PLXHAN-320MP3 PLAYER

Copyright Notices FCC Information Certificated Of Conformity 1. Company : AMAC TEK CO., LTD 3rd Floor, Seyo Bldg, 161-8, Samsung -Dong, Kangnam-Gu, Seoul Korea 135-881 2. Model Name : HAN-320 3. FCC Compliance Statement: This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Caution : Any changes or modifications in construction of this device which are not device expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -EN55022 + A1 : 2000 --- Information Technology Equipment - Radio disturbance -EN55024 : 1998 --- Information Technology Equipment - Immunity -EN55013 + A14 : 1999 --- Sound and television broadcast receivers and equipment - Radio disturbance

12MHz MCLK:25MHz MCLK:8MHz

Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 20 of 28 APPENDIX D – EUT PHOTOGRAPHS
Front View of EUT Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 21 of 28
Rear View of EUT

Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 16 of 28 APPENDIX A – LABELLING REQUIREMENTS The sample label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase.
FCC ID Location of EUT Labelling Requirements

Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 22 of 28
Inside View of EUT Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 23 of 28
Front View of Up Board Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 24 of 28
Rear View of Up Board Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 25 of 28
Front View of Down Board Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 26 of 28
Rear View of Down Board

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 4 3 2 1VCC DATA- DATA+ GND USB JACK 12 1 : CATHODE 2 : ANODE DIODE Series (Top View)(Top View) 12 3 (Top View) 1 : BASE 2 : EMITTER 3 : COLLECTOR TR(2N2222) CT3 Net R39 R54 Net 2003. 09. 19MG USB Interface & Power Custom 25Tuesday, October 07, 2003 Seung-Ryong, Ha HAN-320(Down) Title SizeDocument NumberRev Date:Sheetof Edited By Data- Data+ POWER_EN BA_PW USB_VDD VDD USB_5V USB_5V VCC_MCUVDD AGND AVDD PGNDPGND PGND PGNDPGNDPGNDPGND VDD DGNDDGNDDGND DGNDDGNDDGNDDGNDDGND USB_VDD DGND B1 1608,301(300) BEAD L2 1608,301(300) BEAD R35 390K 1005 B7 1608,301(300) BEAD R3647K, 1% 1005 B3 1608,301(300) BEAD L10 22uH 2012 B4 1608,301(300) BEAD B5 1608,301(300) BEAD + CT15 100UF/7V TYPE B(3528) C34 0.1uF 1005 C43 1uF 1608 R41 22 1005 R44 100 1005 J2 USB SoketK USB Soket 1 3 2 4 5 6 VCC D+ D- GND CGND CGND C21 0.1uF 1005 + CT16 100UF/7V TYPE B(3528) + CT5 100UF/7V TYPE B(3528) R42 1.5K 1005 C35 150pF 1005 U3 TPS61010 MSOP 41 8 7 6 5 39 10 2 GNDEN ADEN SW VBAT VOUT FBLBI LBO COMP R40 22 1005 C33 0.1uF 1005 + CT1 10UF/10V TYPE A(3216) D6 UDZ 3.6V SC-76 2 1 B6 1608,301(300) BEAD R45 NI,47K 1005 + CT4 10UF/10V TYPE A(3216) L8 1608,301(300) BEAD L5 22uH, 20%(M) Power Inductor Q1 UMT2222A SOT-23 1 2 3 R37 2.2M,1% 1005 TP2 Battery+ 1 R38 510K,1% 1005 B10 1608,301(300) BEAD R82 1.5K 1005 TP3 Battery- 1 C36 22nF 1005 L6 1608,301(300) BEAD 5 5 4 4 3 3 2 2 1 1 DD CC BB AA R26, CT14 TELECHIPS BEAD Net TCC731Y Net C23 GND PAD( ) MCLK GND Crystal Library MENU VOL+ VOL- 2003. 09. 19MG TCC731Y & Flash & Key & Connector Custom 35Tuesday, October 07, 2003 Seung-Ryong, Ha HAN-320(Down) Title SizeDocument NumberRev Date:Sheetof Edited By R/BCLE CZ1 POWER_EN LCD_R/W TMS HOLD_KEY TDI_RXD DP IO4 SD_DATA2 SD_DATA1 WS0 UCLK CE0 SD_DATA0 CODEC_SDIN IO6TCLKIO2SD_CHECKSD0 EXTBK0 IO3CE0 FM_DATA DM NGIDISX LCD_CS TMODE EXTBK3 IO1 FM_CLK ALEIO5 LCD_ELON EXTBK2 WEREBAT_DETECTNTRST LCD_E/RD MCLK SD_CHECK CZ0 CODEC_SCLK SD_CLK SD_CMD IO7IO0CODEC_CSB XI WS1KEY_INPUT LCD_D/C NSCS0 SD1 DVCC_PLL0 PLAY_SWSW_RM TDO_TXD XO JTAGSEL NRESET SD_DATA3 LCD_RES WP CP1 EXTBK1 CP0 BKREQX AVREF SCLK1 LCD_DB5 LCD_DB4 LCD_DB0 LCD_DB6 LCD_DB1 NSCS0 LCD_DB2 LCD_DB3 LCD_DB7 UCLK NTRST TDI_RXD SD_CLK TDO_TXD SD_DATA3 TCLK PLAY_SW SD_DATA1 JTAGSEL SD_DATA2 GND KEY_DOWN TMS SD_CHECK SD_DATA0 POWER_EN SD_CMD KEY_INPUT KEY_DOWN HOLD_KEY IO2WE IO7 IO4 IO6 IO5 CLE IO1 IO0 RE ALE R/B CE0 WP IO3 MIC_INPUT LCD_DB7 LCD_DB0 LCD_ELON LCD_D/C LCD_DB4 LCD_DB6 LCD_DB3 LCD_R/W LCD_DB5 LCD_DB2 LCD_CS LCD_RES LCD_E/RD LCD_DB1 SD0 CODEC_CSB SCLK1 MCLK POWER_EN Data+ CODEC_SDIN CODEC_SCLK WS0 FM_CLK WS1 SW_RM SD1 BA_PW FM_DATA Data- BA_PW MIC_INPUT DGND DGND VCC_MCU DGNDDGND DGND VCC_MCU DGND VCC_MCU DGND VCC_MCU DGND VCC_MCU DGND DGND VCC_MCU DGND DGND DGND VCC_MCU VCC_MCU DGND DGND VCC_MCU VCC_MCU DGNDDGND VDD VDD DGND VDDVDD DGND DGND DGND AGND VDD VDD R24 4.7K 1005 + CT13 10UF/10V TYPE A(3216) C37 0.1uF 1005 R32 2.2K 1005 R19 4.7K 1005 C4 0.1uF 1005 C19220nF 1005 C20220nF 1005 R214.7K 1005 C86 NI, 10pF 1005 R30 10K 1005 R46 10K 1005 R29 4.7K 1005 R44.7K 1005 + CT2 10UF/10V TYPE A(3216) C9 0.1uF 1005 B12 1608,301(300) BEAD R142K 1005 R34.7K 1005 C3 0.1uF 1005 R10 6.2M 1005 C22220nF 1005 R28 10K, 1% 1005 C18220nF 1005 S1 SSM120 1 2 3 R15100 1005 U4 K9F1G08U0M 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 2425 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 NC NC NC NC NC SE R/BY RE CE NC NC VCC VSS NC NC CLE ALE WE WP NC NC NC NC NCNC NC NC NC I/O0 I/O1 I/O2 I/O3 NC NC NC VSS VCC NC NC NC I/O4 I/O5 I/O6 I/O7 NC NC NC NC C6 0.1uF 1005 X1 32.768KHz Clinder U9 XC61CC2302MR SOT-23 1 2 3 VOUT VSS VIN C17 0.01uF 1005 R43 10K 1005 R25 NI,100K 1005 R110 1005 R17 4.7K 1005 R64.7K 1005 S3 SW 3PDT 2 1 3 5 4 6 R54.7K 1005 C14100pF 1005 C13100pF 1005 R234.7K 1005 B11 1608,301(300) BEAD C85 NI, 10pF 1005 C7 0.1uF 1005 C5 0.1uF 1005 R224.7K 1005 R12100 1005 R132K 1005 C15 0.01uF 1005 C38 0.1uF 1005 C16 0.01uF 1005 C12 0.1uF 1005 R204.7K 1005 + CT11 10UF/10V TYPE A(3216) C10 0.1uF 1005 R18 4.7K 100 5 B13 1608,301(300) BEAD C11 0.1uF 1005 J7 SHBM - 08 - 20G(0.8) 1 3 5 7 9 11 13 15 17 19 2 4 6 8 10 12 14 16 18 20 C8 0.1uF 1005 C2 0.1uF 1005 J9 CON10A 1 3 5 7 9 2 4 6 8 10 U8 TCC730 A1 C2 D4 B1 C1 D2 D3 E4 D1 E2 E3 F4 E1 F2 F3 G4 F1 G2 G3 H4 G1 H2 H3 J4 H1 J2 J3 K4 J1 K2 K3 L4 K1 L2 L3 M4 L1 M2 M3 N4 M1 N2 N3 N1 P1 P2 P3 R1 T1 R2 R3 T2 U1T3P4U2U3T4R4P5U4T5R5P6U5T6R6P7U6T7R7P8U7T8R8P9U8T9R9P10U9T10R10P11U10T11R11P12U11T12R12P13U12T13R13U13U14T14R14U15U16T15R15T16 U17 R16 P14 T17 R17 P16 P15 N14 P17 N16 N15 M14 N17 M16 M15 L14 M17 L16 L15 K14 L17 K16 K15 J14 K17 J16 J15 H14 J17 H16 H15 G14 H17 G16 G15 F14 G17 F16 F15 F17 E16 E15 E17 D17 D16 D15 C17 B17 C16 C15 156 A17B15D14A16A15B14C14D13A14B13C13D12A13B12C12D11A12B11C11D10A11B10C10D9A10B9C9D8A9B8C8D7A8B7C7D6A7B6C6D5A6B5C5A5A4B4 E14 C4A3A2B3C3B2 PA.0 PA.1 PA.2 PA.3 PA.4 PA.5 VDD PA.6 PA.7 NC NC TEST1 TEST2 VSS XI XO TEST3 PJ.0 PJ.1 PJ.2 PJ.3 VDD PJ.4 PB.0 PB.1 PB.2 PB.3 VSS PB.4 PB.5 PB.6/USB_DM PB.7/USB_DP VDD_ADC VSS_ADC AD_VREF VDD_USB VSS_USB VDD_PLL0 CP0 CZ0 VSS_PLL0 VDD_PLL1 CP1 CZ1 VSS_PLL1 PC.0 PC.1 PC.2 PC.3/IIC_SCL PC.4/IIC_SDA PC.5 PC.6/UART_RX VDDPC.7/UART_TXPG.0/INT8PG.1/INT9PG.2/SMC_CE2PD.0/ADC0/INT0PD.1/ADC1/INT1VSSPD.2/ADC2/INT2PD.3/ADC3/INT3PD.4/ADC4/INT4PD.5/ADC5/INT5PD.6/ADC6/INT6PD.7/ADC7/INT7PH.0/SMC_CE0VDDPH.1/SMC_CE1PH.2/SMC_CLEPH.3/SMC_ALEPH.4/SMC_BUSYPH.5/SMC_WPPH.6/SMC_REPH.7/SMC_WEVSSPI.0/SMC_IO0PI.1/SMC_IO1PI.2/SMC_IO2PI.3/SMC_IO3PI.4/SMC_IO4PI.5/SMC_IO5VDDPI.6/SMC_IO6PI.7/SMC_IO7PE.0PE.1PE.2PE.3VSSIIS_WCK0IIS_BCK0IIS_DATA0IIS_WCK1IIS_BCK1IIS_DATA1IIS_MCKVDDTEST4TEST5TRSTTCKTDIJTAG TMS UCLK TEST6 T17 TDO VSS TEST8 TEST9 TEST10 TEST11 TEST12 TEST13 TEST14 TEST15 PF.0/LCD_DATA8 PF.1/LCD_DATA9 VDD PF.2/LCD_DATA10 PF.3/LCD_DATA11 PF.4/LCD_DATA12 PF.5/LCD_DATA13 PF.6/LCD_DATA14 VSS PF.7/LCD_DATA15 LCD_DATA.0 LCD_DATA.1 LCD_DATA.2 LCD_DATA.3 LCD_DATA.4 LCD_DATA.5 VDD LCD_DATA.6 LCD_DATA.7 LCD_BIAS LCD_FCLK LCD_LCLK VSS LCD_PCLK RESET TEST16 TEST17 BA0 BA1 CA…

Text truncated - open the document above for the full version.

Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 1 of 28 Nemko Korea CO., Ltd. 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Kyungki-Do, KOREA TEL:+82 31 322 2333 FAX:+82 31 322 2332 FCC EVALUATION REPORT FOR CERTIFICATION Applicant : AMAC TEK Co., Ltd. Dates of Issue : October 08, 2003 3 rd floor, Seyo Bldg, 161-8, Samsung-1dong, Test Report No. : NK2DE615 Kangnam--Gu, Seoul, 135-881 Korea Test Site : Nemko Korea Co., Ltd. Attn. : Mr. Seung-Ryong, Ha EMC site, Korea FCC ID Brand Name CONTACT PERSON Applied Standard: FCC 47 CFR Part 15, Subpart B : 2000 Classification : FCC Class B Device EUT Type: MP3 Player The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested By : S. K. Lee Reviewed By : H.H. Kim Senior Engineer Manager & Chief Engineer PLXHAN-320 Amac, Hansori Amac Tek Co., Ltd. 3 rd floor, Seyo Bldg, 161-8, Samsung-1dong, Kangnam-Gu, Seoul, 135-881, Korea Mr. Seung-Ryong, Ha Telephone No. : +82 2 574 8012 Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 2 of 28 TABLE OF CONTENTS SCOPE INTRODUCTION (Site Description) TEST CONDITIONS & EUT INFORMATION SUMMARY OF TEST RESULTS RECOMMANDATION / CONCLUSION SAMPLE CALCULATION DESCRIPTION OF TESTS (Conducted Emissions) DESCRIPTION OF TESTS (Radiated Emissions) TEST DATA (Conducted Emissions) TEST DATA (Radiated Emissions) PLOT OF EMISSIONS (Conducted Emissions Diagram) ACCURACY OF MEASUREMENT TEST EQUIPMENT APPENDIX A - LABELLING REQUIREMENTS APPENDIX B - CIRCUIT DIAGRAM APPENDIX C - PHOTOGRAPHS OF TEST SET-UP APPENDIX D - EUT PHOTOGRAPHS APPENDIX E - USER’S MANUAL APPENDIX F - SCHEMATIC DIAGRAM 3 4 5 6 6 6 7 8 9 10 12 14 15 16 17 18 20 27 28 Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 3 of 28 SCOPE Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under FCC part 15. Responsible Party : Contact Person : Manufacturer : Factory : AMAC TEK Co., Ltd. Mr. Seung-Ryong, Ha AMAC TEK Co., Ltd. 3 rd floor, Seyo Bldg, 161-8, Samsung-1dong, Kangnam-Gu, Seoul, 135-881, Korea Tel No.: +82 2 574 8012 AMAC TEK Co., Ltd. 3 rd floor, Seyo Bldg, 161-8, Samsung-1dong, Kangnam-Gu, Seoul, 135-881, Korea Tel No.: +82 2 574 8012
FCC ID: PLXHAN-320
Basic Model: HAN-320
Brand Name: AMAC, HANSORI
EUT Type: MP3 Player
Classification:
Applied Standard:
Test Procedure(s):
Dates of Test:
Place of Tests:
Test Report No.: FCC Class B FCC 47 CFR Part 15 , Subpart B ANSI C63.4 (1992) October 02, 2003 to October 06, 2003 Nemko Korea Co., Ltd. EMC Site NK2DE615 Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 4 of 28 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from Amac Tek Co., Ltd. FCC ID : PLXHAN-320, MP3 Player. These measurement tests were conducted at Nemko Korea Co., Ltd. EMC Laboratory . The site address is 300-2, Osan-Ri, Mohyun-Myun, Yongin-City, Kyungki-Do, KOREA The area of Nemko Korea Corporation LTD. EMC Test Site is located in a mountain area at 80 kilometers (48 miles) southeast and Incheon International Airport (Incheon Airport), 30 kilometers (18miles) south-southeast from central Seoul. It is located in the valley surrounded by mountains in all directions where ambient radio signal conditions are quiet and a favorable area to measure the radio frequency interference on open field test site for the computing and ISM devices manufactures. The detailed description of the measurement facility was found to be in compliance with the requirements of
2.948 according to ANSI C63.4 on October 19, 1992. Fig. 1. The map above shows the Seoul in Korea vicinity area. The map also shows Nemko Korea Corporation Ltd. EMC Lab. and Incheon Airport. Nemko Korea Co., Ltd. EMC Lab. 300-2, Osan-Ri, Mohyun-Myun, Yongin- City Kyungki-Do,KOREA 449-852 Tel)+82-31-322-2333 Fax)+82-31-322-2332 Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 5 of 28 TEST CONDITIONS & EUT INFORMATION Operating During Test The MP3 player connected with PC was operated at download mode and playback mode for the testing. Support Equipment MP3 Player (EUT) Amac Tek Co., Ltd., FCC ID: PLXHAN-320 1.2m Shielded USB Cable 1.2m unshielded Line in stereo phone jack S/N: N/A Notebook PC Compal Electronics Inc., M/N: PP04L (Latitude V710) S/N: N/A AC/DC Adaptor (Notebook PC) Delta Electronics, M/N: ADP-70EB 1.8m unshielded AC power cable 2.0m Shielded DC Cable S/N: N/A Printer HP, M/N: 4557-60104 1.8m Shield Dsub cable S/N: SG88R131GW AC/DC Adaptor (Printer) Yokogawa, M/N: C5870A 1.8m unshielded AC power cable 1.5m unshielded DC Cable S/N: N/A PS/2 Mouse Samsung Electro-Mechanics, M/N: OML3PP 1.5m unshielded Din cable S/N: PRO010 Earphone Amac Tek Co., Ltd., M/N: N/A 1.0m unshielded, stereo phone Jack S/N: N/A EUT Information Clock(s): 32.768kHz(X2), 32.768kHz(X3), 25MHz(Codec) Chipset(s): TLV320AIC23(U7), TCC731Y(U8) Interface Method: USB 1.1 Downloading Speed: 10Mbps I/O Port(s) USB, Earphone, Line In Power Supply: 1.5V DC , AAA size Battery 1 pcs (Playback Mo…

Text truncated - open the document above for the full version.

Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 18 of 28 APPENDIX C – PHOTOGRAPHS OF TEST SET-UP The Conducted Test Picture and Radiated Test Picture and show the worst-case configuration and cable placement.
Conducted Test Picture (Front)
Conducted Test Picture (Rear) Test Report No.: NK2DE615 FCC Certification Amac Tek Co., Ltd. FCC ID:PLXHAN-320 Page 19 of 28
Radiated Test Picture (Front)
Radiated Test Picture (Rear)
