLAN – Novatel Wireless, P/N N/A, Etched on PCB Monopole Antenna Application Type: Certification FCC Rule Parts: Part 2, 15C, 22, 24, 27, 90 KDB Test Methodology: KDB 447498 D01 v05, KDB 248227 v01r02, KDB 941225 D01 v02, D05 v02r01 & D06 v01 Industry Canada: RSS-102, Safety Code 6 Max. Stand Alone SAR Value: 1.49 W/kg Max. Simultaneous SAR Value: 1.57 W/kg Separation Distance: 10 mm © 2013 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. FCC ID: PKRNVWMIFI5580 Table of Contents 1. Introduction ........................................................................................................................ 3 SAR Definition [5] ................................................................................................................... 4 2. SAR Measurement Setup ................................................................................................... 5 Robotic System ...................................................................................................................... 5 System Hardware ................................................................................................................... 5 System Electronics ................................................................................................................. 6 Probe Measurement System .................................................................................................. 6 3. Probe and Dipole Calibration .............................................................................................11 4. Simulating Tissue Specifications .......................................................................................12 Head & Body Simulating Mixture Characterization ................................................................12 5. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] ..............................................................13 Uncontrolled Environment .....................................................................................................13 Controlled Environment .........................................................................................................13 6. Measurement Uncertainty .................................................................................................14 7. System Validation..............................................................................................................15 Tissue Verification .................................................................................................................15 Test System Verification ........................................................................................................15 8. LTE Document Checklist ...................................................................................................16 9. SAR Test Data Summary ..................................................................................................19 Procedures Used To Establish Test Signal ...........................................................................19 Device Test Condition ...........................................................................................................19 Figure 9.1 ..................................................................................................................................20 10. FCC 3G Measurement Procedures ...............................................................................21 10.1 Procedures Used to Establish RF Signal for SAR ......................................................21 10.2 SAR Measurement Conditions for CDMA2000, 1xEV-DO .........................................21 10.3 SAR Measurement Conditions for LTE Bands ...........................................................26 SAR Data Summary – BC0 835 MHz Body – CDMA EvDo ...................................................49 SA…

Text truncated - open the document above for the full version.

Test Report

Report No. SC1303824E June 2013 America Report On Application for Grant of Equipment Authorization of the Novatel Wireless Inc. MiFi5580 Personal Wireless Router FCC CFR 47 Part 2 and 90 FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824E Page 2 of 67 REPORT ON TEST REPORT NUMBER PREPARED FOR Radio Testing of the Novatel Wireless Inc. Personal Wireless Router SC1303824E Novatel Wireless Inc. 9645 Scranton Road, Suite 205 San Diego, CA 92121-3030 USA CONTACT PERSON Todd Gallagher Regulatory Engineering Manager (403) 295-4891 [email protected] PREPARED BY Ferdinand S. Custodio Name Authorized Signatory Title: EMC/Wireless Test Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED June 07, 2013 FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824E Page 3 of 67 Revision History SC1303824E Novatel Wireless Inc. MiFi5580 Personal Wireless Router DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 06/07/13 Initial Release Ferdinand Custodio FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824E Page 4 of 67 CONTENTS Section Page No 1 REPORT SUMMARY ............................................................................................................................ 5 1.1 Introduction ................................................................................................................................................ 6 1.2 Brief Summary Of Results ........................................................................................................................... 7 1.3 Product Information ................................................................................................................................... 8 1.4 EUT Test Configuration ............................................................................................................................. 10 1.5 Deviations From The Standard ................................................................................................................. 12 1.6 Modification Record ................................................................................................................................. 12 1.7 Test Methodology ..................................................................................................................................... 12 1.8 Test Facility ............................................................................................................................................... 12 1.9 Sample Calculations .................................................................................................................................. 13 2 TEST DETAILS .................................................................................................................................... 14 2.1 Transmitter Conducted Power Measurements ........................................................................................ 15 2.2 Effective Radiated Power Output Data ..................................................................................................... 19 2.3 Occupied Bandwidth ................................................................................................................................. 23 2.4 Band Edge (Emission Mask) ...................................................................................................................... 31 2.5 Conducted Spurious Emissions ................................................................................................................. 40 2.6 Field Strength Of Spurious Radiation ........................................................................................................ 51 2.7 Frequency Stability ................................................................................................................................... 56 3 TEST EQUIPMENT USED .................................................................................................................... 58 3.1 Test Equipment Used ................................................................................................................................ 59 3.2 Measurement Uncertainty ....................................................................................................................... 60 4 DIAGRAM OF TEST SETUP ................................................................................................................. 61 4.1 Test Setup Diagram ................................................................................................................................... 62 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT .............................................................................. 66 5.1 Accreditation, Disclaimers and Copyright ................................................................................................. 67 FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824E Page 5 of 67 SECTION 1 REPORT SUMMARY Radio Testing of the Novatel Wireless Inc. Personal Wireless Router FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824E Page 6 of 67 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Novatel Wireless Inc. MiFi5580 Personal Wireless Router to the requirements of FCC CFR 47 Part 2 and 90. Objective To perform Radio Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Novatel Wireless Inc. Model Number(s) MiFi5580 FCC ID Number PKRNVWMIFI5580 IC Number N/A Serial Number(s) Engineering Sample Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 2 and 90 (October 1, 2012). Start of Test May 14, 2013 Finish of Test June 6, 2013 Name of Engineer(s) Ferdinand Custodio Juan Manuel Gonzalez Related Document(s) • KDB971168 (D01 Power Meas License Digital Systems v02) Measurement Guidance for Certification of Licensed Digital Transmitters • 412172 D01 Determining ERP and EIRP v01 (Guidelines for Dete…

Text truncated - open the document above for the full version.

Test Report

NOVATEL WIRELESS, INC. 6715 8th Street NE, Suite 200, Calgary, AB, Canada T2E 7H7 Toll Free: 888.888.9231 Main: 403-295-4800 Fax: 403-295-4801 Internet: www.novatelwireless.com ISO 9001: 2000 ATTESTATION LETTER Date: June 24, 2013 Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Subject: Frequency Stability FCC Part 2.1055 FCC ID: PKRNVWMIFI5580 To whom it may concern; According to FCC Part 2.1055 (b) “Only the portion or portions of the transmitter containing the frequency determining and stabilizing circuitry need be subjected to the temperature variation test.” The frequency determining circuitry on the MiFi5580; 850 bands including CDMA 850 and LTE Band 26 use the same chip and components. The frequency range of LTE B26 fits within both CDMA BC0 and BC10. The frequency stability measurements performed in the CDMA BC0 mode are representative of the LTE Band 26. Sincerely, Todd Gallagher Manager – Regulatory Engineering

Test Report

Report No. SC1303824A Rev1.0June 2013 America Report On Application for Grant of Equipment Authorization of the Novatel Wireless Inc. MiFi5580 Personal Wireless Router FCC CFR 47 Part 2, Part 22 and Part 24 IC RSS-Gen, RSS-132 and RSS-133 * This Report only covers the Radiated portion of the above requirements and the conducted port measurements were performed by Novatel Wireless Inc. and can be found attached to this report in Novatel Report No.: NVTLTR0047-01. Report No. SC1303824A Rev1.0June 2013 America FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824A Rev1.0 Page 3 of 52 REPORT ON TEST REPORT NUMBER PREPARED FOR Radio Testing of the Novatel Wireless Inc. Personal Wireless Router SC1303824A Rev1.0 Novatel Wireless Inc. 9645 Scranton Road, Suite 205 San Diego, CA 92121-3030 USA CONTACT PERSON Todd Gallagher Regulatory Engineering Manager (403) 295-4891 [email protected] PREPARED BY Juan Manuel Gonzalez Name Authorized Signatory Title: EMC Engineer APPROVED BY Chip R. Fleury Name Authorized Signatory DATED June 27, 2013 FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824A Rev1.0 Page 4 of 52 Revision History SC1303824A Rev1.0 Novatel Wireless Inc. MiFi5580 Personal Wireless Router DATE OLD REVISION NEW REVISION REASON PAGES AFFECTED APPROVED BY 06/24/13 Initial Release Juan M Glez. 06/27/13 1.0 Correct Power Conversion (W) in table 1.3.3 (CDMA2000-1xRTT PCS Band & CDMA2000-1xRTT PCS Band) & Section 2.2.7 10,20 Juan M Glez. FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824A Rev1.0 Page 5 of 52 CONTENTS Section Page No 1REPORT SUMMARY ................................................................................................................... 6 1.1 Introduction ................................................................................................................................... 7 1.2 Brief Summary of Results ............................................................................................................. 8 1.3 Product Information ...................................................................................................................... 9 1.4 EUT Test configuration ............................................................................................................... 11 1.5 Deviations from the Standard ..................................................................................................... 14 1.6 Modification Record .................................................................................................................... 14 1.7 Test methodology ....................................................................................................................... 14 1.8 Test facility.................................................................................................................................. 14 1.9 Sample calculations.................................................................................................................... 15 2TEST DETAILS .......................................................................................................................... 16 2.1 Effective Radiated Power ........................................................................................................... 17 2.2 Equivalent Isotropic Radiated Power.......................................................................................... 19 2.3 Field Strength Of Spurious Radiation ......................................................................................... 21 2.4 Receiver spurious emissions ...................................................................................................... 29 2.5 Power line conducted emissions ................................................................................................ 32 3TEST EQUIPMENT USED ......................................................................................................... 42 3.1 Test Equipment Used ................................................................................................................. 43 3.2 Measurement Uncertainty .......................................................................................................... 44 4Diagram of test setup ............................................................................................................... 46 4.1 Test setup diagram ..................................................................................................................... 47 5ACCREDITATION, DISCLAIMERS AND COPYRIGHT............................................................ 51 5.1 Accreditation, Disclaimers and Copyright................................................................................... 52 FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824A Rev1.0 Page 6 of 52 SECTION 1 REPORT SUMMARY Radio Testing of the Novatel Wireless Inc. Personal Wireless Router FCC ID PKRNVWMIFI5580 IC: N/A Report No. SC1303824A Rev1.0 Page 7 of 52 1.1INTRODUCTION The information contained in this report is intended to show verification of the Novatel Wireless Inc. Personal Wireless Router to the requirements of the following: xFCC CFR 47 Part 2, Part 22 and Part 24. xIC RSS-Gen, RSS-132 and RSS-133. Note .- This Report only covers the Radiated portion of the above requirements and the conducted port measurements were performed by Novatel Wireless Inc. and will be presented in a different exhibit. Objective To perform Radio Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Novatel Wireless Inc. Model Number(s) MiFi5580 FCC ID Number PKRNVWMIFI5580 IC Number N/A Serial Number(s) Engineering Sample Number of Samples Tested 1 Test Specification/Issue/Date xFCC CFR 47 Part 2, Part 22 and Part 24 (October 1, 2011). xRSS-132 - Cellular Telephones Employing New Technologies Operating in the Bands 824-849 MHz and 869-894 MHz (Issue 2, September 2005). xRSS-133 – 2 GHz Personal …

Text truncated - open the document above for the full version.

Test Report

Certificate Number: 3228.01 Copyright © 2013 Novatel Wireless, Inc. All rights reserved. Test Report shall not be reproduced except in full This document contains information which is proprietary and confidential to Novatel Wireless, Inc. Disclosure to persons other than the officers, employees, agents, or subcontractors of the Company or licensee of this document without the prior written permission of Novatel Wireless, Inc. is strictly prohibited. Page 1 of 134 Novatel Wireless, Inc. Test Report EMC Conducted Certific…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Roman Olmos(Sr. Staff Regulatory Engineer)

[email protected]858-812-3400Fax: 858-408-4345

Test Firm

TUV SUD America, Inc.Chip Fleury

[email protected]1-858-678-1439Fax: 1-858-546-0364

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
26	27	2.51 GHz - 2.68 GHz	239.00 mW	18M0W7D	13 Hz

Confidentiality

Long Term

Grant Notes

Output power for Part 22H/90 is ERP and for Part 24E/27 is EIRP. This device and its antenna(s) must not be co-located or operated in conjunction with any antenna or transmitter except as described in this filing or in accordance with FCC multi-transmitter RF exposure procedures. SAR compliance for body-worn operation is based on a separation distance of 1.0 cm between the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not listed in this filing may not contain metallic components. The highest reported SAR values for stand-alone and simultaneous transmission conditions are 1.49 W/kg and 1.57 W/kg respectively.
